Reed Instruments R5000 User manual

Watt Meter
Instruction
Manual
R5000
www. .com [e-mail]1.800.561.8187

Table of Contents
Introduction ................................................................................................ 3
Product Quality........................................................................................... 3
Safety ......................................................................................................... 3
Features...................................................................................................... 3
Included...................................................................................................... 3
Specications............................................................................................. 4
Instrument Description............................................................................... 5
Operating Instructions.............................................................................6-8
Voltage Measurements .......................................................................... 6
Current Measurements.......................................................................... 6
Watt Measurements............................................................................6-7
Data Hold............................................................................................... 7
Data Record (Max/Min Reading)............................................................ 8
Backlight................................................................................................ 8
Auto Power Off...................................................................................... 8
Battery Replacement.................................................................................. 8
Accessories and Replacement Parts ......................................................... 9
Product Care .............................................................................................. 9
Product Warranty ....................................................................................... 9
Product Disposal and Recycling .............................................................. 10
Product Support....................................................................................... 10
www. .com [e-mail]1.800.561.8187

3
Introduction
Thank you for purchasing your REED R5000 Watt Meter. Please read the
following instructions carefully before using your instrument. By following the
steps outlined in this manual your meter will provide years of reliable service.
Product Quality
This product has been manufactured in an ISO 9001 facility and has
been calibrated during the manufacturing process to meet stated product
specications. If a certicate of calibration is required please contact the
nearest authorized REED distributor or authorized Service Center. Please
note an additional fee for this service will apply.
Safety
 
product, other than for the purpose of replacing batteries, may cause
damage that will not be covered under the manufacturer's warranty.
Servicing should only be provided by an authorized service center.
 
 
 
Features
 
 
 
 
 
Included
 
 
www. .com [e-mail]1.800.561.8187

4
Specifications
Watt
Range: 0 to 6000W
Resolution: 1W
Accuracy: ±(1% + 5W)
AC Voltage
 
 
AC Current
Range: 0 to 10A
Resolution: 0.01A
Accuracy: ±(0.3% + 0.03A)
Power Factor
Range: 0 to 1.0
Resolution: 0.01
Accuracy: ±(1% + 2d)
General Specifications
 
 
 
 
 
 
 
 
Product Certications: CE
Operating Temperature: 32 to 104°F (0 to 40°C)
Storage Temperature: -4 to 140°F (-20 to 60°C)
 
Weight: 0.88lb (398g)
www. .com [e-mail]1.800.561.8187

5
Instrument Description
3
4
5
6
7
8
9
10
 
2.  Button
 
4. AC Adapter Terminal
 
6. Power Source
 
8. Record Button
9. Stand (Back)
10. Battery Cover (Back)
www. .com [e-mail]1.800.561.8187

6
Operating Instructions
Press and hold the POWER button to turn the meter on and off.
Voltage Measurements
1. Turn the meter on.
2. Press the FUNCTION
 
to the COM input terminal.
4. Touch the test leads to the voltage source.
5. Read the AC voltage measurement on the display. If the display

Current Measurements
1. Turn the meter on.
2. Press the FUNCTION button to select ACA.
3. Connect the red test lead to the 10A input terminal and the black test
lead to the COM input terminal.
4. Touch the test leads to the current source.
5. Read the AC current measurement on the display. The value indicated

indicates an out-of-range measurement.
Watt Measurements
Note:

is required (not included).
1. Turn the meter on.
 
3. Turn off the power source if applicable.
 
5. Plug in the power source to the WATT terminal and 10A terminal.
6. Push the FUNCTION button to change the function for

continued...
www. .com [e-mail]1.800.561.8187

7
7. Turn on the power source (if applicable) or insert a probe into each
vertical slot on the outlet as shown below and read out the Work

8. Turn on the equipment power switch (if applicable) or place one probe
to the ground slot of the light bulb (side of the light bulb) and the other

reading stabilize before reading out the Power Consumption from the

9. Push the FUNCTION
 
Data Hold
While taking a measurement, press the HOLD button. The measured

HOLD button again to resume normal operation.
continued...
www. .com [e-mail]1.800.561.8187

8
Data Record (Max/Min Reading)
1. Press the REC button once to start the Data Record function. A

2. Press the REC

 HOLD

4. Press the REC 

5. To delete the minimum value, press the HOLD

6. Press and hold the REC
the Data Record function and resume normal operation.
Backlight


Auto Power Off
To preserve battery life, the meter is programmed to turn itself off after
10 minutes of inactivity. To turn this function off, enter the Data Records
function by pressing the REC button.
Battery Replacement

you will need to replace the batteries. Make sure there are no test leads
attached to the meter, and that the meter is turned off before opening the
battery compartment.
1. Remove the battery cover with a screwdriver.
 
www. .com [e-mail]1.800.561.8187

9
Accessories and Replacement Parts
• CA-05ASoft Carrying Case
• R8888
• AP-9VA-110VAC Adapter
• FC-300
Don't see your part listed here? For a complete list of all accessories and
replacement parts visit your product page on www.reedinstruments.com.
Product Care
To keep your instrument in good working order we recommend the following:
 
 
 
please remove the battery.
 

Product Warranty
REED Instruments guarantees this instrument to be free of defects in
material or workmanship for a period of one (1) year from date of shipment.
During the warranty period, REED Instruments will repair or replace, at no
charge, products or parts of a product that proves to be defective because
of improper material or workmanship, under normal use and maintenance.
REED Instruments total liability is limited to repair or replacement of the
product. REED Instruments shall not be liable for damages to goods,
property, or persons due to improper use or through attempts to utilize the

order to begin the warranty service process, please contact us by phone at
1-877-849-2127 or by email at [email protected] to discuss the
claim and determine the appropriate steps to process the warranty.
www. .com [e-mail]1.800.561.8187

10
Product Disposal and Recycling
Please follow local laws and regulations when disposing or recycling your

disposed of separately from standard waste products.
Product Support
If you have any questions on your product, please contact your authorized
REED distributor or REED Instruments Customer Service by phone at
1-877-849-2127 or by email at [email protected].
Please visit www.REEDINSTRUMENTS.com for the most
up-to-date manuals, datasheets, product guides and software.
Product specifications subject to change without notice.
All rights reserved. Any unauthorized copying or reproduction of
this manual is strictly prohibited without prior written permission
from REED Instruments.
