Redback A 4415 User manual

A 4415
Audio Splitter
®
A 4415 2 Input / 6 Output Audio Splitter
Proudly Manufactured in Australia
OPERATING INSTRUCTIONS
Distributed by Altronic Distributors Pty. Ltd. Perth. Western Australia.
Phone: [phone] Fax: [phone] Internet: www.altronics.com.au
Overview
Housed in a 1RU enclosure, this excellent design incorporates two inputs
and six outputs. All inputs and outputs consist of a balanced 3 pin XLR
and dual RCA sockets. Both input and output XLR’s can be switch select-
ed for either balanced microphone or balanced line levels.
Each input can be selected either on or off to any output via the front
panel DIP switches. Level controls are provided for both inputs and all
outputs. Individual LED VU meters are provided for each input. The ver-
satility of the design allows for both inputs to accept either microphone,
balanced line or auxiliary source signals to be fed to any output at either
microphone, balanced line or auxiliary level. This allows great flexibility
to the system designer. Ideal for routing common signals to six different
zones or outputs in large installations, or for recording applications such
as media press conferences and courtrooms. The system can also be pow-
ered from 24V DC in battery backup situations.
Features
• 2 inputs to 6 outputs
• Compact 1RU design
• 240V AC or 24V DC operation
• Any input switchable to any output
• Each input & output can be set up for balanced mic/line or aux
• Individual input/output level controls
• All settings can be made without lifting the lid
• LED VU meters for each input
Specifications
Inputs: .......................................................................2 XLR 3 pin balanced mic 600 Ω
or switchable to balanced line 10k Ω
2 Line unbalanced dual RCA 10k Ω
Output: ...............................................................................6 XLR 3 pin balanced 50 Ω
6 Line unbalanced dual RCA 10k Ω
Controls: ......................................................................................2 input level controls
6 output level controls
Frequency response: ..............................................................................55Hz - 30kHz
S/N ratio:......................................................................................................Mic >60dB
Line > 70dB
Indicators ........................................................................................power, input signal
Power supply:...............................................................................240V AC or 24V DC
Dimensions:...........................................................................482W x 210D x 44H mm
Weight: ................................................................................................................
≈ 3 kg
Colour: .................................................................................................................Black

A 4415 2 Input / 6 Output Audio Splitter
Page 2
DIP Switch Setup
The DIP switches on the front panel are used to
route inputs 1 and 2 to all 6 outputs.
Figure 1 shows the DIP switches related to outputs
1 and 2.
In this example:
Switch 1 will route input 1 to output 1
Switch 2 will route input 2 to output 1
Switch 3 will route input 1 to output 2
Switch 4 will route input 2 to output 2
Any configuration can be used. ie inputs 1 and 2
can be routed to outputs 1 and 2 simultaneously.
Figure 2 shows the configuration for outputs 1 and
2 plus the DIP switch associated with these out-
puts.
This DIP switch allows each of the 6 outputs to be
configured as either balanced microphone or bal-
anced line level signal.
In this example DIP switch 1 will set output 2 to
either XLR balanced or RCA balanced line level.
DIP switch 4 will set output 2 to either XLR bal-
anced or RCA balanced line level.
Figure 3 shows the configuration for all the DIP
switches on the rear of the unit. Switches 2 and 3
have no connection.
Power
The unit can be powered from a 24V DC source for
use in battery backup installations. Connection is
via 2.1mm DC socket..
Figure 1: Front panel DIP switches relating to outputs 1 and 2.
Figure 2: Rear panel DIP switches relating to outputs 1 and 2.
Figure 3: Rear panel DIP switch configuration. This is also printed on the rear of the unit
for handy reference.
Mic
ON
1234
Line
Mic
No Connection
Line
FRONT PANEL
REAR PANEL
1. 240V AC input
2. 24V DC input
3. Output 6 RCA line level
4. Output 5 RCA line level
5. Output 6 XLR 3 pin mic level
6. Output 5 & 6 DIP switches
7. Output 5 XLR 3 pin mic level
8. Output 4 RCA line level
9. Output 3 RCA line level
10. Output 4 XLR 3 pin mic level
11. Output 3 & 4 DIP switches
12. Output 3 XLR 3 pin mic level
13. Output 2 RCA line level
14. Output 1 RCA line level
15. Output 2 XLR 3 pin mic level
16. Output 1 & 2 DIP switches
17. Output 1 XLR 3 pin mic level
18. Input 2 RCA line level
19. Input 1 RCA line level
20. Input 2 XLR 3 pin mic level
21. Input 1 & 2 DIP switches
22. Input 1 XLR 3 pin mic level
Power
On
REDBACK
A44152Input/6Output
AudioSplitter
6
8
2
010
46
8
2
010
4
6
8
2
010
4
6
8
2
010
4
6
8
2
010
4
6
8
2
010
4
6
8
2
010
46
8
2
010
4
1234
ONDIP
1234
ONDIP
1234
ONDIP
+10dB
0dB
-10dB
-20dB
+10dB
0dB
-10dB
-20dB
Input1Input2
Output1Output2Output3Output4Output5Output6
1234
ONDIP
1234
ONDIP
1234
ONDIP
1234
ONDIP
1
3
2
1
3
2
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
24VDCIN
-+
240VAC
MadeInAustraliaby
AltronicDistributorsPtyLtd
www.altronics.com.au
Input1
Input2
Output1
Output2
Output3
Output4
Output5
Output6
Input1
Input2
Output1
Output2
Output3
Output4
Output5
Output6
1234
ONDIP
Mic
Line
NoConnection
Mic
Line
1.
1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. 18. 19. 20. 21. 22.
2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15.
1. Input 1 level adjustment
2. Input 1 VU meter
3. Input 2 level adjustment
4. Input 2 VU meter
5. Output 1 level adjustment
6. Output 1 & 2 DIP switches
7. Output 2 level adjustment
8. Output 3 level adjustment
9. Output 3 & 4 DIP switches
10. Output 4 level adjustment
11. Output 5 level adjustment
12. Output 5 & 6 DIP switches
13. Output 6 level adjustment
14. Power LED
15. Power switch
