red roo SG350 Operating instructions

SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
SG350
STUMP
GRINDER
4) IGNITION: Must be in “ON” position to start.
“OFF” to stop.
5) Open fuel shut-off valve. Move choke
control to CHOKE or START position.
Note: Choke must fully close. Move throttle
controlto RUN or FAST position. If engine is
equipped with rocker style stop switch, push
RUN or I (I = Ignition) before starting. Rewind
Starter: Grasp rope
handle and pull slowly
until resistance is felt
to prevent kickback.
Then pull cord rapidly
to overcome compression, and start engine.
Repeat if necessary with choke off and
throttle control in FAST position. Operate
engine in FAST position.
NOTE: The operator presence control bar is
designed as a safety feature. The engine will
not start or operate without depressing the
control bar. See Figure 1 (next page).
6) Push the stump grinder to the stump,
position the grinding disc over the front edge
of the stump.
7) Set the wheel brake on the right hand side of
the stump grinder and adjust the handle
position to achieve better leverage
depending on the height of the stump.
8) Use the throttle to gradually bring the engine
RPM s up tofull whilelifting thegrinding
disc off theground.
9) Slowly lower the stump grinder until the
grinding disc comes in contact with the
stump. Move the stump grinder back and
forth in a long, slow sweeping motion.
Maintain the same elevation until a section
has been removed, then lower the stump
grinder to take out the next section.
NOTE: Constant build up of grinding debris
may inhibit the stump grinder from
performing effectively. To help assure safe,
effective and efficient working results, keep
theworking area raked level and free of
grinding debris.
© Copyright 2012, Red Roo Sales & Service Company Pty. Ltd. 1301-0024-A
NOTE: Make sure grinding disc has
stopped completely before clearing debris
10) When the front part of the stump has been
removed, release the brake and push the stump
grinder forward to a new edge.
NOTE: For better performance and to avoid
excessive clutch wear, run the engine at full
throttle during operation.
WARNING!–Keep hands and feet
clear of the Grinding Disc and grinding
zone and other moving parts while
engine is running.
WARNING!–In case ofdifficulty,
release the Operator Presence Control
Bar. This action will stop the engine.
11) After stump has been removed use the throttle to
gradually bring down the engine RPM s. Make sure
thegrinding disc has come to a complete stop
before moving the stump grinder.
12) Stop Engine: Do not
move choke control to
CHOKE position tostop
engine. Backfire or
engine damage may occur. Move throttle control
to SLOW position, then push rocker switchto 0
(STOP), or turn key toOFF, if equipped.
AFTER USE
1) Turn fuel tap to "OFF" position.
2) Allow machine to cool down.
Wash mud and dirt off of the stump grinder.
Ensure no water enters the carburettor.
3) Remove any weeds, wire, rope, etc. that may
have wrapped around the disc grinding shaft assembly.
4) CHECK FOR LOOSE BOLTS ON THE GRINDING DISC.
Commercial Outdoor Power Equipment
OPERATING INSTRUCTIONS FOR SG350
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
“The Right Way to Rent”
SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
SG350
STUMP
GRINDER
OPERATION
1) Remove the garden tiller
from its trailer/carrier. Use caution.
2) Familiarize yourself with the machine and its
controls.
3) Ensure the safety clutch control lever is in the
disengagedposition. The safety clutch
control lever is located on the left handle bar.
The disengaged position of the lever is down.
4) Remove the shaft locking pin located behind
the wheel axle. Store pin in hole provided on
left hand side of handle bar.
5) The wheel axle will now pivot. Lift up on the
handle to allowwheelaxle to pivot. For
transport, keep the wheel axle forward. When
cultivating, keep the wheel axle rearward for
added stability and control.
DO NOT transport the tillerwith the wheel
axle in the rear position.
6) Adjust depth shoe(ifequipped) by removing
shaft locking collarand slidingdepth shoe to
desired position. Replace shaft locking collar.
7) Open fuel shut-off valve. Set choke
control to Choke or Start position.
