Redback E142C User manual

40V LITHIUM-ION CORDLESS
LAWN MOWER
Model: E142C
Operations Manual
www.redbacktool.com [e-mail]

1
TABLE OF CONTENTS
•Symbols……………………........1
•Safety Instructions
and Warnings………………….. 2
•Product Specifications…………7
•Assembly and Operation………7
•Charging The Battery….……....10
•Exploded View and Part List….11
•Maintenance and Care………..12
•Disposal………………………...13
•Guarantee/Warranty…………..13
•Declaration of Conformity…….14
SYMBOLS
General Safety Warnings
1. After release the On/Off
switch, the cutter bar
continues running briefly.
Risk of injury!
2. To protect against injury from
the cutter blade, have a
specialist garage perform all
work such as replacing or
regrinding the cutter blade
(special tools required).
3. Protect the battery contacts
when the battery is not being
used. Loose metal parts may
short-circuit the contacts –
Explosion and fire hazard!
Before switching the power on,
read the operating manual. Read
all safety warnings and all
instructions including the the
currently valid site rules and the
regulations for the prevention of
accidents. Failure to follow the
warnings and instructions may
result in electric shock, fire and/or
serious injury.
Remove the safety key before
carrying out any work on the unit
and before leaving the unit.
Sharp cutting tool! Keep hands
and feet away from the cutter bar!
Do not throw
batteries and
other electrical products into the
household waste, fire, or water.
Recycle to protect
the environment.

2
Do not expose to rain or wet
conditions.
Protective goggles/visor, protective
helmet & hearing protection.
Safety Instructions
User
This garden tool is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction
concerning use of the machine by a
person responsible for their safety.
Never allow children or people
unfamiliar with these instructions to use
the garden tool. Supervise children. This
will ensure that children do not play with
the unit.
Intended Use
This garden tool is intended exclusively
to mow lawns according to the
descriptions and safety instructions
indicated in this operating manual.
Any other use is not as intended.
Improper use is not covered by the
warranty and the manufacturer will reject
any liability. The user is liable for all
injuries to third parties and damage to
their property.
Operate the unit only in the technical
condition as stipulated and delivered by
the manufacturer. Arbitrary changes to
the unit will exclude the manufacturer
from any liability for resulting injury
and/or damage.
Preparation
1. Familiarize yourself with the unit and
its functions as well as its controls.
2. Inspect the lawnmower before switching
it on and check for signs of wear and
damage. Never use the lawnmower with
damaged or missing guards, e.g. dis-
charge flap and/or grass catcher, housing,
etc.
3. Have damage repaired by a qualified
technician or the service center.
4. Do not use a unit which has a defective
switch and can no longer be switched on
or off.
5. When working with or on the unit,
always wear sturdy footwear and long

3
trousers. Do not operate the unit when
barefoot or wearing sandals.
6. Check the terrain on which the unit will
be used and remove any stones, sticks,
wires, bones and other foreign objects,
which could be picked up by the unit, to
avoid endangering people.
During Operation
1. Do not switch on the unit if there are
persons (particularly children)or animals in
the immediate vicinity.
2. Ensure that children do not play with
the unit.
3. Interrupt working if you notice that
persons (particularly children)or pets are
nearby.
4. Working on steep slopes can be
dangerous.
5. Ensure that you have a firm footing
and mow slowly.
6. Always mow across the slope and
not up and down.
7. Be particularly careful when changing
direction. There is a risk of tripping!
8. Do not mow on steep slopes.
9. Be particularly careful when mowing
backwards and pulling the lawnmower
towards yourself.
10. Do not tilt the lawnmower when
switching on the motor.
11. Maintain a safe distance as provided
by the handle frame.
12. Do not switch on the motor until your
feet are at a safe distance from the cutter
bar.
13. Be careful and do not reach into the
rotating cutter bar.
14. Switch the lawnmower off before tilting
or transporting it, e.g. from/to lawn or over
paths.
15. Never run over gravel while the motor
is running. There is a risk of being hit by
stones!
16. Before lifting or transporting the lawn-
mower, switch the motor off, pull out the
safety key and wait until the cutter bar has
come to a standstill.
17. Do not adjust the cutting height until
the motor has been switched off and the
cutter bar has come to a standstill.
18. Never open the discharge flap while
the motor is running.
19. Before removing the grass catcher,
switch the motor off and wait until the
cutter bar has come to a standstill. After
emptying the grass catcher, carefully re-
attach it and ensure that the grass catcher
is attached securely to the lawnmower.
20. If possible, do not mow wet grass.
21. Do not work with the garden tool in a
potentially explosive environment in which
there are flammable liquids, gases or dust.
22. When interrupting work, never leave
the unit unattended and keep it in a safe
place.

