Razor E100 series User manual

User Manual of Product 1:
Razor Power Core E100 Electric Scooter for Kids Ages 8+ -
100w Hub Motor, 8" Pneumatic Tire, Up to 11 mph and 60 min
Ride Time, For Riders up to 120 lbs
User Manual of Product 2:
Razor Power Core E100 Electric Scooter - 100w Hub Motor, 8"
Air-filled Tire, Up to 11 mph and 60 min Ride Time, for Kids
Ages 8+

OWNER’S MANUAL
Read and understand this entire manual before allowing
child to use this product! For assistance contact Razor.
DO NOT RETURN TO STORE.
NOTE: Manual illustrations are for demonstration purposes only.
Illustrations may not reflect exact appearance of actual product.
Specifications subject to change without notice.
Please have your product along with the 19 character product I.D. code with you
before contacting Razor for warranty assistance and/or replacement parts.
Product I.D. Code: _____________ - ____________ - ____________
POWER CORE E100 SERIES
ELECTRIC HUB MOTOR SCOOTERS
NOTE: The unit must be traveling at least 3 mph (5 km/h) before motor will engage.
Kick to start to at least 3 mph (5 km/h) while applying the throttle to engage motor.

1
CONTENTS
Safety Warnings............................................................................................ 1
Before You Begin .......................................................................................... 2
Assembly and Set-Up................................................................................3-5
Charging the Battery ................................................................................... 5
Pre-Ride Checklist - Usage ......................................................................... 6
Repair and Maintenance........................................................................7-10
Troubleshooting Guide ............................................................................... 11
Power Core E100 Series Electric Scooter Parts.................................... 12
Warranty and Contact Information .....................................................13-14
SAFETY WARNINGS
WARNING: Riding an electric scooter does present potential risks
and caution is required. Like any riding product, an electric scooter has
inherent hazards associated with its use (for example, falling off or riding
it into a hazardous situation). Like any riding product, electric scooters
can and are intended to move and it is therefore, of course, possible to
lose control or otherwise get into dangerous situations. Both children,
and adults responsible for supervising them, must recognize that if such
things occur, a rider can be seriously injured or die even when using
safety equipment and other precautions. RIDE AT YOUR OWN RISK AND
USE COMMON SENSE.
WARNING: PARENTAL AND ADULT RESPONSIBILITY AND
SUPERVISION IS NECESSARY: Because products, like electric scooters,
can and do present potential hazards plainly associated with their
use, it is well recognized THE NEED FOR EXERCISE OF PARENTAL
RESPONSIBILITY IN SELECTING RIDING PRODUCTS APPROPRIATE TO
THE AGE OF A CHILD, OR PARENTAL SUPERVISION IN SITUATIONS IN
WHICH CHILDREN OF VARIOUS AGES MAY HAVE ACCESS TO THE SAME
RIDING PRODUCTS, IS IMPORTANT. Not every product is appropriate for
every age or size of child, and different age recommendations are found
within this category of product which are intended to reflect the nature
of the hazards and the expected mental or physical ability, or both, of a
child to cope with the hazards.
The recommended minimum rider age is 8 and older. Any rider unable
to fit comfortably on the scooter should not attempt to ride it. A parent’s
decision to allow his or her child to ride this product should be based on
the child’s maturity, skill and ability to follow rules.
Keep this product away from small children and remember that it is
intended for use only by persons who are, at a minimum, completely
comfortable and competent while operating the scooter.
Persons with any mental or physical conditions that may make them
susceptible to injury, impair their physical dexterity or mental capabilities
to recognize, understand, and follow safety instructions and to be able
to understand the hazards inherent in scooter use, should not use or
be permitted to use products inappropriate for their abilities. Persons
with heart conditions, head, back or neck ailments (or prior surgeries to
these areas of the body), or pregnant women, should be cautioned not to
operate such products.
DO NOT EXCEED THE WEIGHT LIMIT OF 120 lb (54 kg). Rider weight does
not necessarily mean a person’s size is appropriate to fit or maintain
control of the scooter.
CHECK AND MAINTAIN SCOOTER CONDITIONS
Before use, check to confirm that covers and guards are in place and in
serviceable condition. Check that the brake is functioning properly, that
the front tire is inflated properly and has sufficient tread remaining and
that the rear wheel is free of flat spots from wear. The scooter should
be maintained and repaired in accordance with the manufacturer’s
specifications, using only the manufacturer’s authorized replacement
parts, and should not be modified from the manufacturer’s original design
and configuration.
ACCEPTABLE RIDING PRACTICES AND CONDITIONS
Always check and obey any local laws or regulations which may affect
the locations where the electric scooter may be used. Keep safely away
from cars and motor vehicle traffic at all times. Only use where allowed
and with caution.
Do not activate the speed control on the hand grip unless you are on
the scooter and in a safe, outdoor environment suitable for riding. The
electric scooter must be moving at least 3 mph (5 km/h) before the motor
will engage.
The normal powered top speed of this scooter will be approximately
11 mph (18 km/h), which can be affected by conditions, such as rider
weight, inclines and battery charge level. Avoid excessive speeds that
can be associated with downhill rides.
Maintain a hold on the handlebars at all times. Do not touch the brake or
motor on your scooter when in use or immediately after riding, as these
parts can become very hot.
Ride defensively. Watch out for potential obstacles that could catch
your wheel or force you to swerve suddenly or lose control. Be careful
to avoid pedestrians, skaters, skateboards, scooters, bikes, children or
animals who may enter your path, and respect the rights and property of
others.
The electric scooter is intended for use on flat, dry surfaces, such as
pavement or level ground, without loose debris, such as sand, leaves,
rocks or gravel. Wet, slick, bumpy, uneven or rough surfaces may impair
traction and contribute to possible accidents. Do not ride your scooter in
mud, ice, puddles or water. Watch out for potential obstacles that could
catch your wheel or force you to swerve suddenly or lose control. Avoid
sharp bumps, drainage grates, and sudden surface changes.
Do not attempt or do stunts or tricks on your electric scooter. The
scooter is not made to withstand abuse from misuse, such as jumping,
curb grinding or any other type of stunts. Racing, stunt riding, or
other maneuvers also enhance risk of loss of control, or may cause
uncontrolled rider actions or reactions.
Never allow more than one person at a time to ride the scooter.
Do not ride at night or when visibility is limited.
Never use near steps or swimming pools.
Do not allow hands, feet, hair, body parts, clothing, or similar articles to
come in contact with moving parts or wheels while the motor is running.
Do not touch hot brake or electric motor when in use or immediately
after riding.
Never use headphones or a cell phone to talk or text when riding.
Never hitch a ride with a vehicle.
Do not ride your scooter in wet or icy weather and never immerse
the scooter in water, as the electrical and drive components could
be damaged by water or create other possibly unsafe conditions.
Never risk damaging surfaces, such as carpet or flooring, by use of an
electric scooter indoors.
PROPER RIDING ATTIRE
Always wear proper protective equipment, such as an approved safety
helmet (with chin strap securely buckled), elbow pads and kneepads.
A helmet may be legally required by local law or regulation in your
area. A long-sleeved shirt, long pants, and gloves are recommended.
Always wear athletic shoes (lace-up shoes with rubber soles) and
keep shoelaces tied and out of the way of the wheels, motor and drive
system. Never ride barefooted or in sandals.
USING THE CHARGER
The charger supplied with the electric scooter should be regularly
examined for damage to the cord, plug, enclosure and other parts. In
the event of such damage, the scooter must not be charged until the
charger has been repaired or replaced.
Use only with the recommended charger.
Use caution when charging.
The charger is not a toy. Charger should be operated by an adult.
Do not operate charger near flammable materials.
Unplug charger and disconnect from scooter when not in use.
Always disconnect from the charger prior to wiping down and cleaning
your scooter with damp cloth.
FAILURE TO USE COMMON SENSE AND HEED THE ABOVE WARNINGS
FURTHER INCREASES RISK OF SERIOUS INJURY. USE AT YOUR OWN
RISK AND WITH APPROPRIATE AND SERIOUS ATTENTION TO SAFE
OPERATION. USE CAUTION.

Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed at the back of this manual.
2
BEFOREYOU BEGIN
Remove contents from box. Remove the separators that protect the components from damage during shipping.
Inspect the contents of the box for scratches in the paint, dents or kinked cables that may have occurred during
shipping. Because the scooter was 95 percent assembled and packed at the factory, there should not be any
problems, even if the box has a few scars or dents.
MAKE SURE POWER SWITCH IS TURNED “OFF” BEFORE CONDUCTING ANY ASSEMBLY OR
MAINTENANCE PROCEDURES.
Estimated Assembly and Set-Up Time
Razor recommends assembly by an adult.
Allow up to 10 minutes for assembly, not including initial charge time.
Allow up to 12 hours for charge (see page 5 for charging information).
WARNING:
DO NOT USE NON-RAZOR
PRODUCTS WITH YOUR RAZOR
ELECTRIC SCOOTER. The scooter
has been built to certain Razor
design specifications. The original
equipment supplied at the time
of sale was selected on the basis
of its compatibility with the
frame, fork and all other parts.
Certain aftermarket products
may not be compatible and will
void the warranty.
Note: Electric scooter must be
moving at least 3 mph (5km/h)
while applying throttle to
engage motor.
Product ID Locations:
(See locations to the left)
1. Handlebar Stem
2. Underneath Battery Tray
3. Charger
4. UPC Side of Box (Not Shown)
Box Contents:
• Electric Scooter
• Charger
• Tool(s)
• Owner’s Manual
Charger
(Note: Charger design may vary from
one shown)
Twist-Grip Throttle Brake Lever
Collar Clamp
Limiter
1.
On/Off Switch
Charger Port
- Battery
- Control Module
Hub Motor
3.
2.
Seat (Power Core E100S only)
Required Tools
5 mm Allen Wrench (Included)
Two (2) 4 mm Allen Wrenches
(Included - Power Core E100S only)

