Redback 107330 User manual

This safety alert symbol identies important safety messages in
this manual. Failure to follow this important safety information may
result in serious injury or death.
MODEL # 107330
Operation Manual
!
Part # 107860 Rev A
Robotic Lawn Mower

1100 W 120th Ave, Suite 600
Westminster, CO 80234 • 720-287-5182
For Service or Questions
Call 1-877-487-8275
720-287-5182
www.redbackpowerusa.com
Redback products are distributed by

3
Table of Contents
Important Safety Information
Intended Use ...........................................................................................4
Personal Protective Equipment ...........................................................4
General Safety ........................................................................................5
Safety Decals ..........................................................................................6
Overview of Components.........................................................................7
Planning and Laying Boundary Lines ....................................................8
Docking Station Installation....................................................................9
Testing The Docking Station.................................................................10
Operation
Mowing...................................................................................................11
Sensors...................................................................................................12
Maintenance and Storage .....................................................................13
Replacing the Blades ...........................................................................13
Troubleshooting................................................................................. 15-15
Warranty and Specifications ..............................................Back Cover

4
Important Safety Information
WARNING: Read and thoroughly understand all instructions
and safety information before assembling or operating the Robot
Mower. Failure to do so may cause serious injury. Do not allow
anyone to operate this Robot Mower who has not read this manual.
As with all power equipment, a Robot Mower can be dangerous if
assembled or used improperly. Do not operate this mower if you
have doubts or questions concerning safe operation.
Call our customer service department at 720-287-5182,
1-877-487-8275, or visit www.redbackpowerusa.com if you
have any questions or concerns about the safe operation of this
equipment.
Intended Use
The Robot Mower has been designed for residential lawn mowing
up to 1/4 acre in area. It is not suitable for lawns with grades
greater than 30°. Do not use the Robot Mower for any purpose
other than for which it was designed. Any other use is unauthorized
and may result in serious injury.
Personal Protective Equipment
Always remove the security key before lifting, moving or
transporting the Robot Mower. When handling the Robot Mower
it is important to avoid the blades that are two sided and double
edged and therefore extremely sharp. It is recommended to wear
safety gloves to make adjustments to the Robot Mower or when
changing the blades or blade disc.
!
WARNING
!
DANGER

5
Important Safety Information
General Safety
Failure to follow warnings, cautions, assembly and operation instructions
in the Operation Manual may result in serious injury.
READ THE OPERATION MANUAL BEFORE OPERATION.
• Do not permit children to operate this equipment at any time.
•Do not permit others that have not read and understood the complete
Operation Manual to operate this equipment.
• Keep all people and pets a minimum of 10 feet away from the work
area.
• Do not operate the Robot Mower in rain or other wet conditions.
• Use caution when handling the Robot Mower. Blades are extremely
sharp.
• The security key should be removed before any adjustments are made.
Docking Station
• Use only the docking station designed for the Robot Mower.
• Do not attempt to modify the Robot Mower or the docking station in any
way other than specied by the manufacturer.
• When battery replacement is required, replace only with an original or
manufacturer authorized replacement.
•DO NOT dispose of the Robot Mower in household waste.
•DO NOT dispose of the battery in household waste.
• Ensure correct installation of the boundary wire.
• Make a regular inspection of the Robot Mower’s working area and
remove stones, branches, toys and other objects that may cause
damage to the robot.
• Never place anything on top of the Robot Mower or the docking station.
• Check the blades or wear and replace when necessary.
• Check that bolts, screws and nuts are securely fastened to ensure the
optimum operation of the Robot Mower.
• Avoid running the Robot Mower in wet grass. Clean the Robot Mower’s
wheels and wheel holder carefully of earth, grass and dust to avoid
imbalance.
!
DANGER