4
For The Battery Charger
1. Do not place any objects on the
battery charger and do not place the
battery charger on soft surfaces.
2. Please read safety instructions for Li-
ion batteries. There is a risk of
explosion.
3. Liquid ejected from the battery may
cause irritation or burns.
4. If other batteries are used, e.g.
imitations, reconditioned batteries or
third-party products, there is a risk of
injuries as well as damage caused by
exploding batteries.
5. A charger that is suitable for one type
of battery pack may create a risk of fire
when used with another battery pack.
This may cause an internal short-circuit
and the battery to burn, smoke, explode
or overheat.
General Power Tool
Safety Warnings
The term "power tool" in the warnings
refers to your main-operated (corded)
power tool or battery-operated
(cordless) power tool.
Work Area Safety
1. Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
2. Do not operate power tools in
explosive atmospheres, such as in the
presence of flammable liquids, gases, or
dust. Power tools create sparks which
may ignite the dust or fumes.
3. Keep children and bystanders away
while operating a power tool.
Distractions can cause you to lose
control.
Electrical Safety
1. Power tool plugs must match the
outlet. Never modify the plug in any way.
Do not use any adapter plugs with
earthed (grounded) power tools.
Unmodified plugs and matching outlets
will reduce the risk of electric shock.
2. Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators.
There is an increased risk of electric
shock if your body is earthed or
grounded.
3. Do not expose power tools to rain or
wet conditions. Water entering a power
tool will increase the risk of electric
shock.
4. Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep the cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase
the risk of electric shock.
5. When operating a power tool
outdoors, use an extension cord suitable

5
for outdoor use. Use of a cord suitable
for outdoor use reduces the risk of
electric shock.
6. If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply.
Use of an RCD reduces the risk of
electric shock.
Personal Safety
1. Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power tool
while you are tired or under the
influence of drugs, alcohol, or
medication. A moment of inattention
while operating power tools may result
in serious personal injury.
2. Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing
protection used for appropriate
conditions will reduce the risk of injury.
3. Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to the power source and/or
battery pack, picking up, or carrying the
tool. Carrying power tools with your
finger on the switch or power tools that
have been turned on invites accidents.
4. Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a
rotating part of the power tool may
increase the risk of injury.
5. Do not overreach. Keep proper
footing and balance at all times. This
enables better control of the power tool
in unexpected situations.
6. Dress properly. Do not wear loose
clothing or jewelry. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewelry or long hair
can be caught by moving parts.
7. If devices are provided for the
connection of dust extraction and
collection facilities, ensure that these
are connected and properly used. Use
of dust collection can reduce dust-
related hazards.
Power Tool Use And Care
1. Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job
better and safer at the rate for which it is
designed.
2. Do not use the power tool if it can’t be
turned on and off by its switch. Any
power tool that cannot be controlled with
the switch is dangerous and must be
repaired.
3. Disconnect the plug from the power
source and/or the battery pack from the
power tool before making any
adjustments, changing accessories, or

6
before storing the power tool. Such
preventive safety measure reduces the
risk of starting the power tool
accidentally.
4. Store idle power tools out of reach of
children and do not allow persons
unfamiliar with the power tool or these
instructions to operate it. Power tools
are dangerous in the hands of untrained
users.
5. Maintain the power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other
condition that may affect the power
tool’s operation. If damaged, have the
power tool repaired before use. Many
accidents are caused by poorly
maintained power tools.
6. Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to
bind and are easier to control.
7. Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
Battery Tool Use And Care
1. Recharge only with the charger
specified by the manufacturer. A charger
that is suitable for one type of battery
pack may create a risk of fire when used
with another battery pack.
2. Use power tools only with specifically
designated battery packs. Use of any
other battery packs may create a risk of
injury and fire.
3. When battery pack is not in use, keep
it away from other metal objects like
paper clips, coins, keys, nails, screws,
or other small metal objects that can
make a connection from one terminal to
another. Shorting the battery terminals
together may cause burns or fire.
4. Under abusive conditions, liquid may
be ejected from the battery; avoid
contact. If you accidentally contact the
battery liquid, flush it with water. If the
battery liquid contacts the eyes, seek
medical help as soon as possible. Liquid
ejected from the battery may cause
irritation or burns.
Service
Have your power tool serviced by a
qualified repair professional using only
the identical replacement parts. This
will ensure that the safety of the power
tool is maintained.

