Raypak 992B-2342B User manual

Catalog No.: 2000.312D Effective: 11-15-07 Replaces: 1-1-07
Job:
Engineer:
Contractor:
Prepared By: Date:
Model: Indoor/Outdoor: MBTUH Input:
100% Factory Fire Tested
Efficiency: 84%
Maximum Outlet Temperature: 230°F
Minimum Non-Condensing Inlet Temperature: 105°F
Thermal Shock Proof Heat Exchanger
Limited Twenty-Year Thermal Shock Warranty
Limited Ten-Year Closed-System Heat Exchanger
Warranty
Diagnostic Center with Fault History
PolyTuf Powder Coated Cabinet
No Combustible Floor Shield Required
Fan-Assisted
Patented Burner Security Blanket
Heat Exchanger
H Stamp
Headers
Glass-Lined Cast Iron – Standard
Bronze – Option A-1
ASME Inspected and Stamped
160 PSIG Working Pressure
National Board Approved
Fin Tubing
Copper – Standard
Cupro Nickel – Option A-3
ASME Steel Tube Sheet
Silicone High Temp. O-Rings
ASME Pressure Relief Valve
60 PSIG – Standard
PSIG – Optional
Temperature and Pressure Gauge
Water Connections
Left – Standard
Right – Option A-6
Controls
120V, 60Hz, 1∅Power Supply
120/24V 60Hz Transformer
100% Shut-Off/Lockout
Hot Surface Ignition
Remote Flame Sensor
High Limit Control, Manual Reset
On/Off Power Switch
Manual Shut-Off, Front-Mounted
Flow Switch
Blocked Vent Pressure Switch
Combustion Air Proving Switches
Economaster Pump Time Delay
Enable/Disable
Gas Train
Manual Gas Shut-Off Valve(s)
Gas Pressure Regulator
Safety Shut-Off Valve
Firing Control Valve
Low Gas Pressure Switch, Manual
Firing Mode
3-Stage (H8): Model 992B
4-Stage (H9): Models
1262B-2342B
Fuel
Natural Gas
Propane Gas
4” WC Gas Supply Pressure
G-20
Design Certified ANSI Z21.13/
CSA 4.9
Construction
Indoor/Outdoor Construction
Enclosed Front Controls
Venting
Vent Location
Top – Standard
Rear – Option D-14
Vent Termination Cap
Outdoor D-11
Indoor, Horizontal D-15
Indoor, Vertical (by others)
Combustion Air
In-Line Filter Kit (TruSeal only)
D-17
Air Intake Elbow D-16
Extractor – Optional
By others
Not required
Burner
Ultra-Low NOx: Less than 30 PPM
Temperature Controls
B- TempTracker Digital Controller,
4-Stage
Y-241 Electronic Sequencer, 4-Stage
Y-281 Electronic Sequencer, 8-Stage
Options
C-6 Ignition Module, Manual Reset
D-21 TruSeal®Direct Vent
F-10 Low Water Cut-Off, Remote
Probe
I-1 High Limit Control, Auto Reset
P- Pump: HP, 120V, 1∅,
60Hz
Water Hardness: GPG
Cast Iron Bronze
Mounted Loose
Front Rear
P-26 Cold Water Start (See 2000.49)
S-2 High Gas Pressure Switch,
Manual
X-1 SureRack™ Kit
X-2 SureRack Add-on
Regulatory Agency Requirements
Hi Delta®- Type H
Space Heating/Hot Water Boilers
Models 992B-2342B

Catalog No.: 2000.312D Effective: 11-15-07 Replaces: 1-1-07
Hi Delta – Type H
Models 992B-2342B Model
SPECIFICATIONS
A
pprox.
MBTUH Firing
A
H
K
TW
A
mp. Shipping
Model Input Output Stages Width NPT Draw* Wt. (Lbs.)
992B 990 832 3 57-1/8 2-1/2 10 10 16-13/16 <12 900
1262B 1260 1058 4 68-1/2 2-1/2 12 10 20-9/16 <12 1010
1532B 1530 1285 4 79-7/8 2-1/2 12 10 24-3/8 <12 1225
1802B 1800 1512 4 91-1/8 2-1/2 14 10 28-1/8 <12 1350
2002B 1999 1679 4 102-1/2 2-1/2 14 10 31-15/16 <12 1450
2072B 2070 1739 4 102-1/2 2-1/2 14 10 31-15/16 <12 1450
2342B 2340 1966 4 113-7/8 2-1/2 16 10 35-11/16 <12 1520
Dimensions are in inches. * Without pump
RATES OF FLOW AND PRESSURE DROPS
20°F ∆T 30°F ∆TMin. Flow Max. Flow
Model GPM ∆P (ft) GPM ∆P (ft) GPM ∆P (ft) ∆T GPM ∆P (ft) ∆T
992B 84 5.6 56 2.5 42 1.5 40 132 14.0 13
1262B 107 10.0 71 4.5 53 2.6 40 132 15.5 16
1532B 130 16.0 86 7.1 65 4.1 40 132 16.5 20
1802B N/A N/A 102 10.8 76 6.0 40 132 18.0 23
2002B N/A N/A 113 14.0 85 8.1 40 132 19.5 26
2072B N/A N/A 117 15.0 88 8.7 40 132 19.5 27
2342B N/A N/A 132 21.0 99 12.0 40 132 21.0 30
Basis is 30 GPM or 40°F ∆T for minimum flow, 132 GPM for maximum flow.
NOTE: Pump location
varies based on model
and application
NOTES: 1. Rates shown are for natural or propane gas, and elevations up to 5,000 feet. For installation above 5,000 feet, please contact manufacturer.
2. Required natural gas pressure is 7 – 10.5” WC. Required propane gas pressure is 11 - 13” WC.
