Raypak RHP 5100ti Instruction manual

Technical Data
Professional Series Heat Pumps
Swimming Pool and Spa
Heating Products
39
3-3/8
3
9-5/16
23
4-3/16
2" WATER
CONNECTION
1-7/8
35
ALL DIMENSIONS ARE IN INCHES
The Pool and Spa Heating Expertssm
Professional Model
MODEL RHP 5100ti
Heat BTUH Output 100,000
80°F Air 80% RH 80°F Water
C.O.P. 4.9
Compressor Copeland Scroll
Refrigerant R-22
Voltage 208/230V-1Ph-60Hz
Minimum Circuit Ampacity 38
Maximum Breaker Size (Amps) 50
Electrical Input (kw) 6.0
Heat Exchanger Titanium
Water Flow (gpm) 25-80
Shipping Weight (lbs.) 325
See our complete line of heat pumps:
Classic Series heat pumps, catalog 6000.18.2
Specialty Series heat pumps, catalog 6000.18.4

Swimming Pool and Spa
Heating Products
Cabinet
• Exclusive DuraSteelTM Powder-Coated Cabinet
Polyester powder-coated, non-corrosive cabinet is more
durable than plastic heat pump cabinets. Same rugged
steel construction used by all the major air conditioner
manufacturers.
• Small Footprint
Great for smaller equipment pads and tight spaces.
Coil
• Large Air Coils
Raised lanced-fin design maximizes heating at lower
temperatures.
• Venturi Fan Cowling
High-capacity 3000-cfm fan provides unrestricted air
flow for better heating.
Compressor
• Scroll Compressor
The Copeland Scroll is the leading scroll compressor in
quality and reliability. It provides you with higher
efficiency, lower sound levels, superior durability and
unsurpassed reliability.
• Sound Isolation Pads
Prevents sound transfer to equipment pad and elevates
the base pan to improve water drainage.
Controls
• Remote/Local Switch
Compatible with the latest automated pool control
systems. Exclusive remote/local switch ends the conflict
between outside control systems and the heat pumps
control system. Great for troubleshooting.
• Dual Thermostats
Allows separate pool and spa temperature settings.
• Exclusive Direct-Set Thermostat
Take the guesswork out of adjusting your pool or spa to
your desired temperature. Our direct-set thermostat is
easy to use; the numbers are right on the dial.
Heat Exchanger
• Spiral Titanium Tube
Our spiral titanium tube heat exchanger provides a
corrosion-free waterway that can withstand the abuses
of harsh pool chemistry. The spiral tube helps reduce
deposit build-up and increases efficiency by performing
a “scoop-and-lift” action.
• Internal Valving
Automatically compensates for normal day-to-day
changes in your pool’s hydraulics, maximizing heat
transfer efficiency.
• Plumbing Connections
2” PVC union connections are included for ease of
installation. The connections are offset to easily
accommodate left side or right side plumbing.
Standard Features
Technical Data
Professional Series Heat Pumps
6000.18.1B • 10-01-05
In keeping with its policy of continuous progress and product improvement, Raypak reserves the right to make changes without notice
