reci FSC 1000 User manual

User Guide for
Single-Mode Continuous-Wave Fiber Laser
FSC 1000, FSC 1500
Beijing Reci Laser Technology Co., Ltd.
2020.04

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
I
CONTENT
Chapter 1 Safety Information .........................................................................................................1
1.1 Safety Conventions used in the User Guide ....................................................................1
1.2 Laser Classification........................................................................................................2
1.3 Labels on the Product.....................................................................................................2
1.4 Safety Instructions for Optical Operation........................................................................3
1.5 Safety Instructions for Electrical Operation ....................................................................4
1.6 Other Safety Instructions................................................................................................5
Chapter 2 Product Description........................................................................................................7
2.1 Property Introductions....................................................................................................7
2.2 Model description ..........................................................................................................7
2.3 Unpacking and inspection ..............................................................................................8
2.4 Operation Conditions .....................................................................................................8
2.5 Instructions for use....................................................................................................... 11
2.6 Characteristic Parameters ............................................................................................. 11
Chapter 3 Installation of the laser ................................................................................................. 13
3.1 Dimension of the machine............................................................................................13
3.2 The optical output head ................................................................................................14
3.3 Connection and Requirements of the Cooling system ...................................................15
3.4 Installation precautions.................................................................................................18
Chapter 4 Using of the product.....................................................................................................20
4.1 Front Panel...................................................................................................................20
4.2 Back Panel Description ................................................................................................21
4.3 Electric Power Connect................................................................................................ 22
4.4 Interface Definition ......................................................................................................23
4.5 Laser Control ...............................................................................................................26
4.6 Local AD Mode............................................................................................................27
4.7 Remote AD Model .......................................................................................................28
Chapter 5 Use of monitoring software ..........................................................................................29
5.1 Connect........................................................................................................................29

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
II
5.2 Monitor Page ...............................................................................................................31
5.3 Setting Page .................................................................................................................33
5.4 Decrypt Page................................................................................................................34
5.5 Fault Query Page.......................................................................................................... 35
Chapter 6 Common faults treatment ............................................................................................. 37
6.1 Fault alarm and query...................................................................................................37
6.2 Common faults solution ...............................................................................................37
Chapter 7 Warranty and Return ....................................................................................................39
7.1 General warranty..........................................................................................................39
7.2 Limit of warranty .........................................................................................................39
7.3 Transportation ..............................................................................................................40

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
1
Chapter 1 Safety Information
Thank you for choosing the FSC series fiber laser from Reci laser.
In order to guarantee the fiber laser is operated safely (including personnel
safety, equipment safety, production safety), ensure the product remain its best
condition for a long time. We compile this document with important safety, operating,
maintaining and other information. Please take time to read and understand this
User's Guide and familiarize yourself with the operating and maintenance instructions
before using the product.
1.1 Safety Conventions used in the User Guide
SYMBOLS
DESCRIPTION
WARNING :
Refers to a potential hazard that may leads to a personal injury
or death.
CAUTION :
Refers to a potential hazard on product, or a potential physical
injury on personnel.
NO
SYMBOL
IMPORTANT :
Refers to any information regarding the operation of the
product. Please do not overlook this information.

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
2
1.2 Laser Classification
This series of lasers emit invisible laser radiation around a wavelength of 1080
nm. The average power of the products is ranged from 10% to 100% at a maximum
power about 1000W or 1500W, which classifies the series of lasers Class 4 laser
instrument. Direct or indirect exposure of this level of light intensity may cause very
serious damage to the eyes or skin. In view of this, appropriate and approved laser
safety protective glasses must be worn all the time while the laser is operating.
WARNING :
The laser safety protective glasses are selected according to the
wavelengths of the output laser. The users must ensure that the laser
safety protective glasses covered the entire range of wavelengths of
the laser emission.
1.3 Labels on the Product
All safety warning symbols posted on the FSC1000 is shown below in
Figure1.1:
1: Top view of FSC1000 (same as FSC1500)
2: Rear view of FSC1000 (same as FSC1500)
Figure 1.1 Positions of the symbols on the series of lasers

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
3
Table 1.1 the details of the symbols
1: Class 2M Laser Product Label for Guide
Laser
2: Class 4 Laser Product(take 1000W as
example)
3: Laser Radiation Hazard Label
4: Electrical Hazard
5: Identification Plate of the device
1.4 Safety Instructions for Optical Operation
We strongly recommend that you read the following procedures before
operating the fiber laser:
(1) Never look directly into the optical output when the Electrical switch is
on.
(2) Make sure that a pair of appropriate and approved laser safety protective
glasses is worn all the time while the laser is operating.
(3) No eyes are on the path of the laser beam (direct or reflected light, scatter
light from high reflective material, etc.), at the same time, the direction of
laser output must be Shelter by reliable objects.

