RecPro RP-SAWN-FRM User manual

RP-SAWN-FRM
Slideout Awning
Installation Instructions

Contents
②
③
④⑤ ⑥ ⑦
Slide out awning
Hex shaped connecting rods
Brackets
plastic plug
Φ5.5x22 pan head self-Drilling screw
Φ3.9x13 pan head self-Drilling screw
Φ4.2x32 pan head self-Drilling screw
Number
①
②
③
④
⑤
⑥
⑦
Name Quantity
Awning Width=Fabric Length+6.3"
Fabric rail track Width=Awning Width-4"
Max. Max.
4"
8"
11" 11"
18" 18"
7~12
9
1
2
2
2
11
pic 1

Preparation
Installation
Step 1
Step 2
Connect rods, mounting brackets, and spring reel bracket connection.
Prepare tools and materials such as ladders, riveting gun, tape measures,
markers, and sealants. Before installation, ensure that the walls of your slide
box have a backer within the structure of the wall and have sufficient weight
bearing capacity.
a. Insert the connecting rod into the left mounting bracket.
b. Adjust the spring reel bracket to an appropriate angle and slide it into the
connecting rod.
Notice: Do the same for the left and right ends.
c. After confirming the angle and position, secure them with the provided
Φ3.9x13 pan head self-Drilling screw for c-①② .
Φ3.9x13 pan head
self-Drilling screw
d. Finish connecting rod with plastic plug.
Position the left and right mounting bracket according
to the size of the box (Pic 1) and then fix it with the
provided Φ5.5x22 pan head self-Drilling screw.
Please make sure the slide out is
closed before installation.
pic 2
pic 3

Step 3
Step 4
Step 5
Position the awning rail along the line where the roof and wall meet(Pic 1), or a
minimum of 3 inches above the upper edge of the slide out room. Once marked,
attach them to the body and secure them with multiple Φ4.2x32 pan head
self-Drilling screw.
After completing step 4, open and close the
slide out box to test if the awning is working
well. If the awning and awning fabric are
working properly,then the installation was
successful. If the fabric is not centered, pull the
fabric to the correct position on the rail track
and fx it with Φ3.9x13mm pan head self-Drilling
screw. After all steps are completed, Use
sealant around the rail track and bracket to
prevent water leakage or damage.
After completing the above steps, remove
the spring safety pin at both ends of the reel
end cover. as shown in pic 5.
There is spring got tensioned in our awning，please do not release
the safety pin when install awning，people may got hurts,after you
take out the safety pin, please keep it well for future use.
pic 4
pic 5
pic 6
safety pin
WARNING

Maintenance and care
Awning care and maintenance
Regularly check if the awning fasteners are kept tight. If they are loose, tighten all
fasteners. Periodically clean the awning fabric and arms.
How to clean awning fabric
fabric with a soft brush and warm water every one or two years.
Note: When you clean the fabric only use natural soap and clean water and make
sure ALL of the cleaner is rinsed off after cleaning. Never use detergent, oil-based
cleaners, or any caustic, granulate, or abrasive type cleaners.
Air-dry. DON’T roll up the awning until the fabric is completely dry.
Vinyl fabric offers the advantage of durability and water resistance. Wrinkling may
be more noticeable when retracted and after prolonged periods of storage. In warm
weather, open it up for a period of time to minimize the wrinkling. Leave the awning
open during warm weather to minimize the wrinkling over time.
Precautions:
1.DO NOT use insecticides or other sprays near the awning fabric. These could
cause stains and could adversely affect the fabric’s ability to repel water.
2.DO NOT expose awning to adverse environmental conditions, corrosive agents,
or other harmful conditions. In the event of high winds, storms, and other adverse
weather conditions, roll up your awning to protect it from these conditions.
4.NEVER close the awning for storage when wet. The combination of moisture and
dirt could result in mildew, discoloration, and stains. If it is necessary to roll up
the awning while it’s wet, make sure you roll it out and let it dry as soon as
possible before rolling up again.
5.DO NOT allow dirt, leaves, or other debris to accumulate on the awning, as this
could cause abrasion and stains. Mildew could grow on dirt and organic debris,
causing permanent discoloration, stains, and odors to awning fabric.
6.DO NOT use strong chemicals or abrasives to clean awning or awning assembly
To prevent damage to the surface of the protective layer, a neutral detergent can
be used.
7.NEVER leave the awning open while traveling or moving your RV. Make sure
ALL attachments are secure.
Warranty Information
RecPro Awning Assemblies are covered under warranty for a period of 1 year and
includes replacement or refunds for shipping or manufacturing errors. Shipping
damage is covered for 30 days after receiving the product. Make sure to inspect
the unit when it arrives for shipping damage. Damage from incorrect use or
disregarding the above precautions is not covered under warranty.