4mm 4mm
5mm
5mm
3
HEADLINEHEADLINEASSEMBLY AND SET-UP
Attaching the Handlebars
Required Tool: 5 mm Allen Wrench (included)
Seat Assembly (Power Core E100S Only)
Required Tools: Two (2) 4 mm Allen Wrenches and Two (2) 5 mm Allen Wrenches (included)
WARNING: Do not attempt
to thread the stem into the front
fork thread.
Note: Make sure any cables/wires
are out of the way before inserting
the stem into the fork.
WARNING: Failure to
properly tighten the collar clamp
may allow the handlebars to
dislodge while riding and may
cause you to lose control and fall.
When correctly tightened, the
handlebars will not rotate out of
alignment with the front wheel
under normal circumstances.
Note: The cable and wire assembly
from the handlebar must not
wrap around the steering tube or
handlebar. Sharp bends or twisting
of the brake cable can cause the
brake to malfunction.
1Using 5 mm Allen wrench loosen
the bolts from the collar clamp.
2With a twisting motion, push and
twist to slide the handlebars onto
the fork.
3With the front wheel pointed straight ahead and the handlebars square to
the front wheel, tighten both bolts on the clamp with a 5 mm Allen wrench.
Tighten securely.
1Remove bolts on the middle of the deck using 4 mm
and 5 mm Allen wrenches.
2Place seat post on to the deck.

4mm
4mm
2X2X
4mm
2X
5mm
2X
4mm
5mm
4
ASSEMBLY AND SET-UP
3Using 4 mm and 5 mm Allen wrenches, secure seat
post to deck using the bolts that were removed in Step 1.
5Align the holes on seat with the holes on the
seat post.
7Adjust seat position.
4Use 4 mm Allen wrenches to remove bolts and
washers from the top of the seat post.
6Use 4 mm Allen wrenches to secure seat onto the
seat post using bolts removed in Step 4.
8Tighten bolts after seat adjustment using 4 mm
Allen wrenches.
Seat Assembly (Power Core E100S Only – Continued)
Required Tools: Two (2) 4 mm Allen Wrenches and Two (2) 5 mm Allen Wrenches (included)
Note: Do not completely tighten
at this time. Adjust the seat tilt
approximately level to the ground,
or slightly tilted depending on
your personal preference. Tighten
securely. The seat tilt adjustment
should not move when riding.

5
Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed at the back of this manual.
ASSEMBLY AND SET-UP
Inflating the Tire
The front tire is inflated when shipped, but it invariably may lose some pressure between the point of manufacturing
and your purchase. Always inflate tire to the correct PSI before first time use.
Lower air pressure can result in a shorter ride time.
Periodically check front tire. Reinflate when needed.
1Using a bicycle-style tire pump
equipped for a Schrader-type valve,
inflate the front tire to the correct PSI
indicated on the sidewall of the tire.
WARNING: Do not use the
electric scooter for the first time
until you have inflated the front tire
to the correct PSI. Failure to do so
may damage your electric scooter
and void your warranty.
WARNING: Do not
overinflate, as this could damage
the tire or wheel.
Note: The pressure air supplies
found at gasoline stations are
designed to inflate high-volume
automobile tires. If you decide to
use such an air supply to inflate your
electric scooter tire, first make sure
the pressure gauge is working, then
use very short bursts to inflate to
the correct PSI. If you inadvertently
overinflate the tire, release the
excess pressure immediately.
CHARGING THE BATTERY
LED light
2 Note: Make sure power
switch is in the OFF position.
Plug the charger into the
charger port. The light on the
charger should turn red during
charging. The light will turn
green again when charging
is complete.
Charger
WARNING: Use ONLY
with the recommended charger.
Batteries are only to be charged
under adult supervision. The charger
is not a toy. Always disconnect the
charger before wiping down and/or
cleaning the electric scooter with a
damp cloth.
The charger supplied with the
electric scooter should be regularly
examined for damage to the cord,
plug, enclosure and other parts.
In the event of such damage,
the electric scooter must not be
charged until it has been repaired
or replaced.
Chargers have built-in overcharge
protection to prevent battery from
being overcharged.
Note: If the charger gets warm
during regular use, this is a normal
response and is no cause for
concern. If your charger does not
get warm during use, it does not
mean that it is not working properly.
Wall outlet - Green (stand by)
Wall outlet and unit - Red (charging)
Wall outlet and unit - Green (charged)
Note: Continue charging unit even
if light turns green prior to 12 hours.
WARNING: Battery charge
can deplete over time. Periodically
recharge battery when not in use.
1 Plug the charger plug into wall
outlet. The light on the charger
should be green.
Note: If green light (LED) does not
turn on, try a different outlet.
Your electric scooter may not have a fully charged battery; therefore you must charge the battery prior to use.
• Initial charge time: 12 hours.
• Recharge time: up to 12 hours, even if the light
turns green. Recommended maximum charging time
is 24 hours.
• Always charge the battery immediately after riding.
• Fully charge battery before storing for extended
periods of time.
• Unplug charger from the wall outlet when not in use.
• Failure to recharge battery periodically may result in a
battery that will not accept a charge.
• Make sure the power is turned OFF when product
is not in use. If the ON/OFF switch is left on for an
extended period of time, the battery may reach a stage
at which it will no longer hold a charge.
• To ensure long battery life, never store the product in
freezing or below freezing temperatures! Freezing will
permanently damage the battery.
• Run time: Up to 60 minutes of continuous ride time.
Run time may vary depending on riding conditions,
rider weight, climate, and/or proper maintenance.
• Constant starting and stopping may shorten ride time.
• Battery life can vary depending on proper maintenance
and usage of the product.
Charger
(Note: Charger design may vary
from one shown)

