RCB KE-CD 1000 Specification sheet

Conductivity / TDS
Controller
KE –CD 1000 PIM - R0
© 2020 RCB Chemicals & Services. All rights Reserved
PRODUCT INSTRUCTION MANUAL

KE-CD 1000 Process Controller
Essential Instructions
READ THIS BEFORE USING KE-CD 1000(CONTROLLER)
Thank you for choosing the KE-CD 1000 controller.
KE-CD 1000 is a microprocessor-based controller used to analyze and control Conductivity or
TDS parameter in various water application. KE-CD 1000 provides set point values and relay for
High Low signal.
This manual explains the use of KE-CD 1000 controller. This instruction manual is written to
cover as many anticipated applications of controller. The information presented in this manual
is subject to change without notice as improvements are made. Inform and educate your
personnel in the proper installation, operation, and maintenance of the product. To ensure
proper performance make sure that proper personnel operates, maintains and update the
product. When replacement parts are required, ensure that qualified personnel use
replacement parts specified by RCB Chemicals representative or call at provided number for
assistance. Unauthorized parts and procedures can affect the product’s performance and place
the safe operation of the process at risk.
Refer installation ,operation and servicing to qualified personnel. Making cable connections to
controller and servicing this instrument requires access to shock hazard level voltages which
can cause death or serious injuries ,therefore disconnect all hazardous voltage before accessing
the electronics. Relay contacts made to separate power sources must be disconnected before
servicing. For safety and proper performance this instrument must be connected to a properly
grounded three-wire power source.
RCB Chemicals & Services does not accept any responsibility for damage or malfunctioning of
the unit due to improper usage and maintenance of the instrument.
KE-CD 1000 controller comes with a 3-Years limited warranty. Kindly make sure to read the
Warranty Terms & Conditions enclosed in the box.
KE –CD 1000 PIM - R0
© 2020 RCB Chemicals & Services. All rights Reserved

Table of Contents
Section : 1 Introduction
1.1 General ...................................................................................................... 1
1.2 Features ..................................................................................................... 1
1.3Specifications ............................................................................................. 2
1.4Applications ............................................................................................... 3
Section : 2 Controller Mounting
2.1 Panel Mounting .......................................................................................... 3
Section : 3 Sensor Mounting
3.1 General Guidelines ..................................................................................... 4
Section : 4 Controller Electrical Connections
4.1 General Guidelines ..................................................................................... 4
4.2 Power ........................................................................................................ 4
4.3 Sensor Electrode ........................................................................................ 5
4.4 PLC / Autologger Connection ..................................................................... 6
4.5 Relay HI /LO Connection ............................................................................. 6
Section : 5 Keypad Function
5.1 General Guidelines ..................................................................................... 7
Section : 6 LCD Display
6.1 General Guidelines ..................................................................................... 8
Section : 7 Initial Setup
7.1 Startup ....................................................................................................... 9
7.2 Menu Tree ................................................................................................. 9
Section : 8 Sequential Functions Setup
8.1 Main Menu ............................................................................................... 10
8.1.1 Settings................................................................................................ 10
ADisplay Setting .............................................................................. 10

Table of Contents
A.1 Backlight ON/OFF .................................................................. 10
A.2 Contrast ................................................................................ 11
BLoop Current ................................................................................ 11
B.1Conductivity ..................................................................... 11, 12
B.2Temperature ......................................................................... 12
C Clock Setting ................................................................................. 12
C.1Time ...................................................................................... 13
C.2Date ...................................................................................... 13
D Units ............................................................................................ 14
8.1.2Calibration ............................................................................................ 14
ACond. / TDS ................................................................................... 14
A.1Cell Constant ..................................................................... 14, 15
A.2 Calibration ............................................................................. 15
BTemperature ................................................................................. 15
B.1Status (MTC / ATC) ................................................................. 16
B.2Temperature Setting .............................................................. 16
b.1Set Temperature ............................................................ 16
b.2Temperature Coefficient ................................................. 17
8.1.3Relays Output ....................................................................................... 18
ARelay 1 LO .................................................................................... 18
BRelay 2 HI ..................................................................................... 19
8.1.4 Others .................................................................................................. 19
ACh. Password ................................................................................ 20
BTDS Factor .................................................................................... 20
C Reset ............................................................................................ 21
DLogger Data .................................................................................. 21