6
Important Safety Information
Safety Icons
Safety icons are to remind you of important information while
you are operating the unit.
Safety Decals
Safety decals on the Robot Mower are to remind you of
important information while you are operating the unit. Make
sure all decals are attached and in readable condition. Replace
missing or defaced decals. Contact Redback USA at 1-877-487-
8275 for replacement decals.
Use caution when operating this power
equipment.
Read and understand the Operation
Manual before operating the Robot
Mower.
The Robot Mower has sharp blades. Use
caution when operating, transporting and
handling.
The Robot Mower may throw objects.
Keep children, pets and bystanders away
from mower when operating.
!
The Robot Mower has sharp blades. Use
caution when operating around other
people and pets.
Keep your hands and feet away from the
rotating blades. Use extreme caution when
lifting and transporting. Wear gloves to
handle the blades or blade disc.
Avoid operating in the rain, protect the
battery and docking station from wet
conditions.
The Robot Mower can only start when the
security key is correctly inserted. Remove
this key when performing any maintenance.
!
READ
OPERATORS
MANUAL
MAY
THROW
OBJECTS
KEEP
SAFE
DISTANCE
KEEP
HANDS AND
FEET AWAY
REMOVE
KEY BEFORE
SERVICING
107854
CAUTION
SHARP BLADES!
USE CARE WHEN
HANDLING. 107859
KEEP HANDS and FEET AWAY
DANGER
107
8
55
107855
107859
107854
!
READ
OPERATORS
MANUAL
MAY
THROW
OBJECTS
KEEP
SAFE
DISTANCE
KEEP
HANDS AND
FEET AWAY
REMOVE
KEY BEFORE
SERVICING
107854
!
READ
OPERATORS
MANUAL
MAY
THROW
OBJECTS
KEEP
SAFE
DISTANCE
KEEP
HANDS AND
FEET AWAY
REMOVE
KEY BEFORE
SERVICING
107854
!
READ
OPERATORS
MANUAL
MAY
THROW
OBJECTS
KEEP
SAFE
DISTANCE
KEEP
HANDS AND
FEET AWAY
REMOVE
KEY BEFORE
SERVICING
107854
!
READ
OPERATORS
MANUAL
MAY
THROW
OBJECTS
KEEP
SAFE
DISTANCE
KEEP
HANDS AND
FEET AWAY
REMOVE
KEY BEFORE
SERVICING
107854
!
READ
OPERATORS
MANUAL
MAY
THROW
OBJECTS
KEEP
SAFE
DISTANCE
KEEP
HANDS AND
FEET AWAY
REMOVE
KEY BEFORE
SERVICING
107854

7
Overview of Components
Parts List
Item Quantity
Docking Station 1
Robotic Lawn Mower 1
Blades 9
Blade Retaining Screws 9
AC Lithium Ion Adapter 1
Adapter Cord 1
Docking Station Connection Cord 1
Docking Station Stakes 4
Boundary Line 328 feet
Boundary Line Stakes 100
Security Keys 4
AC Lithium Ion
Adapter
Docking Station
Connection
Cord
Docking
Station
Emergency
Stop
Security
Key
Power
Switch
Control
Panel
(Front Cover)
Start
Mow Area
Sizes
Home
Height
Adjustment
(Rear Cover)
Control Panel
(Front Cover)
Boundary
Line Stakes
Security
Key
Docking
Station
Stakes
Blades
Screws
LED
Indicator
Charging
Contacts
AC Adapter
Cord
Boundary Wire
Terminals

