CZZN FL48-M300 User manual

1
FL48-M300
Red and Blue Flashing Light
User Manual
2021.12.23
Catalog
ⅰ.Introduction of FL48-M300 red and blue flashing light 2
ⅱ.Disclaimer and warning 2
ⅲ.FL48-M300 red and blue flashing light parameters 4
ⅳ.FL48-M300 mounting operation 5
ⅴ.FL48-M300 software tutorial 9
ⅵ.Attention 16
Subscribe to DeepL Pro to edit this document.
Visit www.DeepL.com/profor more information.

2
ⅰ.Introduction of FL48-M300 red and blue flashing light
FL48-M300 red and blue flashing light, suitable for police UAV patrol
duty work. Adopting DJI M300 RTK UAV's Onboard SDK interface for power
supply and signal control, no additional power supply is required, and it
is suitable for DJI M300 RTK series UAV.
ⅱ.Disclaimers and Warnings
Thank you for purchasing a CZI product. The contents of this document are
related to your safety and legal rights and responsibilities. Before using this
product, please read this document carefully to ensure that you have set up the
product properly. Failure to follow and comply with the instructions and
warnings in this document may result in injury to you and others around you,
damage to the product or other surrounding items. This document and all related
documents are subject to the final interpretation of CZI. Updates are subject
to change without notice. Please visit www.gzczzn.com official website for the
latest product information.

3
Warnings
FL48-M300 red and blue flashing lights are precision equipment. If you
encounter hardware problems, please contact the factory after-sales
service, do not disassemble to repair by your own, otherwise you will lose
the warranty, repair eligibility.
Cautions
When the M300 RTK is not in flight, the FL48-M300 red and blue
flashing light cannot be turned on for a long time, otherwise the power
will be too high due to the heating of the light board, resulting in
the OSDK interface power failure.

4
ⅲ.FL48-M300 red and blue flashing light parameters
FL48-M300 red and blue flashing light (including control box) weighs
≤385g, connects with M300 RTK OSDK interface, can be mounted on DJI MATRICE
M300 RTK and used. Light switch can be controlled through CZZN APP. It is easy
to use.
Technical parameters
Model
FL48-M300
Electrical interface
M300 RTK OSDK
Weight/g
385±5g
Rated power/W
50
Operating temperature
-20°C~+50°C

5
ⅳ.FL48-M300 mounting operation
1.Use screws to fix the red and blue flashing light control box in the top of the
machine, the location is as follows:

6
2. Install the red and blue flashing lights in the M300 tripod and connect the light
cable with the control box, the installation position and direction as shown:

7

8
3. Connect the data cable of the control box to the M300, turn on the drone and check
the display status of the light on the top of the control box, if you can see red
light of control box on once turning on the drone power, it means the power supply of
the OSDK interface is normal. The next step is to turn on the M300 RTK OSDK function.

9
ⅴ. FL48-M300 software tutorial
1、Activate M300 RTK OSDK function
Step 1：Download the new version of DJI Assistant 2 (Enterprise Series) for
debugging software via https://www.dji.com/cn/matrice-300/downloads as shown
in the picture below. Notably, do not use DJI Assistant 2, DJI Assistant 2
does not support M300 RTK tuning.
Step 2: Open Onboard SDK APP ID service in DJI Assistant 2 (Enterprise
Series) for debugging software, as shown in the figure below:

10
Step 3: Enable the OSDK API control function in DJI Assistant 2 For Matrice
tuning software, as shown in the figure below：
1）Select "Start API control"
2）"Baud rate" select 921600
Step 4: Close the tuning software after setting the parameters and restart
the drone twice. After waiting for five seconds for power on, if the control
box status light shows a green light blinking once a second, it means that
the OSDK function is opened and completed, otherwise it should be re-tested
whether the set parameters are effective. Note: Every time the drone
performs upgrade or downgrade operation, you have to turn on the OSDK
function again to use the flashing light.

11

12
2、Operating control instructions
Step 1: Install the control software CZZN APP to the DJI remote control
screen, the download link of APP installation file is as follows:
http://www.gzczzn.com/product/download/18
Step 2: After connecting the red and blue flashing light control box cable
to the drone, turn the drone on, wait until the status light at the top of
the control box shows a flashing green light, then open the CZZN APP, you
can see that the drone has been connected to the load “OSDK Device” .

13
Step 3: Open the "OSDK Device Control" by clicking on the settings button
in the upper right corner
Step 4: After the prompt box of "whether to open DJI Pilot at the same
time?" pops up, press the confirmation button, the interface will cut to
the main interface of DJI Pilot APP, and the control buttons of red and
blue flashing lights will be displayed at the same time.

14
When the light is not on, the control button is white. At this time, you
can control the flight of the drone through DJI POLIT APP and control the
light on/off with the hover button.
Step 5: Press the control button, red and blue flashing light began to work,
the control button shows yellow, indicating that the light is in working
condition.

15

16
ⅵ, Attention
If you encounter a drone firmware update that causes the red and blue
flashing lights to not work properly, please contact your local agent or
factory in a timely manner.
ChengZhi Intelligence Support
www.gzczzn.com
If you have any questions or
suggestions about the manual,
please contact us at the
following email address:
[e-mail]
[e-mail]
Printed in China
