REDMOL AIR PURIFIER (JP-08)
Quick Reference Booklet (Version 2.0)

Product Features
This product is designed by our environmental specialist to address the need for better air quality especially in
various Chinese cities to eliminate harmful pollutants and substances like Formaldehyde, 2nd hand smoke,
bacteria, dusts, and odors and harmful fine particles (PM 2.5) that can easily be breath and absorb by human
bodies.
The product is specially designed for its ease of use, compactness, quietness and elegance. Suitable to be
placed at small spaces like bedrooms and offices.
Technical Specification:
Brand
REDMOL
Model
JP-08
Color
Champagne Gold
Package size
180mm*146mm*183mm
Outward material
Aluminium Alloy
Five features
3-in-1 Filter (HEPA, Carbon and Photocatalysts), Ionizer and UV
Purification Effect
Neutralize Formaldehyde, Benzene, remove smoke and dust,
kill air-borne germs, PM2.5
Max air flow
80 CFM
Applicable area
10-15m²
Power
220V/50Hz
Power consumption
5W(energy saving)
Air flow rate
2.3m³/s
Negative ion output
6 million pcs/cm³

Value of activated carbon odour
13QB(European Standard)
Value of activated carbon absorption
28mr
Small particulate filtering range
PM1.0-PM2.5
HEPA filtering value
≥0.1µm
Applicable temperature
-10°C-50°C
Net weight
0.9Kg
Operation Guide
The unit is operated using a touch sensitive control panel on top of the unit (as shown in the
picture below).

On/Off: Press once to either turn on or off the unit.
Function selection: Gently touch the function button to select the purification function. 除臭 (deodorization),
粉尘 (remove dust), 甲醛 (Formaldehyde), 苯(Benzene), 杀菌 (Sterilization). By default, all these
features are already activated as part of the basic filtration and purification functions as the air are
passing through the 3-in-1 air filter.
Timer mode: To set timer mode, press the function mode button until the indicator light move into the timer
row. Wait for 3-5 seconds the let the setting to take effect. The timer can be set from 30 minutes to 5 hours for
auto turn off.
The system will automatically shut off after 12 hours of continuous operation as a safety measure as this
unit is designed for office / cubicle and bedroom setting. However you may operate the unit more than
12 hours if desired.
Wind Speed: Press the Wind Speed button to set the desired fan speed.
Note:the product is touch control and does not require hard pressing of the button.

FIVE Product Features:
HEPA Filter
HEPA (High Efficiency Particular Air Filter), serving as the first
layer of air purification that is able to filter particles 0.1µm or
bigger (or equivalent to 1/800 of hair strain), with 99.7% filtering
efficiency.
Active Carbon Filter
The honeycombed structure of active carbon membrane provide
large surface area to effectively remove grease, dust, odor and
harmful particles from the air. Choosing the best activated carbon
from Hainan’s coconut shell by Nobik, the material can effectively
eliminates toxic particles like formaldehyde with up to 94.8% and
deodorization effectiveness of up to 98%.
Photocatalyst Filter
The Filter uses additional layer of Nano-tech materials which
under the action of light can effectively neutralize harmful air
particles from formaldehyde, benzene, toluene, ammonia and
other toxic gas particles.
UV Sterilization
Filtered air passed through the 3-in-1 HEPA filter is further
sterilized with in-built UV light to keep any residue bacteria before
releasing back.
Negative Ions
The powerful high density negative ions generator will fill the
clean air in the last stage of processing with anions (vitamins of
the air). Anions is a known for its positive health effects and will
help to further neutralize harmful bacteria and dust particles in
air.

Schematic Diagram
Precautionary Notes:
Avoid operating the unit with wet hands. Turn off and remove the plug before cleaning the unit.
Avoid operating the unit in a moist and humid area like bathroom.
Avoid operating the unit in oily environment like Kitchen. This unit is not designed to filter oily
pollutant
This unit is equipped with high power negative ion generator. Do not attempt to open out the
unit or repair by yourself. Please contact appointed distributor or service provider for equipment
repair (email: [e-mail] / Phone [phone])
Do not block the intake and the openings of the unit as this will impact the air flow and hence air
purification effectiveness.
Avoid touching the metal plate at the opening or insert any foreign objects to avoid
multifunctioning.

Warranty and Support
Dear Customers:
Thank you for choosing REDMOL. Please kindly read the following terms and conditions for the
product warranty:
1. The product comes with 1 year warranty from the date of purchase (or receiving for online
customers) for all manufacturer’s related defect and issues. For products purchased. For products
purchased via local distributor (EastbayShop / EastbayWellness.SG) in Singapore, local support
and warranty will be provided.
2. Followings are excluded from warranty coverage:
User induced damaged (i.e. fall, knock, or placing the unit at hazardous environment)
Damaged caused by natural disaster (i.e. earthquake, fire, flood or other natural causes)
Services and repaired by non-authorized service agents
Improper usage not according to product’s operation and usage guide
3. Proof of purchase must be produced during services.
4. For product exchange and return (subjected to reseller’s purchase term & condition), the product
must be in its original and resalable condition.
