CSE2 MIX F W 1F
CSE2 MIX F W 1F
EN
Installation and Operation Manual
CSE2 MIX F W 1F PUMP STATION

│2
Regulus CSE2 MIX F W 1F - www.regulus.eu
Contents
1. INTRODUCTION ...................................................................................... 3
2. PUMP STATION DESCRIPTION AND DATA ........................................... 3
3. PUMP STATION COMPONENTS ............................................................ 4
3.1. WILO PARA 25/8 SC PUMP .......................................................... 5
3.2. AVC ACTUATOR FOR MIXING VALVE ......................................... 9
3.3. LK 840 MIXING VALVE .................................................................. 10
3.4. CHECK VALVE .............................................................................. 11
3.5. FILTER WITH MAGNET ................................................................ 11
3.6. BALL VALVES ................................................................................ 12
4. PUMP STATION INSTALLATION ............................................................. 13
5. TEMPERATURE SENSOR INSTALLATION ............................................ 14
6. OPTIONAL ACCESSORIES .................................................................... 15

3 │
Regulus CSE2 MIX F W 1F - www.regulus.eu
1. INTRODUCTION
CSE2 MIX F W 1F twin-line pump station is designed for mixed heating circuits. It
provides ow through the heating system, mixes to the outlet temperature using a
motorized mixing valve (controlled by an external controller). The pump station includes
a lter with magnet, so it is also suitable for older steel pipe systems. It can be easily
mounted on a wall or on a manifold for multiple heating circuits.
2. PUMP STATION DESCRIPTION AND DATA
Main Features
Description The pump station consists of:
● Wilo Para 25/8 SC pump
● 2 ball valves w. sensor sheath
● check valve
● lter with strainer&magnet
● LK 840 actuated mixing valve
● thermometers, insulation
Working uid water, antifreeze heat-transfer uid for heating systems
Installation vertically on a wall or manifold (125 mm pitch)*
Connections 4 x G 1“ F
Code 17937
* A set of manifold connecting ttings can be purchased as optional accessories (see chapter 6)
Data for CSE2 MIX F W 1F Pump Station
Fluid working temperature 5 - 95 °C
Max. working pressure 6bar
Ambient temperature 0 - 40 °C
Max. relative humidity 95%, non condensing
Pump power supply 1 ~ 230 V, 50 - 60 Hz
Mixing valve power supply 230 V, 50 Hz; from external controller w. 3-point control
Insulation material EPP RG 60 g/l
Overall dimensions 360 x 133 x 245 mm
Total weight 6.7 kg

│4
Regulus CSE2 MIX F W 1F - www.regulus.eu
3. PUMP STATION COMPONENTS
1 – Thermometer at the heating circuit outlet
2 – Thermometer at the heating circuit inlet
3 – Wilo Para 25/8 SC circulation pump
4 – 3-point control AVC actuator with LK 840 mixing valve
5 – Check valve
6 – Dirt lter with magnet
7 – Lever for ball valves
8 – Ball valve w. sheath for temperature sensor (heating circuit outlet)
9 – Ball valve w. sheath for temperature sensor (heating circuit inlet)
2
4
3
5
8
7
1
6
9
3
4

5 │
Regulus CSE2 MIX F W 1F - www.regulus.eu
3.1. WILO PARA 25/8 SC PUMP
Wilo Para 25/8 SC circulation pump is a wet-running circulation pump permitting to
set speed control to Δp-v, Δp-c or n=constant. The operating status and possible faults
of the pump are displayed by means of LEDs directly on the pump display. It is used
exclusively for the circulation of liquids in hot water heating systems. Operating the
pump in other systems or in systems lacking water, containing air bubbles or not
pressurized can lead to its rapid destruction.
Wilo Para 25/8 SC Pump Data
Power supply 230 V, 50 Hz
Power input (min./max) 2 / 75 W
Current (min./max) 0.03 – 0.66 A
Max. speed 4800 rpm
Speed control frequency converter
Energy Efciency Index (EEI) ≤ 0.21 by EN 16297/3
IP rating IPX4D
Motor protection integrated
Min. pressure at the suction port to
avoid cavitation
0.5 mH2O at 55 °C
4.5 mH2O at 95 °C
Operating Parameters
Fluid working temperature 0 - 100°C at 58°C ambient temperature
Max. static pressure 10 bar
Max. head 8.4 m
Pump Wiring
1. POWER SUPPLY (1 ~ 230V, 50 Hz)
brown (L)
blue (N)
yellow-green (PE)
LED signals State description and possible fault reasons
GREEN IS LIT 1 - pump is running in trouble-free operation
RED IS LIT 1 - rotor is blocked
2 - electric motor winding defect
FLASHING RED
1 - power supply lower/higher than 230 V
2 - electric short circuit in pump
3 - pump overheated
FLASHING RED AND GREEN
1 - unforced uid circulation through the pump
2 - pump speed lower than desired
3 - air in pump
FAULT INDICATION

