Realme DIZO Watch R User manual

DIZO Watch R
User Guide
封面

Enter pairing mode
1
Charge the smartwatch to
activate it before first use.
Press and hold the power button
on the side to power on.

Download DIZO APP
2
Search DIZO APP in Google Play
Store (Android) or App Store (iOS),
or scan the QR code to download
DIZO APP.
DIZO

Set up and pair
3
Click " " in DIZO APP to add the
device:
1. Scan the QR code on the watch
screen;
2. Search the watch Bluetooth for
pairing.

A. Home Button:
Power On: Press and hold till
screen lights up;
Power O: Press and hold and
choose Power O;
Back to Home Screen: Single click.
B. Sports Button:
Click to enter Sports Modes list.
A
B

Swipe on home screen
Notifications
Menu
Fitness data, weather
and music control
Shortcuts and settings

Charging
To charge the watch, place the
watch flat and make sure that
the two metal holes on the back
are aligned with the metal tip of
the charging head.

Change straps
Slide the spring pin and hold it
to remove a strap from the
watch or attach a strap to
the watch.

DIZO Watch R
Charging Cable
User manual
Contens
To view regulatory information,
please go to Settings - About -
Regulatory Information
Regulatory Information
Parameters
Model: DW2120
Ingress protection level: 5ATM
Input rating: 5V 0.5A
Sensor : 3-axis acceleration sensor,
HRM and SpO2 sensor
Battery capacity: 280mAh
Sync mode: Bluetooth BLE 5.1
Resolution: 360*360 pixels
Display: 1.3 AMOLED
Operating temperature:
0°C ~ 45°C
Operating frequency:
2400 ~ 2483.5MHZ
Bluetooth transmit power: ≤ 8dBm

Documentation & Help
Need help or more information?
Please scan QR code
You can also visit DIZO APP for
frequently asked questions.
DIZO

Note
Please read the instructions before use:
1. The company reserves the right to modify the content of this notice
without notice. According to normal circumstances, some
functions are dierent in specific software versions.
2. The product should be charged for more than 2 hours before use,
but avoid prolonged charging in an unmanned environment.
3. Please use a charger of 5V/1A or 5V/2A along with the original
charging cable from DIZO.

Safety Instructions
. If you currently have any preexisting physical diseases, and using this product
may have an impact on this disease, please consult your doctor first;
. Do not check the display information when driving, being distracted or in other
potentially dangerous situations;
. This product is not a toy. Do not allow children or pets to play with this product.
Small components of the product may cause suocation;
. The product function may be aected by external factors, so the data is for
reference only;
. The product has a heart rate recording function.
Wearing it for a long time may cause some users to have skin discomfort and
allergic symptoms, or bring certain risks to users with certain diseases. Please
consult your doctor before using or stop using the product in any of the following
situations:
- Epilepsy or sensitive to light;
- Poor blood circulation or prone to have bruises; heart disease or other
diseases;
- You are taking any light-sensitive drugs.
. This product is not a medical device and should not be used as a substitute
for professional medical judgment. It is not designed or intended for use in the
diagnosis of disease or other conditions, or in the cure, mitigation, treatment, or
prevention of any condition or disease. Please consult your healthcare provider
prior to making any decisions related to your health.

Hereby, Realfit (Shenzhen) Intelligent Technology Co., Ltd., declares that this device
is in compliance with Directive //EU. The full text of the EU declaration of
conformity is available at the following internet address:
https://www.dizo.net/global/eu-compliance.
RF exposure information: The EIRP power of the device at maximal case is below
the exempt condition, mW specified in EN: . RF exposure assessment
has been performed to prove that this unit will not generate the harmful EM
emission above the reference level as specified in EC Council Recommendation
(//EC).
Warnings
• Replacement of a battery with an incorrect type that can defeat a safeguard (for
example, in the case of some lithium battery types);
• Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of
a battery, that can result in an explosion;
• Leaving a battery in an extremely high temperature surrounding environment that
can result in an explosion or the leakage of flammable liquid or gas;
• A battery subjected to extremely low air pressure that may result in an explosion or
the leakage of flammable liquid or gas.

FCC Statement
This device complies with Part  of the FCC Rules. Operation is subject to the
following two conditions: () this device may not cause harmful interference, and ()
this device must accept any interference received, including interference that may
cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part  of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help important
announcement

Important Note:
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance cm between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
FCC ID: AYPPDW
Disposal and Recycling Information
This symbol (with or without a solid bar) on the device, batteries
(included), and / or the packaging, indicates that the device and its
electrical accessories (for example, a headset, adapter or cable) and
batteries should not be disposed of as household garbage.

Warranty
Thank you for purchasing DIZO products.
1. We will provide comprehensive warranty services according to local laws
and regulations.
2. From more details about our warranty policy, please visit
https://www.dizo.net/global
Matters Needing Attention:
1. When you buy the product, the sales unit will issue a valid proof of purchase.
2. The warranty card and the proof of purchase should be kept by the user
properly, and it will not be replaced if lost.
3. If the product fails due to non-human factors, the user can present the
warranty card and proof of purchase to the DIZO customer service center
for free maintenance during the warranty period.

Non-warranty situation:
This warranty does not cover the following cases:
1. Out of warranty period.
2. Damage caused by use not in accordance with the instructions.
3. Damage caused by man-made causes.
4. Failure caused by unauthorized disassembly, maintenance, or
modification of the product.
5. Damage caused by force majeure factors (such as floods,
earthquakes, lightning, etc.).
6. There is no warranty card, invoice, or warranty card that does not
match the invoice information.
7. The product wears naturally.
8. Other failures and damages that are not caused by the quality of
the product itself.
www.dizo.net/global

Warranty Card (Stub Copy)
Dear user, thank you for using the product of our company.
Please read and keep properly the warranty card after purchasing the product so
that we can provide better services to you.
Product Information
Product Model
Product Serial Number
Purchase Date
Invoice Number
Sales Unit
Phone Number
Address
User Information
User's name
Phone Number
Address
Email
Sales Information

Dear user, thank you for using the product of our company.
Please read and keep properly the warranty card after purchasing the product so
that we can provide better services to you.
Product Information
Product Model
Product Serial Number
Purchase Date
Invoice Number
Sales Unit
Phone Number
Address
User Information
User's name
Phone Number
Address
Email
Sales Information
Warranty Card (Customer Copy)

Paarungs-Modus aufrufen
1
Laden Sie die Smartwatch auf,
um sie vor dem ersten Gebrauch
zu aktivieren.
Drücke die Power-Taste an der
Seite und halte sie gedrückt, um
das Gerät einzuschalten.
