Reed Instruments R5099 User manual
Compact Multimeter
with NCV
Instruction
Manual
R5099
W
A
R
R
A
N
T
Y
W
A
R
R
A
N
T
Y
1 YEAR
1 AN
G
A
R
A
N
T
I
E
G
A
R
A
N
T
I
E
W
A
R
R
A
N
T
Y
W
A
R
R
A
N
T
Y
G
A
R
A
N
T
I
E
G
A
R
A
N
T
I
E
W
A
R
R
A
N
T
Y
W
A
R
R
A
N
T
Y
G
A
R
A
N
T
I
E
G
A
R
A
N
T
I
E
White background
Transparentbackground
White
REED Instruments
2
Table of Contents
Introduction ................................................................................................ 3
Product Quality........................................................................................... 3
Safety ......................................................................................................3-4
Safety Symbols ...................................................................................... 4
Features...................................................................................................... 4
Included...................................................................................................... 4
Specications..........................................................................................4-6
Instrument Description............................................................................... 6
Display Description .................................................................................... 7
Operating Instructions...........................................................................7-11
DC Voltage Measurement ...................................................................... 7
AC Voltage Measurement ...................................................................... 7
DC Current Measurement...................................................................... 8
AC Current Measurement ...................................................................... 8
Resistance Measurement....................................................................... 9
Capacitance Measurement .................................................................... 9
Frequency Measurement ....................................................................... 9
Diode Measurement............................................................................. 10
Continuity Measurement...................................................................... 10
Non-Contact AC Voltage Measurements............................................. 10
Data Hold ............................................................................................. 11
Auto Power Off .................................................................................... 11
Backlight .............................................................................................. 11
Battery Replacement................................................................................ 11
Applications.............................................................................................. 11
Product Care ............................................................................................ 12
Product Warranty ..................................................................................... 12
Product Disposal and Recycling .............................................................. 12
Product Support....................................................................................... 13
REED Instruments
3
Introduction
Thank you for purchasing your REED R5099 Compact Multimeter with
NCV. Please read the following instructions carefully before using your
instrument. By following the steps outlined in this manual your meter will
provide years of reliable service.
Product Quality
This product has been manufactured in an ISO9001 facility and has been
calibrated during the manufacturing process to meet the stated product
specications. If a certicate of calibration is required please contact the
nearest authorized REED distributor or authorized Service Center. Please
note an additional fee for this service will apply.
Safety
• Never attempt to repair or modify your instrument. Dismantling your
product, other than for the purpose of replacing batteries, may cause
damage that will not be covered under the manufacturer's warranty.
• Servicing should only be provided by an authorized service center.
• Do not use the meter or test leads if they look damaged.
• Do not use the meter around explosive gas, vapor, or in damp or
wet environments.
• Do not switch the function dial while taking a measurement.
• Use the meter only as specied in this manual; otherwise, the protection
provided by the meter may be impaired.
• Use caution when working near voltages above 60V DC or 30V ACrms,
as such voltages pose a shock hazard.
• Use extreme caution when working with high voltages.
• Always discharge lter capacitors in power supplies and disconnect the
power when making resistance, continuity or diode tests.
• Always turn off the power before opening the cover to replace the batteries.
• Never operate the meter unless the battery cover is in place and
fastened securely.
continued...
REED Instruments
4
Safety Symbols
Refer to this manual before using the meter.
Dangerous voltages.
Meter is protected throughout by double insulation or
reinforced insulation.
Features
• Measures AC/DC voltage and current, resistance, capacitance,
frequency, diode and continuity
• Built-in non-contact voltage detector and double molded plastic housing
• 4,000-count backlit LCD display
• Low battery indicator and auto shut-off
• CAT III 600V safety rating
Included
• Test Leads
• Batteries
Specifications
AC/DC Voltage
Range: AC: 4, 40, 400, 600V
DC: 400mV, 4, 40, 400, 600V
Accuracy: AC: 4, 40V ±(1.2% rdg. + 5 dgt.)
400, 600V ±(2% rdg.+ 10 dgt.)
DC: 400mV ±(1% rdg.+ 8 dgt.)
4, 40V ±(0.5% rdg.+ 5 dgt.)
400, 600V ±(0.8% rdg.+ 5 dgt.)
Resolution: AC: 0.01, 0.01, 0.1, 1V
DC: 0.1mV, 0.001, 0.01, 0.1, 1V
continued...
REED Instruments
5
AC/DC Current
Range: 400µA, 4, 40, 400mA
Accuracy: AC: 400µA, 4, 40, 400mA ±(2% rdg. + 8 dgt.)
DC: 400µA, 4, 40, 400mA ±(1.8% rdg. + 5 dgt.)
Resolution: 0.1µA, 0.001, 0.01, 0.1mA
Resistance
Range: 400Ω, 4, 40, 400kΩ, 4, 40MΩ
Accuracy: 400Ω, 4, 40, 400kΩ: ±(1% rdg. + 5 dgt.)
4MΩ: ±(1.2% rdg. + 10 dgt.)
