Redback MOWRO RM24 User manual

this manual. Failure to follow this important safety information may
result in serious injury. Carefully read and understand the manual
completely before attempting to operate the MowRo.
Operation Manual
!
MOWRO RM24

For Service or Questions
Call 1-800-976-3009
www.mowro.com

Table of Contents
Important Safety Information .................................................................
.............................................................................
.....................................................................
....................................................................
.................................................................
..................................................................................
.................................................................................
.......................................................
.......................................................................................
...................................................
............................................................................
4
Warranty Information 7
Mower Part and Overview 8
Planning and Layout Guide 10
Docking Station Installation 12
Mower Operations 13
Color Customization 17
........................................................................................
Mower Sensors 16
Mower Maintenance and Storage 18
Troubleshooting 20
Trouble Shooting Information Codes 21
Product Specifications 23
3
Installation
Video
http://installvideo.mowro.com

4
Important Safety Information
WARNING: Read and thoroughly understand all instructions
and safety information before assembling or operating the MowRo
Lawn Mower. Failure to do so may cause serious injury. Do not allow
anyone to operate this MowRo Lawn Mower who has not read this manual.
As with all power equipment, the MowRo can be dangerous if
assembled or used improperly. Do not operate this mower if you
have doubts or questions concerning safe operation.
Call our customer service department at 1-800-976-3009, or
www.mowro.com if you have any questions or
concerns about the safe operation of this equipment.
Intended Use
The MowRo Lawn Mower has been designed for residential lawn mowing
up to 0.25 acre in area. It is not suitable for lawns with grades
greater than 30°. Do not use the MowRo for any purpose
other than for which it was designed. Any other use is unauthorized
and may result in serious injury.
Personal Protective Equipment
Always have the MowRo stopped before lifting, moving or
transporting the MowRo. When handling the MowRo Lawn
Mower it is important to avoid the blades that are two sided
and double edged and therefore extremely sharp. It is
recommended to wear safety gloves to make adjustments
to the MowRo or when changing the blades or blade disc.
!
WA R NI N G
!
DANGER
visit

5
Important Safety Information
General Safety
Failure to follow warnings, cautions, assembly and operation instructions
in the Operation Manual may result in serious injury.
!
DANGER
READ THE OPERATION MANUAL BEFORE OPERATION.
• Do not permit children to operate this equipment at any time.
•Do not permit others that have not read and understood the complete
Operation Manual to operate this equipment.
• Keep all people and pets a minimum of 10 feet away from the work
area.
• Do not operate the MowRo in rain or other wet conditions.
• Use caution when handling the MowRo. Blades are extremely
sharp.
Docking Station
• Use only the docking station designed for the MowRo.
• Do not attempt to modify the Robot Mower or the docking station in any
• When battery replacement is required, replace only with an original or
manufacturer authorized replacement.
•DO NOT dispose of the MowRo in household waste.
•DO NOT dispose of the battery in household waste.
• Ensure correct installation of the boundary wire.
• Make a regular inspection of the MowRo’s working area and
remove stones, branches, toys and other objects that may cause
damage to the robot.
• Never place anything on top of the MowRo or the docking station.
• Check the blades for wear and replace when necessary.
• Check that bolts, screws and nuts are securely fastened to ensure the
optimum operation of the MowRo.
• Avoid running the MowRo in wet grass. Clean the MowRo’s
wheels and wheel holder carefully of earth, grass and dust to avoid
imbalance.

6
Important Safety Information
Safety Icons
Safety icons are to remind you of important information while
you are operating the unit.
Safety Decals
Safety decals on the MowRo are to remind you of
important information while you are operating the unit. Make
sure all decals are attached and in readable condition. Replace
missing or defaced decals. Contact us at 1-800-976-3009 or go to
www.mowro.com for replacement decals.
Use caution when operating this power
equipment.
Read and understand the Operation
Manual before operating the MowRo
Lawn Mower.
The MowRo has sharp blades. Use
caution when operating, transporting and
handling.
The MowRo may throw objects.
Keep children, pets and bystanders away
from mower when operating.
!The MowRo has sharp blades. Use
caution when operating around other
people and pets.
Keep your hands and feet away from the
rotating blades. Use extreme caution when
lifting and transporting. Wear gloves to
handle the blades or blade disc.
Avoid operating in the rain, protect the
battery and docking station from wet
conditions.
!
READ
OPERATORS
MANUAL
MAY
THROW
OBJECTS
KEEP
SAFE
DISTANCE
KEEP
HANDS AND
FEET AWAY
CAUTION
SHARP BLADES!
USE CARE WHEN
HANDLING.
KEEP HANDS and FEET AWAY
DANGER
107854