Set throttle control to Run or Fast
position. Set engine
stop switch to On or
Run position. Pull
starter cord rapidly.
Repeat (if necessary)
with choke off.
8) Wheninposition to begingarden tilling,
engage the safety clutch controllever. The
tyneswillbeginrotating. Wheel axle must be in
the rearpositionwhile tilling.Release the
safety clutch controllever to stop the tynes
rotating. Tynespeed is governed by engine
throttle setting.
WARNING! –KEEPHANDSAND
FEET CLEAR OF TYNES AT ALL
TIMES!
9) Do not hurry the job. Proceed slowly and allow
the machine time to do the job. When ground
is extremely hard, reduce engine speed.
WARNING! –IN CASE OF DIFFICULTY,
DISENGAGE THE SAFETY CLUTCH
CONTROL LEVER. ALL TILLING ACTION
STOPS.Press the engine"STOP"button
located on the engine.
10) Stop Engine: Release the safety clutch control
lever.Move throttle to Slowposition. Set engine
stop switch to Stop or Offposition.DO NOT move
choke control to Choke
or Start position to stop
engine.Backfire or
enginedamagemay
occur.
AFTER USE
1) Turn fuelshut off valve to the "OFF"
position.
2) Allow machine to cool down.
3) Wash mud and dirt off of the garden tiller.
Ensure no water enters the carburettor.
4) Removeanyweeds,wire,rope or other
material thatmayhavewrappedaround the
tynes and rotor assembly.
5) Returnwheelaxle to forwardposition for
transport. Replace shaft locking collar.
6) Returndepth shoe(ifequipped) to full Up
position.
© Copyright 2001, Red Roo Sales & Service Company Pty. Ltd. 1301-0018
Commercial Environmental Equipment
Online Demonstration Available at:
www.redroo.com/products/stumpgrinder
SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
GT622
GARDEN
TILLER
OPERATION
1) Remove the garden tiller
from its trailer/carrier. Use caution.
2) Familiarize yourself with the machine and its
controls.
3) Ensure the safety clutch control lever is in the
disengagedposition. The safety clutch
control lever is located on the left handle bar.
The disengaged position of the lever is down.
4) Remove the shaft locking pin located behind
the wheel axle. Store pin in hole provided on
left hand side of handle bar.
5) The wheel axle will now pivot. Lift up on the
handle to allowwheelaxle to pivot. For
transport, keep the wheel axle forward. When
cultivating, keep the wheel axle rearward for
added stability and control.
DO NOT transport the tillerwith the wheel
axle in the rear position.
6) Adjust depth shoe(ifequipped) by removing
shaft locking collarand slidingdepth shoe to
desired position. Replace shaft locking collar.
7) Open fuel shut-off valve. Set choke
control to Choke or Start position.
Set throttle control to Run or Fast
position. Set engine
stop switch to On or
Run position. Pull
starter cord rapidly.
Repeat (if necessary)
with choke off.
8) Wheninposition to begingarden tilling,
engage the safety clutch controllever. The
tyneswillbeginrotating. Wheel axle must be in
the rearpositionwhile tilling.Release the
safety clutch controllever to stop the tynes
rotating. Tynespeed is governed by engine
throttle setting.
WARNING! –KEEPHANDSAND
FEET CLEAR OF TYNES AT ALL
TIMES!
9) Do not hurry the job. Proceed slowly and allow
the machine time to do the job. When ground
is extremely hard, reduce engine speed.
WARNING! –IN CASE OF DIFFICULTY,
DISENGAGE THE SAFETY CLUTCH
CONTROL LEVER. ALL TILLING ACTION
STOPS.Press the engine"STOP"button
located on the engine.
10) Stop Engine: Release the safety clutch control
lever.Move throttle to Slowposition. Set engine
stop switch to Stop or Offposition.DO NOT move
choke control to Choke
or Start position to stop
engine.Backfire or
enginedamagemay
occur.
AFTER USE
1) Turn fuelshut off valve to the "OFF"
position.
2) Allow machine to cool down.
3) Wash mud and dirt off of the garden tiller.
Ensure no water enters the carburettor.