│6
Regulus CSE2 MIX F W 1F - www.regulus.eu
TROUBLESHOOTING, RESTART, FACTORY SETTINGS
If air is present in the pump:
Activate the pump venting function by pressing and holding the
operating button for 3 sec. The upper and lower rows of LEDs will
ash in 1sec interval, see Fig.
Pump venting takes 10 minutes, after that the pump returns to
current mode. In order to cancel pump venting, press and hold the
operating button for 3 sec.
Operating button locking/unlocking
To lock the operating button, press it for 8 seconds.
The selected setting then starts ashing and cannot be changed.
To unlock, hold down the operating button again for 8 seconds
and the LEDs will stop ashing.
Manual restart
If the pump has been inactive for a long time or is blocked, activate
the manual restart by holding the operating button for 5 seconds.
The LEDs ash sequentially clockwise. The manual restart takes
max. 10 minutes before the pump returns to normal operation. To
cancel the manual restart, hold down the operating button for 5
seconds.
If the pump does not get unblocked, contact a qualied technician.
Factory settings
To return to the factory settings, press and hold the operating button for at least 4
seconds (all LEDs ash for 1 second) and turn off the pump by unplugging. When
switched on again, the pump will run at the factory settings.
sec3
min10
sec8
sec5
min10

7 │
Regulus CSE2 MIX F W 1F - www.regulus.eu
PUMP CONTROL
Constant speed operating mode and pump performance curve III are preset as
factory settings for the PARA SC pump. After switching on, the pump runs at the
factory setting or at the last setting. The settings can be changed using the operating
button, see below.
Briey press the control button to:
select the pump operating mode: constant speed, Δp-v
or Δp-c and the pump performance curve (I,II,III).
Press and hold the operating button for the specied time to activate:
- Pump venting function - hold the control button for 3 seconds.
- Manual restart - hold the operating button for 5 seconds.
- Locking/unlocking the operating button - hold the button for 8 seconds.
- Factory setting - hold the control button for at least 4 seconds and switch off the
pump by disconnecting it from the mains.
SETTING THE PUMP SPEED CONTROL MANNER
Briey press the operating button for 1 second to select the pump speed control manner
and pump performance curve. LEDs show pump settings (operating mode Δp-v / Δp-c
/ n=const and the respective performance curve).
LED indicators Operating mode Performance curve
constant speed
constant speed
Δp-v variable
Δp-v variable
Δp-v variable
Δp-c constant
Δp-c constant
Δp-c constant
constant speed
OPERATING BUTTON