40MΩ: ±(2% rdg. + 10 dgt.)
Resolution 0.1, 1, 10, 100Ω, 1, 10kΩ
Capacitance
Range: 50, 500nF, 5, 50, 100μF
Accuracy: 50nF: ±(4% rdg.+ 30 dgt.)
500nF: ±(3% rdg. + 15 dgt.)
5, 50, 100μF: ±(4% rdg. + 10 dgt.)
Resolution: 0.01, 0.1, 1, 10, 100nF
Frequency
Range: 9.999Hz to 60kHz
Accuracy: ±(0.1% rdg. + 5 dgt.)
Resolution: 0.001Hz to 0.001Mz
General Specifications
Range Selection: Autoranging
Display: 4,000 count LCD display
Display Hold: Yes
Diode Test: Yes
Continuity Check: Audible signal if resistance ≤10Ω
Non-Contact
Voltage Detector: Yes
Auto Power Off: Yes (after 30 minutes)
continued...
REED Instruments
6
Power Supply: 2 x AAA
Low Battery Indicator: Yes
Fuse Protection: Yes
Replaceable Test Leads: No
Overange Indicator: Yes (OL)
Overvoltage Category: CAT III 600V
Product Certications: CE
Operating Temperature: 32 to 104°F (0 to 40°C)
Storage Temperature: 14 to 122°F (-10 to 50°C)
Dimensions: 4.4 x 2.3 x 1.4" (112 x 58 x 35mm)
Weight: 6.3oz (180g)
Instrument Description
SELECT HOLD Hz %
Compact Multimeter
NCV R5099
FUSED
MAX 400mA/600V
CAT III 600V
1
2
4
5
3
6
7
8
9
AUTO nm FVA Mk
AC
DC
Hz %
Ω
H
1. NCV LED Indicator
2. LCD Display
3. HOLD/Backlight Button
4. SELECT Button
5. Function Dial
6. Hz/% Button
7. Test Leads
8. Test Leads Holder
9. Battery Cover
REED Instruments
7
Display Description
AUTO nm FVA Mk
AC
DC
Hz %
Ω
H
1
2
4
35
6
1. Auto Range Indicator
2. Low Battery Indicator
3. AC/DC Indicators
Operating Instructions
DC Voltage Measurement
1. Set the function dial to the position.
2. Press the SELECT button to indicate "DC" on
the LCD display.
3. Measure the voltage by touching the test
probe tips to the load in parallel.
4. Note the measured value.
AC Voltage Measurement
1. Set the function dial to the position.
2. Press the SELECT button to indicate "AC" on
the LCD display.
3. Measure the voltage by touching the test probe
tips to the load in parallel.
4. Note the measured value.
continued...
4. Data Hold Indicator
5. 4000 Count Display
6. Units of measurement
Compact Multimeter
NCV R5099
AUTO nm FVA Mk
AC
DC
Hz %
Ω
H
SELECT HOLD Hz %
Compact Multimeter
NCV R5099
AUTO nm FVA Mk
AC
DC
Hz %
Ω
H
SELECT HOLD Hz %
REED Instruments
8
DC Current Measurement
1. Set the function dial to the or position.
2. Press the SELECT button to indicate "DC" on
the LCD display.
3. Remove power from the circuit under test, then
open up the circuit at the point where you wish to
measure the current.
4. Touch the black test probe tip to the negative side
of the circuit. Touch the red test probe tip to the
positive side of the circuit.
5. Apply power to the circuit.
6. Note the measured value.
AC Current Measurement
1. Set the function dial to the or position.
2. Press the SELECT button to indicate "AC" on
the LCD display.
3. Remove power from the circuit under test, then
open up the circuit at the point where you wish to
measure the current.
4. Touch the black test probe tip to the negative side
of the circuit. Touch the red test probe tip to the
positive side of the circuit.
5. Apply power to the circuit.
6. Note the measured value.
Resistance Measurement
1. Set the function dial to the position.
2. Press the SELECT button to select resistance
as indicated by on the LCD display.
3. Measure the resistance by touching the test
probe tips to the load in parallel.
4. Note the measured value.
continued...
Compact Multimeter
NCV R5099
AUTO nm FVA Mk
AC
DC
Hz %
Ω
H
SELECT HOLD Hz %
Compact Multimeter
NCV R5099
AUTO nm FVA Mk
AC
DC
Hz %
Ω
H
SELECT HOLD Hz %
Compact Multimeter
NCV R5099
AUTO nm FVA Mk
AC
DC
Hz %
Ω
H
SELECT HOLD Hz %
Compact Multimeter
NCV R5099
AUTO nm FVA Mk
AC
DC
Hz %
Ω
H
SELECT HOLD Hz %
Compact Multimeter
NCV
R5099
AUTO nm FVA Mk
AC
DC
Hz %
Ω
H
SELECT HOLD Hz %
REED Instruments
9
Capacitance Measurement
1. Set the function dial to the position.
2. Press the SELECT button to select capacitance
as indicated by "nF" on the LCD display.