4) Removeanyweeds,wire,rope or other
material thatmayhavewrappedaround the
tynes and rotor assembly.
5) Returnwheelaxle to forwardposition for
transport. Replace shaft locking collar.
6) Returndepth shoe(ifequipped) to full Up
position.
© Copyright 2001, Red Roo Sales & Service Company Pty. Ltd. 1301-0018
Commercial Environmental Equipment
SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
GT622
GARDEN
TILLER
OPERATION
1) Remove the garden tiller
from its trailer/carrier. Use caution.
2) Familiarize yourself with the machine and its
controls.
3) Ensure the safety clutch control lever is in the
disengagedposition. The safety clutch
control lever is located on the left handle bar.
The disengaged position of the lever is down.
4) Remove the shaft locking pin located behind
the wheel axle. Store pin in hole provided on
left hand side of handle bar.
5) The wheel axle will now pivot. Lift up on the
handle to allowwheelaxle to pivot. For
transport, keep the wheel axle forward. When
cultivating, keep the wheel axle rearward for
added stability and control.
DO NOT transport the tillerwith the wheel
axle in the rear position.
6) Adjust depth shoe(ifequipped) by removing
shaft locking collarand slidingdepth shoe to
desired position. Replace shaft locking collar.
7) Open fuel shut-off valve. Set choke
control to Choke or Start position.
Set throttle control to Run or Fast
position. Set engine
stop switch to On or
Run position. Pull
starter cord rapidly.
Repeat (if necessary)
with choke off.
8) Wheninposition to begingarden tilling,
engage the safety clutch controllever. The
tyneswillbeginrotating. Wheel axle must be in
the rearpositionwhile tilling.Release the
safety clutch controllever to stop the tynes
rotating. Tynespeed is governed by engine
throttle setting.
WARNING! –KEEPHANDSAND
FEET CLEAR OF TYNES AT ALL
TIMES!
9) Do not hurry the job. Proceed slowly and allow
the machine time to do the job. When ground
is extremely hard, reduce engine speed.
WARNING! –IN CASE OF DIFFICULTY,
DISENGAGE THE SAFETY CLUTCH
CONTROL LEVER. ALL TILLING ACTION
STOPS.Press the engine"STOP"button
located on the engine.
10) Stop Engine: Release the safety clutch control
lever.Move throttle to Slowposition. Set engine
stop switch to Stop or Offposition.DO NOT move
choke control to Choke
or Start position to stop
engine.Backfire or
enginedamagemay
occur.
AFTER USE
1) Turn fuelshut off valve to the "OFF"
position.
2) Allow machine to cool down.
3) Wash mud and dirt off of the garden tiller.
Ensure no water enters the carburettor.
4) Removeanyweeds,wire,rope or other
material thatmayhavewrappedaround the
tynes and rotor assembly.
5) Returnwheelaxle to forwardposition for
transport. Replace shaft locking collar.
6) Returndepth shoe(ifequipped) to full Up
position.
© Copyright 2001, Red Roo Sales & Service Company Pty. Ltd. 1301-0018
Commercial Environmental Equipment
SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
GT622
GARDEN
TILLER
OPERATION
1) Remove the garden tiller
from its trailer/carrier. Use caution.
2) Familiarize yourself with the machine and its
controls.
3) Ensure the safety clutch control lever is in the
disengagedposition. The safety clutch
control lever is located on the left handle bar.
The disengaged position of the lever is down.
4) Remove the shaft locking pin located behind
the wheel axle. Store pin in hole provided on
left hand side of handle bar.
5) The wheel axle will now pivot. Lift up on the
handle to allowwheelaxle to pivot. For
transport, keep the wheel axle forward. When
cultivating, keep the wheel axle rearward for
added stability and control.
DO NOT transport the tillerwith the wheel
axle in the rear position.
6) Adjust depth shoe(ifequipped) by removing
shaft locking collarand slidingdepth shoe to
desired position. Replace shaft locking collar.
7) Open fuel shut-off valve. Set choke
control to Choke or Start position.
