red lion DSPLE User manual

1
CONVERTS NUMEROUS PROTOCOLS SIMULTANEOUSLY
EXTENSIVE BUILT-IN DRIVER LIST ALLOWS EASY DATA
MAPPING TO PLCs, PCs, AND SCADA SYSTEMS
10 BASE-T/100BASE-TX ETHERNET PORT SUPPORTS FOUR
SIMULTANEOUS PROTOCOLS
INDEPENDENT SERIAL PORTS PROVIDE VIRTUALLY
UNLIMITED INTEGRATION METHODS
SUPPORTS UP TO NINE PROTOCOLS SIMULTANEOUSLY(with
expansion card)
GENERAL DESCRIPTION
The Data Station Plus was designed to act as a nexus for industrial data
collection and management. With three built in serial ports and a 10 Base-T/100
Base-TX Ethernet port, the unit performs protocol conversion, allowing
disparate devices to communicate seamlessly with one another. The Ethernet
port supports up to ten protocols simultaneously using Crimson 3, so even
Ethernet to Ethernet conversion may be performed.
The CompactFlash card allows new configuration files to be loaded into the
Data Station Plus. The USB port may be used for blazing fast file downloads, or
to mount the Data Station’s CompactFlash card as an external drive to your PC.
The Data Station’s DIN rail mounting saves time and panel space and snaps
easily onto standard top hat (T) profile DIN rail.
SOFTWARE
The Data Station is programmed with Crimson®2.0 software for Windows®
2000 or later platforms. The software is an easy to use graphical interface which
can be purchased as part of a kit that includes a manual and cables, or
downloaded free of charge from www.redlion.net.
SAFETY SUMMARY
All safety related regulations, local codes and instructions that appear in the
manual or on equipment must be observed to ensure personal safety and to
prevent damage to either the instrument or equipment connected to it. If
equipment is used in a manner not specified by the manufacturer, the protection
provided by the equipment may be impaired.
Do not use the controller to directly command motors, valves, or other
actuators not equipped with safeguards. To do so can be potentially harmful to
persons or equipment in the event of a fault to the controller. An independent
and redundant temperature limit indicator with alarm outputs is strongly
recommended.
CompactFlash is a registered trademark of CompactFlash Association.
MODEL DSPLE – DATA STATION PLUS
Bulletin No. DSPLE-H
Drawing No. LP0671
Released 04/15
CAUTION: Risk of Danger.
Read complete instructions prior to
installation and operation of the unit.
5.30 (134.7)
RS232
ETHERNET
CF
STS
USB/PG
RS485
RS232/PG
3.09 (78.5) 4.15 (105.4)
DIMENSIONS In inches (mm)
FOR USE IN HAZARDOUS LOCATIONS:
Class I, Division 2, Groups A, B, C, and D
CUS LISTED
UL
R
3PWL
PROGRAMMABLE
CONTROLLERS
WARNING - EXPLOSION HAZARD - SUBSTITUTION OF
COMPONENTS MAY IMPAIR SUITABILITY FOR CLASS I,
DIVISION 2
THIS EQUIPMENT IS SUITABLE FOR USE IN CLASS I,
DIVISION 2, GROUPS A, B, C, D, OR NON-HAZARDOUS
LOCATIONS ONLY
C
US LISTED
UL
R
IND. CONT. EQ.
34AD

2
SPECIFICATIONS
1. POWER: 24 VDC ± 10%
200 mA min., without expansion card
1 Amp maximum with expansion card fitted
Must use NEC Class 2 or Limited Power Source (LPS) rated power supply.
2. COMMUNICATIONS:
USB/PG Port: Adheres to USB specification 1.1. Device only using Type B
connection.
Serial Ports: Format and Baud Rates for each port are individually software
programmable up to 115,200 baud.
RS232/PG Port: RS232 port via RJ12
COMMS Ports: RS422/485 port via RJ45, and RS232 port via RJ12
DH485 TXEN: Transmit enable; open collector, VOH = 15 VDC,
VOL = 0.5 V @ 25 mA max.
Ethernet Port: 10 BASE-T / 100 BASE-TX
RJ45 jack is wired as a NIC (Network Interface Card).
3. LEDs:
STS – Status LED indicates condition of Data Station.
TX/RX – Transmit/Receive LEDs show serial activity.
Ethernet – Link and activity LEDs.
