Chapter1:Importantinformation
Makingadistresscall
Inanemergencyyoucanuseyourproducttomakeanautomatic
DSCdistresscall.
0
0
0
0
0
0
0
0
0
D12810-1
OK
RX HI
DIS TRESS
UNDESI GNATED
...3
COUNTI NG DOWN
OK
RX HI
DIS TRESS
UNDESI GNATED
...2
COUNTI NG DOWN
OK
RX HI
DIS TRESS
UNDESI GNATED
...1
COUNTI NG DOWN
OK
RX HI
DIS TRESS
UNDESI GNATED
TRANSMITTING ...
CANCELPAUSE
RX HI
DIS TRESS
AWAITI NG ACK...
REMAIN ING TI ME
TO RESEND..04'20
OK PAUSE P1/3
RX HI
DIS TRESS 00'01
ACKNOWLEDGED
FROM:0012345 6 7
ORI G:mYSHIP
10
15
20
25
30
35
40
45
50
55 60 5
INTCM
1.Openthespringloadeddoorontherearofthehandset.
2.PressandholdtheDISTRESSbuttonfor3seconds.
OncetheDISTRESSbuttonispresseda3secondcount
downwillbegin,whenthecountdownreacheszerothe
distresscallistransmitted.
3.Waitforanacknowledgementofyourdistresscall.
Thedistresscallisrepeatedautomaticallyuntilitis
acknowledged.
4.PressandholdthePTTbutton.
5.Slowlyandclearlyspeakthedetailsofthedistress:
MAYDAY ,MA YDAY,MAYDAY
Thisis<statenameofvessel3times>
MAYDAY<statenameofvessel1time>
Mypositionis<statelatitudeandlongitude,ortruebearing
anddistancefromaknownpoint.>
Iam<statenatureofdistresse.g.sinking,onreetc.>
Ihave<statenumberofpersonsonboardandanyother
information—drifting,aresredetc.>
IREQUIREIMMEDIATEASSISTANCE
OVER
6.ReleasethePTTbutton.
MakingaMaydaycall
InanemergencyyoucanuseyourproducttomakeaMayday
call.
1.Pressthe16/9or16PLUSbutton.
2.PressandholdthePTTbutton.
3.Slowlyandclearlyspeakthedetailsofthedistress:
MAYDAY ,MA YDAY,MAYDAY
Thisis<statenameofvessel3times>
MAYDAY<statenameofvessel1time>
Mypositionis<statelatitudeandlongitude,ortruebearing
anddistancefromaknownpoint.>
Iam<statenatureofdistresse.g.sinking,onreetc.>
Ihave<statenumberofpersonsonboardandanyother
information—drifting,aresredetc.>
IREQUIREIMMEDIATEASSISTANCE
OVER
4.ReleasethePTTbutton.
5.Ifanacknowledgementisnotreceivedthenrepeatsteps
2to4above.
Safetynotices
CertiedInstallation
RaymarinerecommendscertiedinstallationbyaRaymarine
approvedinstaller.Acertiedinstallationqualiesforenhanced
productwarrantybenets.ContactyourRaymarinedealerfor
furtherdetails,andrefertotheseparatewarrantydocument
packedwithyourproduct.
Warning:Productinstallationand
operation
Thisproductmustbeinstalledandoperatedin
accordancewiththeinstructionsprovided.Failure
todosocouldresultinpersonalinjury,damageto
yourvesseland/orpoorproductperformance.
Warning:Potentialignitionsource
ThisproductisNOTapprovedforusein
hazardous/ammableatmospheres.DoNOTinstall
inahazardous/ammableatmosphere(suchasin
anengineroomornearfueltanks).
Warning:Positivegroundsystems
Donotconnectthisunittoasystemwhichhas
positivegrounding.
Warning:Switchoffpowersupply
Ensurethevessel’spowersupplyisswitchedOFF
beforestartingtoinstallthisproduct.DoNOT
connectordisconnectequipmentwiththepower
switchedon,unlessinstructedinthisdocument.
Warning:Chassisgrounding
DoNOTgroundthisproductusingthechassis
groundterminal.
Groundingthisproducttoavessel’sRFground
maycausegalvaniccorrosion.