│8
Regulus CSE2 MIX F W 1F - www.regulus.eu
PUMP SPEED CONTROL
The following speed control can be selected:
Variable differential pressure ∆p-v
Constant differential pressure ∆p-c
Constant speed n=const.
Variable differential pressure (∆p-v)
This prole is suitable for use with two-line
radiator heating systems to reduce the
noise caused by the ow of liquid through
thermostatic valves. If the ow in the pipe
network decreases, the pump reduces the
head in half. This saves electrical energy by
adapting the head to the pumping capacity
requirement and lower ow velocities.
Constant differential pressure (∆p-c)
This prole is suitable for use in underoor
heating or for piping of bigger diameters. It
is also suitable for all applications without
variable characteristics (e.g. pumps for
HW storage tank heating) and for single-
line heating systems with radiators. The
pump maintains a constant set delivery
head regardless of pumping capacity.
0
1
2
3
4
5
6
7
0
20
40
60 III
I
II
III
I
II
H [m]
max.
Δp-v
max.
Q [m³/ h]
0 1 2 3 4
P [W]
1
Q [m³/ h]
0 1 2 3 4
Δp-v (variabilní)
(variable)
III
II
I
0
2
4
6
8
0
20
40
60 III
I
II
max.
Δp-c
max.
H [m]
P [W]
1
0 1 2 3 4
0 1 2 3 4
Q [m³/ h]
Q [m³/ h]
Δp-c (konstantní)
(constant)

9 │
Regulus CSE2 MIX F W 1F - www.regulus.eu
Constant speed (n=const.)
This prole is suitable for use in
constant resistance systems that
require constant pumping capacity. The
pump runs uncontrolled in three preset
constant speed stages.
3.2. AVC ACTUATOR FOR MIXING VALVE
LK 840 mixing valve is controlled by an AVC actuator with three-point control. The current
position of the valve member can be read from the sight glass on the actuator housing. The
control mode switch is used to set automatic or manual control. If manual control is set, the
actuator is controlled by turning the control knob.
Technical Data
Torque 5 Nm
Angle of rotation 90°
Shift time 120 s
Control 3-point
Auxiliary switch no
Power supply 230 V AC
Max. power input 2.5 VA
IP rating IP42
Protection class II by EN 60730-1
Ambient temperature 0 - 40 °C
Cable (cross section - length) 3 x 0.5 mm² - 2 m
0 1 2 3 4
max.
0
2
4
6
8
0
40
60
I
III
II
I
III
II
max.
Q [m³/ h]
Q [m³/ h]
H [m]
P [W]
1
0 1 2 3 4
konstantní otáčky I, II, III
20
constant speed I, II, III

│10
Regulus CSE2 MIX F W 1F - www.regulus.eu
3.3. LK 840 MIXING VALVE
Technical Data
Max. working temperature 5 - 110 °C (120 °C in short term)
Max. working pressure 10 bar
Ambient working temperature 5 - 60 °C
Valve Kvs 6.3 m3/h
Max. pressure difference 5 mH2O
Leak rate < 1 % Kvsat 5 m H2O pressure difference
Connections 3 x G 1“ M
Materials
Valve housing, spindle and member brass
Gasket EPDM
Mixing Valve Pressure Drop Diagram
AVC ACTUATOR ELECTRICAL WIRING
1 – (blue)
2 – (black)
3– (brown)
The actuator is factory-set and ready for operation. If it needs to be removed or
replaced, follow the instructions in the appendix.

11 │
Regulus CSE2 MIX F W 1F - www.regulus.eu
3.4. CHECK VALVE
The check valve downstream of the lter prevents natural circulation in the heating circuit.
Check Valve Pressure Drop Diagram
3.5. FILTER WITH MAGNET
The lter located on the return line of the pump station is designed to collect solid particles
from the working uid. It consists of a brass housing, a removable metal strainer collecting
coarse impurities and a brass cap with magnet that collects magnetic impurities.
The lter should be checked regularly and cleaned if necessary. The lter shall be cleaned
with the circulation pump switched off and the section where the lter is installed shut off. In
the section upstream of the lter, shutting off is done by a ball valve, in the section downstream
of the lter the piping is shut off by a check valve. The lter cap needs to be unscrewed, the
metal strainer removed and rinsed thoroughly from any dirt. Dirt trapped on the magnet must
be wiped off and then reassembled by inserting the strainer, screwing in and tightening the
cap.
Filter w. Magnet Pressure Drop Diagram
0
0,1
0,2
0,3
0,4
0,5
0,6
0,7
0,0 0,3 0,6 0,9 1,2 1,5 1,8 2,1 2,4 2,7 3,0
∆p [mH20]
V [m3/h]