CF – CompactFlash LED indicates card status and read/write activity
4. MEMORY:
On-board User Memory: 4 Mbytes of non-volatile Flash memory.
On-board SDRAM: 2 Mbytes
Memory Card: CompactFlash Type II slot for Type I and Type II cards.
Used for optional database storage only
5. REAL-TIME CLOCK: Typical accuracy is less than one minute per month drift.
Battery: Lithium Coin Cell. Typical lifetime of 10 years at 25 ºC.
A “Battery Low” system variable is available so that the programmer can
choose specific action(s) to occur when the battery voltage drops below
its nominal voltage.
This unit is NOT field serviceable. All work must be done by a qualified
technician.
6. ENVIRONMENTAL CONDITIONS:
Operating Temperature Range:
DSPLE000: 0 to 50 °C
DSPLE001: -20 to 70 °C
Storage Temperature Range: -30 to 70 °C
Operating and Storage Humidity: 80% max relative humidity,
non-condensing, from 0 to 50 °C
Vibration to IEC 68-2-6: Operational 5 to 150 Hz, 2 g.
Shock to IEC 68-2-27: Operational 30 g
Altitude: Up to 2000 meters
7. CONSTRUCTION: Case body is burgundy high impact plastic and
stainless steel. For indoor use only. Installation Category II, Pollution
Degree 2.
8. POWER CONNECTION: Removable wire clamp screw terminal block.
Wire Gage Capacity: 24 AWG to 12 AWG
Torque: 4.45 to 5.34 in/lb (0.5 to 0.6 N-m)
9. MOUNTING: Snaps onto standard DIN style top hat (T) profile mounting
rails according to EN50022 -35 x 7.5 and -35 x 15.
10. CERTIFICATIONS AND COMPLIANCES:
CE Approved
EN 61326-1 Immunity to Industrial Locations
Emission CISPR 11 Class A
Safety requirements for electrical equipment for measurement, control, and
laboratory use:
EN 61010-1: General Requirements
EN 61010-2-201: Particular Requirements for Control Equipment
RoHS Compliant
UL Listed: File #E302106
UL Hazardous: File #E317425
ABS Certificate #09-HS426719-B-4-PDA
Refer to EMC Installation Guidelines section of the bulletin for additional
information.
11. WEIGHT: 15.1 oz (428 g)
HARDWARE
INSTALLATION
DIN rail should be mounted horizontally so that the unit’s ventilation holes
are vertical in relation to cabinet orientation. A minimum clearance of 1 inch
(25.4 mm) should be maintained above and below the unit in order to ensure
proper thermal regulation.
The unit shall be installed inside a UL Listed Industrial Control Panel or
similar type of enclosure. A minimum 3.2 mm distance shall be maintained
between the hazardous live parts of the equipment and accessible parts of the
fire/electrical enclosure.
Figure 1 - Attach Data Station To DIN Rail
2
1
ETHERNET
RS485
RS232
USB/PG
CF
RS232/PG
STS
1.00"
1.00"
min. clearance
min. clearance
TOP
BOTTOM
WARNING - DO NOT CONNECT OR DISCONNECT CABLES
WHILE POWER IS APPLIED UNLESS AREA IS KNOWN TO BE
NON-HAZARDOUS. USB PORT IS FOR SYSTEM SET-UP AND
DIAGNOSTICS AND IS NOT INTENDED FOR PERMANENT
CONNECTION.
WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT
EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF OR
AREA IS KNOWN TO BE NON-HAZARDOUS.

3
COMPACTFLASH®CARD
CompactFlash socket is a Type II socket that can accept either Type I or II
cards. Use cards with a minimum of 4 Mbytes and formatted to a maximum of
2 Gbytes (see Note box below) with the Data Station’s CompactFlash socket.
Cards are available at most computer and office supply retailers. The
CompactFlash can be used for optional database storage only.
Information stored on a CompactFlash card can be read by a card reader
attached to a PC. This information is stored in IBM (Windows®) PC compatible
FAT16 file format.
CompactFlash
(Top Side)
CompactFlash-
Insert Top Side
Towards Left
Note: Do not remove or insert
the CompactFlash card while
power is applied.
POWER SUPPLY REQUIREMENTS
It is very important that the power supply is mounted correctly if the unit is
to operate reliably. Please take care to observe the following points:
– The power supply must be mounted close to the unit, with usually not more
than 6 feet (1.8 m) of cable between the supply and the Data Station.