A
B
A
6
q Starting the Scooter
Turn power “ON”; put kickstand up and place both hands on the handlebars.
Place one foot on deck plate and with the other foot, push (kick start) scooter while twisting throttle (A). Place other
foot on deck plate once motor has engaged.
q Stopping the Scooter
To stop, release the throttle (A) and apply the brake, by squeezing brake lever (B), until the product
comes to a complete stop.
Note: Electric scooter must be
moving at least 3 mph (5 km/h)
while engaging throttle to
engage motor.
Note: As an additional safety
feature, the scooter is designed to
cut power to the motor when the
hand brake is applied.
Note: Motor will re-engage,
(without having to kick start),
if brake is released and throttle
is engaged before scooter has
slowed down to under 3 mph
(5km/h).
USAGE
PRE-RIDE CHECKLIST
qBrake
Check the brake for proper function. When you squeeze
the brake lever, the brake should provide positive braking
action. When you apply the brake with the throttle on/
engaged, the brake cut-off switch should cut power to the
motor.
qWheels
Periodically inspect the wheels for excessive wear.
qTire
Periodically inspect the tire for excess wear and replace
as needed. Regularly check the tire pressure and inflate
as needed.
qFrame, Fork and Handlebars
Check for cracks or broken connections. Although broken
frames are rare, it is possible for an aggressive rider to
run into a curb or object and wreck and bend or break
a frame. Get in the habit of inspecting your scooter on a
regular basis.
qHardware/Loose Parts
Before every ride, check all parts, such as nuts, bolts, cables,
fasteners, etc., to ensure they are secure and assembled
correctly. There should not be any unusual rattles or sounds
from loose parts or broken components. If the product is
damaged, do not ride. Reference “Safety Warnings” on page
1 of this manual.
qSafety Gear
Always wear proper protective gear, such as an approved
safety helmet. Elbow pads and kneepads are recommended.
Always wear athletic shoes (lace-up shoes with rubber
soles) and keep shoelaces tied and out of the way of the
wheels, motor and drive system. NEVER RIDE BAREFOOTED
OR IN SANDALS.
qLaws and Regulations
Always check and obey any local laws or regulations.
qInsurance
Do not assume that your existing insurance policies
necessarily provide coverage for scooter use. Check with
your insurance company for information regarding insurance.
qStorage
Prolonged exposure to UV rays, rain and the elements may
damage the enclosure materials, store indoors when not in use.

