REITEL DELIMER COMFORT User manual

Operating Instructions
LABORATORY EQUIPMENT
IN STAINLESS STEEL
DELIMER COMFORT
REITEL Feinwerktechnik GmbH
Senfdamm 20 | 49152 Bad Essen
Tel.: [phone] | Fax: [phone]
www.reitel.com | [email protected]

II
Dear customer!
The DELIMER COMFORT is a water softening device (ion exchange) for decalcifying tap
water without cartridge replacement. The DELIMER COMFORT removes calcium from the
water and thus prevents lime-scale deposits that can cause damage to the appliance . Even
existing lime-scale deposits are gradually reduced.
Any other use or usage beyond this scope is considered unintended use. The manufacturer
shall not be responsible for any damages that may result thereby. Prior to installation of the
device operating instructions and especially the safety instructions must be read and
followed by all personnel who use this device.
After having unpacked the device, please check carefully whether transportation damages of
any kind have occurred. If that is the case, the carrier or manufacturer must be notified within
3 days. The company will not be responsible for any damages found after that.
These operating instructions must be read and followed by all personnel who use this device.
To ensure quick access we recommend to keep it at a safe place near the device. In case of
loss it can be ordered from the manufacturer.

III
INDEX
TECHNICAL DESCRIPTION......................................................................................... 4
BASIC EQUIPMENT ....................................................................................................... 4
SPECIAL ACCESSORIES................................................................................................ 4
DEVICE COMPONENTS.................................................................................................. 4
TECHNICAL DATA......................................................................................................... 6
SAFETY NOTES........................................................................................................... 7
GENERAL SAFETY NOTES ............................................................................................ 7
SPECIFIC SAFETY NOTES............................................................................................. 8
INSTALLATION ............................................................................................................ 9
INSTALLATION.............................................................................................................. 9
FILLING WITH REGENERATION SALT............................................................................... 9
OPERATION................................................................................................................. 9
START-UP ................................................................................................................... 9
REGENERATION..........................................................................................................10
TROUBLESHOOTING .................................................................................................10
MAINTENANCE...........................................................................................................10
WARRANTY.................................................................................................................11
DISPOSAL REGULATIONS ........................................................................................14
SPARE PARTS LIST ...................................................................................................14
EC-CONFORMITY DECLARATION.............................................................................15

4
Technical description
Basic equipment
•Water softening device DELIMER COMFORT with water inlet hose
Special accessories
•Order-No.: 20201 Water tap
•Order-No.: 20202 Back pressure valve
Device components
1 Housing
2 Main switch
3 Lid for salt container
4 Rotary switch for regeneration
5 Water connector for the supply line
6 Drain hose connector
7 Hose connector for connecting devices
8 Mains connection
9 Device fuse
10 Regeneration salt indicator

5
Fig.: Device view
Fig.: Rear view
1
10
2
3
9
4
8
5
6
7

6
Technical data
Line voltage
230 V/50–60 Hz
Current consumption
100 W
Height / Width / Depth
434/327/294 mm
Weight
11 kg
Water pressure
max. 3 bar
Mains water supply
3,5 l/min
Extracted water
Kalkreduziertes Wasser (50 % dH)
Sound level
≤70 dB(A)
Housing
Stainless steel
Order-No.:
10205
Made in Germany (Subject to modifications)

7
Safety Notes
General Safety Notes
•All equipment undergoes final inspection and testing before leaving our factory. However,
if equipment is damaged during shipping or through any other circumstances, it must not
be used in service. Please check the device regularly for damages. Damaged parts
should be replaced immediately.
•All power / air / water / gas sources should be rated for the demands of the device as
listed in the technical data sheets. Maximum ratings must not be exceeded. All VDE
(Verein Deutscher Elektro-Ingenieure) standards should be followed. Equipment should
be grounded according to standards.
•Adherence to valid regulations regarding necessary checks (e.g. according to Accident
Prevention & Insurance or electrical equipment) is exclusively taken over by the
buyer/user of this product.
•This device has been designated to be used only for its intended purpose. All other
applications must be prohibited for safety reasons as otherwise the manufacturer’s
warranty expires.
•The device may only be used by persons who have been instructed in the handling and
are expressly commissioned with the operation.
•The device should be set-up in a clean, well-ventilated room, if necessary under a hood.
•Supporting surfaces should be straight, flat and adequately stable.
•No objects may be placed on the device.
•To avoid injury, appropriate protection should be worn (as gloves, safety glasses, safety
shoes, hearing protection etc.)
•If the machine is defective or working improperly it must be taken out of service. In case
of further use of the machine the owner will be held responsible for any consequential
damage.
•To prevent accidents from water, fire or explosion, all power/air/water/gas sources should
be turned off after working hours and during breaks, and secured against unauthorized
access.
•When carrying out maintenance works or repairs or when opening the device always turn
off the main power switch and unplug the whole unit.
•Repairs should be carried out only by the manufacturer or by qualified and certified
personnel appointed according to chapter 7 –warranty.
•In case of leaking water out of housing or tank shut down device and call service.
•Check all hose connections for leak tightness, if necessary tighten hose clamps again