8
Planning and Laying the Boundary Line
Laying Boundary Lines
In order to make the Robot Mower mow within the desired
area – and only that area – you need to mark the area by means
of boundary wiring. Remove all foreign objects, rocks, roots,
etc. that may interfere with the Robot Mower’s operation in the
mowing area. Large objects such as trees, swings sets, ponds
should be encircled by the boundary line. The boundary wire
line needs to be laid out in a continuous line (see Figure 1).
Route the boundary line around objects using a minimum of
100° angles (135° angles are recommended). Keep the line at
least 12” from the lawn’s edge and from any object (see Figure
1). Keep the boundary line at least 6.5 feet (78”) wide at the
narrowest part of the lawn. Do not allow the boundary wire to
cross itself.
The boundary line should be placed at the root level of the grass
(see Figure 2). Secure the boundary line into the ground and
anchor with the boundary stakes. Place a stake approximately
every 3 feet.
NOTE: The Robot Mower will nd it difcult to work on grades
greater than 30°. On slopes steeper than 30° the robot’s sensor
will shut the mower off.
Figure 1
Figure 2

9
Docking Station Installation
The docking station must be placed on a solid, at surface.
Avoid placing the docking station in a corner of the lawn or in low-lying
areas where the docking station or the Robot Mower may be damaged
by puddles, or under a high tree due to the risk of lightning.
Note: It is important that the adapter and the electrical plug are always
kept dry!
The docking station must have 6.5 feet of free space in front of it so the
Robot Mower can return to charge or when mowing is complete (see
Figure 3). The docking station must be located on level ground for correct
operation.
Connecting the Boundary Line to the Docking Station
Strip 1/4” of plastic coating from either end of the boundary wire to
ensure a good connection. Remove the terminal cover on the back
of the docking station. Insert the boundary line ends into the docking
station (see Figure 4). Route the “IN” end of the boundary line beneath
the docking station and secure within the plastic brackets on the bottom
of the dock. Place the “IN” wire into the red terminal. After laying and
securing the boundary line, place the “OUT” end of the boundary wire
into the black terminal (see Figure 4). Secure the docking station to the
ground with four long ground stakes provided.
Figure 3
Red
Terminal
Black
Terminal Detail of
Connection
Terminal
Back of the
Docking Station
Figure 4
Red
Terminal
Black
Terminal

10
Testing the Docking Station
Charging The Robot Mower
1. Attach the AC adapter cord to the AC adapter.
2. Attach the docking station connection cord to the AC adapter
and to the docking station.
3. Place the Robot Mower in the docking station for charging
ensuring that the contacts on the Robot Mower engage the
charging arms on the docking station on both sides.
Testing the Docking Station
1. Plug the adapter into an AC power outlet. The green LED
should light up.
2. Disconnect the boundary wire from the red terminal and the
green LED should blink and an alarm sounds.
3. Reconnect the boundary line into the red terminal and the
green LED lights continually which indicates that the dock is
connected correctly and ready to charge the Robot Mower.
4. Place the Robot Mower into the docking station making sure
the front of the mower is in contact with the charging arms
on the dock. Allow the mower to charge for 2 - 3 hours before
use.
Preparation for Use
1. Remove all obstacles is the mowing area before starting the
Robot Mower.
2. If the grass is taller than 2-3/8”high (60mm) it is recommended
that you mow the lawn rst with a traditional lawn mower or
set the Robot Mower at its highest cutting position.
Notes on Operation
1. The Robot Mower will sense the presence of rain and return
to the docking station following a course along the boundary
line.
2. The Robot Mower will sense a battery power decline when
there is 20% or less capacity and will automatically return to
the docking station to recharge its battery.
3. Low temperature may effect the operating time.
4. Bumper sensors on the robot mower will cause it to change
direction when it encounters an obstacle.
5. Blades stop rotating in 3 seconds when the mower senses an
incline greater than 30°, the mower is lifted or in the presence
of rain.