Warning:Antennaisolation
Topreventgalvaniccorrosionyourantennamust
beisolatedfromanyvesselmetalworkusinga
suitableinsulatede.g.plastic,mountingbracket.
Warning:FCCWarning(Part15.21)
Changesormodicationstothisequipmentnot
expresslyapprovedinwritingbyRaymarine
IncorporatedcouldviolatecompliancewithFCC
rulesandvoidtheuser’sauthoritytooperatethe
equipment.
Warning:MaximumPermissible
Exposure
Failuretoobservetheseguidelinesmayexpose
thosewithinthemaximumpermissibleexposure
(MPE)radiustoRFradiationabsorptionthat
exceedstheFCCMPElimit.Itistheradio
operator’sresponsibilitytoensurethatnoone
comeswithinthisradius.
Foroptimalradioperformanceandminimalhuman
exposuretoradiofrequencyelectromagnetic
energy,makesuretheantennais:
•connectedtotheradiobeforetransmitting
•locatedwhereitwillbeawayfrompeople
•locatedatleast1.5meters(5feet)fromthe
radio’smainunit
Importantinformation7

Caution:Powersupplyprotection
Wheninstallingthisproductensurethepower
sourceisadequatelyprotectedbymeansofa
suitably-ratedfuseorautomaticcircuitbreaker.
Caution:Performregularradio
checks
Performregularradiocheckswhenusingyour
vessel,asrecommendedinradiotrainingand
certicationschemesandradioequipmentrules
ofuse.
Caution:Ensureproperradiouse
UndernocircumstancesshouldaDSCdistress
alertbesentfromyourradiofortestpurposes.
Suchactionisaviolationofrulesofuseforradio
equipment,andcanresultinheavynes.
Caution:Cleaning
Whencleaningthisproduct:
•DoNOTwipethedisplayscreenwithadrycloth,
asthiscouldscratchthescreencoating.
•DoNOTuseabrasive,oracidorammoniabased
products.
•DoNOTuseajetwash.
GeneralInformation
Wateringress
Wateringressdisclaimer
Althoughthewaterproofratingcapacityofthisproductmeets
thestatedIPXstandard(refertotheproduct’sTechnical
Specication),waterintrusionandsubsequentequipment
failuremayoccuriftheproductissubjectedtocommercial
high-pressurewashing.Raymarinewillnotwarrantproducts
subjectedtohigh-pressurewashing.
Disclaimer
Raymarinedoesnotwarrantthatthisproductiserror-freeorthat
itiscompatiblewithproductsmanufacturedbyanypersonor
entityotherthanRaymarine.
Raymarineisnotresponsiblefordamagesorinjuriescausedby
youruseorinabilitytousetheproduct,bytheinteractionofthe
productwithproductsmanufacturedbyothers,orbyerrorsin
informationutilizedbytheproductsuppliedbythirdparties.
FCC
ComplianceStatement(Part15.19)
ThisdevicecomplieswithPart15oftheFCCRules.Operation
issubjecttothefollowingtwoconditions:
1.Thisdevicemaynotcauseharmfulinterference.
2.Thisdevicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesiredoperation.
FCCInterferenceStatement(Part15.105(b))
Thisequipmenthasbeentestedandfoundtocomplywiththe
limitsforaClassBdigitaldevice,pursuanttoPart15oftheFCC
Rules.
Theselimitsaredesignedtoprovidereasonableprotection
againstharmfulinterferenceinaresidentialinstallation.This
equipmentgenerates,uses,andcanradiateradiofrequency
energyand,ifnotinstalledandusedinaccordancewith
theinstructions,maycauseharmfulinterferencetoradio
communications.However,thereisnoguaranteethat
interferencewillnotoccurinaparticularinstallation.Ifthis
equipmentdoescauseharmfulinterferencetoradioortelevision
reception,whichcanbedeterminedbyturningtheequipmentoff
andon,theuserisencouragedtotrytocorrecttheinterference
byoneofthefollowingmeasures:
1.Reorientorrelocatethereceivingantenna.
2.Increasetheseparationbetweentheequipmentand
receiver.
3.Connecttheequipmentintoanoutletonacircuitdifferent
fromthattowhichthereceiverisconnected.