│12
Regulus CSE2 MIX F W 1F - www.regulus.eu
3.6. BALL VALVES
Technical Data
Kv value 20.2 m3/h
Ball valves are intended to isolate the pump station from the heating circuit. Then it is not
necessary to drain the heating circuit for servicing (incl. cleaning the lter). In order to have
a more solid hydraulic section of the pump station, they are xed to the rear mounting plate.
The ball valves are controlled by a lever that is not present on the valve during operation.
The valve is closed by turning the lever clockwise by 90°. The open / closed position on the
ball valve is indicated by a groove on the control wheel. The groove is perpendicular to the
direction of ow when the ball valve is closed. The ball valve opens by turning the lever anti-
clockwise by 90°, the groove is then in the ow direction. Before closing / opening the ball
valve, the top section of the insulation shall be removed rst. As a result, unintentional closure
of the system by an unauthorized person is not possible.
OPEN CLOSED
groove in the ow direction groove perpendicular to the ow direction

13 │
Regulus CSE2 MIX F W 1F - www.regulus.eu
4. PUMP STATION INSTALLATION
The load unit is designed to be mounted on a wall or a manifold with 125 mm connection
pitch. In the rear section of the insulation there are two mounting holes for xing the metal
plate to the wall. Mounting holes pitch is 175 mm.
Installation dimensions are shown in the gure below.
The package includes a mounting kit that is used to x the pump station to the
intended place.
The mounting kit includes:
Screw 5x50, round head 2 pcs
6.4 stainless steel washer, DIN 9021/A2 2 pcs
Wall plug 8mm TX 2 pcs
340 360
125
245

│14
Regulus CSE2 MIX F W 1F - www.regulus.eu
5. TEMPERATURE SENSOR INSTALLATION
The ball valve housings are equipped with a sheath for the temperature sensor, where the
sensor can be inserted and secured by a xing screw against being pulled out. In the top
and bottom section of the insulation there are passages to run the cables through, then it is
necessary to cut the appropriate part of the passage lock from the front part of the insulation
with a knife, so that the exiting cables are rmly wrapped around by the lock.
1.
Temperature sensor placement
2.
Securing the temperature sensor with
the screw
3.
Running the sensor cable through the
recess in the insulation

15 │
Regulus CSE2 MIX F W 1F - www.regulus.eu
4.
Trimming the cable passage lock
5.
Installed sensors
6. OPTIONAL ACCESSORIES
The following optional accessories are available for the pump station:
- set of two ball valves with drain
valve G 1“ Fu x G 1“ F x G 1/2“ M
with manifold connection ttings
Code 17928
– G 1“ Fu x G 5/4“ F manifold
connection ttings
Code 17920
code 17928

│16
Regulus CSE2 MIX F W 1F - www.regulus.eu
APPENDIX – AVC ACTUATOR ADJUSTMENT
– The actuator is set and ready for operation from the production
– The instructions apply only if the actuator had to be removed e.g. to be replaced
1.
When tting the actuator, turn the
D-shaft in such a manner that the
valve member is between inlets 2
and 3.
2.
Fit the plastic adapter on the shaft.
The at edge of the shaft and the
arrow on the plastic adapter are
located on the same side as the valve
member.
valve member position
D shaft
D shaft
valve member
position
arrow on
plastic adapter

17 │
Regulus CSE2 MIX F W 1F - www.regulus.eu
3.
Prior to tting the actuator on the
plastic adapter, switch it to manual
control, set the control knob exactly to
the middle of its movement range.
4.
Fit the actuator onto the plastic
adapter. Check its turning: the control
knob shall be able to turn freely both
to left and right by 45° (when turned to
the right by 45° the path 3 is closed,
and when turned to the left by 45° the
path 2 is closed). Having performed
the check, tighten the fastening screw
and switch back to automatic control.
5.
The actuator shall be installed in the
same manner as in the gure.
control mode
switch
middle of the movement range
automatic control
manual control control knob

©2020 We reserve the right to errors, changes and improvements without prior notice.
REGULUS spol. sr.o.
E-mail: [e-mail]
Web: www.regulus.eu
v1.0-05/2020
