RedDot LED RD Series User manual

RedDot LED
REDDOTLEDREDDOTLEDREDDOTLED.COM
User Manual
RD & RDS Series Therapy Light

Lifestyle Choice
Healthy

TABL E OF CONTENTS
/21
/20
Connecting Multiple
RDS Series Light Units
Warranty
Understanding Red Light Therapy
/01
Why choose us
/02
/04
RD Series Compare Specs
/05
RD Series Specifications
/07
RDS Series Compare Specs
/08
RDS Series Specifications
09/10 /11
RD Series Irradiance RD Series Optional Mounting
Configurations and Instructions
/12 /13
Package ContentsRDS Series Optional Mounting
Configurations and Instructions
/16
14/15
Install Your Therapy Light Setting up Your RD Series Light
/19
17/18
Connecting Multiple
RD Series Light Units
Setting up Your RDS Series Light

Red light therapy is also known as low-level laser
therapy (LLLT). It uses low-energy light emitting
diodes (LEDs) or lasers as an alternative therapy for
pain relief, or to promote good cell functions.
The principle of red light therapy can be thought
of as like a human version of the way plants
photosynthesize. It is thought that certain
Reduce Joint Stiffness
Relieves Muscle Spasms
Improves Blood Flow
Reduces Inflammation
Aids Pain Relief
Improves Elasticity of
Collagen Fibres
What is Red Therapy Light and How Does it Work?
Benefits Of RedDot LED Light Therapy
Near Infrared light
Red light
wavelengths of light can enhance the functioning
of mitochondria, which are the organelles in a cell
which take in nutrients and break them down to
create energy molecules for the cell. By
enhancing the cellular respiration, it will improve
the functioning of the whole cell.
01
Hair Growth

1. RedDot led Light Therapy is safe for
regular use.
2.Using varying LED wavelengths, this
skincare technique purportedly helps treat
acne, reduce inflammation, and promote
anti-aging effects.
3.Convenience to use, At-home LED
devices can be used at your convenience
without having to go to any
appointments.20 minutes at a time
4. These light wavelengths have been
scientifically proven by many customers.
1. RedDot led Light Therapy is safe for regular use.
2.Using varying LED wavelengths, this skincare
technique purportedly helps treat acne, reduce
inammation, and promote anti-aging effects.
3.Convenience to use, At-home LED devices can
be used at your convenience without having to
go to any appointments.20 minutes at a time
4. These light wavelengths have been
scientically proven by many customers.
Why choose us?

04
RD Series Compare Specs
LED Power
Daisy-chained
Dimensions
Warranty
Smart Built-in Cooling
Fans
Max Area
500W
10.4" x 8.7" x 2.3"
36" x 34"
Wavelengths:
1000W
18.9" x 8.7" x 2.3"
1500W
27.2" x 8.7" x 2.3"
RD500 RD1000 RD1500
46" x 34" 52" x 34"
Door Mount
Mobile Stand
Tabletop Stand
Built-in Programmable
Timer
3 Years 3 Years 3 Years
Irradiance (mW/cm2)*
Weight
135
2.8KG/6.2LBS
145
4.5KG/9.9LBS
161
7KG/15.4LBS
EMF Emission – Negligible – Negligible – Negligible
RD60
60W
5.9" x 3.9" x 1.4"
—
3 Years
＞100 mw/cm2
at the surface of the LEDs
0.85KG/1.9LBS
– Negligible
Wireless &Rechargeable
WiFi Ready
×
× ×
×
×
×
×
×
×
×
×
×
×
Maximum 6pcs Maximum 5pcs Maximum 4pcs
42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm

05
LED Power
Amps @110v
Weight
Lifespan
EMF Emission
Warranty
Best For
Max Area
500W60W
1.1A—
2.8KG/6.2LBS0.85KG/1.9LBS
– Negligible– Negligible
100,000hrs100,000hrs
3 Years3 Years
Targeted TreatmentTargeted Treatment
36" x 34"—
Wavelengths
1000W
2.1A
4.5KG/9.9LBS
– Negligible
100,000hrs
3 Years
Targeted Treatment
1500W
3.3A
Amps @220v 0.4A— 1.1A 1.3A
7KG/15.4LBS
– Negligible
100,000hrs
3 Years
Full Body Treatment
RD Series Specifications
RD500 RD1000 RD1500
46" x 34" 52" x 34"
RD60
Dimensions
Power Consumption
LEDs
Beam Angle
Cooling Fans
10.4" x 8.7" x 2.3"
120W14W
100 x 5W12 x 5W
30 Degree30 Degree
1pc fanNo
18.9" x 8.7" x 2.3"
235W
200 x5W
30 Degree
3pcs fans
27.2" x 8.7" x 2.3"
352W
300 x 5W
30 Degree
4pcs fans
5.9" x 3.9" x 1.4"
42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm

RDS Series Compare Specs
LED Power
Daisy-chained
Dimensions
Warranty
Smart Built-in Cooling
Fans
Max Area
500W
10.4" x 8.7" x 2.3"
36" x 34"
Wavelengths
1000W
18.9" x 8.7" x 2.3"
1500W
27.2" x 8.7" x 2.3"
RDS500 RDS1000 RDS1500
46" x 34" 52" x 34"
Door Mount
Mobile Stand
Tabletop Stand
Built-in Programmable
Timer
3 Years 3 Years 3 Years
Irradiance (mW/cm2)*
Weight
135
2.8KG/6.2LBS
145
4.5KG/9.9LBS
161
7KG/15.4LBS
EMF Emission – Negligible – Negligible – Negligible
Wireless &Rechargeable
WiFi Ready
× ×
×
×
×
×
×
×
×
×
×
×
Maximum 6pcs Maximum 5pcs Maximum 4pcs
× ×
42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm
07