BBAA
8-2 8-4 8-4 8-2
8-1 8-18-3 8-38-5
7
Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed at the back of this manual.
REPAIR AND MAINTENANCE
1To adjust brake cable play, thread
the brake lever adjuster in or out 1/4
to 1/2 turn until the desired brake
adjustment is attained. Most adjust-
ments are complete at this step. If
brake still needs further adjustment,
proceed to step 2.
2If brake is too tight or has too
much slack, use a 10 mm wrench
to loosen the brake cable and
adjust accordingly.
3Inspect the brake pads (A) for
proper alignment against the wheel
or excess wear. To realign brake
pads, loosen the fixing nut (B) and
adjust the pad to contact the rim.
Re-tighten and readjust as needed.
Verify proper brake function prior to
riding the scooter.
Adjusting the Brake
Required Tool: 10 mm Wrench (not included)
Turn power “OFF” before beginning repair or maintenance:
• Read the instructions
• Remove charger plug
• Turn the power off
• Secure the product under repair
• Exercise caution around
exposed parts
• Contact Razor customer service
if unsure about any repair or
maintenance
Right Side (Throttle)
8-4 Spacer
8-3 Washer
8-2 Spring Washer
8-1 M10 locknut
Middle
8-5 Front axle bolt
Left Side (Brake)
8-4 Spacer
8-3 Washer
8-2 Spring Washer
8-1 M10 locknut
1 Using two (2) 16 mm wrenches, loosen the axle bolt.
Remove wheel and install replacement wheel.
(Note the sequence of the hardware)
q Front Tire Replacement
Required Tools: Two (2) 16 mm Wrenches (not included)
Note: Front wheel
hardware sequence

4mm
5mm
4mm
5mm
14-3
14-4
14-6
14-5
14-7
A.
A.
B.
1 Using a Phillips screwdriver remove the six
(6) screws and remove the deck plate.
(Note: There are two (2) sizes of screws,
A-Small, B-Large)
2 Using a Phillips screwdriver remove
the battery strap.
3 Disconnect the battery wire connector from
the control module and carefully remove the
battery.
Note: If only replacing battery, install new
battery and reverse steps 1-3.
4 Disconnect the motor wire connector from
the control module.
8
REPAIR AND MAINTENANCE
Note: Rear wheel/motor
hardware sequence
Left Side
14-1 Phillips Screws (x3)
14-2 Motor Housing
Right Side
14-3 Spacer
14-4 Nut
Frame
14-5 Flat Washer
14-6 Lock-Washer
14-7 Locknut
q Removing Seat Post For Rear Wheel/Hub Motor/ Battery
Replacement (E100S ONLY)
Required Tools: Two (2) 4 mm Allen Wrenches and Two (2) 5 mm Allen Wrenches (included)
q Rear Wheel/Hub Motor/Battery Replacement
Required Tools: Phillips Screwdriver and Two (2) 13 mm Wrenches (not included)
(Battery Replacement Steps 1-3)
14-1 14-2
1Remove bolts on deck using 4 mm and 5 mm
Allen wrenches.
2Remove seat post from deck.

Red
Black
5 Using a pointed object carefully depress the
tabs on the metal pins inside of the motor wire
connector and remove the wires. Carefully pull
wires out from battery tray.
6 Using a Phillips screwdriver remove the
three (3) screws that attach the motor housing
to the frame.
7 Using a 13 mm wrench, loosen the outside
locknut (14-6). Use a 13 mm wrench to prevent
the inside nut (14-3) from turning.
Remove wheel/hub motor.
A.
A.
B.
8 To install the replacement wheel/hub motor,
reverse steps 1 through 7.
9
Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed at the back of this manual.
REPAIR AND MAINTENANCE
q Rear Wheel/Hub Motor/Battery Replacement (Continued)
Required Tools: Phillips Screwdriver and Two (2) 13 mm Wrenches (not included)
Note:
Motor Control Module
Red 1Yellow
Black 1Blue
Note: When re-inserting the
motor wires into the connector,
make sure the red wire connects
to the yellow wire and the black
wire connects to the blue wire.

10
REPAIR AND MAINTENANCE
Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed at the back of this manual.
q Charger
The charger supplied with the electric scooter
should be regularly examined for damage to the
cord, plug, enclosure and other parts and in the
event of such damage, the product must not be
charged until it has been repaired or replaced.
Use ONLY with the recommended charger.
q Wheels
Wheels and drive system are subject to normal
wear and tear. It is the responsibility of the user to
periodically inspect wheels for excess wear and
replace hub motor components as required.
q Replacement Parts
The most frequently requested replacement parts
are available for purchase at some Razor retail
partners. For the complete selection of replacement
parts visit www.razor.com.
q Repair Centers
For a list of authorized Razor repair centers:
• Check online at www.razor.com.
• Additional Customer Service contact information is
listed on the back of this manual. WARNING: Battery
posts, terminals and related
accessories contain lead and
lead compounds. Wash your
hands after handling.
q Battery Care and Disposal
Do not store in freezing or below freezing temperatures. To properly maintain your battery and ensure
maximum battery life, carefully read the “Charging the Battery” section on page 5 of this owner’s manual.
Pb
Pb
CONTAINS SEALED LEAD-ACID BATTERIES. BATTERIES MUST BE RECYCLED.
Disposal: Your Razor product uses sealed lead-acid batteries which must be recycled or disposed of in
an environmentally safe manner. Do not dispose of a lead-acid battery in a fire. The battery may explode
or leak. Do not dispose of a lead-acid battery in your regular household trash. The incineration, land filling
or mixing of sealed lead-acid batteries with household trash is prohibited by law in most areas. Return
exhausted batteries to a federal or state approved lead-acid battery recycler or a local seller of automotive
batteries. If you live in Florida or Minnesota, it is prohibited by law to throw away lead-acid batteries in the
municipal waste stream.
WARNING: If a battery
leak develops, avoid contact
with the leaking acid and place
the damaged battery in a plastic
bag. Refer to the disposal
instructions
at left. If acid comes into contact
with skin or eyes, flush with cool
water for at least 15 minutes and
contact a physician.
In the US and Canada only:
For more information regarding
recycling of rechargeable batteries,
call toll free 1-800-822-8837,
or visit http://www.call2recycle.org

