Rejuvenation The Petrel User manual

OWNER’S MANUAL
To achieve successful installation and fan operability, please
read and fully follow these step by step installation instructions.
Net Weight 15.52 lbs (7.04 kgs)
Ceiling Fan
The Petrel

1. LIMITED LIFETIME MOTOR WARRANTY - If any part of your fan motor fails, due to a defect in materials or workmanship during
the lifetime of the original purchaser, Fanimation will provide the replacement part free of charge, when the defective fan is returned
to our national service center. Proof of purchase is required. Customer shall be responsible for all costs incurred in the removal or
reinstallation and shipping of the product for repairs or replacement.
2. ONE YEAR MOTOR LABOR WARRANTY - If your fan motor fails at any time within one year from the original purchase, due to
defects in materials or workmanship, labor to repair the motor will be provided free of charge at our national service center. Purchaser
will be responsible for labor charges after this one-year period. Customer shall be responsible for all costs incurred in the removal or
reinstallation and shipping of the product for repairs or replacement.
3. If any other part of your fan fails at any time within one year after original purchase, due to a defect in materials or workmanship, we
will repair, or replace, at our option, the defective part free of charge for parts and labor performed at our national service center.
4. Because of varying climate conditions, this warranty does not cover changes in the finish, including rusting, pitting, corroding,
tarnishing, or peeling.
5. This warranty is void and does not apply to damage from improper installation, neglect, accident, misuse, exposure to extremes of
heat or humidity, or as a result of any modification to the original product.
6. All costs of removal and reinstallation of the fan are the sole responsibility of the owner of the fan and not the store that sold the fan
or Fanimation.
7. Fanimation reserves the right to modify or discontinue any product at any time and may substitute any part under this warranty.
8. Under no circumstances may a fan be returned without prior authorization from Fanimation. The receipt of purchase must ac-
company authorized returns and must be sent freight prepaid to Fanimation. The fan to be returned must be properly packed to avoid
damage in transit; Fanimation will not be responsible for any damage resulting from improper packaging.
9. It is understood that any repair or replacement is the exclusive remedy available from Fanimation. There is no other expressed or
implied warranty. Fanimation hereby disclaims any and all implied warranties, including, but not limited to those of merchantability and
fitness for a particular purpose to the extent permitted by law. Some states do not allow limitations on implied warranties. Fanimation
will not be liable for incidental, consequential, or special damages arising out of or in conjunction with product use or performance,
except as may otherwise be accorded by law. This warranty gives you special legal rights and you may also have other rights that vary
from state to state.
10. A certain amount of wobble is normal and should not be considered a problem or a defect.
LIMITED LIFETIME WARRANTY
Extends to the original purchaser of a Fanimation Fan
Important Safety Instructions
WARNING: To avoid fire, shock and serious personal injury, follow these instructions.
1. Read your owner’s manual and safety information before installing your new fan. Review the accompanying assembly diagrams.
2. Before servicing or cleaning unit, switch power off at service panel and lock service panel disconnecting means to prevent power
from being switched on accidentally. When the service disconnecting means cannot be locked, securely fasten a warning device, such
as a tag, to the service panel.
3. Be careful of the fan and blades when cleaning, painting, or working near the fan. Always turn off the power to the ceiling fan before
servicing.
4. Do not insert anything into the fan blades while the fan is operating.
5. Do not operate reversing switch until fan blades have come to a complete stop.
Additional Safety Instructions
1. To avoid possible shock, be sure electricity is turned off at the fuse box before wiring, and do not operate fan without blades.
2. All wiring and installation procedures must satisfy National Electrical Codes (ANSI/ NFPA 70) and Local Codes. The ceiling fan
must be grounded as a precaution against possible electrical shock. Electrical installation should be made or approved by a licensed
electrician.
3. The fan base must be securely mounted and capable of reliably supporting at least 35 lbs. See page 6 of owner’s manual for
support requirements. Consult a qualified electrician if in doubt.
4. The fan must be mounted with the fan blades at least 7 feet from the floor to prevent accidental contact with the fan blades.
5. Follow the recommended instructions for the proper method of wiring your ceiling fan. If you do not have adequate electrical
knowledge or experience, have your fan installed by licensed electrician.
6. Suitable for use with solid-state speed controls.
WARNING: TO REDUCE THE RISK OF SHOCK, THIS FAN MUST BE INSTALLED WITHA GENERAL USE ISOLATING WALL
CONTROL/SWITCH.
WARNING: This product is designed to use only those parts supplied with this product and/or accessories designated specifically for
use with this product. Using parts and/or accessories not designated for use with this product could result in personal injury or property
damage.
WARNING:
WARNING: Do not operate this fan with a variable (Rheostat) wall controller or dimmer switch. Doing so could result in damage to the
To reduce the risk of personal injury, do not bend the blade bracket (flange or blade holder) when installing the brackets,
balancing the blades, or cleaning the fan. Do not insert foreign objects in between rotating fan blades.
6. The appliance is not intended for use by young children or infirm persons without supervision. Young children should be supervised to
ensure that they do not play with the appliance.
8. For supply connections, if the conductor of a fan is identified as a grounded conductor, then it should be connected to a grounded
conductor power supply. If the conductor of a fan is identified as an ungrounded conductor, then it should be connected to an ungrounded
conductor power supply. If the conductor of a fan is identified for equipment grounding, then it should be connected to an
equipment grounding conductor.
7. This fan is to be used in damp locations.
ceiling fan's remote control unit.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Please note that changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.