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
4
WARNING :
Even though the protective glasses are worn, staring into the
optical output is forbidden absolutely while the electrical switch of the
laser is on.
(4) Make sure that the black cap of the QBH is taken off when you are
prepared to use the laser.
(5) Make sure the end surface of the quartz head and the protective window
lens of the optical output is clean, if not, please clean it with dust-free lens
paper soaked by high purity (≥99.8%) anhydrous ethanol under a
microscope.
(6) Make sure that the processing devices can support a maximum laser power
above 1500W. If you find that the processing equipment is being heated to
a higher temperature, please stop processing immediately. An appropriate
and approved processing system is needed.
CAUTION :
A damage of the end surface of the QBH or Processing lens may
lead more serious hazard on product.
1.5 Safety Instructions for Electrical Operation
We strongly recommend that you read the following procedures before
operating the fiber laser:
(1) Make sure the power source connected to the equipment is properly
grounded with PE wire. At the same time the shell of this equipment must

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
5
be properly grounded. Any interruption of the ground loop may result in
personal injury.
WARNING :
The input voltage of the fiber laser is three-phase AC current
(380V AC), which may cause risk of electric shock. All the relevant
cables and connection wires have potential hazards.
(2) Make sure that the input AC voltage and capacity meet the requirements of
the very series of lasers.
(3) If the air switch shut down frequently, please contact Reci as soon as
possible to ensure the safety use of the equipment.
CAUTION :
(1) Any incorrect wiring method or AC voltage may cause
damage to people or instrument.
(2) The equipment does not have any part which can be
maintained by operators, and all the maintenance operations
must be finished by the professionals of Reci Co., Ltd.
1.6 Other Safety Instructions
(1) There are often numerous secondary laser beams produced at various
angles in the output port of the laser. These divergent beams are produced
when the primary beam of laser reflects off a smooth surface, and they are
called specular reflections. Although these secondary beams may be less
powerful than the total power emitted from the primary beam, the intensity

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
6
may be great enough to cause damage to the eyes and skin as well as
surface of materials.
WARNING :
You must exercise caution to avoid/minimize specular reflections
as these laser radiations are invisible!
(2) Optical accessories relevant to the laser, such as light-sensitive elements
that may be damaged from exposure to the laser light, video cameras,
photomultipliers and photodiodes, need related protections.
CAUTION :
The Reci FSC laser is strong enough to cut or weld metal, burn
skin, clothing and paint. In addition, this laser can ignite volatile
substances such as alcohol, gasoline, ether and other solvents.
During the operating process, the flammable materials around the
laser must be isolated.
(3) Please do not operate laser in darkened environments.
(4) Do not turn on the laser without an optical coupling fiber or the optical
output connector.
(5) Carry out commissioning, calibration and focusing at low output power and
then increase the output power gradually when the calibrating and focusing
work is done.
(6) If the equipment is operated in a manner not specified in this document, the
protection devices and performance of the equipment may be impaired and
the warranty will be voided.

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
7
Chapter 2 Product Description
2.1 Property Introductions
As high power fiber lasers developed for industrial application, FSC Series fiber
lasers are compact and efficient. The lasers are mainly applied to the fields of
welding, cutting, brazing, etc.
Main Features:
➢High wall-plug efficiency
➢High power with Excellent beam quality
➢High reliability, long service life, maintenance free
➢All fiber structure, compact, rugged package
➢Multiple anti-high-reflection
Applications:
➢Industrial applications: Material cutting（major in metal processing）, metal
welding, metal cladding.
➢Scientific research, Military application.
2.2 Model description
As a series of lasers, its model name description is illustrated as the following
figure 2.1, take FSC1000 as an example. Similarly, the FSC1500 means its maximum
average power can reach 1500W:

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
8
FSC 1000 1000W(The maximum average power)
Continuous Wave
Single Mode (or Module sometimes)
Fiber laser
Figure 2.1 the meaning of the model names
2.3 Unpacking and inspection
Reci certifies that this equipment has been thoroughly tested and inspected and
meets published specifications prior to shipping. We advise that the receiver should
check the packaging, for there should be potential damage during the transport.
Please do as follow:
(1) Check whether the packaging is placed correctly (Flat, upright) and no
collision, crack, rain or water immersion outside the box.
(2) Please check actual items refer to the packing list.
If damage is apparent on the laser or part of its accessories in transit, please
contact Reci and the carrier immediately.
CAUTION :
The fiber cable and output head are very precise optical devices,
will cause irrecoverable damage to the laser while is be twisting, over
bending. At the same time, strong vibration and impact on the output
head are forbidden.
2.4 Operation Conditions
The basic operation conditions are listed in the table followed:

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
9
Table 2.1 the operation conditions for the FSC series lasers
Item
Value
Supply Voltage(V)
220±10% V AC 50/60Hz
Placement
Flat, upright, no vibration and impact
Environment Temperature
5~40℃
Relative Humidity
30%RH~70%RH
Electromagnetic Environment
Avoid too strong electromagnetic interference, which
may lead to false alarm of laser
Cooling water quality
QBH and even the whole machine need deionized water
to prevent scaling.
At the absence of deionized water, pure water for
drinking can be used. When the ambient temperature is lower
than 0 ℃, antifreeze (30% volume ratio for alcohol) needs to
be added to the cooling water.
Note:
(1) Never use the tap water or other cooling water with high ion concentration.
(2) The cooling water shall be replaced timely to prevent microorganism and
ions growth.
(3) It is very easy to be damaged when the QBH getting scaling, and there is no
warranty in this case。
(4) The output of the laser is connected with the cable. Please check the end
surface of the quartz head carefully to prevent dust or other pollution.
Lens-cleansing paper must be used when cleaning is necessary。
(5) Never installing the laser output with the processing system when the
equipment is power on。
(6) The protective glasses should be worn all the time.

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
10
CAUTION:
(1) When this product need work in high humidity （＞ 95% ） ,
please pour dry air into the machine shell in time.
(2) Never let this product work below the ambient dew point
temperature(like the table 2.2)
Table 2.2 the Constant Dew Point Table
Maximum Relative
humidity (%)
20
30
40
50
60
70
80
90
95
Room
Temperature(℃)
Ambient Dew Point (Td-℃)
10
-11.9
-7
-0.3
0
2.5
4.8
6.7
8.4
9.2
15
-7.9
-2.3
1.5
4.6
7.3
9.6
11.6
13.4
14.2
20
-3.5
2
6
9
12
14.5
16.5
18
19
25
0.5
6
10.5
14
16.5
19
21
23
24
30
4.6
10.5
15
18.5
21.5
24
26
28
29
35
8.5
15
19.5
23
26
28.5
31
33
34
40
13
20
24
27.5
31
33.5
36
38
39
Temperature range for laser operating
NO
SYMBOL
IMPORTANT :
The lifetime of the laser will be shortened and the output power will
degrade while the cooling system working at a higher temperature for
too long time. Please ensure the cooling system is enough and the
temperature is suitable.

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
11
2.5 Instructions for use
(1) Before supplying the power to the device, make sure the power supply and
the connection of all wires are correct (See table 2.3 and subsection 4.3).
(2) Keep the outer black cap covered while the device is not in use, dust-proof
should not be absent any time.
(3) There is no warranty in case of no following this instruction.
2.6 Characteristic Parameters
The characteristic parameters of the FSC series fiber laser which the power is
ranged from 1000W to 1500W is demonstrated in the table。

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
12
Table 2.3 Parameters of the FSC1000&FSC1500 laser
MODEL
FSC1000
FSC1500
Optical
Specification
Output Power (W)
≥1000
≥1500
Operating Mode
CW/Modulate
Polarization
Random
Power Range (%)
10~100
Central Wavelength (nm)
1080±3
Power Instability (%)
<3
Max. Modulation Frequency (kHz)
20
Red Laser power (mW)
>0.2
Beam Delivery Optics
QBH
Output Fiber Diameter (μm)
20
30/50
Beam Quality M2
<3
Delivery Fiber Length (m)
15 (optional for 20)
Electric
Specification
Operating Voltage (VAC)
220V±10% 50/60Hz
Power Consumption (W)
<5000
<6000
Control Mode
Ext. RS 232/Ext. AD/Hyper terminal
Other
Specification
Dimensions W×H×D (mm3)
483×191×740 (including handle)
Weight (kg)
<60
Ambient Temperature (℃)
5~40
Ambient Humidity (%)
<70
Cooling Method
Water cooling
QBH Cooling Water Temperature (℃)
Room temperature (No condensation)
Cooling Water Temperature (℃)
25
Cooling Water Flow (L/min)
>12(With load)
>20(With load)
Storage temperature (℃)
-10~60