Set throttle control to Run or Fast
position. Set engine
stop switch to On or
Run position. Pull
starter cord rapidly.
Repeat (if necessary)
with choke off.
8) Wheninposition to begingarden tilling,
engage the safety clutch controllever. The
tyneswillbeginrotating. Wheel axle must be in
the rearpositionwhile tilling.Release the
safety clutch controllever to stop the tynes
rotating. Tynespeed is governed by engine
throttle setting.
WARNING! –KEEPHANDSAND
FEET CLEAR OF TYNES AT ALL
TIMES!
9) Do not hurry the job. Proceed slowly and allow
the machine time to do the job. When ground
is extremely hard, reduce engine speed.
WARNING! –IN CASE OF DIFFICULTY,
DISENGAGE THE SAFETY CLUTCH
CONTROL LEVER. ALL TILLING ACTION
STOPS.Press the engine"STOP"button
located on the engine.
10) Stop Engine: Release the safety clutch control
lever.Move throttle to Slowposition. Set engine
stop switch to Stop or Offposition.DO NOT move
choke control to Choke
or Start position to stop
engine.Backfire or
enginedamagemay
occur.
AFTER USE
1) Turn fuelshut off valve to the "OFF"
position.
2) Allow machine to cool down.
3) Wash mud and dirt off of the garden tiller.
Ensure no water enters the carburettor.
4) Removeanyweeds,wire,rope or other
material thatmayhavewrappedaround the
tynes and rotor assembly.
5) Returnwheelaxle to forwardposition for
transport. Replace shaft locking collar.
6) Returndepth shoe(ifequipped) to full Up
position.
© Copyright 2001, Red Roo Sales & Service Company Pty. Ltd. 1301-0018
Commercial Environmental Equipment
SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
SG350
STUMP
GRINDER
4) IGNITION: Must be in “ON” position to start.
“OFF” to stop.
5) Open fuel shut-off valve. Move choke
control to CHOKE or START position.
Note: Choke must fully close. Move throttle
controlto RUN or FAST position. If engine is
equipped with rocker style stop switch, push
RUN or I (I = Ignition) before starting. Rewind
Starter: Grasp rope
handle and pull slowly
until resistance is felt
to prevent kickback.
Then pull cord rapidly
to overcome compression, and start engine.
Repeat if necessary with choke off and
throttle control in FAST position. Operate
engine in FAST position.
NOTE: The operator presence control bar is
designed as a safety feature. The engine will
not start or operate without depressing the
control bar. See Figure 1 (next page).
6) Push the stump grinder to the stump,
position the grinding disc over the front edge
of the stump.
7) Set the wheel brake on the right hand side of
the stump grinder and adjust the handle
position to achieve better leverage
depending on the height of the stump.
8) Use the throttle to gradually bring the engine
RPM s up tofull whilelifting thegrinding
disc off theground.
9) Slowly lower the stump grinder until the
grinding disc comes in contact with the
stump. Move the stump grinder back and
forth in a long, slow sweeping motion.
Maintain the same elevation until a section
has been removed, then lower the stump
grinder to take out the next section.
NOTE: Constant build up of grinding debris
may inhibit the stump grinder from
performing effectively. To help assure safe,
effective and efficient working results, keep
theworking area raked level and free of
grinding debris.
© Copyright 2012, Red Roo Sales & Service Company Pty. Ltd. 1301-0024-A
NOTE: Make sure grinding disc has
stopped completely before clearing debris
10) When the front part of the stump has been
removed, release the brake and push the stump
grinder forward to a new edge.
NOTE: For better performance and to avoid
excessive clutch wear, run the engine at full
throttle during operation.
WARNING!–Keep hands and feet
clear of the Grinding Disc and grinding
zone and other moving parts while
engine is running.
WARNING!–In case ofdifficulty,
release the Operator Presence Control
Bar. This action will stop the engine.
11) After stump has been removed use the throttle to
gradually bring down the engine RPM s. Make sure
thegrinding disc has come to a complete stop
before moving the stump grinder.
