Rayzr MC series User manual

1SETTING UP
2FUNCTIONS
Multi-Color LED PANELS
QUICK START GUIDE - January 2019 V.04
3WHAT IS IN THE BOX

Power Switch
MC 100
MC 120
MC 200
●
●
●
12 -24 V DC
12 -24 V DC
12 -24 V DC
●
●
●
14.8 V DC
14.8 V DC
14.8 V DC
Mounting
Mount the light on a
light stand with the
installed TVMP receptacle.
The receptacle offers two
ways to mount the light
to a light stand.
Male Female
Pin 1: Ground Pin 2: Data 1- Pin 3: Data 1+
12
3
21
3
Powering
The light can be powered by:
1×V-Mount battery / AC adapter through XLR-4 connector.
Tilting
The tilt position of the light can
be adjusted by the high strength
tilt lock lever, which can be
repositioned by pulling and
turning it (lift & lock).
Position 1
V-Mount
AC Adapter
through XLR-4
Position 2
DMX (only models including DMX)
Connect a standard DMX console by the
XLR 3-pin connector.
16mm/28mm
Combo Pin
14.4 V DC
14.4 V DC
○
○
—
3-stud Mount
DMX IN
DMX OUT
●Standard ○Optional — Not available
1SETTING UP
>
>>
>
>
>
>

Mode Selection | <MENU> &<↑> <↓>
Start in the main menu interface.
From other interface pages press <MENU> to return to the
main menu.
Select Mode: Press <↑> <↓> to move the cursor to select the
Enter Mode: Press <MENU> to enter the selected mode or
Adjusting Parameters | <Adjustment Knob> &<↑> <↓>
Enter a lighting mode or setting interface first:
Select: Press <↑> <↓> to move the cursor to the parameter of choice.
Adjust: Turn top <Adjustment Knob> to quickly or bottom
Presets | <MODE> +<1~4> &<1~4>
Four scene presets can be saved independently in each mode. Please enter one of the lighting mode operation interfaces first:
Save: To save the light parameters in the current mode to a preset, press and hold <SAVE> and press one of the preset number buttons <1> <2> <3> <4>.
Recall: To recall a saved preset in the current mode, press one of the saved preset number buttons <1> <2> <3> <4>.
Confirm / Return
Menu
Adjustment Knob Quick
Adjustment Knob Fine
>
>
>
>
>
>
>
>
>
2FUNCTIONS
mode or setting menu.
setting interface.
<Adjustment Knob>to slowly adjust the selected parameter.

Copyright © VIBESTA All Rights Reserved.
VIBESTA B.V. | Professor Rommelaan 2, 5707 KS Helmond, The Netherlands
Light Body
Barndoors
AC Adapter & Cable
MODEL Rayzr MC 100 Rayzr MC 120
●
●
●
●
●
●
Rayzr MC 200
●
●
●
●Standard ○Optional — Not available Technical data and offerings are subject to change without notice.
3WHAT IS IN THE BOX
Copyright © VIBESTA B.V.
VIBESTA B.V. · Professor Rommelaan 2, 5707KS Helmond, The Netherlands · Tel [phone]