4.Consultthedealeroranexperiencedradio/TVtechnician
forhelp.
IndustryCanada
ThisdevicecomplieswithIndustryCanadaLicense-exempt
RSSstandard(s).
Operationissubjecttothefollowingtwoconditions:
1.Thisdevicemaynotcauseinterference;and
2.Thisdevicemustacceptanyinterference,including
interferencethatmaycauseundesiredoperationofthe
device.
ThisClassBdigitalapparatuscomplieswithCanadian
ICES-003.
Licensing
Priortousingthisproductpleasecheckyournational
requirementsforbothoperatorsandequipmentlicensing.
StationLicence
FCCstationlicenserequirement
AnFCCShipRadioStationLicenseandCallSignarenot
requiredformostrecreationalvesselstravellinginUSwaters.
However,youmustobtainalicenseifyourvesseltravelsto
foreignports.
ShipsthatuseMF/HFsingleside-bandradio,satellite
communications,ortelegraphymustbelicensedbytheFCC.
YoucanobtainaStationLicensebylingFCCForm605,which
isavailablefromtheFCCwebsitelistedabove.
IndustryCanada
IndustryCanadalicenserequirement
Youdonotneedalicensetooperatethisproductwithin
sovereignwatersofCanadaortheUS.Youwillneedalicense
tooperatethisradiooutsideofCanadaortheUS.Toobtain
IndustryCanadalicensinginformation,contactthenearesteld
orregionalofce,orwrite:
IndustryCanadaRadioRegulatoryBranch
Attention:DOSP
300SlaterStreet
Ottawa,Ontario
Canada,KIAOC8
Europeanlicensingrequirements
RegulationsinsomeareasrequirethatanOperator’slicenseis
obtainedbeforeoperatingaVHFradio.Itisyourresponsibility
todeterminewhetheralicenseisrequiredinyourareabefore
operatingthisequipment.
Additionalinformation
Thefollowingadditionalinformationisrequiredforcompletinga
licenseapplicationinCanadaandtheUS.
IndustryCanada
certicationnumber
4069B-RAY260D
FCCIDPJ5–RAY260
FCCTypeacceptedParts2,15and80
Outputpower1watt(low)and25watt(high)
8Ray260

ModulationFM
Frequencyrange155.000MHzto165.000MHz
MaritimeMobileServiceIdentity(MMSI)
Thisproductisaclass“D”DigitalSelectiveCalling(DSC)device.
A9digitMMSInumberisrequiredtooperateDSCequipment.
Insomeareas,aradiooperatorlicenseisrequiredbeforean
MMSInumbercanbeissued.
Note:YoucanrequestanMMSInumberfromthesame
agencythatissuesradioorshipradiolicensesinyourarea.
Onceobtained,youcanprogramtheMMSInumberintoyour
productbyfollowingtheinstructionsuppliedwiththeproduct.
Onceobtained,youcanprogramtheMMSInumberintoyour
productusingtheinstructionsprovidedinthishandbook.
Ifregulationsinyourareadonotpermityoutoprogramthe
MMSInumberyourself,yourRaymarinedealercanprogram
thenumberforyou.
ObtaininganMMSInumberintheUnitedStates
YoucanrequestanMMSInumberfromtheFCCwhenyou
applyforaStationLicense.Ifyourvesseldoesnotrequire
alicense,youmayobtainanMMSIbycontactingBoatUS
www.boatus.com.
ObtaininganMMSInumberinCanada
YoucanobtainanMMSInumberfromyournearestIndustry
CanadaOfce.
ObtaininganMMSInumberinEuropeandrestofworld
AmMMSInumbershouldberequestedfromthesameagency
thatissuesradiooperatorlicensesinyourarea.
AutomaticTransmitterIdenticationSystem
(ATIS)
YourproductincludesATISfunctionalityforuseontheinland
waterwaysofcontractinggovernmentsofthe“Regional
ArrangementConcerningtheRadiotelephoneServiceonInland
Waterways”—alsoknownasthe“BaselAgreement”.
ATISaddsdataattheendofradiotransmissionsthatidenties
yourstation.ATISoperationcanbeturnedonoroffasneeded
viatheradio’smenu.