Ideally, the shortest length possible should be used.
– The wire used to connect the Data Station’s power supply should be at least
22-gage wire. If a longer cable run is used, a heavier gage wire should be
used. The routing of the cable should be kept away from large contactors,
inverters, and other devices which may generate significant electrical
noise.
– A power supply with an NEC Class 2 or Limited Power Source (LPS) and
SELV rating is to be used. This type of power supply provides isolation to
accessible circuits from hazardous voltage levels generated by a mains
power supply due to single faults. SELV is an acronym for “safety extra-
low voltage.” Safety extra-low voltage circuits shall exhibit voltages safe
to touch both under normal operating conditions and after a single fault,
such as a breakdown of a layer of basic insulation or after the failure of a
single component has occurred.
Visit www.redlion.net for a complete list of our PSDR Series of Class 2
power supplies.
EMC INSTALLATION GUIDELINES
Although Red Lion Controls Products are designed with a high degree of
immunity to Electromagnetic Interference (EMI), proper installation and wiring
methods must be followed to ensure compatibility in each application. The type
of the electrical noise, source or coupling method into a unit may be different
for various installations. Cable length, routing, and shield termination are very
important and can mean the difference between a successful or troublesome
installation. Listed are some EMI guidelines for a successful installation in an
industrial environment.
1. A unit should be mounted in a metal enclosure, which is properly connected
to protective earth.
2. Use shielded cables for all Signal and Control inputs. The shield connection
should be made as short as possible. The connection point for the shield
depends somewhat upon the application. Listed below are the recommended
methods of connecting the shield, in order of their effectiveness.
a. Connect the shield to earth ground (protective earth) at one end where the
unit is mounted.
b. Connect the shield to earth ground at both ends of the cable, usually when
the noise source frequency is over 1 MHz.
3. Never run Signal or Control cables in the same conduit or raceway with AC
power lines, conductors, feeding motors, solenoids, SCR controls, and
heaters, etc. The cables should be run through metal conduit that is properly
grounded. This is especially useful in applications where cable runs are long
and portable two-way radios are used in close proximity or if the installation
is near a commercial radio transmitter. Also, Signal or Control cables within
an enclosure should be routed as far away as possible from contactors, control
relays, transformers, and other noisy components.
4. Long cable runs are more susceptible to EMI pickup than short cable runs.
5. In extremely high EMI environments, the use of external EMI suppression
devices such as Ferrite Suppression Cores for signal and control cables is
effective. The following EMI suppression devices (or equivalent) are
recommended:
Fair-Rite part number 0443167251 (RLC part number FCOR0000)
Line Filters for input power cables:
Schaffner # FN2010-1/07 (Red Lion Controls # LFIL0000)
6. To protect relay contacts that control inductive loads and to minimize radiated
and conducted noise (EMI), some type of contact protection network is
normally installed across the load, the contacts or both. The most effective
location is across the load.
a. Using a snubber, which is a resistor-capacitor (RC) network or metal oxide
varistor (MOV) across an AC inductive load is very effective at reducing
EMI and increasing relay contact life.
b. If a DC inductive load (such as a DC relay coil) is controlled by a transistor
switch, care must be taken not to exceed the breakdown voltage of the
transistor when the load is switched. One of the most effective ways is to
place a diode across the inductive load. Most RLC products with solid state
outputs have internal zener diode protection. However external diode
protection at the load is always a good design practice to limit EMI.
Although the use of a snubber or varistor could be used.
RLC part numbers: Snubber: SNUB0000
Varistor: ILS11500 or ILS23000
7. Care should be taken when connecting input and output devices to the
instrument. When a separate input and output common is provided, they
should not be mixed. Therefore a sensor common should NOT be connected
to an output common. This would cause EMI on the sensitive input common,
which could affect the instrument’s operation.
Visit RLC’s web site at http://www.redlion.net/emi for more information on
EMI guidelines, Safety and CE issues as they relate to Red Lion Controls
products.
NOTE
For reliable operation of this and other Red Lion products, one of the
following brands of CompactFlash card must be used...
SimpleTech SMART®Modular swissbit®
SanDisk® Silicon Systems
Not all of the above manufacturers offer CompactFlash cards recognized to
UL standards, which may be required for your application.