12) Stop Engine: Do not
move chokecontrol to
CHOKE position tostop
engine. Backfire or
engine damage may occur. Move throttle control
to SLOW position, then push rocker switchto 0
(STOP), or turn key toOFF, if equipped.
AFTER USE
1) Turn fuel tap to "OFF" position.
2) Allow machine to cool down.
Wash mud and dirt off of the stump grinder.
Ensure no water enters the carburettor.
3) Remove any weeds, wire, rope, etc. that may
have wrapped around the disc grinding shaft assembly.
4) CHECK FOR LOOSE BOLTS ON THE GRINDING DISC.
Commercial Outdoor Power Equipment
OPERATING INSTRUCTIONS FOR SG350
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
“The Right Way to Rent”
SAFETYPRECAUTIONS
AND OPERATING
INSTRUCTIONS
™
SG350
STUMP
GRINDER
4) IGNITION: Must be in “ON” position to start.
“OFF” to stop.
5) Open fuel shut-off valve. Move choke
control to CHOKE or START position.
Note: Choke must fully close. Move throttle
controlto RUN or FAST position. If engine is
equipped with rocker style stop switch, push
RUN or I (I = Ignition) before starting. Rewind
Starter: Grasp rope
handle and pull slowly
until resistance is felt
to prevent kickback.
Then pull cord rapidly
to overcome compression, and start engine.
Repeat if necessary with choke off and
throttle control in FAST position. Operate
engine in FAST position.
NOTE: The operator presence control bar is
designed as a safety feature. The engine will
not start or operate without depressing the
control bar. See Figure 1 (next page).
6) Push the stump grinder to the stump,
position the grinding disc over the front edge
of the stump.
7) Set the wheel brake on the right hand side of
the stump grinder and adjust the handle
position to achieve better leverage
depending on the height of the stump.
8) Use the throttle to gradually bring the engine
RPM s up tofull whilelifting thegrinding
disc off theground.
9) Slowly lower the stump grinder until the
grinding disc comes in contact with the
stump. Move the stump grinder back and
forth in a long, slow sweeping motion.
Maintain the same elevation until a section
has been removed, then lower the stump
grinder to take out the next section.
NOTE: Constant build up of grinding debris
may inhibit the stump grinder from
performing effectively. To help assure safe,
effective and efficient working results, keep
theworking area raked level and free of
grinding debris.
© Copyright 2012, Red Roo Sales & Service Company Pty. Ltd. 1301-0024-A
NOTE: Make sure grinding disc has
stopped completely before clearing debris
10) When the front part of the stump has been
removed, release the brake and push the stump
grinder forward to a new edge.
NOTE: For better performance and to avoid
excessive clutch wear, run the engine at full
throttle during operation.
WARNING!–Keep hands and feet
clear of the Grinding Disc and grinding
zone and other moving parts while
engine is running.
WARNING!–In case ofdifficulty,
release the Operator Presence Control
Bar. This action will stop the engine.
11) After stump has been removed use the throttle to
gradually bring down the engine RPM s. Make sure
thegrinding disc has come to a complete stop
before moving the stump grinder.
12) Stop Engine: Do not
move choke control to
CHOKE position tostop
engine. Backfire or
engine damage may occur. Move throttle control
to SLOW position, then push rocker switchto 0
(STOP), or turn key toOFF, if equipped.
AFTER USE
1) Turn fuel tap to "OFF" position.
2) Allow machine to cool down.
Wash mud and dirt off of the stump grinder.
Ensure no water enters the carburettor.
3) Remove any weeds, wire, rope, etc. that may
have wrapped around the disc grinding shaft assembly.
4) CHECK FOR LOOSE BOLTS ON THE GRINDING DISC.
Commercial Outdoor Power Equipment
OPERATING INSTRUCTIONS FOR SG350
You alone know the operational demands and
special conditions affecting the equipment in
your situation and therefore assume the
responsibility for developing, carrying out, and
enforcing the safety concepts which apply to your
own operation to effect the greatest safety for
yourself andthe people around you.