AnATISnumbercanbeobtainedfromthesameagencythat
issuesradiooperatorlicensesinyourarea.
YourATISIDnumberisderivedfromyourvessel’scallsign.
Ifyourcallsignissuitable,yourauthorizedRaymarinedealer
canassistyouindecodingyourATISIDnumber,whichyoucan
thenprogramintoyourproductusingtheinstructionsprovided
inthishandbook.
Note:TheBaselAgreementincludes:Germany,Austria,
Belgium,Bulgaria,Croatia,France,Hungary,Luxembourg,
Moldova,theNetherlands,Poland,Romania,Russian
Federation,theSlovakRepublic,Switzerland,theCzech
Republic,UkraineandtheFederalRepublicofYugoslavia.
Note:WhenATISisenabled,certainprogrammingsteps
havebeenimplementedtoprotecttheintegrityoftheBasel
agreement,includingtheblockingofDSCfunctionswhen
ATISisactive.
EMCinstallationguidelines
Raymarineequipmentandaccessoriesconformtothe
appropriateElectromagneticCompatibility(EMC)regulations,
tominimizeelectromagneticinterferencebetweenequipment
andminimizetheeffectsuchinterferencecouldhaveonthe
performanceofyoursystem
CorrectinstallationisrequiredtoensurethatEMCperformance
isnotcompromised.
ForoptimumEMCperformancewerecommendthatwherever
possible:
•Raymarineequipmentandcablesconnectedtoitare:
–Atleast1m(3ft)fromanyequipmenttransmittingor
cablescarryingradiosignalse.g.VHFradios,cablesand
antennas.InthecaseofSSBradios,thedistanceshould
beincreasedto7ft(2m).
–Morethan2m(7ft)fromthepathofaradarbeam.A
radarbeamcannormallybeassumedtospread20degrees
aboveandbelowtheradiatingelement.
•Theproductissuppliedfromaseparatebatteryfromthatused
forenginestart.Thisisimportanttopreventerraticbehavior
anddatalosswhichcanoccuriftheenginestartdoesnot
haveaseparatebattery.
•Raymarinespeciedcablesareused.
•Cablesarenotcutorextended,unlessdoingsoisdetailedin
theinstallationmanual.
Note:Whereconstraintsontheinstallationprevent
anyoftheaboverecommendations,alwaysensurethe
maximumpossibleseparationbetweendifferentitemsof
electricalequipment,toprovidethebestconditionsforEMC
performancethroughouttheinstallation
AntennamountingandEMEexposure
Ensurethattheantennaisconnectedtotheradiobefore
transmission.
RaymarinedeclaresaMaximumPermissibleExposure(MPE)
radiusof1.5metres(4.9ft)(perOETBulletin65)forthissystem,
assuming25wattsoutputtoanomnidirectionalantennaof3dBi
gainorless.
Forwatercraftwithsuitablestructures,theantennabasemust
beatleast3.5metres(11.5ft)abovethemaindecktomeet
theMPEforpersonsupto2metres(6.6ft)tall.Forwatercraft
withoutsuchstructures,theantennamustbemountedsothat
itsbaseisaminimumof1.5metres(4.9ft)verticallyfromheads
ofallpersons.
Theantennamustbeisolatedfromthevessel’smetalworkusing
aninsulated(e.g.plastic)mountingbracket.
Connectionstootherequipment
Requirementforferritesonnon-Raymarinecables
IfyourRaymarineequipmentistobeconnectedtoother
equipmentusingacablenotsuppliedbyRaymarine,a
suppressionferriteMUSTalwaysbeattachedtothecablenear
theRaymarineunit.
Declarationofconformity
RaymarineUKLtd.declaresthatthisproductiscompliantwith
theessentialrequirementsofR&TTEdirective1999/5/EC.
TheoriginalDeclarationofConformitycerticatemaybeviewed
ontherelevantproductpageatwww.raymarine.com.
Productdisposal
DisposeofthisproductinaccordancewiththeWEEEDirective.
