RCA NT2 Series User manual

Installation Manual
Integrated with Sensor
LED Recessed Troffer
• For your safety, please read the「Safety Precautions」prior to installation.
Failure to follow the RCA installation manual and instructions could lead to product damage or serious physical injury.
WARNING
Safety precautions
Installation
3
Connect input conduit to access plate. Connect wires as shown in wiring diagram.
Push all wires back into the body. Re-install access plate.
(GREEN/YELLOW – Ground, WHITE – Neutral , BLACK – Live)
When the fixture is connected to the intended circuit, the installer must
use a UL approved wire connector having a flame retardence of UL94 V-0 or higher.
This installation manual is only valid for
the following RCA LED Recessed Troffer
integrated with sensor
T-Bar
Clip
Bend T-Bar clips out perpendicular to T-Bar. Place the RCA troffer into the T-Bar Ceiling panel.
Ensure T-Bar clips are attached to the T-Bar.
Remove access plate from junction box. Using screw driver blade, remove appropriate
knockout from access plate door to route input conduit.
1
Access Plate
[Wiring Diagram]
BLACK
WHITE
YELLOW-GND
GREEN /
2
2’ x 4’’2x’2
3350GDKM0306A (Rev.01)
• To avoid the risk of electrical shock, all electrical work must be performed as instructed in this installation manual by a licensed and qualified electrician.
• Prior to installation, please verify and confirm all electrical circuit breakers are properly operating and functional. Designated circuits and circuit
breakers should be turned OFF prior to installing the fixture.
• Prior to installation, please verify all electrical circuitry or wiring is properly operating and functional. Please confirm the correct circuit voltage
(120 V - 277 V) and polarity prior to installing fixtures.
• To avoid the risk of electrical shock, ensure that the fixture and electrical circuits are properly grounded prior to installation.
• Installation in areas experiencing casual water damage, flooding, or high humidity should be avoided.
This fixture is not suitable for underwater lighting purposes or water spray down applications.
• Do not install this fixture if defects are noticeable or the product has experienced damage during shipping or storage. Contact RCA Technical Support for
warranty coverage and assistance.
• Do not temporarily store nor permanently install this product near flammable objects or in areas with high risks of fire.
• Failure to install this fixture, in its entirety and as provided by RCA Lighting Solutions, may void the warranty. RCA is not responsible for fixtures that are
modified to be used in any other way than its intended purpose.
• Do not use or install if the fixture has been damaged due to dropping or prior electrical shock. Should the product owner or installer determine the
fixture is not operable, please contact RCA Technical Support for product and warranty assistance.
• During cleaning, please attempt to minimize the use of water, alcohol, benzene, or acetone in order to avoid the risk of electrical shock as well as
potential degradation of the fixture surfaces and lens.
• To prevent damage during ceiling installation, RCA recommends having at least (2) qualified electricians assisting with the installation.
• Operating temperature of the LED Troffer and Driver is to be maintained between -20 ℃~ 40 ℃(-4℉~104℉) to comply with all safety and
warranty regulation.
• Do not install where the product may be exposed to direct sunlight.
• Wear gloves to prevent cuts or abrasions when removing the product from carton, when handling, when installing, and when maintaining the product.
• Do not install nearby air conditioners and heating appliance.
• Avoid metal and reinforced concrete walls etc, between products if you want to use its wireless communication function.
• This product meets the electromagnetic wave standards specified by CE and FCC/IC, but it may malfunction in noisy RF environments.
(Example : Where strong RF transmit / receive devices or strong electromagnetic machines are used)
• This product has been manufactured and sold under the responsibility of DTI SERVICES LLC..
• RCA, the RCA logo and the two dogs (Nipper and Chipper) logo are trademarks used under license by DTI SERVICES LLC. – further information at www.rca-brand.com.
• All other products, services, companies, trademarks, trade or product names and logos referenced herein are the property of their respective owners.
Edges can cut. Handle with care.

Sensors information
- Turn the main power on and off 10 times in a row.
- Press "Task switch"on the sensor 10 times in a row.
• Factory reset
Motion sensor
Light sensor
Task switch
• Smart Multi Sensor with ZigBee Dongle
• Design
• Technical data
• Motion sensing area
8.2 ft (2.5 m)
11.5 ft (3.5 m)
H ft
H m
13.1 ft (4 m)
18.4 ft (5.6 m)
(1.6 x H) ft
(1.6 x H) m
16.4 ft (5 m)
23 ft (7 m)
(2 x H) ft
(2 x H) m
Height Shortside Long side
* Height : up to 11.5 ft (3.5 m)
(1.6 x H) m
(2 x H) m
• Field adjustable sensor values
(for stand-alone luminaire use only)
 CAUTION
: Make sure that the number of troffer reaction is same
with the number of times you pressed the button.
For further details, please consult sales representatives.
RCA SENSOR CONNECT is the stand-alone system that doesn't need any additional control devices except sensor-embedded troffers.
RCA SENSOR CONNECT
• Light sensing area
)
)
8.2 ft (2.5 m)
11.5 ft (3.5 m)
H ft
H m
H ft
H m
8.2 ft (2.5 m
11.5ft (3.5 m
RadiusHeight
* Height : up to 11.5 ft (3.5m)
W
I
N
D
O
W
Min. (0.5 x H) m
H m
80%
80%
0%
Enabled
Disabled
N/A
30:00 Minutes
HIGH
Motion sensor
Max L ight Level
Default Light Settings
Mid Light Level
Minimum Light Level
Motion
Daylight
Dim Down
Time Out
Sensitivity
Max
80%
60%
40%
100%
Dim Down
05:00 Minutes
15:00 Minutes
Task Switch # of Presses
Button Configuration
1
2
3
4
5
6
25:00 Minutes
7
Frequency
Wireless range
Operating conditions
Humidity
Installation height
Light sensing range
Passive Infrared(PIR) Sensor
2405.0 ~ 2480.0 MHz
Line of sight 98 ft (30 m)
1 ~ 1000 lx
For Indoor use only
0 to 85 % Rh
Up to 11.5 ft (3.5 m)
Mid
40%
40%
20%
40%
Time Out
05:00 Minutes
05:00 Minutes
05:00 Minutes
Min
0%
0%
0%
0%
Total
10:00 Minutes
20:00 Minutes
00:30 Minutes
800:30 Minutes 01:00 Minutes
30:00 Minutes
Default
5000K 4500K 4000K 3500K 3000K
Long Presses (5 seconds hold)
CCT
Rotation
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON FAMILLIAR WITH
THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED
Responsible Party :
RCA Lighting Solutions
5935 W. 84th Street, Suite A,
Indianapolis, In 46278
www.rcaled.com
Phone. [phone]
FCC Notice :
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that may cause undesired operation of the device.
Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
FCC RF Radiation Exposure Statement :
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
This equipment should be installed and operated with a minimum distance of 20 cm (7.8 inches) between the
antenna and your body.Users must follow the specific operating instructions for satisfying RF exposure compliance.
Contains FCC ID : TGEACM20ZEA1
10 Factory Reset
9 (Night-light / EM Driver Mode) 100% 40% 20%