Table of Contents
Section : 9 Troubleshooting
9.1 General Guidelines.................................................................................... 22
9.2 Troubleshooting Chart............................................................................... 22
Section : 10 Maintenance
10.1 General Guidelines.................................................................................... 23
10.2 Maintenance Parts.................................................................................... 23
10.3 Panel Mounting Parts................................................................................ 23
10.4 Field Mounting Parts................................................................................. 23
Section : 11 Technical Drawings
11.1 Controller Dimensions .............................................................................. 24
11.2 Exploded View.......................................................................................... 25

1 / 25
Section : 1 Introduction
1.1 General
KE-CD 1000 is a microprocessor-based controller used to analyze and control Conductivity or
TDS parameter in various water application. KE-CD 1000 provides set point values and relay for
High Low signal. KE-CD 1000 is simple to control through its 6-buttons control panel.
The backlit LCD contrast can be adjusted to user requirement. Provided logging function can
save instant parameter values with respect to time.
Inspect the exterior of the shipping package for any damage. Open the package and inspect the
controller and related hardware for missing or damaged parts.
If there is evidence of damage, notify the carrier immediately. If parts are missing, contact RCB
Chemicals & Services customer support representative.
How to enter password?
KE-CD 1000 controller contains built in 4-digit password feature which can be customized as
per user selection. Press upward and downward button to change the value of digit from 0-9.
Press forward button for next digit. Press enter button to enter the password.
Default password is 0000 for KE-CD 1000 controller.
1.2 Features
KE-CD 1000 controller is designed to be a fully isolated instrument for two-wire DC
applications.
-Automatic and manual temperature compensation via RTD Pt1000.
-Instrument supplied in durable (IP65) enclosure. (when installed in control panel)
-Built-in internal Time, Date and Logger function.
-Built-in programmable high low relay function.
-High end encapsulated electronic components for humid and harsh environments.
-Usually no calibration is required but 1 point calibration through any NIST or TCT
standard buffers can be done if required through buffer solution.
-4 ~ 20 mA customizable analogue loop current outputs for plant operation.
-Quick connection with sensors through connectors. (require tinned wires sensor)
-Built in password protection for safety of instrument and process.

2 / 25
1.3 Specifications
Measuring Range
(Conductivity)
0.00 μS/cm - 10.00 S/cm, 0.01 μS/cm resolution, +/- 0.5%
accuracy
Measuring Range
(TDS)
0.00 - 10000 PPT, 0.01 PPM resolution, +/- 0.5% accuracy
Measuring Range
(Temperature)
0.0-200.0C, 0.1C resolution, linear coefficient
+/- 1.0C accuracy
Clock
Internal Clock, 24 Hr format, +/- 1 min / month accuracy
Logger
Internal Logger can save up to 60 conductivity & temperature
values with respective time & date
Calibration Mode
Usually no calibration is required but 1 point calibration through
any NIST or TCT standard buffers can be done if required
Analog Output 1
4-20mA corresponding to conductivity, +/- 0.1mA accuracy,
0.1mA resolution, maximum load 500Ω
Analog Output 2
4-20mA corresponding to temperature, +/- 0.1mA accuracy,
0.1mA resolution, maximum load 500Ω (will be added on request)
Cell Constants
0.01 –20 /cm fixed, 0.001 –19.99 /cm freely selectable (user
defined)
Relays
1 (HI) –200 VDC, 0.5A –On/Off Programmable
2 (LO) –200 VDC, 0.5A –On/Off Programmable
Display
Large graphical LCD (128 x 64) with adjustable contrast and
adjustable backlight
Dimensions (Volume
Based)
L x W x D (113mm x 113mm x 60mm)
Mounting Type
Panel Mount
Panel Cutout Size
L x W (93mm x 93mm)
Temperature
Rectification
2-wire & 3-wire RTD Pt1000 auto/manual
Power Requirement
+16 - 24 VDC (Maximum up to 35 VDC)
Weight (Assembly)
≈ 230 Grams
Encapsulation
Electronic circuit can be encapsulated with epoxy
coating to work in corrosive environment on user request
IP Class Protection
IP 65 (In panel mount installation)
Interface Protection
Built in user interface protection (4-digit customizable password)