TheWasteElectricalandElectronicEquipment(WEEE)
Directiverequirestherecyclingofwasteelectricalandelectronic
equipment.WhilsttheWEEEDirectivedoesnotapplytosome
Raymarineproducts,wesupportitspolicyandaskyoutobe
awareofhowtodisposeofthisproduct.
Warrantyregistration
ToregisteryourRaymarineproductownership,pleasevisit
www.raymarine.comandregisteronline.
Itisimportantthatyouregisteryourproducttoreceivefull
warrantybenets.Yourunitpackageincludesabarcodelabel
indicatingtheserialnumberoftheunit.Y ouwillneedthisserial
numberwhenregisteringyourproductonline.Youshouldretain
thelabelforfuturereference.
Importantinformation9

IMOandSOLAS
Theequipmentdescribedwithinthisdocumentisintendedfor
useonleisuremarineboatsandworkboatsnotcoveredby
InternationalMaritimeOrganization(IMO)andSafetyofLifeat
Sea(SOLAS)CarriageRegulations.
Technicalaccuracy
Tothebestofourknowledge,theinformationinthisdocument
wascorrectatthetimeitwasproduced.However,Raymarine
cannotacceptliabilityforanyinaccuraciesoromissionsit
maycontain.Inaddition,ourpolicyofcontinuousproduct
improvementmaychangespecicationswithoutnotice.Asa
result,Raymarinecannotacceptliabilityforanydifferences
betweentheproductandthisdocument.Pleasecheckthe
Raymarinewebsite(www.raymarine.com)toensureyouhave
themostup-to-dateversion(s)ofthedocumentationforyour
product.
10Ray260

Chapter2:Documentandproductinformation
Chaptercontents
•2.1Handbookinformationonpage12
•2.2Productinformationonpage12
Documentandproductinformation11

2.1Handbookinformation
Thishandbookcontainsimportantinformationregardingyour
DSCVHFRadio.
Ray260handbooks
ThefollowinghandbooksareapplicabletoyourRay260:
Alldocumentsareavailabletodownloadinpdfformatfromthe
Raymarinewebsitewww.raymarine.com.
Handbooks
DescriptionPartnumber
Mountingandgettingstarted88014
Installationandoperation
instructions
81343
Ray260mountingtemplate87167
Speakermountingtemplate87168
SeaTalknghandbooks
DescriptionPartnumber
SeaTalkngreferencemanual
Planningandconnectionofsystemsbasedaroundthe
SeaTalkngnetwork.
81300
SeaTalk–SeaTalkngconverterhandbook
InstallationandconnectionoftheSeaTalk-SeaTalkng
converter.
87121
UsermanualsPrintShop
RaymarineprovidesaPrintShopservice,enablingyouto
purchaseahigh-quality,professionally-printedmanualforyour
Raymarineproduct.
Printedmanualsareidealforkeepingonboardyourvessel,asa
usefulsourceofreferencewheneveryouneedassistancewith
yourRaymarineproduct.
Visithttp://www.raymarine.co.uk/view/?id=5175toordera
printedmanual,delivereddirectlytoyourdoor.
ForfurtherinformationaboutthePrintShop,pleasevisitthePrint
ShopFAQpages:http://www.raymarine.co.uk/view/?id=5751.
Note:
•Acceptedmethodsofpaymentforprintedmanualsare
creditcardsandPayPal.
•Printedmanualscanbeshippedworldwide.
•FurthermanualswillbeaddedtothePrintShopoverthe
comingmonthsforbothnewandlegacyproducts.
•Raymarineusermanualsarealsoavailabletodownload
free-of-chargefromtheRaymarinewebsite,inthepopular
PDFformat.ThesePDFlescanbeviewedonaPC/
laptop,tablet,smartphone,oronthelatestgenerationof
Raymarinemultifunctiondisplays.
2.2Productinformation
TheRay260isaClassDDigitalSelectiveCalling(DSC)VHF
radio.DSCenablesyoutomakeaselectivecalltoaspecic
radio,andtotransmitandreceivepositioninformationtoand
fromtheselectedradio.DSCalsoallowstransmissionof
adistressalerttoallradioswithinrangeatthetouchofa
button.OnceaDSCrequestissentandacknowledgedvoice
communicationiscarriedoutonthechannelchosenbythe
caller.TheradiocantransmitandreceiveonallavailableUS,
CanadianandinternationalandprivatemarineVHFchannels.
