ReActiveMicro MINI AV2HDMI User manual
Owner’s Manual
Apple 🙼Personal Computer
ReActiveMicro
Since 2005
AV2
HDMI
MINI
Apple 🙼Personal Computer
AV2
HDMI
MINI
Customer Satisfaction
The ReActiveMicro MINI AV2HDMI comes with a one
year replacement warranty to the original purchaser
only.
Limitation on Warranties and Liability
Even though ReActiveMicro has tested the hardware
described in this manual and reviewed its contents,
neither ReActiveMicro nor its aliates make any
warranty or representation, either express or implied,
with respect to this manual or to the hardware
described in this manual, their quality, performance,
merchantability, or fitness for any particular purpose.
As a result, this hardware and manual are sold “as is”,
and you the purchaser are assuming the entire risk as
to their quality and performance. In no event will
ReActiveMicro or its suppliers be liable for direct,
indirect, incidental, or consequential damages resulting
from any defect in the hardware or manual, even if they
have been advised of the possibility of such damages.
In particular, they shall have no liability for any programs
or data stored in or used with ReActiveMicro products,
including the costs of recovering or reproducing these
programs or data. Some states do not allow the exclusion
or limitation of implied warranties or liability for incidental
or consequential damages, so the above limitation or
exclusion may not apply to you.
Contents at a glance
Introduction
Standard Features
What’s Included
MINI Specifications
Apple II, IIplus, IIe
Video Setup Only
Video and Mockingboard
Video and RM Phasor
Video and AE Phasor
Apple //c, IIc Plus
//c Complete Setup
IIc Plus Complete Setup
Apple IIGS
Complete Setup
Apple IIGS RGB Video
YouTube Reviews
Quick Reference
................................
....................
.........................
...................
.................
..
.........
..........
.............
.....
...................
.........
....................
.......................
1
2
3
4
6
7
8
9
11
12
14
15
17
18
Introduction
Thank you for purchasing this product from
ReActiveMicro.
For optimum performance and safety, please
read these instructions carefully before
connecting, operating or adjusting this
product.
Keep this manual for future reference.
The ReActiveMicro Mini AV2HDMI UP Scaler
is a analog composite video signal converter
for the Apple II Personal Computer System.
The analog to digital conversion in this module
employs 10 bits maximal 162MSPS sampling,
black/white level expansion, color transition
improvement, dynamic range expansion, blue
stretch, auto-detect and auto-convert the
composite signal to 1080p(60Hz) output.
Making your Apple II Personal Computer come
alive, delivering a high quality visual image.
ReActiveMicro.com 01
AV2
HDMI
MINI
• Up-scales AV (Audio/Video) to HDMI
720P or 1080P.
• No need to install computer drivers, portable,
flexible, plug and play.
• Advanced signal processing provides great
precision, colors, resolution and details.
• Supports PAL, NTSC3.58, NTSC4.43, SECAM,
PAL/M, PAL/N standard format input.
• Supports HDMI 1080P / 720P Display Devices,
this product may or may not function correctly
on a 4K or 3D display.
Standard Features
ReActiveMicro.com 02
AV2
HDMI
MINI
1080p 60Hz, 720P 60Hz.
1 Year Parts and Labor.
0°C to +70°C
10% to 85% RH (no condensation)
-10°C to +80°C
5% to 90% RH (no condensation)
USB Power Cable
5W (Max)
FCC, CE
CE, FCC
PAL, NTSC3.58, NTSC4.43,
SECAM, PAL/M ,PAL/N.
MINI Specifications
Note: Specifications are subject to change without notice.
Signal Inputs
Output Signals
Dimensions(mm)
Weight
Composite Input
HDMI Output
Limited Warranty
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Power Supply
Power Consumption
Converter Unit Certification
Power Supply Certification
Apple II Composite Video and
Sound Card Audio Signals
HDMI Signal
66(D) x 55(W) x 20(H)
40 (g)
ReActiveMicro.com 04
AV2
HDMI
MINI
AV2
HDMI
MINI
Video Setup Only
Composite
Video Output
ReActiveMicro
2020
OUTPUT
INPUT
AV2
HDMI
06ReActiveMicro.com
HDMI
Input
HDMI
Output
HDMI Cable
HDMI FLAT
DISPLAY
LCD MONITOR
OR HDTV
Screen Resolution
Selection
Video Input
RCA INPUT JACKS
USB Power
Adapter
AV2
HDMI
UP Scaler 1080P
USB/Power
720P 1080P
MINI
MINI
USB Power Cable
BACK PANEL CONNECTORS
Video and Sound Setup -
Stereo Plug (3.5mm) to Installed*
Mockingboard Soundcard Stereo Output.