7
PRODUCT
SPECIFICATIONS
Type
E142C
Nominal voltage
V
40
Battery
type
EP20
EP40
EP60
Ah
Ah
Ah
2.0
4.0
6.0
Charger
EC20
EC50
A
A
2.0
5.0
Deck size
inch
17”
Cutting height
inch
1”-3”
Capacity grass
catcher
gal.
10.5
Idle speed
r.p.m.
3300
Sound power level
LwA
dB(A)
96
Weight (without
battery)
Lbs
38
ASSEMBLY AND
OPERATION
Before Initial Operation
Unpack the tool and accessories to
check that no parts are missing or
damaged.
NOTE: The batteries (optional;
depending on delivery scope) are not
fully charged on delivery. Prior to initial
operation, charge the batteries fully. See
user manual of the battery charger.
Safety Key
The unit has a security key. The key is
located under the battery cover. By
removing the key, the power supply to
the motor is interrupted.
Remove the safety key:
a.) if the unit is left unattended;
b.) before checking, cleaning or
performing other work on the unit;
c.) before removing blockages;
d.) if a foreign object is hit;
e.) if the unit starts vibrating
excessively.
Check the lawnmower for damage, and
have any damage repaired at a qualified
technician or a service center.
To remove the key, press the lock and
pull out the safety key .
To insert the safety key, press down the
key until it clicks.

8
Assembly
Attaching The Handle Bar
Tools are not required to attach the
handle bar.
1. Fold the lower handle upwards.
Insert the two screws into the two
holes and fasten the bar with the
screws.
2. Place the upper handle on the
lower handle.
3. Attach the upper handle.
4. Insert the threaded bolt through
the holes in the upper handle and
the lower handle. Fasten the
5. screw with the triangle knob.
Attaching The Grass
Catcher
1. Lift the back cover of the mower.
2. Hook the grass catcher bag into the
lawn-mower.
3. Fold the back cover down again.
Adjusting The Cutting
Height
The cutting height can be adjusted from
1” to 3”.
1. Pull the handle outwards slightly.
2. Set the required cutting height.
3. Release the lever again.

9
Inserting/Replacing The
Battery
Ensure that the battery is fully charged
before inserting it into the tool.
1. Open the battery cover.
2. Press the charged battery into the
power tool until it clicks into place.
3. Close the battery cover.
Removing The Battery
1. Press the release button.
2. Pull out the battery.
GENERAL SAFETY WARNING
#3!
Switching The Power Tool
On
1. Press the switch interlock and hold
down (see #1 in the illustration
below).
2. Pull back On/Off switch towards the
handle (see #2 in the illustration
below).
3. The motor runs.

10
Switching The Power Tool
Off
1. Release the On /Off switch (see #2
in the illustration above).
GENERAL SAFETY WARNING
#1!
Removing And Emptying
The Grass Catcher
1. If the grass catcher bag is full and
should be emptied immediately.
2. Switch the motor off.
3. Wait until the cutter bar stops.
4. Lift the discharge flap.
5. Remove the grass catcher.
6. Lower the discharge flap down
again.
7. Empty the grass catcher.
8. Before hooking, remove any
obstructions from the cutting area
Working Without the Grass
Catcher
When working without the grass
catcher, the mowed
grass is ejected directly downwards.
Charging The Battery
1. Plug the charger into an AC outlet
100-250V (normal household voltage).
2. Insert the battery into the slots of the
charger and slide
into place until the battery locks into
place
3. The LED will flash green while the
battery is charging.
- Once the battery is fully charged, the
LED indicator will show a steady green
light.
- Remove the battery by pressing and
holding the latch button and sliding out
of the charger. Lithium Ion batteries
have no memory effect – a partial
charge will not damage your battery.
TIPS ON LAWN CARE
Here are some tips to help you keep your
lawn looking healthy and ensure uniform
growth:
Lawns consist of various grass types.
Frequent mowing promotes the growth of
grass, resulting in strong roots and a firm
sward. If you seldom cut the grass, you
will enhance the development of high-
growing types of grass and other weeds,
such as clover, daisies). The normal
height of a lawn is approx. 4–5 cm. Only
one third of the total height should be
mown; therefore cut 7–8 cm long grass to
normal height.