Although RLC products limit use of CompactFlash card memory to 2 GB,
cards with a larger capacity can be used. They MUST be formatted to 2
GB and use the FAT 16 file system. It is recommended to format the CF
card using the format utility from within Crimson.

4
COMMUNICATION PORTS
COMMON
+24 VDC +24
N/C
COMM
WIRING
POWER CONNECTION
PROGRAMMING PORTS
RS232
RTS
COMM
Tx
COMM
CTS
Rx
YELLOW LED
GREEN/AMBER LED
CBLUSB00
CBLPROG0
ETHERNET
RS232
CF
RS485
USB/PG
RS232/PG
STS OR
Ethernet (Crossover)
OR
Tx
RS232
RTS
COMM
COMM
CTS
Rx
RS232
RS485
USB/PG
RS232/PG
ETHERNET
CF
STS
CBLxxxxx*
CHASSIS GND
OR
CBLPROG0
REM
SLC 5/03 CPU
RUN
BATT
FLT
RUN
RS232
DH485
FORCE
PROG
VDC
PWR OUT +24
PWR OUT COM
VAC NEUT
120/240 VAC
USER
POWER
POWER
RS232/PG
USB/PG
RS232/PG
ETHERNET
WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT
WHILE CIRCUIT IS ALIVE UNLESS AREA IS KNOW TO BE
NON-HAZARDOUS.
INPUT AND OUTPUT (I/O) WIRING MUST BE IN
ACCORDANCE WITH CLASS I, DIV. 2 WIRING METHODS
AND IN ACCORDANCE WITH THE AUTHORITY HAVING
JURISDICTION.

ETHERNET
RS232
RS485
USB/PG
RS232/PG
CF
STS
Standard Ethernet cable
CTS
Tx
COMM
Rx
RTS
COMM
RS232
TxB
RxB
RxA
TxA
TxB
COMM
TxEN
TxA
RS485
GREEN/AMBER LED
YELLOW LED
ETHERNET
RS232
RS485
USB/PG
RS232/PG
CF
STS
CBLxxxxx*
REM
SLC 5/03 CPU
RUN
RUN
FLT
BATT
FORCE
PROG
DH485
RS232
120/240 VAC
VAC NEUT
CHASSIS GND
VDC
PWR OUT COM
PWR OUT +24
USER
POWER
POWER
RS232
ETHERNET
RS485
USB/PG
RS232/PG
CF
STS
CBLxxxxx*
REM
SLC 5/03 CPU
RUN
RUN
FLT
BATT
FORCE
PROG
DH485
RS232
120/240 VAC
VAC NEUT
CHASSIS GND
VDC
PWR OUT COM
PWR OUT +24
USER
POWER
POWER
* Use appropriate communications cable. See Ordering
Information for descriptions of the available cables.
WARNING: Do NOT use a standard DH-485
cable to connect this port to Allen Bradley
equipment.
PORT 3 - ETHERNET CONNECTION
RS232
RS485
5
EXPANSION
24VDC ±10%
USB/PG
TxA (PIN 8)
GREEN/ YELLOW LED LED AMBER
(NIC)
ETHERNET
RS232
PORT
COMMS
COMMS
PORT
COMM CTS (PIN 1) COMM Rx Tx RTS (PIN 6) TxB
COMM RxA RxB TxA TxB (PIN 1)
TxEN
RS485
ETHERNET
RS232
RS485
CF
RS232/PG PORT
RTS (PIN 6) CTS (PIN 1)
USB/PG
RS232
COMM Tx COMM Rx
RS232/PG
STS
POWER
CONNECTOR
N/C
3
2
COMMON
1
PORT
DATA STATION PORT PIN OUTS
TROUBLESHOOTING
If for any reason you have trouble operating,
connecting, or simply have questions concerning your
new Data Station, contact Red Lion’s technical support.
For contact information, refer to the back page of this
bulletin for phone and fax numbers.
EMAIL: [email protected]
Web Site: http://www.redlion.net

6
CONFIGURING A DATA STATION
The Data Station is configured using Crimson®2.0 software. Crimson 2.0 is
available as a free download from Red Lion’s website, or it can be ordered on
CD. Updates the software for new features and drivers are posted on the website
as they become available. By configuring the Data Station using the latest
version of the software, you are assured that your unit has the most up to date
feature set. Crimson®2.0 software can configure the Data Station through the
RS232/PG port, USB/PG port, Ethernet, or CompactFlash. The USB/PG port is
connected using a standard USB cable with a Type B connector.