7
IMPORTANT NOTICE
Redback warranties this product, to the original purchaser with proof of purchase,
for a period of two (2) years against defects in materials, parts or workmanship.
Redback, at its own discretion, will repair or replace any and all parts found
to be defective, through normal use. This warranty is valid for only units that
have been used for personal use, and that has been maintained in accordance
with the instructions in the owner’s manual.
The battery carries a one (1) year limited warranty, including warranty against
defects in workmanship and materials. Batteries must be charged in accordance
with the owner’s manual directions and regulations in order to be valid.
Transportation charges for the movement of any unit are the responsibility of the
purchaser. It is the purchaser’s responsibility to pay transportation charges for
any product submitted for replacement under this warranty, unless such return
is requested in writing by Redback.
This warranty is null and void in the event of the installation of unauthorized
spare parts.
Items not covered by warranty:
1. Any part that has become inoperative due to misuse, commercial use,
abuse, neglect, accident, improper maintenance, or alteration; or
2. The unit, if it has not been operated and/or maintained in accordance
with the owner’s manual; or
3. Normal wear, except as noted below;
4. Routine maintenance items such as lubricants, unauthorized blades;
5. Normal deterioration of the exterior finish due to use or exposure.
Redback Helpline:
Contact Us: 1-800-976-3009 www.mowro.com

8
AC Lithium Ion
Adapter
Docking Station
Connection
Cord
Docking
Station
Emergency
Stop
Control
Panel
(Front Cover)
Height
Adjustment
(Rear Cover)
B
L
Charging
Contacts
AC Adapter
Cord
Boundary W
Terminals
Boundary Wire
Terminals
Overview

9
Overview
PIN Code Clock Mow Area Start Time Rain Sensor
Power switch
Settings
Battery Capacity
6 docking station ground screws
150 boundary line pegs
6 spare blades with screws
100m boundary line
100m boundary line
2 Wire Clamps
4 Wire Splicers

10
Planning and Laying the Boundary Line
Laying Boundary Lines
In order to make the Robot Mower mow within the desired
area – and only that area – you need to mark the area by means
of boundary wiring. Remove all foreign objects, rocks, roots,
etc. that may interfere with the Robot Mower’s operation in the
mowing area. Large objects such as trees, swings sets, ponds, etc. should
be encircled by the boundary line. The boundary wire line needs
to be laid out in a continuous line (see Figure 2 on following page).
Route the boundary line around objects using a minimum of
100° angles (135° angles are recommended). Keep the boundary
line at least 30cm (12”) away from any: walls, drop-offs, or uneven
edge. If the lawn is level with the edge of the grass set the wire 10cm
(4”) away from the edge. Do not allow the boundary wire to
cross itself.
The boundary line should be placed at the root level of the grass
(see Figure 1). Secure the boundary line into the ground and
anchor with the boundary stakes. Place a stake approximately
every 3 feet.
greater than 30°. On slopes steeper than 30° the robot’s sensor
will shut the mower off.

Figure 2
Ensure
this
side of
docking
station is
facing inward
to the lawn.
11

12
Docking Station Installation
Avoid placing the docking station in a corner of the lawn or in low-lying
areas where the docking station or the Robot Mower may be damaged
by puddles, or under a high tree due to the risk of lightning.
Note: It is important that the adapter and the electrical plug are always
kept dry!
The docking station must have 6.5 feet of free space in front of it so the
Robot Mower can return to charge or when mowing is complete (see
Figure 3). The docking station must be located on level ground for correct
operation.
Connecting the Boundary Line to the Docking Station
Remove the terminal cover located on the back of the docking station. Insert the
end of the boundary wire into a blue T- clip and use a pair of pilers to press the
clip on the wire until you hear a click. Repeat this action on the other end of the
wire. Insert the wire that leaves the docking station into the negative (-) metal
prong. Connect the wire that comes from under the docking station to the
positive (+) metal prong. Proceed to plug in the docking station and confirm
the LED is a solid GREEN light. If the LED is flashing RED and GREEN confirm all
of your docking station connections are securely inserted and the boundary
wire does not have any cuts or breakage.
Figure 4
IN OUT
CLICK
Figure 3