3. Measure the capacitance by touching the test
probe tips to the load in parallel.
4. Note the measured value.
Frequency Measurement
1. Set the function dial to the position.
2. Press the HZ button to select frequency as
indicated by "Hz" on the LCD display.
3. Measure the frequency by touching the test
probe tips to the load.
4. Note the measured value.
Diode Measurement
1. Set the function dial to the position.
2. Press the SELECT button to select diode as
indicated by on the LCD display.
3. Measure the frequency by touching the test
probe tips to the load in parallel.
4. Note the measured value.
Forward voltage will indicate 0.5V to 0.8V. Reverse voltage
will indicate “OL”. Shorted devices will indicate near 0mV
and an open device will indicate “OL” in both polarities.
continued...
Compact Multimeter
NCV
R5099
AUTO nm FVA Mk
AC
DC
Hz %
Ω
H
SELECT HOLD Hz %
Compact Multimeter
NCV
R5099
AUTO nm FVA Mk
AC
DC
Hz %
Ω
H
SELECT HOLD Hz %
Compact Multimeter
NCV
R5099
AUTO nm FVA Mk
AC
DC
Hz %
Ω
H
SELECT HOLD Hz %
REED Instruments
10
Continuity Measurement
1. Set the function dial to the position.
2. Press the SELECT button to select continuity
as indicated by on the LCD display.
3. Measure the continuity by touching the
test probe tips to the load in parallel.
4. Note the measured value.
If the measured resistance is >1000Ω, circuit is open. If the
measured resistance ≤10Ω, the audible buzzer will sound.
Non-Contact AC Voltage Measurements
WARNING: Risk of electrocution. Before use, always test the
Voltage Detector on a known live circuit to verify proper operation.
1.
Set the function dial to any position.
2. Place the tip of the meter to the hot
conductor or on the hot side of the
electrical outlet.
3. If AC voltage is present, the detector light
will illuminate.
NOTE: The conductors in electrical cord sets are
often twisted. For best results, rub the meter tip
along the length of the cord to assure placing
the tip in close proximity to the live conductor.
NOTE 2: The detector is designed with high sensitivity. Static
electricity or other sources of energy may randomly trip the sensor. This
is normal operation.
continued...
Compact Multimeter
NCV
R5099
AUTO nm FVA Mk
AC
DC
Hz %
Ω
H
SELECT HOLD Hz %
Compact Multimeter
NCV
R5099
SELECT HOLD Hz%
REED Instruments
11
Data Hold
1. While taking a measurement, press the HOLD button to freeze the
current reading on the LCD display.
2. While in this mode an "H" symbol will appear.
3. Press the HOLD button again to resume normal operation.
Auto Power Off
To preserve battery life, the meter is programmed to turn itself off after 30
minutes of inactivity. Press any button to delay the auto power off function
and resume normal operation.
Backlight
To turn the backlight on or off, press and hold the BACKLIGHT button for
2 seconds.
Battery Replacement
When the low battery icon
appears on the LCD, the batteries
must be replaced.
1.
Use a small Phillips head screwdriver
to remove the battery cover located
on the back of the meter.
2. Replace the 2 x "AAA" batteries.
3. Secure the battery cover back and
tighten the screw.
Applications
• Testing batteries
• Testing household wiring
• Testing electric motors
• Testing power supplies
REED Instruments
12
Product Care
To keep your instrument in good working order we recommend the following:
• Store your product in a clean, dry place.
• Change the battery as needed.
• If your instrument isn't being used for a period of one month or longer
please remove the battery.
• Clean your product and accessories with biodegradable cleaner. Do not
spray the cleaner directly on the instrument. Use on external parts only.
Product Warranty
REED Instruments guarantees this instrument to be free of defects in
material or workmanship for a period of one (1) year from date of shipment.
During the warranty period, REED Instruments will repair or replace, at no
charge, products or parts of a product that proves to be defective because
of improper material or workmanship, under normal use and maintenance.
REED Instruments total liability is limited to repair or replacement of the
product. REED Instruments shall not be liable for damages to goods,
property, or persons due to improper use or through attempts to utilize
the instrument under conditions which exceed the designed capabilities.
In order to begin the warranty service process, please contact us by email
determine the appropriate steps to process the warranty.
Product Disposal and Recycling
Please follow local laws and regulations when disposing or recycling your
instrument. Your product contains electronic components and must be
disposed of separately from standard waste products.
REED Instruments
13
Product Support
If you have any questions on your product, please contact your authorized
REED distributor or REED Instruments Customer Service by phone at
Please visit www.REEDINSTRUMENTS.com for the most
up-to-date manuals, datasheets, product guides and software.
Product specifications subject to change without notice.
All rights reserved. Any unauthorized copying or reproduction of
this manual is strictly prohibited without prior written permission
from REED Instruments.
REED Instruments
TEST & MEASURE
WITH CONFIDENCE
CHECK OUT OUR LATEST PRODUCTS!
REED Instruments
Table of contents
Other Reed Instruments Multimeter manuals