“The Right Way to Rent”

USE COMMON SENSE
AND PLENTY OF IT
1) DO NOT allow any person to operate
the stump grinder without first reading
and understanding the safety
precautions and operating instructions. KNOW
THE CONTROLS AND HOW TO STOP
THE STUMP GRINDER QUICKLY IN AN
EMERGENCY.
2) NEVER allow children or untrained adults to
operate the stump grinder.
3) ALWAYS wear
protective clothing
when operating the
stump grinder. This includes, but is not limited
to; safety glasses, loose fitting gloves, steel
capped boots and hearing protection. NEVER
wear loose fitting clothing or jewellery when
operating the stump grinder. Keep all clothing
away from moving parts. Items could become
caught in the machine, resulting in injury.
4) ALWAYS operate the stump grinder in a well
lit area.
5) ALWAYS operate stump
grinder on level ground only.
Inspect the immediate area
before grinding. Remove any foreign objects in
the grinding area eg bricks, rocks, wire and
sticks. Locate and mark any sprinkler heads,
water pipes, gas lines, electrical and telephone
cables or any other hazard either below or
above ground.
6) DO NOT allow other persons near the
stump grinder. It is up tothe operator
to keep bystanders and animals a
minimum of 6 metres (18ft) away from the
machine while in operation.
7) NEVER operate the stump grinder when
fatigued. ALWAYS BE ALERT! If you get tired
while operating the stump grinder, take a
break. If you have any type of physical or
mental condition that may be aggravated by
strenuous work, check with your physician
before you operate this equipment. NEVER
operate the stump grinder under the influence
of medication, alcohol or drugs.
8) ALWAYS KEEP YOUR HANDS,
FEET AND BODY AWAY FROM
THE CUTTING AREA WHILE
ENGINE IS RUNNING.
9) NEVER operate the stump grinder
without the safety guards in place and
in working order. Keep the unit well
maintained and in good working order
10) DO NOT leave the machine unattended while
the engine is running.
11) DO NOT overspeed the engine or alter the
governor settings. Excessive speed is
dangerous and will shorten engine life.
12)
13) STOP the engine and disconnect the
spark plug lead(s) and allow engine
to cool before inspecting or
performing maintenance on the stump grinder.
14) REFUELLING
* Shut off engine. DO NOT REFUEL
AN ENGINE WHILE OPERATING!
* Allow engine to cool; minimum 5
minutes.
*USE UNLEADED FUEL ONLY.
Use clean, fresh unleaded fuel.
*DO NOT mix oil with unleaded fuel.
*DO NOT over-fill fuel tank. Allow
space for fuel expansion.
*DO NOT smoke.
* Allow no naked flame or hot material
in refuelling area.
* Use only approved fuel containers
and funnels. Remember, fuel is a
potential hazard.
SAFETY PRECAUTIONS FOR SG350 USERS
OPERATING
INSTRUCTIONS
FOR SG350
BEFORE USE
1) Inspect the immediate area.
Remove any foreign objects
from the area.
2) Identify and mark the location of sprinkler
heads, gas pipes, telephone cables, etc.
3) Check the fuel and oil level of engine
OPERATION
1) Remove the stump grinder from its
carrying vehicle, trailer or ute. Use caution.
2) Familiarize yourself with the machine and its
controls.
3) Manoeuvre the stump grinder to area near
the stump to be removed.
Operator Presence Control Bar
Wheel Brake
Engine
Lifting
Hook
Throttle Adjustment
Cutting
Height
Adjustment
Lever
Grinding Zone
“STAY ALERT – DON’T GET HURT”
NEVER operate the stump grinder
in an enclosed area. Engine exhaust
contains carbon monoxide, an
odourless and tasteless poison.
OPERATOR ZONE
Handle Height
Adjustment Level
Engine Stop Switch
Engine Dust Protection
Lifting Point
Engine Exhaust
Belt Guard
Wheel
Brake
Engine
Pull
Cord
Engine
Operator Presence Control Bar
Throttle Control
Centrifugal Clutch
GRINDING ZONE
DISCHARGE ZONE
Figure 1
