RDL EZ-VM14 User manual

INSTALLATION AND
OPERATION MANUAL
RDL EZ Series products provide the highest level of value to A/V professionals and A/V users who demand professional quality.
For long-term performance, quality and value, you have made the EZ choice. EZ products are made in the USA by RDL, the
inventor of application-specific modules bringing decades of experience as the world’s leading manufacturer of high-reliability
performance products to the A/V industry. Visit the RDL website for hundreds of professional A/V products made in the USA by RDL.
RDL•659 N. 6th Street •Prescott, AZ •USA 86301 •Sales: 800-281-2683 •928-443-9391
Tech Support: 800-933-1780 •928-778-3554 •RDL Europe Sales & Support: (31) 20-6238-983
www.rdlnet.com
Decades of Performance, Quality and Value
EZ-VM14
VGA/XGA Distribution Amplifier
Model numbers:
EZ-VM14 includes power supply with North American plug
EZ-VM14X includes worldwide power supply (specify plug)
INSTALLATION AND
OPERATION MANUAL
RDL EZ Series products provide the highest level of value to A/V professionals and A/V users who demand professional quality.
For long-term performance, quality and value, you have made the EZ choice. EZ products are made in the USA by RDL, the
inventor of application-specific modules bringing decades of experience as the world’s leading manufacturer of high-reliability
performance products to the A/V industry. Visit the RDL website for hundreds of professional A/V products made in the USA by RDL.
RDL•659 N. 6th Street •Prescott, AZ •USA 86301 •Sales: 800-281-2683 •928-443-9391
Tech Support: 800-933-1780 •928-778-3554 •RDL Europe Sales & Support: (31) 20-6238-983
www.rdlnet.com
Decades of Performance, Quality and Value

www.rdlnet.com • ••www.rdlez.com
•
•
•
•
•
•
•
Input and Four Outputs on HD15 Female Connectors
Wide RGB Bandwidth > 360 MHz Loaded
High Resolution Compatibility VGA through QXGA
Reliable Full-Size Front-Panel Switch for ID Bit Selection
NORM ID BIT Connects LOCAL MONITOR and INPUT ID
DC RGB Coupling, Output Polarity & Offset Follow Input
HD15 Input Cable Included - 36¨, 91.44 cm long
EZ-VM14
VGA/XGA Distribution Amplifier
TYPICAL APPLICATION
The EZ-VM14 is a high-resolution computer video distribution amplifier with four outputs. The input has an associated front-panel
BIT ID switch to assure compatibility with various computers. The four outputs are driven by video line amplifiers that provide
flat, wideband response. The EZ-VM14 is used in houses of worship, restaurants, clubs, meeting rooms, class rooms, conference
rooms, stores and in commercial A/V systems.
Computer
Monitors
EZ-VM14
www.rdlnet.com • ••www.rdlez.com

POWER CONNECTION FIXED MOUNTING RUBBER FEET ATTACHMENT
Insert Power Plug
Bottom View
of chassis
Recess
Screw
directly to flat
surface without
installing rubber feet.
Rotate 1/4-turn
clockwise to lock
Rotate 1/4-turn
counter-clockwise
to unlock Peel backing and stick the 4 rubber
feet to chassis in recesses provided.
24 VDC POWER INPUT
Insert plug from power
supply. Rotate 1/4 turn
clockwise to lock.
MONITOR OUTPUTS
Connect to the video inputs of
1, 2 or 3 monitors or projectors.
VIDEO INPUT
Connect the video source to the INPUT jack.
ID BIT
Set to NORM OFF position (button OUT) unless computer video
output fails to operate with the connected monitors; set switch
to ON position (button IN) if needed to activate computer video
monitor output (not typically required unless using certain laptops).
LOCAL MONITOR OUTPUT
Connect the LOCAL MONITOR output to the input
of the local computer video monitor (if used) or
to the video input of any monitor or projector.
POWER INDICATOR
Glows blue when the
product is connected to
a valid power source.
FOR BEST PICTURE QUALITY, REMOTE VIDEO MONITOR “OPTIMIZATION” FUNCTION SHOULD BE RUN, IF PROVIDED.
POWER CONNECTION FIXED MOUNTING RUBBER FEET ATTACHMENT
Insert Power Plug
Bottom View
of chassis
Recess
Screw
directly to flat
surface without
installing rubber feet.
Rotate 1/4-turn
clockwise to lock.
Rotate 1/4-turn
counter-clockwise
to unlock. Peel backing and stick the 4 rubber
feet to chassis in recesses provided.

EZ-RA6
EZ-CC6
SELECTED MOUNTING ACCESSORIES
TYPICAL PERFORMANCE
Rack Adapter for 6 Increments of 1/6 Rack Width
Component Chassis for 6 Increments of 1/6 Rack Width
EZ-UCB2
Under-Counter Brackets 1/6 or 1/3 Rack Width
Use In Place of Filler Panel
Holds Adapters and Cables
Mounts in EZ-CC6 and EZ-RA6
Complete accessory listing available at: rdlez.com
Copyright © 2009 Radio Design Labs, Inc. RDL, Radio Design Labs and the RDL logo are registered trademarks of Radio Design Labs, Inc. Data reflects product at publication time, subject to change without notice. “Made in USA” applies to all EZ products except power supplies.
Input: VGA - QXGA RGBHV or RGB with combined sync
Outputs (4): LOCAL MONITOR (1, ID bit pass-thru to INPUT), OUTPUTS (3)
Gain: Unity
Video bandwidth: > 360 MHz
Video impedance: 75 Ω(Input and output)
Sync (HV) input: 500 ΩTTL 0.7 V to 5 V p-p
Sync (HV) output: 5V TTL
Sync (HV) Propogation delay: < 4 nS typ.
Sync (HV) Rise time: < 4 nS typ.
Sync (combined): Output follows input
Bit Control: Switch-selectable (Pin 4, over-rides LOCAL MONITOR jack ID bit pass-thru)
24 Vdc power supply current: 50 mA (idle), 70 mA (max.)
Power supply input voltage: 100 to 240 VAC
Warranty: 3 Years; contact RDL technical support department for assistance
Case dimensions: 5.75” (14.6 cm)W x 3” (7.6 cm)D
Mounting size: 1/3 rack width
891-1552
EZ-DC2
EZ-SMB2
TYPICAL PERFORMANCE
Desktop Chassis 1/3 Rack Width
EZ-UCB2
Under-Counter Brackets 1/6 or 1/3 Rack Width
Surface Mount Bezel for 1/3 Rack Width Products
EZ-SD2
Storage Drawer 1/3 Rack Width
Copyright © 2009 Radio Design Labs, Inc. RDL, Radio Design Labs and the RDL logo are registered trademarks of Radio Design Labs, Inc. Data reflects product at publication time, subject to change without notice. “Made in USA” applies to all EZ products except power supplies.