13
Operation
PIN Code Clock Mow Area Start Time Rain Sensor
Power switch
Settings
Battery Capacity
Mower Operation
Note: To ensure proper setup, verify that the mower is fully charged and is in
contact with the docking station.
Note: Make sure that the path of perimeter is compeltly clear before operating.
Unlocking the Mower
1) Turn on the mower by switching the red button
(located to the left of the LCD screen)
2) The LCD screen will show “Idle”.
3) Press the “Set” button one time.
4) Four zeros and battery life symbol will show
on the LCD screen. (This is the PIN code)
5) The first zero will be blinking.
6) Press the “OK” button four times to unlock the mower.
(The factory default code is: 0000)
7) The mower is now unlocked, and the user may change the settings of the mower.
Manual Start
1) Unlock the mower. (If locked, see steps 1-7 in
the Unlocking the Mower section.)
2) Press the “Start” Button and the mower will immediately start to mow.

14
Operation
Settings Guide and Automatic Start
1) Unlock the mower. (If locked, see steps 1-7 in the Unlocking the Mower section.)
2) Once the mower is unlocked press the “Set” button to shift through the icons
at the top of the screen.
Setting Your Security PIN
1) Unlock the mower. (If locked, see steps 1-7 in the Unlocking the Mower section.)
2) Press the “Set” button until the lock icon is showing on the top the LCD screen.
3) Upon reaching the lock icon, your screen will display four zeros, with the first
zero blinking.
4) From this screen, you can switch between the zeros by pressing
the “OK” button.
5) To set your PIN, shift to the desired zero and use the up and down
arrows located on the “Home” and “Start” button to set the number.
6) Repeat steps four and five for all remaining numbers.
7) Once you have entered your desired PIN, press the “OK” button to toggle
through all the numbers until none of them are blinking.
8) Press “Set” to save your PIN.
Setting the Clock
Note: For the mower to properly operate on a schedule, you will need to set the
time on the mower’s clock.
Note: THE CLOCK IS FORMATTED IN MILITARY TIME.
1) Unlock the mower. (If locked, see steps 1-7 in the Unlocking the Mower section.)
2) Press the “Set” button until the clock icon is showing at the top of the
LCD screen.
3) Upon reaching the clock icon, your screen will display four zeros, with the first
zero blinking.
4) From this screen, you can switch between the zeros by pressing the
“OK” button.
5) To set the time, shift to the desired zero and use the up and down arrows
located on the “Home” and “Start” button to set the number.
6) When complete, toggle to the end of all the numbers until none of them are blinking.
7) Press “Set” to save the time.

15
Operation
Setting the Mow Area
Note: Roughly measure the size of your lawn to determine its area.
1) Unlock the mower. (If locked, see steps 1-7 in the Unlocking the Mower section.)
2) Press the “Set” button until the meters squared icon is showing at the top of
the LCD screen.
3) Use the up and down arrows located on the “Home” and “Start” to increase
or decrease the mowing area.
4) Press the “Set” button to save your mowing area.
Setting the StartTime
Note: The start time function will not work unless the clock time is set correctly on
the mower. (See “Setting the Clock” Section)
Note: THE CLOCK IS FORMATTED TO MILITARY TIME.
1) Unlock the mower. (If locked, see steps 1-7 in the Unlocking the Mower section.)
2) Press the “Set” button until the hourglass icon is showing at the top of the
LCD screen.
3) Upon reaching the hourglass icon, the first number in the sequence will
be blinking.
4) Press the up and down arrows located on the “Home” and “Start” buttons
to change the number.
5) Press the “OK” to shift to the next number in the sequence, and set the time
you want the mower to start.
6) Once time is set, press the “OK” button until none of the numbers in the
sequence are blinking, then press the “Start Button”.
7) The mower will begin mowing the area of your lawn.
Note:The mower will begin its first session immediately, once
the “Start” button is pressed manually. Scheduled mowing set
by the user will begin 48 hours after the initial manual session
has completed.

16
Operation
Rain Sensor
NOTE: The rain icon will only display on the LCD screen if the rain sensor
on the mower is wet. The rain sensor consitsts of two small metal circles that
are located to the left of the control panel and the external shell of the mower.
When the rain sensor is engaged, the mower will immediately find the boundary
wire and return to the docking station. Once the sensor is dry, the mower will
begin operation again.