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
13
Chapter 3 Installation of the laser
3.1 Dimension of the machine
The dimension of the laser device is just below, figure 3.1, 3.2 for FSC 1000
(same as FSC1500).
Figure 3.1 Front view and Rear view of FSC 1000（unit: mm）
Figure 3.2(a) Bottom view of FSC 1000（unit: mm）

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
14
Figure 3.2(b) Side view of FSC 1000（unit: mm）
3.2 The optical output head
A passive device named QBH was used as the optical output in the FSC series
laser, its dimensions are just as figures below.
Figure 3.3 the top view of the QBH (unit: mm)
Figure 3.4 the side view of the QBH (unit: mm)
The slot size of QBH is standard, matched well with most of processing heads
from the market. During installation, you need to ensure the QBH installed in place,
and then establish a reliable connection between the ring contactor with the
processing head’s contactor; otherwise the laser will give an alarm.
Before the QBH is installed, the end face of the QBH must be checked. Of
course, it must be cleaned when the end face is polluted (check under a microscope).

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
15
3.3 Connection and Requirements of the Cooling system
3.3.1 Connection of the cooling system
A water cooler with dual temperature output is required. Quick plug water pipes
with outer diameter of 12mm is used for connecting the laser and the water cooler,
and two segments of quick plug water pipes with outer diameter of 6mm are for
connection between QBH and the water cooler. The method is shown in Figure 3.5:
the outlet of the water cooler is connected with the “WATER IN”of the laser, and the
inlet of the water cooler is connected with the “WATER OUT”of the laser, and so
is the QBH.
Outlet
Inlet
WATER IN
WATER OUT
Lower temperature
water（25℃）
Outlet
Inlet
Dual temperature (With
heating function) Laser
PU pipe with outer
diameter of 12mm
PU pipe with outer
diameter of 6mm
Output
IN
OUT
Higher temperature
water
（25℃~30℃）
Cooling-water system
Figure 3.5 Sketch Map for the connection of the cooling system
If a water cooler with dual temperature output isn’t ready there, an extra water
cooler for QBH specialized will be needed. And you’d better follow the notes below:
(1)Water with poor quality cannot be used, and the water temperature should not
make QBH dewy.
(2)Just as the figure 3.6, the QBH must be connected in the water way first, and
then the processing head. Do not reverse or divide water in order to avoid
cooling capacity lacked

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
16
Figure 3.6 the connection of water way between QBH and processing head
3.3.2 Requirement of the cooling system
The requirement of the cooling system is on display in the table below:
Table 3.1 the requirement of the cooling system for FSC1000& FSC1500
Item
Unit
FSC1000
FSC1500
Refrigerating
capacity
For the laser machine
kW
>6
For QBH
>0.5
Water flow
For the laser machine
L/min
12~30 (With load)
20~30(With load)
For QBH
1.5~2.5(with load)
Hydraulic
pressure
For the laser machine
Bar
<7
For QBH
<6
Water
temperature
For the laser machine
℃
25 (29 when it is summer)
For QBH
Room temperature (No condensation)
Diameter of
the pipe
For the laser machine
mm
Φ12 (outer diameter)
For QBH
Φ6(Outer diameter)-Φ4(Inner diameter)
(1)Requirement for cooling fluid
(a) Make sure the water is pure enough-- the de-ionized water is the best choice,
or you can also use purified water which is for drinking;

Beijing Reci Laser Technology Co., Ltd
User Guide for FSC1000, FSC1500
17
(b)Please pour some ethanol into the water in order to avoid the waterway
stopped by the putrefaction, which is suggested about 10% of all.
(c) When the surrounding temperature is between -10℃~ 0℃, gain the ethanol
proportion to 30%, and replace once two months。
(d)When the surrounding temperature is below -10℃, the water cooler with a
heating system should never lay off all the time 。
(2)The other requirement of the cooling system
(a) When the cooling machine works the first time, please make sure the
waterway is unclogged and watertight, at the same time the water supply
(outlet) is connected to the “WATER IN”，and return water (Inlet) is
connected to the “WATER OUT”;
(b)If the laser is away from work for a long time, please empty the water in it.
CAUTION:
Set temperature for the cooling machine according to the
surrounding temperature. Unsuitable temperature will lead bad
results—too high temperature can lead the laser exceptional, even
damaged, and the low temperature may cause badly condensation
trouble both on the laser device and the QBH.
CAUTION:
Make sure the cooling system works before the laser device does,
and the temperature is required being 25 ℃ , when you decide to turn
on the laser device.