YourproductincludestheRay260basestation,ahandsetand
eitherapassiveorandactivespeaker(dependingonvariant).
Extrahandsets,activeandpassivespeakerscanbeaddedto
thestandardRay260providingupto3fullyfunctionalstations.
Withanoptionalloudhailerconnectedtheradiocanalsobe
usedasafoghornorloudpublicaddress(PA)system.
TheRay260isavailableinthefollowingvariants:
VariantDescription
Speaker
typePartnumber
Ray260US/CanadianvariantPassiveE70087
Ray260
AIS
US/Canadianvariant
withbuiltinAIS
receiver
PassiveE70088
Ray260EEuropeanvariantPassiveE70089
Ray260EEuropeanvariantActiveE70253
Ray260E
AIS
Europeanvariantwith
builtinAISreceiver
PassiveE70090
Passiveandactivespeakers
Theproductcanbesuppliedwitheitherapassiveoranactive
speaker.
00
00
Dxxxxx-1
1 1
1Passivespeaker(A80198)
2Activespeaker(A80199)
Activespeakers
Activespeakersconnectin-linewithyourhandsetandincludea
built-inamplieranddedicatedvolumecontrol.
Passivespeakers
Passivespeakersconnecttothespeakerpigtailonthehandset
adaptorcable,speakervolumeiscontrolledusingthehandset
volumecontrols.Passivespeakersdonothaveabuilt-in
amplierorvolumecontrol.
Note:Youcanonlyconnect1activespeakeror1passive
speakerperhandsetstation.
12Ray260

Chapter3:Planningtheinstallation
Chaptercontents
•3.1Systemintegrationonpage14
•3.2Typicalsystemsonpage15
•3.3Installationchecklistonpage16
•3.4Schematicdiagramonpage16
•3.5Systemprotocolsonpage17
•3.6Partssuppliedonpage17
Planningtheinstallation13

3.1Systemintegration
YourVHFradiocanbeconnectedtothefollowingmarineelectronicsdevices.
0
0
12
56
34
D12 611-1
0
0
ItemDevicetypeMaximumquantitySuitabledevicesConnections
1Ray260handset3Ray260handset1perbasestationhandsetconnection
2ActiveSpeaker3Ray260activespeaker1perhandset
3Passivespeaker3Ray260passivespeaker1perhandset
4Loudhailer1•30WattLoudhailer
•30WattLoudhailerwithlisten-back
power/datacable
5Raymarinemultifunction
display
6TheRay260iscompatiblewiththefollowing
Raymarinemultifunctiondisplays:
•aSeries
•cSeries
•eSeries
•gSSeries
•C-SeriesWidescreen(NMEA0183DSC
messagesonly)
•E-SeriesWidescreen(NMEA0183DSC
messagesonly)
•G-Seriessystem(NMEA0183DSC
messagesonly)
SeaTalkngorNMEA0183
6GPSReceiver1•RS130
•RS125
•Raymarinemultifunctiondisplayequipped
withinternalGPS
SeaTalkngorNMEA0183withan
NMEA0183toNMEA2000converter.
Note:TheRay260doesnotsupportconnectiontoNMEA0183andSeaT alkngatthesametime.
14Ray260

3.2Typicalsystems
TheRay260canbeinstalledasastandaloneradiowith
peripheralsoraspartofamarineelectronicsnetwork.
StandaloneDSCVHFradiosystem
0
D12614-3
1
4
3
2
5
1.Ray260basestation
2.Handset
3.Handsetextensioncable
4.Handsetadaptorcable
5.Passivespeaker
Planningtheinstallation15

Extendedsystem
0
00
00
SeaTalk
ng
INTCM
INTCM
INTCM
1
6
3
9
5
2
7
10
D1281 1-1
4
8
1.Station1activespeaker
2.Station1handset
3.Ray260basestation
4.Loudhailer
5.GPSreceiver
6.Station2activespeaker
7.Station2handset
8.Station3handset
9.Station3passivespeaker
10.Multifunctiondisplay
Note:Eachstationcansupportconnectionof1passiveOR1activespeaker.