8
Specific Safety Notes
•Install the appliance so that damage is prevented in the event of unwanted water
leakage.

9
Installation
The electrical equipment is ready for immediate use. The sealed plug can be connected
directly to the mains supply 230 V/16 A. For installation please refer to safety notes in
chapter 2.
Installation
Connect the delivered water inlet hose to the water connector for the supply line (5) and
attach the other end to a tap with ¾” external thread.
Connect the inlet hose of the connecting device (REITEL steam cleaner TRONADA) to
the hose connector (7).
Attach a hose to the drain hose connector (6) and lead the other end of the hose to a
suitable drainage port.
Filling with regeneration salt
When using the appliance for the first time, or when the regeneration salt indicator (10) lights
up in red, regeneration salt needs refilling. Prior to refilling, empty water from the DELIMER
COMFORT’s tank to prevent an overflow (if necessary, use a dry cloth to wipe away surplus
water in the bowl).
The filling quantity with empty container is approx. 1 kg.
Caution: Use only special salt for regeneration appliances (for example, dishwasher
regeneration salt). Other regenerating agents will destroy the ion exchanger.
Open the lid (3).
Fill in special salt (when filling up for the first time, add water) until the regeneration
salt indicator light (10) goes off.
Close the lid (3).
Operation
Start-up
Open the tap.
Switch on the device with the main switch (2).
Switch on the connecting device.

10
Regeneration
Perform the regeneration once a week. Duration: approx. 15 min. During this time no water
removal is possible. The regeneration must not be interrupted.
Open the tap.
Switch on the device with the main switch (2).
Switch off the connection device (e.g REITEL “TRONADA”).
Turn the rotary switch for regeneration (4) clockwise until it stops.
Wait for the process to complete.
Troubleshooting
Device doesn’t turn on.
a. Check fuses in the building.
b. Check device fuse
Device fuse has triggered.
Disconnect the mains plug and replace
the fuse (9).
Lid (3) pops off.
Leaking solenoid valve, inform customer
service.
Regenerating salt indicator (10) lights up
red.
Regenerating salt quantity insufficient, top
refill regenerating salt according to chapter
3.2.
Connection device calcified (for example
steam cleaner).
a. No regenerating salt in the container.
b. Regeneration failed.
c. Intervals too long (please observe the
maintenance cycles according to
chapter 4.2 Regeneration).
Maintenance
•Check the device at regular intervals for visible damage to housing or power cord.
•Please observe the intervals for regeneration according to chapter 4.
•Periodically clean the housing with a damp cloth.
Note
Clean and protect your device at regular intervals with the REITEL stainless steel care
spray (order -no.: 90405) to remove lime, plaster and dust as well as other
contaminants from the surface of the equipment and to prevent corrosion. The spray
creates a lasting, water repellent protective film which helps keep the equipment clean.

11
Warranty
We, REITEL Feinwerktechnik GmbH, offer a 1 year’s warranty beginning from the proven
date of purchase. This warranty covers all defects traceable to materials, design or
workmanship. The following warranty regulations are applicable:
Within the warranty period Reitel Feinwerktechnik GmbH or an authorized distributor agrees
at its sole option, to perform repair or replace this product at no charge covering all defects
traceable to materials, design or workmanship. Warranty only applies to appropriate use and
regular maintenance of this product according to the operating instructions. Claims under
warranty are restricted to complementary performance. Additional claims, especially claims
for indemnifications, are not covered by this warranty.
1.
Warranty claims have to be addressed to the distributor the product was purchased from or
directly to our service department.
Contact:
REITEL Feinwerktechnik GmbH
Senfdamm 20
49152 Bad Essen
Germany
Phone: [phone] (Service Department)
Phone: [phone] (Reception)
Fax-No: [phone]
2.
In case of warranty claim application the sales receipt or your purchase invoice showing the
date of purchase of the product and the serial number must be furnished. Securely pack and
ship the device, freight charges prepaid, at your own risk to us, along with a report describing
the defect. We reserve the right to decline warranty if this information has been removed or
modified after purchase of the product or if they are not included in case of warranty claims.
3.
Warranty repairs have to performed by REITEL Feinwerktechnik GmbH or by authorised
distributors. Repairs performed by non-authorised companies will void the claim for refund
since damages to the product resulting hereof are not covered by warranty.
4.