3 / 25
1.4 Applications
KE-CD 1000 Controller can be used in different industrial applications as mentioned below:
•REVERSE OSMOSIS
•BOILER WATER
•COOLING WATER
•CLOSED LOOP SYSTEM
•DRINKING WATER
•TEXTILES CHEMICALS
•WASTE WATER
Section : 2 Controller Mounting
2.1 Panel Mounting
KE-CD 1000 Controller can be mounted on control panel plate for different industrial
applications as mentioned in below images along with panel cutout dimensions (mm). Panel
cutout sticker is also provided in package for reference cutting.

4 / 25
Section : 3 Sensor Mounting
3.1 General Guidelines
Select a location within the maximum sensor cable length (05 Mtr) for mounting of the sensor.
Sensor to be installed Inline to piping where the pipeline stay filled with the working fluid
(water) whether in operation or not. If there is more than 05 Mtr distance from the electrode
to the controller, purchase an offline sensor housing (available on demand) for measuring
conductivity or use an amplified conductivity sensor. Locate sensor away from pumps,
frequency drive systems or other sources of high frequency.
Refer to the installation manual of conductivity controller for sensor installation and
maintenance. RCB can provide industrial grade sensor KE-CDS 1000 series for industrial
standard applications which is recommended with KE-CD 1000 controller for efficient results
and little to no maintenance.
Section : 4 Controller Electrical Connections
4.1 General Guidelines
KE-CD 1000 controller requires a regulated 16 - 24 VDC connection from an external supply
(not provided) to work properly.
WARNING: Don’t connect AC power cables to the KE-CD 1000 controller.
Important Notes:
•All electrical installations must be supervised by a qualified and responsible electrician.
•Use wiring practices that conform to all national, international and local electrical codes.
•Don’t put sensor cables or instrument 4-20 mA output wires in the same conduit that
contains AC power wires. AC power wires require a separate conduit to prevent electrical
noise from interfering with the instrumentation signals.
4.2 Power
A 16 - 24 VDC power supply (max. 35 VDC) must be used to power the KE-CD 1000 controller.
The exact connection of this power supply is shown in the given image in this section. Always
separate input DC power from high power sources, frequency drives, motors, or other electrical
signal wires, which may contribute noise to a system and cause disturbance in reading.
KE- CD 1000 controller has the power polarity protection which means if +ve power supply is
connected to -ve connection of controller, it will not cause any malfunctioning of controller
however it will not power on the Controller. Make sure input DC power is stable, noise free and
non-fluctuating.

5 / 25
4.3 Sensor Electrode
The sensor electrode cable can be connected to the KE-CD 1000 controller terminal strip by
matching the wire colors on the cable conductors. Route the signal cable away from AC power
wires, frequency drives, motors, or other electrical signal wires. Do not put sensor or signal
cables in conduit that contains AC power cables and motor cables.
Note: Terminal blocks are labeled on Controller back part.
KE-CDS 1000 Series Sensor
KE-CD 1000 Controller
Connections Layout
Image above shows the wiring connection names for RCB conductivity sensor KE-CDS 1000
series and RCB conductivity controller KE-CD 1000. Each sensor wire connection detail is given
below:
1- For 2 wire temperature sensor, short T/P4 and T/P3. Connect TEMP Wire 1 (Red) with
T/P 1 and TEMP Wire 2 (Yellow) with T/P 2.
2- Connect DD Wire 3 (Blue) with CN3 connection of Controller and Short CN3 with CN4.
3- Connect DD Wire 4 (Green) with CN2 connection of Controller and Short CN2 with CN1.
4- GND Wire 5 (Black) can be used if required.
Note: For 3 wire temperature sensor, use T/P1, T/P3, T/P4 and leave T/P2 unconnected while
other connections will be same as mentioned above
POWER SUPPLY (V+)
POWER SUPPLY (V-)
CONDUCTIVITY CONTROLLER BACKSIDE