3.3Installationchecklist
Installationincludesthefollowingactivities:
InstallationTask
1Planyoursystem.
2Obtainallrequiredequipmentandtools.
3Siteallequipment.
4Routeallcables.
5Drillcableandmountingholes.
6Makeallconnectionsintoequipment.
7Secureallequipmentinplace.
8Poweronandtestthesystem.
3.4Schematicdiagram
Aschematicdiagramisanessentialpartofplanningany
installation.Itisalsousefulforanyfutureadditionsor
maintenanceofthesystem.Thediagramshouldinclude:
•Locationofallcomponents.
•Connectors,cabletypes,routesandlengths.
16Ray260

3.5Systemprotocols
Yourproductcansendandreceivepositioninformation,e.g.
latitudeandlongitudeusinganyofthefollowingprotocols:
•SeaT alkng
•NMEA2000
•NMEA0183
Usingtheseprotocolsenablesyourradiotosendposition
informationtootherdevicesinyoursystemwheneveritreceives:
•aresponsetoaDSCpositionrequest.
•aDSCdistresscall
Note:Youmayndthatyourproductorsystemdoesnotuse
alloftheprotocolsdescribedinthissection.
Seatalkng
SeaTalkng(NextGeneration)isanenhancedprotocolfor
connectionofcompatiblemarineinstrumentsandequipment.It
replacestheolderSeaT alkandSeaT alk2protocols.
SeaTalkngutilizesasinglebackbonetowhichcompatible
instrumentsconnectusingaspur.Dataandpowerarecarried
withinthebackbone.Devicesthathavealowdrawcanbe
poweredfromthenetwork,althoughhighcurrentequipmentwill
needtohaveaseparatepowerconnection.
SeaTalkngisaproprietaryextensiontoNMEA2000andthe
provenCANbustechnology.CompatibleNMEA2000and
SeaTalk/SeaTalk2devicescanalsobeconnectedusingthe
appropriateinterfacesoradaptorcablesasrequired.
NMEA2000
NMEA2000offerssignicantimprovementsoverNMEA0183,
mostnotablyinspeedandconnectivity.Upto50unitscan
simultaneouslytransmitandreceiveonasinglephysicalbusat
anyonetime,witheachnodebeingphysicallyaddressable.The
standardwasspecicallyintendedtoallowforawholenetwork
ofmarineelectronicsfromanymanufacturertocommunicateon
acommonbusviastandardizedmessagetypesandformats.
NMEA0183
TheNMEA0183DataInterfaceStandardwasdevelopedby
theNationalMarineElectronicsAssociationofAmerica.Itisan
internationalstandardtoenableequipmentfrommanydifferent
manufacturerstobeconnectedtogetherandshareinformation.
TheNMEA0183standardcarriessimilarinformationtoSeaT alk.
Howeverithastheimportantdifferencethatonecablewillonly
carryinformationinonedirection.ForthisreasonNMEA0183
isgenerallyusedtoconnectadatareceiverandatransmitter
together,e.g.acompasssensortransmittingheadingtoaradar
display.Thisinformationispassedin‘sentences’,eachofwhich
hasathreelettersentenceidentier.Itisthereforeimportant
whencheckingcompatibilitybetweenitemsthatthesame
sentenceidentiersareusedsomeexamplesofwhichare:
•VTG-carriesCourseandSpeedOverGrounddata.
•GLL-carrieslatitudeandlongitude.
•DBT-carrieswaterdepth.
•MWV-carriesrelativewindangleandwindspeeddata.
NMEABaudrates
TheNMEA0183standardoperatesatanumberofdifferent
speeds,dependingupontheparticularrequirementorequipment
capabilities.Typicalexamplesare:
•4800baudrate.Usedforgeneralpurposecommunications,
includingFastHeadingdata.
•38400baudrate.UsedforAISandotherhighspeed
applications.
3.6Partssupplied
ThepartssuppliedwithyourRay260areshownbelow.
00
1
5
9
13
678
2
11
3
4
10
12
D12624-2
1Ray260Basestation
2Ray260Handset
3Ray260speakerincludingcable(dependingonvariantthe
speakermaybepassiveoractive.)