12
If the unit sent in for repair or replacement is still under the original warranty then warranty is
to the end of the original 1 year warranty.
5.
If the unit is destined to be operated in another country than originally intended and
manufactured for, modifications to the product might be necessary to comply to special
technical and /or safety standards of that specific country. Such modifications are no defects
traceable to materials, design or workmanship. and are therefore expressly excluded from
warranty claims.
Modification costs or damages arising from operation of the product under deviating
conditions are not covered by warranty.
6.
Exclusions from warranty:
Service and maintenance work as well as repair and replacement of consumables according
to our consumables‘ list
Transportation cost of the machine or installation and dismounting expenses incurred
Damages due to use of the product other than for its intended purpose
Damages due to faulty installation or insufficient maintenance of the product (e.g.
decalcification)
Damages due to natural disaster e.g. lightning, water, fire, act of nature beyond control, war,
inadequate line voltage, insufficient ventilation, no decalcification, insufficient care and
cleaning or non-adherence to operation and maintenance instructions according to the
accompanying operation guide.
Damage due to use of the product other than in accordance with the instructions provided by
REITEL Feinwerktechnik GmH;
The warranty does not cover the cost of removal and replacement of parts and accessories,
unless supplied as original equipment by REITEL Feinwerktechnik GmbH
All kind of damages occurred not directly at the device as well as consequential damages
(e.g. damages to furniture due to a lack of water, downtime of the machine, material, lost
working hours, wages and other consequential damages).
This warranty shall be rendered null and void if:
the product has been subject to any modification, repair or replacement other than as
authorised by REITEL Feinwerktechnik GmbH

13
the product is continued to be operated despite a functional defect
7.
The warranty is device specific and may be claimed, within the warranty period, by any
person who has legally acquired the device.
8.
Consumables are excluded from warranty. Spare parts are subject to a warranty coverage of
6 months against all defects traceable to materials, design or workmanship according to
these warranty regulations.
9.
Legal default claims on the part of the purchaser remain unaffected by this warranty.
10.
We reserve the right to charge a fee if repair of the device is rejected and the device is
destined to be sent back unrepaired.
11.
Please note:
Upon repair or replacement of this unit, personal data and settings might get lost or
damaged. We don’t accept liability for all kind of data loss. The customer is advised to
backup essential programs and data before sending for service.
12.
This warranty shall be interpreted in accordance with German law to the exclusion of UN
sales law. Place of jurisdiction is our business location.
13.
If any provisions of this warranty are judged to be illegal or unenforceable, the continuation in
full force and effect of the remaining provisions will not be prejudiced. The provisions of this
warranty judged to be illegal or unenforceable shall be construed so as to give effect to the
intent manifested by the provision held invalid, illegal or unenforceable and to give effect to
section 13 hereof.
14.
Should you need to borrow a device while your device is being repaired, please contact
Messrs. REITEL or your distributor. These loans are a service for which availability cannot
necessarily be guaranteed. After the warranty period, a fee may be charged for loan
equipment as well as for shipping and packaging.

14
Disposal Regulations
According to valid regulations our devices are properly disposed of according
to B2B –Regulations for proper disposal. Please contact your local dealer for
further information.
Spare parts list
Z.-Nr.:
Dr.-No.:
Best.-Nr.:
Ref.:
Menge
Qty.
ME
Unit
E60229.3
Dichtung / seal
1
St./pc.
E60229.4
Deckel mit Dichtung (Version aktuell) / Lid with seal
(current version)
1
St./pc.
E60229.3
Dichtung (Version aktuell) / Lid (current version)
1
St./pc.
E76296
Drehknauf / Knob
1
St./pc.
E62140.1
Druckminderer (Version aktuell) / Pressure reducing
valve (current version)
1
St./pc.
E62998
Druckschalter 0,2 - 3 bar Einstellung 1,4 bar 1/8"
oder 1/4" / Pressure switch
1
St./pc.
E62218
Durchflussbegrenzer (Version ab 08.2008) / Flow
limiter (version from 08.2008)
1
St./pc.
E70491
Feinsicherung / Fine fuse
1
St.pc.
E60231
Gehäuse komplett / Complete housing
1
St./pc.
E70496
Gerätestecker mit Sicherungshalter / Device's plug
incl. fuse holder
1
St./pc.
E60203
Gummifüße / Rubber feet
1
Satz/set
E60227
Gummitülle / Rubber sleeve
1
St./pc.
E60229.1
Ionentauscher / Ion exchanger
1
St./pc.
E74134
Kontrolllampe rot, rund / Red control lamp
1
St./pc.
E72139.1
Magnetventil 1/8" NW 3 mm / Solenoid valve 1/8"
NW 3 mm
1
St./pc.
E60940
Mikroschalter (Version aktuell) / Micro switch
(current version)
1
St./pc.
E60229.5
Mutter / Nut
1
St./pc.
E60648
Schalter 2-polig mit Lampe grün / 2-pole switch with
green lamp
1
St./pc.
E60207
Schaltwerk komplett (Version aktuell), incl. 76294 /
Complete control unit (current version), incl. 76294
1
St./pc.
E60650
Schutzkappe für Schalter / Protective cap for switch
1
St./pc.
E60204
Wasserauffangblech / Water drip tray
1
St./pc.
E60232
Wasserschlagdämpfer / Water hammer absorber
1
St./pc.
20201
Wasserhahn für manuelle Wasserentnahme / Water
tap
1
St./pc.
E60220
Zulaufschlauch / Feeding hose
1
St./pc.

15
EC-Conformity Declaration

We manufacture in compliance with Quality Management ISO 9001:2015 incorporating
established standards.
REITEL Feinwerktechnik GmbH
Senfdamm 20 | 49152 Bad Essen
Phone: [phone] | Fax: [phone]
www.reitel.com | [email protected]
032018