11
EXPLODED VIEW AND
PARTS LIST
1. Upper Handle
2. Fasten Screw
3. Lower Handle
4. Grass Catcher
5. Battery
6. Wheels
7. Switch Interlock
8. Foam Pipe
9. On/Off Switch
10. Plastic Stopper
11. Safety Key
12. Cutting Height Adjustment
Ball

12
MAINTENANCE AND
CARE
1. Switch the unit off, remove the safety
key and remove the battery from the
mower then place the unit in a safe
location.
2. Do not keep the unit within the reach
of children.
3. Ensure that the ventilation slots in the
unit are clean.
4. Keep all nuts, bolts and screws tight to
be sure that the lawnmower is in
safe working condition.
5. Check the grass catcherfrequently for
wear or damages.
6. Use only the cutter bar, which are
intended for this lawnmower.
7. Please follow the supplied installation
instructions and remove the battery
beforehand.
8. Have repairs carried out exclusively by
a qualified technician or at a service
center.
Cleaning
Lawn Mower
1. Do not use water or liquid
detergents.
2. Whenever possible, always clean
the unit directly after mowing.
3. Remove the battery.
4. Remove the grass catcher.
5. After mowing, always clean the
lawnmower with a hand brush.
6. Remove grass residues carefully
out of the cutting area. Remove
stuck clipping deposits using a stick.
7. Keep the ventilation slits clean and
dust-free.
Grass Catcher
For thorough cleaning, the grass catcher
can be cleaned with a hose
Storage
1. Remove the safety key and remove
the battery from the mower before
storing
2. Store the unit in a dry and frost-free
place (50-77 °F).
3. Store the battery and the unit
separately.
4. Charge the battery before storing the
unit in winter.
5. Keep the unit, in particular its plastic
components, away from brake
fluids, petrol, petroleum products,
penetrating oil, etc. They contain
chemical substances which may
damage, attack or destroy the
plastic components of the unit.

13
Folding the Lawn Mower
The handle bar can be folded down to
facilitate storage and transport. Loosen
the screws of triangle knob on the upper
handle and move the handle
backwards .
Replacing/Regrinding The
Cutter Blade
GENERAL SAFETY WARNING
#2!
Spare parts must conform with the
requirements specified by the
manufacturer. Therefore use original
spare parts only or spare parts
authorised by the manufacturer.
Repair
Check the unit for damage. Repairs may
be earned out by an authorized customer
service centre only.
DISPOSAL
INFORMATION
Recycle raw materials instead of
disposing the wastes. Device,
accessories and packaging should be
recycled in an environmentally friendly
manner. Plastic parts are identified for
recycling according to material type.
For EU countries only:
Do not throw electric power tools into the
household waste! In accordance with the
European Directive 2012/19/EC on
Waste Electrical and Electronic
Equipment and transposition into
national law, used electric power tools
must be collected separately and
recycled in an environmentally friendly
manner.
GUARANTEE/
WARRANTY
This product has been manufactured to
the highest quality standards. When a
new product is purchased, it is
guaranteed a 12-month manufacturer’s
warranty which comes into force on the
date the product was purchased.
The guarantee covers only the defects
which can be attributed to a material

14
and/or production fault as well as non-
performance of warranted
characteristics. You can extend the
warranty by registering your product
online within 30 days of purchase.
When making a claim under the
guarantee, enclose the original sales
receipt with purchase date. Repairs
under the guarantee may be carried out
only by workshops or service centres
authorised by the manufacturer.
A claim may be made under the
guarantee only if the power tool has
been used as intended.
This warranty is invalid where defects
are caused by or result from:
- misuse, abuse or neglect;
- commercial use (industry, craft,
rental)
- repairs attempted by unauthorized
repair centers
- damage caused by external effects,
foreign objects, substances or
accidents.
DECLARATION OF
CONFORMITY
We hereby declare, that the following
product in it‘s design and construction put
by us into circulation is in accordance
with the appropriate basic safety and
health requirements of the following
directives (see item 4).
This declaration relates exclusively to the
machinery in the state in which it was
placed on the market, and excludes
components which are added and/or
operations carried out subsequently by
the final user.
1. Description: Battery operated lawn
mower
2. Type: E142C
3. Serial number:
4. Applicable EC Directives: 2006/42/EC
5. Used harmonized standards:
EN 60335-1, EN60335-2-77 , EN 62233,
EN ISO 3744, ISO 11094, EN55014-1,
EN55014-2, EK9-BE-52, EK9-BE-34
6. Additional used EC directives:
2004/108/EC (until 19.04.2016),
2014/30/EU (from 20.04.2016);
2000/14/EC
7. Responsible for technical documents:
KeepGreen GmbH
Kreuzstrasse 15
CH-8808 Zürich
8. Conformity assessment method to
2000/14/EC,
Annex V:
Measured Sound Pressure Level: 80.6
dB(A)
Guaranteed Sound Power Level: 96
dB(A)
Uncertainty K: 3 dB
Website: www.redbacktool.com
Email: [e-mail]
