RDL UC-1R User manual

ACCESSORIES
Model UC-1R
RACK-UP Enclosure
The UC-1R is a tabletop utility chassis for mounting RDL modules and accessories. The front and rear each feature one RACK-UP
mounting bay. The mounting bays fit RACK-UP series products and AMS accessories (using AMS-RU4 adapters, available separately).
The interior provides space to mount various STICK-ON and TX series modules.
With Product Installed
(RU-SH1 Available Separately)
Empty
RDL •659 6th St. •Prescott, AZ., USA 86301 •[phone] •FAX [phone] •www.rdlnet.com

STEP #1
Start the screws into the bottom of the RACK UP but do not
install them all the way.
ACCESSORIES
Model UC-1R
RACK-UP Enclosure
891-xxxx
STEP #2
Secure the unit to the mounting chassis by sliding the unit
rearward so that the screws seat into the mounting holes
and tighten the screws. Repeat steps #1 and #2 for any
other RACK-UPs or filler panels that are to be installed.
STEP #3
Slide the top and bottom plates onto the side pieces and
secure the front and back plates to the side pieces with the
8 torx head screws.
STEP #4: Install the trim plates with the 4 crosshead undercut
screws.
Radio Design Labs Technical Support Centers
U.S.A. [phone], [phone]; Fax: [phone]
Europe [NH Amsterdam] (++31) 20-6238 983; Fax: (++31) 20-6225-287
Installation/Operation
EN55103-1 E1-E5; EN55103-2 E1-E4
Typical Performance reects product at publication time
exclusive of EMC data, if any, supplied with product.
Specications are subject to change without notice.
NOTE: When installing a RACK UP product that is in a
plastic box start by removing the screws from the back
of the RACK UP. Bend the tabs on the mounting unit up
at a 90° angle. Secure the unit to the mounting chassis
using the screws.