11
TROUBLESHOOTING GUIDE
Problem Possible Cause Solution
Does not work out of the box Product must be traveling at least
3 mph (5 km/h) before motor will
engage
Loose connection(s)
Kick start to at least 3 mph (5 km/h) while twisting throttle to
engage motor.
Check for loose connections/wires underneath the deck
plate.
No longer works Loose connection(s)
No lights on charger
Undercharged battery
Battery will not hold a charge
Check for loose connections/wires underneath the deck
plate.
Check power to wall outlet and/or try a different outlet.
Check lights on charger:
Plugged into wall - Green
Plugged into wall & product - Red (charging)
Plugged into wall & product - Green (charging complete)
No lights/Blinking lights - Replace Charger
With no weight on the product, lift up back end; manually
(and carefully) spin rear wheel and twist throttle to engage
the motor. If motor engages - replace battery.
Short run time/runs slow Rider’s weight
Riding conditions
Battery not fully charged
Old/damaged battery
Do not exceed 120 lb (54 kg) maximum weight limit.
Use only on flat, dry surfaces. Avoid inclines and areas with
heavy debris.
Charge product for a full 12 hours.
Replace battery.
Charge battery at least once a month when not in use.
Do not store product in freezing or below freezing
temperatures. Freezing will permanently damage the battery
and greatly reduce ride time.
Refer to page 5 for charging information.
Runs intermittently Loose connection(s) Check the wires around the throttle and connectors
underneath the deck plate.
Replace - twist-grip throttle.
For more troubleshooting tips, a list of available replacement parts or to locate an authorized Service Center in your area,
visit our website at www.razor.com or call toll free [phone] to speak to a live Customer Service Representative.
*Product(s) should be turned OFF and fully charged prior to doing any Troubleshooting.
NOTE: All troubleshooting steps should be performed by an adult only.

2 3 4 5 20 1 1
6
7
9
10
8
11 12 12-1
15 17 18 16
19
14
13
Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed at the back of this manual.
12
POWER CORE E100 SERIES ELECTRIC SCOOTER PARTS
Keep your electric scooter running for years with genuine Razor parts. Visit our website or e-mail us for more information on spare part availability.
(Specifications subject to change without notice.)
1. Handlebar Grips (Right/Left)
2. Single-Speed Twist-Grip Throttle
3. Stem
4. Brake Lever Assembly
5. Battery 24V (2 12V)/6A
6. Collar Clamp
7. Headset (Upper/Lower)
8. Front Fork
9. Front Caliper Brake With Brake Pads
10. Front Wheel Complete
11. Kickstand
12. Rear Wheel with Hub Motor Complete
12-1 Motor Cover
13. Deck Plate
14. Battery Strap
15. Battery Tray
16. On/Off Switch
17. Charge Port
18. Reset Button
19. Control Module
20. Seat Post with Seat
(Power Core E100S only)

13
NOTICE: INSURANCE
YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE FOR
ACCIDENTS INVOLVING THE USE OF THIS SCOOTER/ELECTRIC RIDE-
ON PRODUCT. TO DETERMINE IF COVERAGE IS PROVIDED, YOU
SHOULD CONTACT YOUR INSURANCE COMPANY OR AGENT.

