Red Fire 85098 User manual

EN
NL
English
Handleiding
85098 - 2 in 1 Multifunctional Firepit
EAN: 8719956295034
WARNING!
Probable danger to life and risk of injury!
Use in closed spaces can be dangerous
and is FORBIDDEN.
Please read the manual before usage.
NOTE - IMPORTANT!
Carefully remove the packaging before use,
but keep the safety manual. These are part
of the product. Please note all safety
warnings mentioned in this manual.
Read the instructions in their entirety and
keep them for future reference. These must
be stored with the product. This product is
for household use and may not be used for
commercial or contractual purposes.
OutTrade BV
Meeleweg 76
7711 EP Nieuwleusen
The Netherlands
Tel: +31-529—48 28 08
Fax: +31-529—48 49 10
[email protected]
www.outtrade.eu
MADE IN P.R.C.
User instructions - please keep
for future references

2
HOW TO ASSEMBLE / HOE TE MONTEREN

3
Spare parts list
Cooking grill (Qty 1) / Grill (1 st)
Cooking plate (Qty 1) / Kook plaat (1 st)
Fire bowl (Qty 1) / Vuur schaal (1 st)
Bolt (Qty 3) / Bout (3 st)
Base-1 (Qty 1) / Basis-1 (1 st)
Ash drawer (Qty 1) / As lade (1 st)
Handle (Qty 3) / Handvat (3 st)
Base-2 (Qty 1) / Basis-2 (1 st)
Bottom base (Qty 1) / Bodem basis (1 st)
Bottom panel (Qty 1) / Bodem plaat(1 st)
1
2
3
4
5
6
7
8
9
10
HOW TO ASSEMBLE / HOE TE MONTEREN
NLEN

4
Hardware list
Explore view
1
2
3
4
5
6
7
8
9
10
Screw M6x12 (Qty 22) / Schroef M6x12 (22 st)
Nut M6 (Qty 2) / Moer M6 (2 st)
A
B
HOW TO ASSEMBLE / HOE TE MONTEREN
NLEN

5
Step 1 + 2
9
5
A
A
8
8
Step 1:
EN:
Assemble base-1 (5) and Base-2 (8)
with screw (A)
NL:
Monteer basis-1 (5) en basis-2 (8)
met schroef (A)
Step 2:
EN:
Assemble base-2 (8) and
bottom base (9) with screw (A)
NL:
Monteer de basis-2 (8) en
bodemplaat (9) met schroef (A)
HOW TO ASSEMBLE / HOE TE MONTEREN
NLEN

6
Step 3: Assemble Bottom base (9) and base panel (10) with screw (A)
Step 5: Assemble handles (7) onto the base-2 (8) with screws (A)
Step 3 + 4
7
10
A
A
9
8
Step 3:
EN:
Assemble bottom base (9) and base
panel (10) with screw (A)
NL:
Monteer bodemplaat (9) en
bodemplaat (10) met schroef (A)
Step 4:
EN:
Assemble handles (7) onto
the base - 2 (8) with screws (A)
NL:
Monteer handgrepen (7) op
de basis - 2 (8) met schroeven (A)
HOW TO ASSEMBLE / HOE TE MONTEREN
NLEN

7
Step 5 + 6
6
A
B
7
4
3
Step 5:
EN:
Assemble the handle (7) to the ash
drawer (6) with screws (A)
NL:
Monteer de handgreep (7) aan de
aslade (6) met schroeven (A)
Step 6:
EN:
Fix the bolts (3) to the re bowl (4) with
screws (A) and nuts (B)
NL:
Bevestig de bouten (3) aan de
vuurschaal (4) met schroeven (A)
en moeren (B)
HOW TO ASSEMBLE / HOE TE MONTEREN
NLEN

8
Step 7 + 8
A
2
4
5
Step 7:
EN:
Assemble the re bowl (3) and nish
base with screws (A)
NL:
Monteer de vuurschaal (3) en werk
de voet af met schroeven (A)
Step 8:
EN:
Place the cooking plate (2) onto the
re bowl bolts (4)
NL:
Plaats de kookplaat (2) op de
vuurschaalbouten (4)
HOW TO ASSEMBLE / HOE TE MONTEREN
NLEN
3

9
NLEN
Step 9 + 10
1
2
Step 9:
EN:
Place the cooking grill (1) onto
the cooking plate (2)
NL:
Plaats het grillrooster (1) op
de kookplaat (2)
Step 10:
EN:
Now this multifunctional re pit / BBQ
is nished, you can enjoy it!
NL:
Nu deze multifunctionele vuurschaal /
BBQ af is, kan je er van genieten!
HOW TO ASSEMBLE / HOE TE MONTEREN

10
WARNING SAFETY RULES: PLEASE READ THE FOLLOWING
SAFETY RULES PRIOR TO OPERATION OF THIS PRODUCT
DANGER!
Direct danger to life and risk of injury!
Directly dangerous situation that may lead
to death or severe injuries.
WARNING!
Probable danger to life and risk of injury!
Generally dangerous situation that may lead
to death or severe injuries.
CAUTION!
Possible risk of injury!
Dangerous situation that may lead to injuries.
NOTICE!
Risk of damage to the device!
Situation that may lead to property damage.
NOTE
Information to help you reach a better
understanding of the processes involved.
NOTE
Remove any packaging before use,
but retain the safety instructions.
Before you begin…
Care and safe use guidelines
This product is not intended for commercial use. Generally
acknowledged accident prevention regulations and enclosed
safety instructions must be observed.
Only perform work described in these instructions for use.
Any other use is improper. The manufacturer will not assume
responsibility for damage resulting from such use.
What are the meanings of the symbols used?
Product information
About this product
EN
