Redback A 2080A User manual

Doc. PS1292
A 2080A
Zone Selection Panel
®
REDBACK A 2080A PA Speaker Zone Selection Panel
Proudly Assembled in Australia
Operating Instructions
Distributed by Altronic Distributors Pty. Ltd. Perth. Western Australia.
The REDBACK A 2080A Public Address Speaker Zone Selection
Panel allows you to select either;
1. One speaker zone only.
2. A combination of speaker zones.
3. All speaker zones
This allows great flexibility when paging.
By connecting together one or more Zone Selection Panels in a ‘Daisy
Chain’ fashion, any number of speaker zones are available (eg Three
Zone Selection Panels will give you a total of 30 speaker zones).
Installation
We recommend the Zone Selection Panels for use only with 70 Volt or
100 Volt line amplifiers with a maximum load of 50 watts per zone (at
100V). Connecting these units to a 4Ωor 8Ωamplifier system may
damage your amplifier.
We have supplied an identification strip (with double sided tape)
which can be attached to the front panel of the unit. The identifica-
tion strip can be engraved to help identify your speaker zones.
Connecting one zone
selection panel.
Connecting two or
more zone selection
panels.

REDBACK A 2080A PA Speaker Zone Selection Panel
Page 2 Doc. PS1292
Operation
1. Press switches for zones required. As mentioned, any combina-
tion of zones is possible. A coloured button indicates that the
zone is activated.
2. For paging to all zones, press the ‘All Call’ button. This is the
same as pressing all the zone buttons in at the same time. If you
have one or more Zone Selection Panels chained together, only
one ‘All Call’ button on any panel is required to be activated.