The driver needed to use the USB port will be installed with Crimson 2.0.
The RS232/PG port uses a programming cable made by Red Lion to connect to
the DB9 COM port of your computer. If making your own cable, refer to the
“Data Station Port Pin Outs” for wiring information.
The CompactFlash can be used to program a Data Station by placing a
configuration file and firmware on the CompactFlash card. The card is then
inserted into the target Data Station and powered. Refer to the Crimson®2.0
literature for more information on the proper names and locations of the files.
CABLES AND DRIVERS
Red Lion has a wide range of cables and drivers for use with many different
communication types. A list of these drivers and cables along with pin outs is
available from Red Lion’s website. New cables and drivers are added on a
regular basis. If making your own cable, refer to the “Data Station Port Pin
Outs” for wiring information.
USB, DATA TRANSFERS FROM THE
COMPACTFLASH CARD
In order to transfer data from the CompactFlash card via the USB port, a
driver must be installed on your computer. This driver is installed with Crimson
2.0 and is located in the folder C:\Program Files\Red Lion Controls\Crimson
2.0\Device\ after Crimson 2.0 is installed. This may have already been
accomplished if your Data Station was configured using the USB port.
Once the driver is installed, connect the Data Station to your PC with a USB
cable, and follow “Mounting the CompactFlash” instructions in the Crimson 2.0
user manual.
Note: The USB port is for system set-up and diagnostics and is not intended for
permanent connection.
ETHERNET COMMUNICATIONS
Ethernet communications can be established at either 10 BASE-T or 100
BASE-TX. The Data Station’s RJ45 jack is wired as a NIC (Network Interface
Card). For example, when wiring to a hub or switch use a straight-through
cable, but when connecting to another NIC use a crossover cable.
The Crimson 2.0 manual contains additional information on Ethernet
communications.
RS232 PORTS
The Data Station has two RS232 ports. There is the RS232/PG port and the
COMMS port. Although only one of these ports can be used for programming,
both ports can be used for communications with a PLC. The RS232/PG port can
be used for either master or slave protocols.
RS422/485 PORT
The Data Station has one RS422/485 port. This port can be configured to act
as either RS422 or RS485.
Note: All Red Lion devices connect A to A and B to B, except for Paradigm
devices. Refer to www.redlion.net for additional information.
DH485 COMMUNICATIONS
The Data Station’s RS422/485 COMMS port can also be used for Allen
Bradley DH485 communications.
WARNING: DO NOT use a standard DH485 cable to connect this port to Allen
Bradley equipment. A cable and wiring diagram are available from Red Lion.
TX
5V
8
1
7
2
TxB
TxA
130K
130K
5TxEN (OC)
RX
130K
5V
130K
RxB
4
RxA
3
GND
6
TxEN (OC)
TX/RX
130K
5
TxA
2
8
130K
5V
7
1
TxB
6 GND
RS422/485 4-WIRE
CONNECTIONS
RS485 2-WIRE
CONNECTIONS
COMMUNICATING WITH THE DATA STATION
WARNING - DO NOT CONNECT OR DISCONNECT CABLES
WHILE POWER IS APPLIED UNLESS AREA IS KNOWN TO BE
NON-HAZARDOUS. USB PORT IS FOR SYSTEM SET-UP AND
DIAGNOSTICS AND IS NOT INTENDED FOR PERMANENT
CONNECTION.

