Your Two-Way Bookshelf Speaker is small

in size, but not in sound! Its 5-inch cone

woofer with patented honeycomb material

between two layers of woven fiberglass

provides superior rigidity for outstanding

bass performance with minimal

distortion. The wide-angle Lineaum

dipole tweeter produces crisp, detailed

highs with 360°dispersion.

Your speaker's acoustic design matches

the woofer and tweeter with the enclosure

and damping materials to provide

amazingly smooth and broad frequency

response. Your speaker can handle up to

150 watts of power.

The speaker is magnetically shielded, so

you can safely place it next to your

television or monitor.

R P

Location and position are vital to your

speaker's performance. The ideal location

is on a table or shelf positioned near the

corner of a room. A shelf attached to a

wooden wall (or some other acoustically-

sound hard surface) greatly reinforces the

speaker's sound quality. If possible, place

the front edge of the speaker flush with

the front edge of the shelf. For the best

sound, avoid floor locations; floor

coverings can absorb much of the sound.

We recommend that you play a familiar,

wide-range recording and experiment

with speaker placement until you find the

location that provides the best sound.

If you are using another speaker with this

one, for the best stereo sound, the

distance between your speakers should be

about equal to the distance from the main

listening area to a point halfway between

the speakers. If you must place your

speakers farther apart, turn them slightly

inward.

You can mount your speaker on a wall, on

a ceiling or under a shelf using optional

speaker brackets (not supplied) or a

3/8-inch wall-mount speaker bracket (not

supplied), both available at your local

RadioShack store. Follow the instructions

provided with the brackets.

::: When you

use a 3/8-inch wall-

mount bracket,

remove the screw

on the back panel

of the speaker so

you can thread the

ball shaft. For any

other type of

mounting bracket,

use the four mounting holes (indicated by

the arrows) and leave the screw in place.

ATT

TTTT

TTA

ING

NGNG

NG T

E R

Rubber feet are supplied with your speaker

so it will not scratch your furniture. Make

sure you apply the thicker feet to the

speaker’s front corners if you want the

speaker to point up or to the back corners if

you want it to point down. Remove the

paper backing and press all four feet onto

the bottom of the speaker.

ONN

NNNN

NNE

With the speaker placed at the desired

location, measure the distance from the

speaker to the amplifier. Use 18-gauge

speaker wire for a distance of 50 feet or less.

For a distance greater than 50 feet, use

heavier 16-gauge wire.

::: For the maximum bass response and

overall best performance, connect speakers

in phase — positive to positive (+ to +) and

negative to negative (– to –).

Speaker wire is either color-coded, with a

different color on each wire, or coded with a

ridge or stripe on one wire to differentiate it

from the other, making the connection

easier. Your local RadioShack store carries a

wide selection of speaker wire.

Follow these steps to prepare the wire and

connect the speaker.

1. Separate the wire conductors for a

length of about 2 inches, then remove

about 1/2inch of insulation from each

wire's end using a wire stripper.

2. Turn the speaker's negative (–) terminal

counterclockwise to loosen it, then

insert one of the wire ends into the

opening. Turn the terminal clockwise to

tighten it.

3. Turn the speaker's positive (+) terminal

counterclockwise to loosen it, then

insert the other wire end into the

opening. Turn the terminal clockwise to

tighten it.

4. Using the speaker wire's coding as a

guide, connect the other end of the

speaker wire to the amplifier's

corresponding (+ or –) speaker

terminals.

1/2inch

2 inches

G T

E F

T A

AND

NDND

P G

To remove the front or top grille, grasp the

grille’s edges and gently pull it away from

the cabinet.

Your Two-Way Bookshelf Speaker is an

example of superior design and

craftsmanship. The following suggestions

will help you care for your speaker so you

can enjoy it for years.

Keep the speaker dry; if it gets wet, wipe it

dry immediately. Use and store the speaker

only in normal temperature environments.

Handle the speaker carefully; do not drop it.

Keep the speaker away from dust and dirt,

and wipe it with a damp cloth occasionally

to keep it looking new.

Modifying or tampering with the speaker’s

internal components can cause a

malfunction and might invalidate its

warranty. If your speaker is not performing

as it should, take it to your local RadioShack

store for assistance.

iiio

::: You might permanently damage

your speakers by cleaning them with a

vacuum cleaner. Use a feather duster or a

soft loose cloth instead.

HOO

OOOO

OOT

ING

NGNG

This speaker has been manufactured to the

specifications of RadioShack and is covered

by a limited warranty from RadioShack. If

your speaker is not operating as it should,

take it to your local RadioShack store or call

1-800-THE-SHACK for assistance.

RadioShack Corporation

Fort Worth, Texas 76102

40-5037

05A01 Printed in Malaysia

Frequency Response ........................................................................................ 80–25,000 Hz

±10 dB

Power Handling ............................................................................................ 75 Watts (RMS)

Maximum Power .................................................................................................... 150 Watts

Impedance ............................................................................................... 8 Ohms (Nominal)

Speaker Complement ........................ 5-Inch Cone Woofer made with KEVLAR brand fiber

and 2 ×4-Inch Linaeum Dipole Tweeter

Dimensions (HWD) w/Front Grille .................................................. 105/8× 61/4×77/8Inches

(27 ×16 ×20 cm)

Weight.......................................................................................................................7 1b 8 oz

(3.4 kg)

Specifications are typical; individual units might vary. Specifications are subject to change and

improvement without notice.

KEVLARis a registered trademark of E. I. du Pont de Nemours and Company.

Limited Five-Year Warranty

This product is warranted by RadioShack against manufacturing defects in material and workmanship under normal use for

five (5) years from the date of purchase from RadioShack company-owned stores and authorized RadioShack franchisees

and dealers. EXCEPT AS PROVIDED HEREIN, RadioShack MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED

WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIM-

ITED IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED HEREIN. EXCEPT AS

PROVIDED HEREIN, RadioShack SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO CUSTOMER OR ANY OTHER

PERSON OR ENTITY WITH RESPECT TO ANY LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY

USE OR PERFORMANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUDING,

BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM INCONVENIENCE, LOSS OF TIME, DATA, PROPERTY, REV-

ENUE, OR PROFIT OR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, EVEN IF RadioShack

HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or conse-

quential damages, so the above limitations or exclusions may not apply to you.

In the event of a product defect during the warranty period, take the product and the RadioShack sales receipt as proof of pur-

chase date to any RadioShack store. RadioShack will, at its option, unless otherwise provided by law: (a) correct the defect

by product repair without charge for parts and labor; (b) replace the product with one of the same or similar design; or (c) re-

fund the purchase price. All replaced parts and products, and products on which a refund is made, become the property of

RadioShack. New or reconditioned parts and products may be used in the performance of warranty service. Repaired or re-

placed parts and products are warranted for the remainder of the original warranty period. You will be charged for repair or re-

placement of the product made after the expiration of the warranty period.

This warranty does not cover: (a) damage or failure caused by or attributable to acts of God, abuse, accident, misuse, im-

proper or abnormal usage, failure to follow instructions, improper installation or maintenance, alteration, lightning or other in-

cidence of excess voltage or current; (b) any repairs other than those provided by a RadioShack Authorized Service Facility;

(c) consumables such as fuses or batteries; (d) cosmetic damage; (e) transportation, shipping or insurance costs; or (f) costs

of product removal, installation, set-up service adjustment or reinstallation.

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

RadioShack Customer Relations, 200 Taylor Street, 6th Floor, Fort Worth, TX 76102

We Service What We Sell

12/99