FCC COMPLIANCE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications to this product not expressly approved by Razor USA LLC, could void the user’s authority to operate the equipment.
WARRANTY
Razor Limited Warranty
The manufacturer warranties this product to be free of manufacturing
defects for a period of 90 days from date of purchase. This Limited Warranty
does not cover normal wear and tear, tire, tube or cables, or any damage,
failure or loss caused by improper assembly, maintenance, storage or use of
the Razor Power Core E100.
This Limited Warranty will be void if the product is ever:
• used in a manner other than for recreation or transportation;
• modified in any way;
• rented.
The manufacturer is not liable for incidental or consequential loss or damage
due directly or indirectly to the use of this product.
Razor does not offer an extended warranty. If you have purchased an extended
warranty, it must be honored by the store at which it was purchased.
For your records, save your original sales receipt with this manual and write
the serial number below.
__________________________________________
CUSTOMER SERVICE CONTACT INFORMATION
Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact
information at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional
Customer Service contact information is listed below:
AMERICAS
Razor USA LLC
P.O. Box 3610
Cerritos, CA 90703
USA
[phone]
Monday - Friday
8:00 AM - 5:00 PM Pacific Time
[e-mail]
EUROPE, MIDDLE EAST, AFRICA
Razor USA LLC (Europe)
Handelsweg 2
2742 RD Waddinxveen
Netherlands
[phone]
[e-mail]
ASIA
Razor USA LLC (Asia)
P.O. Box 3610
Cerritos, CA 90703
USA
[phone]
[e-mail]
UNITED KINGDOM AND IRELAND
Razor USA LLC (UK)
Unit 20
Hartnoll Business Centre
Post Hill, Tiverton
Devon EX16 4NG
UK
[phone]
[e-mail]
AUSTRALIA AND NEW ZEALAND
Razor USA LLC
P.O. Box 4280
Auburn South
VIC 3122
Australia
[phone] (AU)
+0 800 003 221 (NZ)
[e-mail]
IMPORTED IN JAPAN BY B-PLUS ASIA
CORP.
Razor USA LLC
Kurokawa 3-1, Asaoku,
Kawasaki, Kanagawa
215-0035
Japan
[phone] Tel
[phone] Fax
[e-mail]
Printed in China for Razor USA LLC.
Copyright © 2003-2021 Razor USA, LLC. All rights reserved. Razor® and the Razor logo design are among the registered trademarks of Razor USA LLC in the United States and/or select foreign countries. Power Core™ and the
Power Core E100 logo design are trademarks of Razor USA LLC.
US_210510

OWNER’S MANUAL
Read and understand this entire manual before allowing
child to use this product! For assistance contact Razor.
DO NOT RETURN TO STORE.
NOTE: Manual illustrations are for demonstration purposes only.
Illustrations may not reflect exact appearance of actual product.
Specifications subject to change without notice.
Please have your product along with the 19 character product I.D. code with you
before contacting Razor for warranty assistance and/or replacement parts.
Product I.D. Code: _____________ - ____________ - ____________
POWER CORE E100 SERIES
ELECTRIC HUB MOTOR SCOOTERS
NOTE: The unit must be traveling at least 3 mph (5 km/h) before motor will engage.
Kick to start to at least 3 mph (5 km/h) while applying the throttle to engage motor.