6 / 25
4.4 PLC / Autologger Connection
Two (PLC / Autologger) cables can be connected to the KE-CD 1000 controller terminal strip by inserting the wires in
4 ~ 20mA connections. (Marked in Red and Blue)
•One connection can be used for Conductivity / TDS function. Connect top (red marked connection) with positive
terminal and bottom (red marked connection) with negative terminal.
•Second connection can be used for Temperature function. Connect top (blue marked connection) with positive
terminal and bottom (blue marked connection) with negative terminal.
4.5 Relay HI / LO Connection
Two (Relay lo, Relay hi) cables can be connected to the KE-CD 1000 controller terminal strip by inserting the wires in
RELAY HI, RELAY LO connections. (Marked in Yellow and Purple)
•One connection can be used for High relay function. Connect top (yellow marked connections) with RELAY HI
terminals. Relay HI will turn on when cond. / TDS value goes above the input value (see section: 8.1.3).
•Second connection can be used for Low relay function. Connect bottom (purple marked connections) with
RELAY LO terminals. Relay LO will turn on when cond. / TDS value goes below the input value (see section: 8.1.3).
RIGHT CONNECTOR
RIGHT CONNECTOR

7 / 25
Section : 5 Keypad Function
5.1 General Guidelines
KE-CD 1000 is simple to control through its 6-buttons control panel. Figure below shows
individual keypad buttons with their respective functions:
UPWARD / TOP
DOWNWARD / BOTTOM
FORWARD / RIGHT
MENU
ENTER / ACCEPT
ESCAPE / CANCEL / EXIT
UPWARD / TOP
DOWNWARD / BOTTOM
FORWARD / RIGHT
MENU
ENTER / ACCEPT
ESCAPE / CANCEL / EXIT

8 / 25
Section : 6 LCD Display
6.1 General Guidelines
KE-CD 1000 controller is easy and clear to view through its large graphical LCD (128 x 64) with
adjustable contrast and adjustable backlight. Figure below shows the display icons with their
respective description:
MAIN DISPLAY INDICATING CONDUCTIVITY / TDS
VALUE WITH USER SELECTABLE UNITS
TEMPERATURE DISPLAY WITH CELSIUS UNITS &
UPTO TWO DECIMALS
TEMPERATURE COMPENSATION MODE DISPLAY
(MANUAL MODE MTC / AUTOMATIC MODE ATC)
TIME DISPLAY (24H FORMAT)
HOURS : MINUTES
DATE DISPLAY (GREGORIAN SHORT FORMAT)
DAY / MONTH / YEAR
RELAY LOW STATUS DISPLAY (ON / OFF)
RELAY HIGH STATUS DISPLAY (ON / OFF)
RELAY LO
ON/OFF
RELAY HI
ON/OFF
MINUTES
HOURS
DAY
MONTH
YEAR
TEMP.
COMPENSATION
TEMP. VALUE
CONDUCTIVITY / TDS VALUE
CONDUCTIVITY
/ TDS UNITS

9 / 25
Section : 7 Initial Setup
7.1 Startup
Before performing conductivity and temperature calibration, some prerequisites are
necessary. Firstly, ensure the sensor is connected to the KE- CD 1000 controller. Always use
fresh buffer solutions. Check expiration date on buffer bottles. If possible, use deionized water
to wash sensor electrode before calibration and between buffers. Calibration should be done
when using KE-CD 1000 controller with a new electrode for the first time or when feel that the
controller/electrode is out of calibration.
Make sure the temperature sensor wires are connected as shown in section 4.3 if no
temperature sensor is connected, the controller will go to MTC mode and it will print user
defined temperature value from temperature settings (see section: 8.1.2). As temperature
readings effect the accuracy of conductivity measurements, controller supports RTD PT 1000
temperature probe (KE-CDS 1000 series contain built in RTD PT 1000). If the conductivity
sensor doesn’t have any RTD PT 1000, then insert liquid temperature manually in temperature
settings at MTC mode (see section: 8.1.2). If ATC mode is selected, controller measures
temperature automatically from available RTD PT 1000. Conductivity value is compensated
automatically to a reference temperature at 25 C. Once temperature measurement is carried
out, conductivity calibration needs to be performed to ensure accuracy and reliability of
measurements.
7.2 Menu Tree
Before performing any operation on controller, kindly see the below sequential tree chart for
quick access Menu. For detailed information on sub menus kindly refer to (section: 8).

