USER MANUAL
Please read and keep these instrucons
SPACE SAVER CORNER SHOWER STOOL
RG553
September 2019
R REGISTERED DESIGN

redgumbrand.com.au
REDGUM Brand owns the copyright to the Space Saver Corner Shower Stool user manual.
Any informaon contained in this user manual shall not be photocopied, reproduced or
translated into any other languages without the prior wrien consent of REDGUM Brand.
REDGUM Brand strives to provide the highest quality products possible.
Products are subject to change without noce.
© Copyright REDGUM Brand 2019
REDGUM Brand is part of FOR-DE Group Pty Ltd

redgumbrand.com.au
CONTENTS
1. INTRODUCTION - INTENDED USE
2. PRODUCT OVERVIEW - FEATURES / SPECIFICATIONS
3. ASSEMBLY - UNPACK and INSPECT SUPPLIED PARTS
4. ASSEMBLY - LEG ASSEMBLY
5. ASSEMBLY - LEG INSTALLATION
6. USAGE GUIDELINES - DO’s + DON’Ts
7. PRODUCT CARE - INSPECTIONS / CLEANING
8. WARRANTY
9. REDGUM BRAND PRODUCT RANGE
10. NOTES
11. NOTES
12. NOTES

redgumbrand.com.au
INTRODUCTION
Thank you for purchasing this quality REDGUM Brand product.
If you have any issues or quesons about the Space Saver Corner Shower Stool
please contact your supplier or REDGUM Brand direct:
T: [phone]
F: [phone]
E: [e-mail]
A: 1 Business Way, Malaga Western Australia 6090
INTENDED USE
This product has limitaons and should be used in accordance to these guidelines.
Failure to follow these guidelines may result in damage to the product and injury to
the user. It is the responsibility of the user to ensure the suitability of this product
for its intended use. The user should consult their appropriate healthcare
professional if unsure of the correct product usage for their unique circumstances.
Only use your Space Saver Corner Shower Stool for the purpose for which it is
intended, which is as a seang soluon that can adjust to suit the users individual
requirements.
IMPORTANT NOTE
This equipment MUST be assembled
by a competent person.
Maximum User Weight: 130kg
Exceeding the weight limit could
cause damage to the product and
could put the user at risk.
1.

redgumbrand.com.au
PRODUCT OVERVIEW
FEATURES
Modern / Funconal / Compact design
Ideal for use in conned spaces
Easy to assemble - No tools required
Adjustable seat height and angle with sure lock push pins
Three leg stability on uneven oors
Grip seang surface
Flexible PVC leg ps
Strong lightweight construcon
Corrosion free materials
Life me guarantee on corrosion
Designed for easy cleaning
SPECIFICATIONS
(All dimensions shown are nominal)
Overall Width: 430mm (at lowest seng)
Overall Depth: 360mm (at lowest seng)
Overall Height: 490mm (at lowest seng)
Seat Width: 395mm
Seat Depth: 295mm
Seat Height: 490 - 615mm: 6 sengs (oor to top of seat)
Hole 1: 490mm
Hole 2: 515mm
Hole 3: 540mm
Hole 4: 565mm
Hole 5: 590mm
Hole 6: 615mm
Product Weight: 1.5kg
Maximum User Weight: 130kg
Please contact REDGUM Brand if you would like any further informaon
on your Space Saver Corner Shower Stool.
2.

redgumbrand.com.au
ASSEMBLY - UNPACK and INSPECT SUPPLIED PARTS
Ensure you have been supplied with the following parts:
PARTS:
IMPORTANT NOTE
Check the product for any visible damage. If you see any damage or suspect a fault,
DO NOT USE YOUR PRODUCT and contact your supplier for support.
3.
1 x SEAT
3 x ADJUSTABLE LEGS
3 x SURE LOCK PUSH PINS

redgumbrand.com.au
4.
ASSEMBLY - LEG ASSEMBLY
Each adjustable leg needs to be assembled prior to ng to seat:
1. Pull out the inner leg.
2. Line up the holes at the required seng (seng can be changed at any me).
3. Insert sure lock push pin into hole and push clip unl it locates around tube.
4. Repeat this process on all 3 adjustable legs.
Adjustable legs are now ready to be ed to seat.
Check that Leg Tips are fully ed
onto leg prior to ng to seat.
To adjust the legs aer they have been ed to seat:
1. Remove sure lock push pin.
2. Adjust leg to required seng (line up holes).
3. Insert sure lock push pin into hole and push clip unl it locates around tube.
Line up holes
Hole 1 (490mm)
Hole 2 (515mm)
Hole 3 (540mm)
Hole 4 (565mm)
Hole 5 (590mm)
Hole 6 (615mm)