1
CONTENTS
Safety Warnings............................................................................................ 1
Before You Begin .......................................................................................... 2
Assembly and Set-Up................................................................................3-5
Charging the Battery ................................................................................... 5
Pre-Ride Checklist - Usage ......................................................................... 6
Repair and Maintenance........................................................................7-10
Troubleshooting Guide ............................................................................... 11
Power Core E100 Series Electric Scooter Parts.................................... 12
Warranty and Contact Information .....................................................13-14
SAFETY WARNINGS
WARNING: Riding an electric scooter does present potential risks
and caution is required. Like any riding product, an electric scooter has
inherent hazards associated with its use (for example, falling off or riding
it into a hazardous situation). Like any riding product, electric scooters
can and are intended to move and it is therefore, of course, possible to
lose control or otherwise get into dangerous situations. Both children,
and adults responsible for supervising them, must recognize that if such
things occur, a rider can be seriously injured or die even when using
safety equipment and other precautions. RIDE AT YOUR OWN RISK AND
USE COMMON SENSE.
WARNING: PARENTAL AND ADULT RESPONSIBILITY AND
SUPERVISION IS NECESSARY: Because products, like electric scooters,
can and do present potential hazards plainly associated with their
use, it is well recognized THE NEED FOR EXERCISE OF PARENTAL
RESPONSIBILITY IN SELECTING RIDING PRODUCTS APPROPRIATE TO
THE AGE OF A CHILD, OR PARENTAL SUPERVISION IN SITUATIONS IN
WHICH CHILDREN OF VARIOUS AGES MAY HAVE ACCESS TO THE SAME
RIDING PRODUCTS, IS IMPORTANT. Not every product is appropriate for
every age or size of child, and different age recommendations are found
within this category of product which are intended to reflect the nature
of the hazards and the expected mental or physical ability, or both, of a
child to cope with the hazards.
The recommended minimum rider age is 8 and older. Any rider unable
to fit comfortably on the scooter should not attempt to ride it. A parent’s
decision to allow his or her child to ride this product should be based on
the child’s maturity, skill and ability to follow rules.
Keep this product away from small children and remember that it is
intended for use only by persons who are, at a minimum, completely
comfortable and competent while operating the scooter.
Persons with any mental or physical conditions that may make them
susceptible to injury, impair their physical dexterity or mental capabilities
to recognize, understand, and follow safety instructions and to be able
to understand the hazards inherent in scooter use, should not use or
be permitted to use products inappropriate for their abilities. Persons
with heart conditions, head, back or neck ailments (or prior surgeries to
these areas of the body), or pregnant women, should be cautioned not to
operate such products.
DO NOT EXCEED THE WEIGHT LIMIT OF 120 lb (54 kg). Rider weight does
not necessarily mean a person’s size is appropriate to fit or maintain
control of the scooter.
CHECK AND MAINTAIN SCOOTER CONDITIONS
Before use, check to confirm that covers and guards are in place and in
serviceable condition. Check that the brake is functioning properly, that
the front tire is inflated properly and has sufficient tread remaining and
that the rear wheel is free of flat spots from wear. The scooter should
be maintained and repaired in accordance with the manufacturer’s
specifications, using only the manufacturer’s authorized replacement
parts, and should not be modified from the manufacturer’s original design
and configuration.
ACCEPTABLE RIDING PRACTICES AND CONDITIONS
Always check and obey any local laws or regulations which may affect
the locations where the electric scooter may be used. Keep safely away
from cars and motor vehicle traffic at all times. Only use where allowed
and with caution.
Do not activate the speed control on the hand grip unless you are on
the scooter and in a safe, outdoor environment suitable for riding. The
electric scooter must be moving at least 3 mph (5 km/h) before the motor
will engage.
The normal powered top speed of this scooter will be approximately
11 mph (18 km/h), which can be affected by conditions, such as rider
weight, inclines and battery charge level. Avoid excessive speeds that
can be associated with downhill rides.
Maintain a hold on the handlebars at all times. Do not touch the brake or
motor on your scooter when in use or immediately after riding, as these
parts can become very hot.
Ride defensively. Watch out for potential obstacles that could catch
your wheel or force you to swerve suddenly or lose control. Be careful
to avoid pedestrians, skaters, skateboards, scooters, bikes, children or
animals who may enter your path, and respect the rights and property of
others.
The electric scooter is intended for use on flat, dry surfaces, such as
pavement or level ground, without loose debris, such as sand, leaves,
rocks or gravel. Wet, slick, bumpy, uneven or rough surfaces may impair
traction and contribute to possible accidents. Do not ride your scooter in
mud, ice, puddles or water. Watch out for potential obstacles that could
catch your wheel or force you to swerve suddenly or lose control. Avoid
sharp bumps, drainage grates, and sudden surface changes.
Do not attempt or do stunts or tricks on your electric scooter. The
scooter is not made to withstand abuse from misuse, such as jumping,
curb grinding or any other type of stunts. Racing, stunt riding, or
other maneuvers also enhance risk of loss of control, or may cause
uncontrolled rider actions or reactions.
Never allow more than one person at a time to ride the scooter.
Do not ride at night or when visibility is limited.
Never use near steps or swimming pools.
Do not allow hands, feet, hair, body parts, clothing, or similar articles to
come in contact with moving parts or wheels while the motor is running.
Do not touch hot brake or electric motor when in use or immediately
after riding.
Never use headphones or a cell phone to talk or text when riding.
Never hitch a ride with a vehicle.
Do not ride your scooter in wet or icy weather and never immerse
the scooter in water, as the electrical and drive components could
be damaged by water or create other possibly unsafe conditions.
Never risk damaging surfaces, such as carpet or flooring, by use of an
electric scooter indoors.
PROPER RIDING ATTIRE
Always wear proper protective equipment, such as an approved safety
helmet (with chin strap securely buckled), elbow pads and kneepads.
A helmet may be legally required by local law or regulation in your
area. A long-sleeved shirt, long pants, and gloves are recommended.
Always wear athletic shoes (lace-up shoes with rubber soles) and
keep shoelaces tied and out of the way of the wheels, motor and drive
system. Never ride barefooted or in sandals.
USING THE CHARGER
The charger supplied with the electric scooter should be regularly
examined for damage to the cord, plug, enclosure and other parts. In
the event of such damage, the scooter must not be charged until the
charger has been repaired or replaced.
Use only with the recommended charger.
Use caution when charging.
The charger is not a toy. Charger should be operated by an adult.
Do not operate charger near flammable materials.
Unplug charger and disconnect from scooter when not in use.
Always disconnect from the charger prior to wiping down and cleaning
your scooter with damp cloth.
FAILURE TO USE COMMON SENSE AND HEED THE ABOVE WARNINGS
FURTHER INCREASES RISK OF SERIOUS INJURY. USE AT YOUR OWN
RISK AND WITH APPROPRIATE AND SERIOUS ATTENTION TO SAFE
OPERATION. USE CAUTION.
