REI HD400 User manual

Quick-Start
Radio Engineering Industries, Inc.
640431 - Rev A –2/19/13
Software Installation
To install the REI VMS:
1) Locate the installation program, “Setup REI
VMS.exe”on your CD-ROM and double click the
icon.
2) If the User Account Control screen is shown,
click ‘Yes’.
3) When the ‘Welcome Screen’ shows, follow the
instructions on the screen.
Viewing Hard Drive Video
1) Unlock the Hard Drive from the DVR by turning
the key from the “Lock” to the “Unlock”
position. Firmly pull the Hard Drive out of the
BUS-WATCH® Device.
2) Connect the Hard Drive to the computer using
the provided USB Cable.
3) Find and double click the icon REI VMS on your
Windows Desktop.

Quick-Start
Radio Engineering Industries, Inc.
640431 - Rev A –2/19/13
Viewing Video (Continued)
4) The default window should appear like the
below window. The details of each button will
be detailed in other sections.
5) Click ‘SOURCE SELECT’ and then select the
button for ‘Hard Drive’.
6) The Hard Drive will populate the Calendar and
then the Video Segments list. To begin
playback, you may:
a) Find and select the ‘Play’ button
b) Double-click and item in the Video
Segments list
c) Select a location on the Time Bar:
REI has 24/7 technical support to assist
you. If you have any questions please
call the service hotline at:
1-877-726-4617 (Toll Free)

Quick-Start
Radio Engineering Industries, Inc.
640431 - Rev A –2/19/13
PC Specifications
HD400
RECOMMENDED REQUIREMENTS
Operating System: Windows 7
Processor: Intel Core i3 CPU
RAM: 4GB
Hard Disk Space: 35 MB for software, 400GB or
more for video
CD‐ROM required for installation
10/100 Base‐T Network Interface Card /
Controller
One USB 2.0 Controller
DirectXc‐compatible sound card
Video Card: 512 MB nVidia GeForce GTX460 or
AMD HD6850 or better
Resolution: 1600x1200 32k colors or better
DirectX 9.0c
HD800
RECOMMENDED REQUIREMENTS
Operating System: Windows 7
Processor: Intel Quad Core i5 or better
RAM: 6GB or better
Hard Disk Space: 35 MB for software, 1TB or
more for saved video
CD‐ROM required for installation / DVD+/-RW
for archival if applicable
10/100 Base‐T Network Interface Card /
Controller
At least two USB 2.0 Controllers
USB 3.0 Controller
SD Card Reader (if applicable to end use)
DirectX 9.0c compatible sound card
Video Card: 1GB nVidia GeForce GTX660 or AMD
HD6870 or better
Resolution: 1920x1200 with 32k colors or better