4Speakergasket
54xscrewsforbasestationmounting
62xScrewsforhandsetmounting
7SeaTalkngblankingplug
82xhandsetstationblankingplugs
9Handsetextensionkit
104xThumbnutandstudsforspeakermounting
11Handsetmountingclip
12Documentationpack
13Power/Datacable1m(3.3ft.)
Handsetextensionkitcontents
Thehandsetextensionkitincludesthepartsshownbelow.
1
45
67
3
2
D12649-1
1Splash-proofcap
2Nut
3Handsetadaptorcable10m(32.8ft.)
4Washer
53xMountingscrews
6Gasket
7Mountingplate
Planningtheinstallation17

18Ray260

Chapter4:Cablesandconnections
Chaptercontents
•4.1Generalcablingguidanceonpage20
•4.2Connectionsoverviewonpage20
•4.3Powerconnectiononpage21
•4.4NMEA0183connectiononpage22
•4.5Loudhailerconnectiononpage22
•4.6Handsetconnectiononpage23
•4.7Passivespeakerconnectiononpage23
•4.8Activespeakerconnectiononpage24
•4.9SeaTalkngconnectiononpage24
Cablesandconnections19

4.1Generalcablingguidance
Cabletypesandlength
Itisimportanttousecablesoftheappropriatetypeandlength
•Unlessotherwisestateduseonlystandardcablesofthe
correcttype,suppliedbyRaymarine.
•Ensurethatanynon-Raymarinecablesareofthecorrect
qualityandgauge.Forexample,longerpowercablerunsmay
requirelargerwiregaugestominimizevoltagedropalongthe
run.
Routingcables
Cablesmustberoutedcorrectly,tomaximizeperformanceand
prolongcablelife.
•DoNOTbendcablesexcessively.Whereverpossible,ensure
aminimumbenddiameterof200mm(8in)/minimumbend
radiusof100mm(4in).
100 mm (4 in)
200 mm (8 in)
•Protectallcablesfromphysicaldamageandexposuretoheat.
Usetrunkingorconduitwherepossible.DoNOTruncables
throughbilgesordoorways,orclosetomovingorhotobjects.
•Securecablesinplaceusingtie-wrapsorlacingtwine.Coil
anyextracableandtieitoutoftheway.
•Whereacablepassesthroughanexposedbulkheador
deckhead,useasuitablewatertightfeed-through.
•DoNOTruncablesneartoenginesoruorescentlights.
Alwaysroutedatacablesasfarawayaspossiblefrom:
•otherequipmentandcables,
•highcurrentcarryingacanddcpowerlines,
•antennae.
Strainrelief
Ensureadequatestrainreliefisprovided.Protectconnectors
fromstrainandensuretheywillnotpulloutunderextremesea
conditions.
Circuitisolation
Appropriatecircuitisolationisrequiredforinstallationsusing
bothACandDCcurrent:
•Alwaysuseisolatingtransformersoraseparatepower-inverter
torunPC’s,processors,displaysandothersensitiveelectronic
instrumentsordevices.
•AlwaysuseanisolatingtransformerwithWeatherFAXaudio
cables.
•Alwaysuseanisolatedpowersupplywhenusinga3rdparty
audioamplier.
•AlwaysuseanRS232/NMEAconverterwithopticalisolation
onthesignallines.
•AlwaysmakesurethatPC’sorothersensitiveelectronic
deviceshaveadedicatedpowercircuit.
Cableshielding
Ensurethatalldatacablesareproperlyshieldedthatthe
cableshieldingisintact(e.g.hasn’tbeenscrapedoffbybeing
squeezedthroughatightarea).
Blankingplugs
Connectorsnotinuseshouldbeprotectedusingblankingplugs.
Connectorsontheproductoraccompanyingcables,thatare
notinuse(notconnected),shouldbecoveredusingblanking
plugsifsupplied.
4.2Connectionsoverview
TheconnectionsshownbelowareavailableontheRay260
Basestation.
23456
1
D12812-1
1Antennaconnection
2HS1—Station1port
3HS2—Station2port
4HS3—Station3port
5SeaTalkngconnection
6Power/NMEA0183/Loudhailerconnection
20Ray260