*Location of Installed Sound Card Varies by User Installation.
ReActiveMicro
2020
OUTPUT
INPUT
AV2
HDMI
ReActiveMicro.com
HDMI
Input
HDMI
Output
HDMI Cable
HDMI FLAT
DISPLAY
LCD MONITOR
OR HDTV
Audio Input Right
Audio Input Left
Screen Resolution
Selection
Video Input
RCA INPUT JACKS
USB Power
Adapter
07
AV2
HDMI
Composite
Video Output
UP Scaler 1080P
USB/Power
720P 1080P
MINI
MINI
USB Power Cable
BACK PANEL CONNECTORS
Video and Sound Setup - RM PHASOR
Stereo Plug (3.5mm) to Installed*
RM PHASOR Soundcard Stereo Output.
*Location of Installed Sound Card Varies by User Installation.
ReActiveMicro
2020
OUTPUT
INPUT
AV2
HDMI
ReActiveMicro.com
HDMI
Input
HDMI
Output
HDMI Cable
HDMI FLAT
DISPLAY
LCD MONITOR
OR HDTV
Audio Input Right
Audio Input Left
Screen Resolution
Selection
Video Input
RCA INPUT JACKS
USB Power
Adapter
08
AV2
HDMI
Composite
Video Output
UP Scaler 1080P
USB/Power
720P 1080P
MINI
MINI
USB Power Cable
BACK PANEL CONNECTORS
Stereo Left & Right Plugs to Installed*
AE PHASOR Soundcard Stereo Output.
*Location of Installed Sound Card Varies by User Installation.
Video and Sound Setup - AE PHASOR
ReActiveMicro
2020
OUTPUT
INPUT
AV2
HDMI
RIGHT Audio Input
LEFT Audio Input
ReActiveMicro.com
HDMI
Input
HDMI
Output
HDMI Cable
HDMI FLAT
DISPLAY
LCD MONITOR
OR HDTV
Screen Resolution
Selection
Video Input
RCA INPUT JACKS
Audio Input Right
Audio Input Left
USB Power
Adapter
09
AV2
HDMI
Composite
Video Output
UP Scaler 1080P
USB/Power
720P 1080P
MINI
MINI
USB Power Cable
BACK PANEL CONNECTORS
AV2
HDMI
MINI
Apple //c Complete Setup
Composite
Video Output
ReActiveMicro
2020
OUTPUT
INPUT
AV2
HDMI
ReActiveMicro.com
HDMI
Input
HDMI
Output
HDMI Cable
HDMI FLAT
DISPLAY
LCD MONITOR
OR HDTV
Screen Resolution
Selection
Video Input
RCA INPUT JACKS
USB Power
Adapter
11
AV2
HDMI
UP Scaler 1080P
USB/Power
720P 1080P
MINI
MINI
Audio Input Right
Audio Input Left
Stereo Jack can be
found on the front
left side of the
computer.
3.5mm Audio Plug
USB Power Cable
BACK PANEL CONNECTORS
Composite
Video Output
Stereo Jack can be
found on the front
left side of the
computer.
3.5mm Audio Plug
Apple IIc Plus Complete Setup
ReActiveMicro
2020
OUTPUT
INPUT
AV2
HDMI
ReActiveMicro.com
HDMI
Input
HDMI
Output
HDMI Cable
HDMI FLAT
DISPLAY
LCD MONITOR
OR HDTV
Screen Resolution
Selection
Video Input
RCA INPUT JACKS
USB Power
Adapter
12
AV2
HDMI
UP Scaler 1080P
USB/Power
720P 1080P
MINI
MINI
Audio Input Right
Audio Input Left
USB Power Cable
BACK PANEL CONNECTORS
AV2
HDMI
MINI
Composite
Video Output
Stereo
Audio Output
3.5mm
Audio Plug
Apple IIGS Complete Setup
720P 1080P
Screen Resolution
Selection
USB Power Cable
Video Input
RCA INPUT JACKS
ReActiveMicro
2020
OUTPUT
INPUT
AV2
HDMI
Audio Input Right
Audio Input Left
HDMI
Input
HDMI
Output
HDMI Cable
HDMI FLAT
DISPLAY
LCD MONITOR
OR HDTV
BACK PANEL CONNECTORS
USB Power
Adapter
ReActiveMicro.com 14
AV2
HDMI
UP Scaler 1080P
USB/Power
MINI
MINI