10 / 25
Section : 8 Sequential Functions Setup
8.1 Main Menu
KE-CD 1000 controller has an interactive main menu
which has four sub menus and their corresponding
Minor Sub Menus.
Menu Button Insert Password.
Default password is 0000 (See section: 1.1)
Main Menu will appear on the Screen. Main Menu has
four sub menus as Settings, Calibration, Relays
Output and Others.
8.1.1 Settings
User can define own interface from this sub menu.
Menu Button Insert Password Downward
Button Settings
Settings can be selected. Settings has four minor sub
menus as Display Setting, Loop Current, Clock Setting
and Units.
A Display Setting
User can define customized display interface from
this Setting.
Menu Button Insert Password Downward
Button Enter Button Settings
Display setting will appear and can be selected.
Display setting has two options as Backlight
(ON/OFF) and Contrast.
A.1 Backlight (ON/OFF)
User can define backlight display interface from this
Setting.
Menu Button Insert Password Downward
Button Settings Enter Button
Downward Button Display Setting Enter
Button Downward Button Backlight
Enter Button
Backlight can be either set to ON/OFF. Enter Button
will change the Backlight to ON/OFF.

11 / 25
A.2 Contrast
User can define display contrast from this setting.
Menu Button Insert Password Downward
Button Enter Button Settings
Downward Button Display Setting Enter
Button Downward Button Contrast
Enter Button
Contrast can be set by pressing forward button.
Default contrast for controller is 35%.
B Loop Current
User can define initial and final set point values for
respective Conductivity / TDS and Temperature
using loop current. Controller offers isolated Loop
currents with range from 4 ~ 20mA. This isolated
loop current has an accuracy of 0.01mA which
makes this controller accurate in measurements and
control.
Menu Button Insert Password Downward
Button Settings Enter Button Downward Button Loop Current Enter Button
Loop current will appear and can be selected.
Note: Press forward button for 3 secs on main screen to view the loop current for conductivity
and temperature.
B.1 Conductivity
User can define initial and final set point values for respective
Conductivity / TDS.
Menu Button Insert Password Downward Button
Enter Button Settings Downward Button Loop
Current Enter Button Downward Button
Conductivity Enter Button
Loop current for conductivity has two sub menus as 4mA and
20mA.
4mA set point value contains two inputs. First is the Value of
Conductivity / TDS which can be feed by pressing enter after
selection of value tab. Press upward and downward button
for increment and decrement in main value 1st digit by 1,
press forward button for increment in main value 2nd digit
by 1. If the value goes in 3 digits than forward button will
increase the 2nd and 3rd digit value by 1. If the value is larger
than 500 its recommended to come backward from 999 value
by pressing downward button.

12 / 25
Press menu button for increment in decimal values by 0.01.
The value can be selected to
Maximum 999.99. Second is
the Factor which is used for
setting the value above
999.99. Factor can be put as 1
or 10 by pressing enter after
selection of factor tab.
Example: If required to set the value of conductivity to 8555 μS/cm. Firstly check the units if
they are set to μS/cm, next set the value to 855.5 from set value and set factor to 10. This will
make set point value as 855.5 x 10 = 8555 μS/cm. Press enter to save and escape to return
for set value again. Press escape again for main screen.
Follow the same procedure for 20 mA option.
B.2 Temperature
User can define initial and final set point values for
Temperature.
Menu Button Insert Password Downward Button
Settings Enter Button Downward Button Loop
Current Enter Button Downward Button
Temperature Enter Button
Loop current for temperature has two sub menus as 4mA and
20mA.
mA set point value contains only one input. Upward and
downward button for increment and decrement in main value
by 1, press forward button and menu button for increment and
decrement of decimal digit by 0.1. If the value goes larger than
100 its recommended to come backward from
200 value by pressing downward button. Press enter to save
and escape to return for main screen.
Follow the same procedure for 20 mA option.
C Clock Setting
Controller contains the feature of displaying date
and time on its main display. Customized date and
time can be set from this setting.
Menu Button Insert Password Downward
Button Settings Enter Button Downward
Button Clock Setting Enter Button
Clock Setting contains Time and Date settings.