17
Sensors
Obstacle/Contact Sensor
When the Robot Mower meets an obstacle, it will reverse and
a new path within 10 seconds, the robot will shut down and it
will require a manual restart to continue operation.
Rain Sensor
In case of heavy rain, the Robot Mower will automatically return
to the docking station. It will automatically start mowing the
next day at the time originally scheduled.
Lift Sensor
This sensor is placed close to the wheels and measures the
gravity of the wheels. If the Robot Mower is lifted manually or if
both wheels run into a hole, the robot will shut down and must
be restarted manually.
Tilt Sensor
A 6-axle sensor is integrated in the Robot Mower to measure
the tilt angle in all directions. If the tilt angle exceeds 30°,
the cutting motor will stop immediately but continue driving
(see Figure 7). If the angle decreases to less than 30° within
10 seconds, the cutting motor will restart automatically. If,
however, the angle does not decrease within 10 seconds the
mower will shut down and will require a manual restart.
MowRo Model
Grade Capabilities
RM18- 20˚ (35%)
RM24 - 30˚ (50%)
30˚ (50%) MAXIMUM GRADE

18
Maintenance and Storage
Cleaning the Robot Mower
Lift the front and rear covers and remove any collected debris, grass
clippings and dust using a soft brush, vacuum or damp cloth. Repeat for
the bottom side of the robot using care when handling the blade disc and
blades. It is important to keep the blades free from accumulated grass
clippings to ensure proper operation of the robot mower. Ensure all
retaining screws are secure.
Clean and brush the contacts on the robot mower and the docking
station charging arms with steel wool or emery paper.
Cleaning the Docking Station
Remove dirt, grass and other debris from the docking station base plate
on a regular basis.
Blade Replacement
The Robot Mower blades are accessible when you turn the mower
upside down (see Figure 8). Blades have two edges and two sides. The
blades can be turned over one time before replacing. Blade replacement
is indicated when grass shows prominent white edges after cutting or
the mower makes excessive vibration noise. Turn all three blades over or
replace all three blades by unscrewing the three retaining screws.
Cutting
Blades
Blade
Disc
Figure 8

19
Maintenance and Storage
Blades are extremely sharp and will cut even when dull.
Use caution when replacing.
Wear gloves to protect hands from cuts.
!
DANGER
Storage
Disconnect the docking station from the AC power adapter. Remove
the ends of the boundary wire from the docking station. Turn the power
switch off on the Robot Mower to protect the battery. Store the Robot
Mower, docking station and AC adapter and cords in a dry frost free
area. Cover the ends of the boundary wire with electrical tape. To help
preserve the life of the battery, check the charge status of the battery
and recharge the battery in the docking station at regular intervals.
Winter Storage
During winter seasons, please follow all guidelines explained in the
Storage Section above. Failure to properly care for your MowRo
will void any remaining warranty.
Retaining
Screws

20
Troubleshooting
Symptom Cause Action
Robot doesn’t leave docking station. PIN not entered correctly. Enter factory default PIN (0000) or
PIN set by user.
Battery is not charged. Allow robot to charge until battery
symbol has 4 bars on LCD screen.
Docking station not installed IN arrow on docking station should
correctly. point to inside of working area.
Boundary wire not installed Wire end routed under docking
correctly. station should be connected to the
positive (+) metal prong.
Robot’s initial tracking is incorrect. Boundary wire not installed Adjust boundary wire so robot
correctly. follows desired path.
Interference from underground Reroute boundary wire around
power source. obstacle source.
Robot does not reconnect to Docking station is not level.
charging blades on return to level surface.
docking station.
Testing the Docking Station
Symptom Cause Action
Robot leaves boundary area or Wheels are obstructed. Remove debris from mowing area
stops beyond boundary line. and/or clean robot’s wheels.
Grass is wet and/or slope is Reroute boundary wire to avoid
too close to boundary edge. slope. Do not operate in wet
conditions.
First Robot Mower Use
Symptom Cause Action
Excessive vibration and noise. Cutting system unbalanced; Turn power off and reverse or
blades are dull. replace all three blades.
Blade disc is damaged. Replace blade disc.
Disc retaining screws loose. Tighten screws securely.
Working time between charges Charging contacts are dirty. Clean charging contacts on the
decreases. robot and the docking station.
Brush lightly with steel wool.
Battery capacity diminished. Replace battery.
Robot does not leave docking Rain sensor is still activated. Dry and clean metal contacts.
station after rain sensor is activated. Then restart robot mower.
Normal Robot Mower Use
NOTE: Forgot PIN? Contact
customer service
