Ray90/91handbookerratasheet
HandbookErrata
TheInstallationandoperationinstructions(81377–1)suppliedwith
yourproduct,containsthefollowingerrata:
1.Page1—Item11inthepartssuppliedlist(Para2.7)showsthe
SeaT alkng®toDeviceNetdongletypeadaptor,howeveryour
unitissuppliedwiththe1m(3.28ft)Sea Talkng®toDeviceNet
adaptorcable.
2.Page1—Items12to17listedinthepartssuppliedbelowwere
omittedfromoriginalthepartssuppliedlistshowninPara2.7.
3.Page1—Thereareadditionalpartssupplied,thatare
neededwheninstallingthebasestationonmetalstructure,
pleasereferto82385forinstructions.
4.Page35—Item4oftheHomescreenoverview(Para5.3)
detailsthe‘a’and‘b’suffixusedonsomesimplexchannels.
TheRay90/Ray91adherestothenew4digitchannelnaming
conventionandsothechannelsuffixarenolongerused.
Thesechannelsarenowprefixedwith‘10’or‘20’.
5.Page35—TheTransmitandReceivesymbolsthatare
displayedintheStatusbarsymbolstable(Para5.3)havebeen
replacedwithnewsymbols.
.Page35—TheHi/LowBatterywarningsymbolsthatare
displayedintheStatusbarsymbolstable(Para5.3)havebeen
removed.Thesesymbolsarenotshowninthestatusbar,the
warningstheyrepresentaredisplayedfullscreen.
Pleaseseebelowforupdatedsectionswiththeerratacorrected.
Partssupplied
Thefollowingpartsaresuppliedwithyourproduct.Please
ensureyourboxcontentsarecorrectbeforeproceedingwiththe
installation.
1.Ray90/Ray91VHFDSCRadiobasestation(includingfitted
poweranddatacable).
2.Wiredhandsetholster.
3.Wiredhandset.
4.WiredhandsetadaptorcablewithRCAAudio400mm(1.3ft).
5.Passivespeakerandbezel.
.Passivespeakermountinggasket.
7.Passivespeakermountingscrewsx4.
8.Documentation.
9.VHFradiobasestationmountingscrewsx4.
10.Handsetholsterandhookplatemountingscrewsx.
11.DeviceNettoSea Talkng®1m(3.28ft)adaptorcable.
12.Handsethookplate.
13.Throughpanelcablemountingplate.
14.Throughpanelcablemountingplategasket.
15.Throughpanelcablemountingnut.
1.Throughpanelcablemountingplatescrewsx3.
17.Throughpanelcablemountingdustcap.
Additionalpartssupplied
Thefollowingadditionalpartsaresuppliedwithyourproduct.
ThesepartsaretobeusedwheninstallingyourRay90/Ray91
basestationonametalsurface.
1.Insulationsheet(Tobefittedbetweenbasestationanda
metalmountingsurface).
2.Heatshrinktubex2(T obefittedoverVHFandGNSS(GPS)
antennaconnections).
3.Insulationplugs(T obefittedtomountingholestoinsulate
fixingsscrews).
Pleaserefertodocument82385forspecificinstructionsrequired
whenmountingonmetalstructure.
Homescreenoverview
Theinformationbelowdescribestheon-screencharactersand
symbolswhichareshownontheHomescreen..
1.Statusbar—Thestatusbardisplayssymbolswhichindicate
thecurrentstatusoftheunit.
Documentnumber:82389-1AB;7950;2018-03-01T08:50:0Date:02-2018

2.Freuencyband—Indicateswhichchannelfrequencyband
isinuse:
•USA—UnitedStatesofAmerica
•INT—International
•CAN—Canada
•WX—Weather
Note:SpeciallicensingisrequiredtoreceiveUSAand
Canadianchannelsets.
3.Statustext—Indicatesthecurrentradiomodee.g.:ATIS
Modeactive,WeatherAlert,Scanmodeetc.
4.New4digitchannels—Identifiesthefirst2digitswhenthe
radioissettooneofthenew4digitsimplexchannels.
5.Channel—Indicatesthecurrentchannelnumber,orthelast
2digitswhensettoa4digitchannel..
.Location/TimeorLocation/COG/SOG—Dependingon
selectiondisplaysLocationcoordinatesandcurrenttimeor
LocationcoordinatesandcurrentCOGandSOG.
7.ChannelName—Indicatesthenameofthecurrentchannel.
8.Channeltype—Indicatesthetypeofchannel:
•s=Simplex—Simplexchannelstransmitandreceiveon
thesamefrequency.
•d=Duplex—Duplexchannelsuseseparatefrequenciesto
transmitandreceive.
9.Optionaltext—Providesextrauserguidance.
Statusbarsymbols
Thestatusbarisusedtodisplaysymbolsthatindicatetheradio’s
status.
SymbolNameDescription
Lowpower
Highpower
Indicatestheradio
transmittersisinlow
power(1watt)orhigh
power(25watt)mode
LocalIndicatestheradioisin
localreceptionmode,
whichdecreases
receiversensitivityin
hightrafficareasto
decreaseunwanted
reception
FoghornIndicatesthattheradio
isinFoghornmode.
TransmitIndicatestheradiois
currentlytransmitting
(e.g.thePTTbuttonis
beingpressed.)
SymbolNameDescription
ReceiveIndicatestheradiois
currentlyreceivinga
transmission
WeatherIndicatesthatthe
weatheralertsmodeis
activated.
DSCIndicatesthataDSC
callhasbeenreceived
GPSFixIndicatesiftheradio
hasaGPS/GNSSfix.
2Ray90/91handbookerratasheet