7
ORDERING INFORMATION
TYPE MODEL NO. DESCRIPTION PART NUMBER
Data Station Plus DSP
Data Station with multiple protocol converter, Comms, Ethernet and expansion slot. DSPLE000
Data Station with multiple protocol converter, Comms, Ethernet, expansion slot, and extended
operating temperature. DSPLE001
Data Station with multiple protocol converter, data logger, web server with Virtual HMI up to
QVGA (320 x 240) and expansion slot. DSPSX000
Data Station with multiple protocol converter, data logger, web server with Virtual HMI up to
QVGA (320 x 240), expansion slot, and extended operating temperature. DSPSX001
Data Station with multiple protocol converter, data logger, web server with Virtual HMI up to
VGA (640 x 480) size and expansion slot with increased SDRAM. DSPGT000
Data Station with multiple protocol converter, data logger, web server with Virtual HMI up to
VGA (640 x 480), expansion slot with increased SDRAM, and extended operating temperature. DSPGT001
Communications
Cables (10 feet) CBL
RS-232 Programming Cable CBLPROG0
USB Cable CBLUSB00
Communications Cables 1CBLxxxxx
Software SFCRM2 Crimson®2.0 2, Manual and Download Cable SFCRM200
Power Supply PSDR DIN Rail Power Supply PSDRxxxx
Accessories
XCCN CANopen option card for Modular Controller or Data Station Plus XCCN0000
XCDN DeviceNet option card for Modular Controller or Data Station Plus XCDN0000
XCGSM GSM/GPRS Modem option card for Modular Controller or Data Station Plus 3XCGSM000
XCPB PROFIBUS option card for Modular Controller or Data Station Plus XCPBDP00
XCRS RS232/485 option card for Modular Controller or Data Station Plus XCRS0000
G3CF CompactFlash Card 5G3CFxxxx
DR DIN Rail Mountable Adapter Products 4DRxxxxxx
1Visit www.redlion.net for a list of communication drivers and cables.
2Use this part number to purchase the Crimson® software on CD with a printed manual, USB cable, and RS-232 cable. Otherwise, download free of charge
from www.redlion.net.
3Antenna (G3QANT00) is NOT included with the card. Must be purchased separately if needed.
4Red Lion offers RJ modular jack adapters. Refer to the DR literature for complete details.
5Industrial grade two million write cycles. SMART Modular Technologies model SG9CF (UL Listed Directory Category NWGQ).
LEDS
STS – STATUS LED
The green Status LED provides information regarding the state of the Data
Station. This includes indication of the various stages of the start-up routine
(power-up), and any errors that may occur.
Startup Routine
Rapidly Flashing
INDICATION
Data Station is currently running the boot loader and/
or being flash upgraded by Crimson.
Steady Data Station is operating properly.
CF – COMPACTFLASH LED
USER COMMUNICATION PORTS - TX/RX LEDS
ETHERNET LEDS
No CompactFlash Card is present.Off
Incorrectly formatted CompactFlash card present.
Unit is writing to the CompactFlash, either
because it is storing data, or because the PC
connected via the USB port has locked the drive. 1
Flashing Slowly
Flickering
CompactFlash card is being checked.Flashing Rapidly
Valid CompactFlash card is present.Steady
INDICATIONLED
1. Do not turn off power to the unit while this light is flickering. The unit writes
data in two minute intervals. Later Microsoft operating systems will not lock
the drive unless they need to write data; Windows 98 may lock the drive any
time it is mounted, thereby interfering with logging. Refer to “Mounting the
CompactFlash” in the Crimson 2.0 User Manual.
TransmittingGREEN
ReceivingRED
INDICATIONLED
Note: LEDs are not available on the Programming Port: RS232/PG.
Link EstablishedYELLOW (Solid)
100 BASE-TX CommunicationsAMBER
10 BASE-T CommunicationsGREEN
Network ActivityYELLOW (Flashing)
INDICATIONLED

LIMITED WARRANTY
The Company warrants the products it manufactures against defects in materials and workmanship
for a period limited to two years from the date of shipment, provided the products have been stored,
handled, installed, and used under proper conditions. The Company’s liability under this limited
warranty shall extend only to the repair or replacement of a defective product, at The Company’s
option. The Company disclaims all liability for any affirmation, promise or representation with
respect to the products.
The customer agrees to hold Red Lion Controls harmless from, defend, and indemnify RLC against
damages, claims, and expenses arising out of subsequent sales of RLC products or products
containing components manufactured by RLC and based upon personal injuries, deaths, property
damage, lost profits, and other matters which Buyer, its employees, or sub-contractors are or may be
to any extent liable, including without limitation penalties imposed by the Consumer Product Safety
Act (P.L. 92-573) and liability imposed upon any person pursuant to the Magnuson-Moss Warranty
Act (P.L. 93-637), as now in effect or as amended hereafter.
No warranties expressed or implied are created with respect to The Company’s products except
those expressly contained herein. The Customer acknowledges the disclaimers and limitations
contained herein and relies on no other warranties or affirmations.