LED Power
Amps @110v
Weight
Lifespan
EMF Emission
Warranty
Best For
Max Area
500W
1.1A
2.8KG/6.2LBS
– Negligible
100,000hrs
3 Years
Targeted Treatment
36" x 34"
Wavelengths
1000W
2.1A
4.5KG/9.9LBS
– Negligible
100,000hrs
3 Years
Targeted Treatment
1500W
3.3A
Amps @220v 0.4A 1.1A 1.3A
Dimensions
Power Consumption
LEDs
Beam Angle
Cooling Fans
10.4" x 8.7" x 2.3"
120W
100 x 5W
30 Degree
1pc fan
18.9" x 8.7" x 2.3"
235W
200 x 5W
30 Degree
3pcs fans
27.2" x 8.7" x 2.3"
352W
300 x 5W
30 Degree
4pcs fans
7KG/15.4LBS
– Negligible
100,000hrs
3 Years
Full Body Treatment
RDS Series Specifications
RDS500 RDS1000 RDS1500
46" x 34" 52" x 34"
08
42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm 42mil RED 660nm & NIR 850nm

RD & RDS Series Irradiance
RD500 & RDS500 RD1000 & RDS1000
145
mw/cm2
105
mw/cm2
78
mw/cm2
58
mw/cm2
38
mw/cm2
22"x14"
Footprint
28"x18"
Footprint
31"x22" 35"x26" 45"x33"
Footprint Footprint Footprint
6"
Light Meter
12" 18"
Light Meter
24"
Light Meter
Light Meter
36"
Light Meter
135
mw/cm2
96
mw/cm2
56
mw/cm2
40
mw/cm2
21
mw/cm2
14"x12"
Footprint
20"x16"
Footprint
26"x22" 28"x26" 35"x33"
Footprint Footprint Footprint
6"
Light Meter
12" 18"
Light Meter
24"
Light Meter
Light Meter
36"
Light Meter
09

RD1500 & RDS1500
161
mw/cm2
121
mw/cm2
87
mw/cm2
70
mw/cm2
48
mw/cm2
30"x14"
Footprint
37"x18"
Footprint
39"x22" 43"x26" 51"x33"
Footprint Footprint Footprint
6"
Light Meter
12" 18"
Light Meter
24"
Light Meter
Light Meter
36"
Light Meter
RD & RDS Series Irradiance
10

RD Series Optional Mounting Configurations
Distance: Apply from 6-12 inches.
Session Time: Continue for 2-15 minutes,depending on distance.
Frequency:Do this 2 times to 4 times a week until results are felt.
Maintenance: Continue using several times a week.
Instructions
Door Mount
Tabletop Stand Mobile Stand
11

RDS Series Optional Mounting Configurations
Distance: Apply from 6-12 inches.
Session Time: Continue for 2-15 minutes,depending on distance.
Frequency:Do this 2 times to 4 times a week until results are felt.
Maintenance: Continue using several times a week.
Instructions
Tabletop Stand Door Mount
12

Package Contents
① .
③ .
⑤ .
② .
④ .
⑥ .
1
2
3
4
5
6
7
Eye Protection
LED Therapy Light
Cable Assembly & Snap Links
⑦ .
Door Hook
Hanging Hardware
Power Cable
Patch Cable
13

Install Your Therapy Light
Lay all of the included hardware, including your
Reddot LED, on a padded surface. Next, screw in
the threaded posts to the top of the device and
hand-tighten with the included Allen wrench. Then,
screw the cable supports to the threaded posts, as
shown in PIC.1.
STEP 1
Hang the included custom hook on any standard-
sized door, as shown in PIC.2.
STEP 2
PIC.1
PIC.2
14

PIC.3
Connect the cable supports to the snap link
attached to the height-adjusting system. Then,
connect the snap link on the opposite end directly
to the door hook, as shown in PIC.3.
STEP 3
Be sure to adequately support the device while raising
and lowering it with the height-adjusting system .
To raise your Reddot LED to your desired height, pull
down on the loose cable while supporting the
device with your opposite hand, as shown in PIC.4.
STEP 4
PIC.4
15

Remember that near infrared LEDs emit light
that is NOT visible to the naked eye.
1. You can choose only red or only IR or both by
selecting the “Mode” button. The red indicator light
will illuminate indicating which wavelength
conguration is selected.
2.Adjust the time by pressing the “ Time ”button.
3.Press “ok” to run the light,start the treatment.
STEP 2
88888888
MODE
TIME
OK
Red Infrared
1500
Choose
Wavelength
Increase Time
From 1-20
Minutes
Play/pause
Time
Lead / Follow
Buttton
Plug the power cord in the female socket and press
the red switch, it will illuminated.
STEP 1
Setting up Your
RD Series Light
16

To connect the lower Reddot LED, lift it into position
below the lead device that is already in place. Line
up the threaded posts with the holes in the end caps
of the upper device. Then, slide the lower threaded
posts into the holes, and slide forward to lock in
place.
STEP 1
Connecting Multiple
RD Series Light Units
17