13 / 25
C.1 Time
User can define customized time from this setting.
Menu Button Insert Password Downward
Button Settings Enter Button Downward
Button Clock Setting Enter Button
Downward Button Time Enter Button
Press enter to edit time. Use upward and downward
button to increment or decrement hour and minute
by 1 unit. Use forward button to switch between
hour and minute. Press enter to save the
time and escape for main screen.
C.2 Date
User can define customized date from this setting.
Menu Button Insert Password Downward
Button Settings Enter Button Downward
Button Clock Setting Enter Button
Downward Button Date Enter Button
Press enter to edit date.
Use upward and downward button for day, month and year increment or decrement. Use
forward button to change between day, month and year. Press enter to save the date and
escape for main screen.

14 / 25
D Units
User can define
customized units from
this setting.
Menu Button Insert
Password Downward
Button Settings
Enter Button
Downward Button Units Enter Button Units Setting
Controller has the option of displaying both conductivity or TDS units. Microsiemens / cm
(μS/cm) , Millisiemens / cm (mS/cm) to be used for conductivity values and Parts per Million
(PPM), Parts per Thousand (PPT) to be used for Total Dissolved Solids (TDS) values.
8.1.2 Calibration
User can calibrate the conductivity and temperature
values from this setting.
Menu Button Insert Password Downward
Button Calibration
Calibration consists of two sub menus as
conductivity / TDS and temperature.
A Cond / TDS
Conductivity / TDS calibration can be done from this
sub menu.
Menu Button Insert Password Downward
Button Calibration Enter Button
Downward Button Cond. / TDS
Cond / TDS consists of two minor sub menus, cell
constant and calibration.
A.1 Cell Constant
Entering the conductivity sensor’s cell constant is the
first thing to do when performing conductivity / TDS
calibration.
Menu Button Insert Password Downward
Button Calibration Enter Button
Downward Button Cond/TDS Enter Button
Downward Button Cell Constant Enter Button
Cell constant value requires to be entered initially when conductivity sensor is connected to
the controller.

15 / 25
For CDS 1000 series sensor, kindly see the data
sheet KE-CDS 1000 Series TDS-R0 for cell
constant values (k-value) enclosed in the
conductivity sensor package. Cell constant values
can be inserted ranging from 0 to 20. Press
upward and downward button for increment and
decrement in main digits by 1. Press forward
button for increment of 0.1 and menu button for
increment of 0.01. Press enter to save the value and escape for main screen. It is not required
to feed cell constant value every time while performing calibration. Controller will
automatically calibrate the cell constant Value.
A.2 Calibration
Entering the conductivity value of buffer solution is the next
thing to do while performing conductivity / TDS calibration.
Menu Button Insert Password Downward Button
Calibration Enter Button Downward Button
Cond/TDS Enter Button Downward Button
Calibration Enter Button
Insert the conductivity buffer value in the display box. Press
upward or forward and downward button for Increment and
Decrement of 1st digit by 1 up to three digits. Press forward
button for increment of 3rd digit by 1. upward and downward
button will increase and decrease first two digits together by
1. For four-digit values it is recommended to reverse from
(0.00). Upward and downward button will increase and
decrease first two digits together by 1. Forward button will increase 3rd and 4th digit together
by 1. Pressing menu button will increase the decimal values (.00) by 1. Press enter to save the
value. Controller will calibrate the actual conductivity value using user fed cell constant and
user fed conductivity value. Let this value to be stable for min. 60 secs. Controller will display
the new cell constant value and calibration is completed.
B Temperature
Controller allows user to compensate the
conductivity value with the temperature as
conductivity value has a direct relationship with
Temperature.
Menu Button Insert Password Downward
Button Calibration Enter Button
Downward Button Temperature
Temperature consists of two minor menus, status
MTC / ATC and temp. setting.