redgumbrand.com.au
ASSEMBLY - LEG INSTALLATION
Each adjustable leg needs to be installed to seat:
1. Place seat upside down as shown below.
2. Insert assembled leg into socket.
3. Line up red press buon with hole
in wall of socket.
4. Depress press buon and push leg
down into socket.
5. Ensure head of buon protrudes
out of hole.
6. Repeat process for all 3 adjustable legs.
Flip Space Saver Corner Shower Stool over onto feet.
Product is now ready to use.
(Adjust seat height as required.)
5.
IMPORTANT NOTE:
Press buon head MUST
protrude out of hole
Line up press buon
with hole

redgumbrand.com.au
USAGE GUIDELINES - DO’s + DON’TS
Please follow these guidelines to get the opmal benet
from your Space Saver Corner Shower Stool.
Failure to follow these guidelines may result in damage to the
Space Saver Corner Shower Stool and put the user at risk.
130kg Maximum User Weight.
Ensure ALL THREE LEGS remain on ground at all mes
when Space Saver Corner Shower Stool is occupied.
Do not lean too far to the side or backward causing the legs to leave the ground.
SITTING GUIDELINES
The Space Saver Corner Shower Stool
can be set up in various ways to suit
the individuals requirements.
Adjust the seat height to line up
with back of the users knees
(Refer to Page 4 for informaon
on leg adjustment).
To assist the user with geng on
and o of the Space Saver
Corner Shower Stool, extend the
rear leg to open up the seat angle.
(Maximum 90°)
6.

redgumbrand.com.au
7.
PRODUCT CARE - INSPECTIONS / SERVICING / CLEANING
INSPECTIONS
We suggest that you check your Space Saver Corner Shower Stool visually periodically for
signs of damage or wear prior to use. Overall check that no components are loose or worn.
Withdraw the Space Saver Corner Shower Stool immediately if you
suspect damage or any other fault. If in any doubt, please do not issue
or use, but immediately contact your supplier for service support.
IMPORTANT NOTE
Do not t any parts or accessories to your Space Saver Corner Shower Stool
that are manufactured by another company. To do so will void
your warranty and may seriously compromise your safety.
CLEANING
Clean your Space Saver Corner Shower Stool using a non-abrasive cleaner
or mild detergent with a so cloth.
Abrasive cleaners or abrasive cleaning pads could
damage the Space Saver Corner Shower Stool
and should not be used.

redgumbrand.com.au
WARRANTY
Your REDGUM Brand RG553 - Space Saver Corner Shower Stool is covered by a
12 Month Warranty from the date of purchase.
If the product has any manufacturing faults during this period contact the place of
purchase for assessment. Failures as a result of ACCIDENTAL DAMAGE, MISUSE,
MODIFICATION OR WEAR AND TEAR ARE NOT COVERED BY THIS WARRANTY.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entled to a replacement part for a major failure and for
compensaon for any other reasonably foreseeable loss or damage. You are entled
to have the goods repaired or replaced if the goods fail to be of acceptable quality and
failure does not amount to major failure.
If you have any issues or quesons about your Space Saver Corner Shower Stool
please contact your supplier or REDGUM Brand direct on:
T: [phone]
F: [phone]
E: [e-mail]
A: 1 Business Way, Malaga
Western Australia 6090
Please keep this User Manual
in a safe place for future reference.
8.

redgumbrand.com.au
REDGUM Brand - Product Range
REDGUM Brand oer a comprehensive range of products including:
Seat Walkers
Side Folding Seat Walkers
Walking Frames
Wheelchairs
Walking Scks + Quads
Crutches
Reachers
Shower / Bathroom products
Toilet products
Cushions: Air / Foam
Electric Li Chairs
Electric Beds
Portable / Fixed Aluminium Ramps
Exercisers
Personal Alarms
REDGUM Brand stock a large range of Spare Parts for all REDGUM brand products.
Please contact REDGUM Brand for further informaon:
T: [phone]
F: [phone]
E: [e-mail]
A: 1 Business Way, Malaga Western Australia 6090
W: www.redgumbrand.com.au