11
Operation
Mowing
1. Lift the rear cover on top of the mower and adjust the cutting height
with the height adjustment dial. Close the cover before starting.
2. Lift the front cover to access the control panel and insert the security
key into the security key slot (see Figure 5). Close the cover.
3. Insert the security key and press the Power Switch to turn mower on.
4. Select the mow area size by pressing one of the three area buttons.
1/16 acre (~2,750 ft2)requires 4 hours operating time,
1/8 acre (~5,500 ft2) requires 8 hours operating time, or
1/4 acre (~11,000 ft2) requires 12 hours operating time.
5. Press the Start button. The timer begins when the Start button is
depressed. The cutting cycle will repeat in 24 hour intervals. Remove
the security key after starting to prevent any alterations in the
programmed cycle. The Robot Mower will start by cutting along the
boundary wire.
6. The second time the robot runs from the docking station, it will mow
randomly in straight lines until there is 20% left of the battery, then
return to the docking station to recharge. After one hour of charging
the robot will resume cutting until working a total number of hours
corresponding to the size of lawn selected. Then it returns to the
docking station to wait for the next timed cycle.
NOTE: You can stop the Robot Mower at any time by pressing the red
STOP bar on top of the mower (see Figure 6). Press the HOME button to
send the robot mower back to the charging station.
7. To restart the Robot Mower after it has automatically shut down the
mower must be within 6-1/2 feet of the boundary wire and you must
reselect the mow area size and press the Start button. If the robot is
restarted when in the docking station a new timing cycle will begin.
Figure 6
Security
Key
Power
Switch
Start
Mow Area
Sizes
Home
Control Panel
(Front Cover)
Figure 5

12
Sensors
Obstacle/Contact Sensor
When the Robot Mower meets an obstacle, it will reverse and
change direction to avoid the obstacle. If it does not nd a new
path within 3 seconds, the cutting motor stops. If it does not nd
a new path within 10 seconds, the robot will shut down and it
will require a manual restart to start again.
Rain Sensor
In case of heavy rain, the Robot Mower will automatically return
to the docking station. It will automatically start working the
next day at the time originally started.
Lift Sensor
This sensor is placed close to the wheels and measures the
gravity of the wheels. If the Robot Mower is lifted manually or if
both wheels run into a hole, the robot will shut down and must
be restarted manually.
Tilt Sensor
A 6-axle sensor is integrated in the Robot Mower to measure
the tilt angle in all directions. If the tilt angle exceeds 30°,
the cutting motor will stop immediately but continue driving
(see Figure 7). If the angle decreases to less than 30° within
10 seconds, the cutting motor will restart automatically. If,
however, the angle does not decrease within 10 seconds the
mower will shut down and will require a manual restart.
Figure 7

13
Maintenance and Storage
Cleaning the Robot Mower
Lift the front and rear covers and remove any collected debris, grass
clippings and dust using a soft brush, vacuum or damp cloth. Repeat for
the bottom side of the robot using care when handling the blade disc and
blades. It is important to keep the blades free from accumulated grass
clippings to ensure proper operation of the robot mower. Ensure all
retaining screws are secure.
Clean and brush the contacts on the robot mower and the docking
station charging arms with steel wool or emery paper.
Cleaning the Docking Station
Remove dirt, grass and other debris from the docking station base plate
on a regular basis.
Blade Replacement
The Robot Mower blades are accessible when you turn the mower
upside down (see Figure 8). Blades have two edges and two sides. The
blades can be turned over one time before replacing. Blade replacement
is indicated when grass shows prominent white edges after cutting or
the mower makes excessive vibration noise. Turn all three blades over or
replace all three blades by unscrewing the three retaining screws.
Blades are extremely sharp and will cut even when dull.
Use caution when replacing.
Wear gloves to protect hands from cuts.
Battery Replacement
The Robot Mower battery can be accessed by removing the four
retaining screws on the battery compartment cover on the bottom of
the Robot mower (see Figure 9). Always replace with a manufacturer’s
authorized replacement.
Storage
Disconnect the docking station from the AC power adapter. Remove
the ends of the boundary wire from the docking station. Turn the power
switch off on the Robot Mower to protect the battery. Store the Robot
Mower, docking station and AC adapter and cords in a dry frost free
area. Cover the ends of the boundary wire with electrical tape. To help
preserve the life of the battery, check the charge status of the battery
and recharge the battery in the docking station at regular intervals.
!
DANGER
Cutting
Blades
Blade
Disc
Figure 8
Retaining
Screws
Figure 9

14
Troubleshooting
Symptom Cause Action
Robot doesn’t leave docking station. Security key is not engaged. Manual start requires security key.
Battery is not charged. Allow robot to charge until LED
indicator displays constant green.
Docking station not installed IN arrow on docking station should
correctly. point to inside of working area.
Boundary wire not installed Wire end routed under docking
correctly. station should be connected to the
RED terminal.
Robot’s initial tracking is incorrect. Boundary wire not installed Adjust boundary wire so robot
correctly. follows desired path.
Interference from underground Reroute boundary wire around
power source. obstacle source.
Robot does not reconnect to Docking station is not level. Reinstall docking station on at
charging blades on return to level surface.
docking station.
Testing the Docking Station
Symptom Cause Action
Robot stops with red LED ashing. Slope is greater than 30°, Reroute boundary wire to avoid
tilt sensor engages. slope.
Robot cannot detect signal Ensure wire is connecting to
in boundary wire. docking station terminals.
Check for break in boundary wire
and splice ends together.
Lift sensor activated. Ensure wheels are not obstructed
or in unlevel spot in mowing area.
Robot stops with green LED ashing. Robot not programmed Place robot back in docking
correctly. station and restart.
Robot stops with no LED displaying. Battery is out of power. Replace robot in docking station
and allow to charge 2 - 3 hours.
First Robot Mower Use

15
Troubleshooting
Symptom Cause Action
Robot leaves boundary area or Wheels are obstructed. Remove debris from mowing area
stops beyond boundary line. and/or clean robot’s wheels.
Grass is wet and/or slope is Reroute boundary wire to avoid
too close to boundary edge. slope. Do not operate in wet
conditions.
First Robot Mower Use
Symptom Cause Action
Excessive vibration and noise. Cutting system unbalanced; Turn power off and reverse or
blades are dull. replace all three blades.
Blade disc is damaged. Replace blade disc.
Disc retaining screws loose. Tighten screws securely.
Working time between charges Charging contacts are dirty. Clean charging contacts on the
decreases. robot and the docking station.
Brush lightly with steel wool.
Battery capacity diminished. Replace battery.
Robot does not leave docking Rain sensor is still activated. Dry and clean metal contacts.
station after rain sensor is activated. Then restart robot mower.
Normal Robot Mower Use

Model No.
Serial No.
Date of Purchase
Place of Purchase
Warranty and Specications
IMPORTANT NOTICE
We, the manufacturer, reserve the right to change the product and/
or specications in this manual without notication. The manual is for
information usage only and the pictures and drawings depicted herein are
for reference only.
Warranty Repair and Service
Do not return this product to the store for warranty issues or repair. Call
our customer service department at 720-287-5182, 1-877-487-8275, or visit
www.redbackpowerusa.com for the location of the nearest service center.
Record the information below for future reference.
1100 W 120th Ave., Suite 600
Westminster, CO 80234 • 720-287-5182
Redback products are distributed by For Service or Questions
Call 1-877-487-8275
720-287-5182
www.redbackpowerusa.com
SKU/Part No. 107330
Lithium Battery Voltage 28V
Lithium Battery Capacity 4Ah
Motor Type Brushless
Blade Speed 2900 rpm
Cutter Type 3 Blades
Cutting Width 9.5 inches
Cutting Height 1 - 3 inches
Mowing Areas 1/16 acre (~2,750 ft2)
1/8 acre (~5,500 ft2)
1/4 acre (~11,000 ft2)
Maximum Climb Angle 30˚
Maximum Walking Speed 1.64 ft/sec
Standard Wire Length 330 ft
Optional Wire Length 1,640 ft
Warranty 2 Years Limited/1 Year Limited on Battery