Table of Contents
Unpacking Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical and Structural Requirements. . . . . . . . . . . . . .
Energy Efficient Use of Ceiling Fans . . . . . . . . . . . . . . . .4
5
5
7
How to Assemble Your Ceiling Fan. . . . . . . . . . . . . . . . .
How to Hang Your Ceiling Fan . . . . . . . . . . . . . . . . . . . .
How to Assemble Your Ceiling Fan (Close to Ceiling) . .
How to Wire Your Ceiling Fan . . . . . . . . . . . . . . . . . . . . . 11
10
. 9
How to Install Your Canopy Housing . . . . . . . . . . . . . . .13
How to Assemble Your Fan Blade. . . . . . . . . . . . . . . . . .14
How to Assemble Your Light Kit Assembly . . . . . . . . . . .15
How to Operate Your Ceiling Fan. . . . . . . . . . . . . . . . . . . .17
Setup the fanSync App (optional) . . . . . . . . . . . . . . . . . .
How to Install Your Remote Control . . . . . . . . . . . . . . . . 20
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
21
How to Clean Your Ceiling Fan Blades . . . . . . . . . . . . . . .21
Petrel Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Fan Blade Optional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Petrel Exploded-View Illustration. . . . . . . . . . . . . . . . . . .
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
23

This manual is designed to make it as easy as possible for you
to assemble, install, operate, and maintain your Rejuvenation ceiling fan.
Unpacking Instructions
For your convenience, check-off each step. As each step is completed, place a check mark. This will ensure that all
.detpurretniebuoydluohsecalpruoygnidnifnilufpleheblliwdnadetelpmocneebevahspets
Wiring outlet box and box connectors must be of type
required by local code. The minimum wire would be a 3-
conductor (2-wire with ground) of the following size:
NOTE: Place the parts from the loose parts bags in a small
container to keep them from being lost. If any parts are missing,
contact Rejuvenation technical support at 888.567.2055
Tools Needed for Assembly Materials
Wire Size A.W.G.Installed Wire Length 14
12
Up to 50 ft.
50 - 100 ft.
NOTE: If you are uncertain of part description, refer to
exploded view illustration.
4
1. Check to see that you have received the following
parts:
Hardware BagsMotor Assembly
Downrod/Hanger Ball
Assembly
Ceiling Canopy
• One Phillips head screwdriver
• One 1/4˝flat head screwdriver
• One stepladder
• One wire stripper
• One hex wrench
• Four wire connectors
WARNING
WARNING
Before assembling your ceiling fan, refer to section on
proper method of wiring your fan (page 11). If you feel you
do not have enough wiring knowledge or experience,
have your fan installed by a licensed electrician.
• Motor Assembly
• Hanger Bracket Assembly
• Downrod/Hanger Ball
Assembly
• Ceiling Canopy
• Motor Coupling Cover Assembly
• Blade Holder Set
• Blade Holder Cover Set
• Light Plate Assembly
• Light Housing Assembly with Glass
• LED Assembly
• Hand-Held Remote
• Receiver Unit
• Canopy Trim Ring Assembly
• Hardware bags:
– Ten 1/4˝-20 Pan Head screws
(blade holder to fan motor hub)
with lockwashers
– Four wire connectors
Hanger Bracket
Assembly
Motor Coupling
Cover Assembly
Canopy Trim
Ring Assembly
Do not install or use fan if any part is damaged or
missing. This product is designed to use only those
parts supplied with this product and/or any accessories
designated specifically for use with this product by
Fanimation. Substitution of parts or accessories not
designated for use with this product by Fanimation could
result in personal injury or property damage. Contact
Rejuvenation at 888.567.2055 for missing or damaged
parts.
Blade Holder Set Blade Holder Cover Set
Light Plate Assembly
Light Housing Assembly
With Glass
LED Assembly
– Ten 3/16˝-24 Flat and Serrated
Head screw (blade to blade holder)
– Bag Assembly Safety Cable
Hand-Held Remote
Receiver Unit

5
Energy Efficient Use of Ceiling Fans
Ceiling fan performance and energy savings rely
heavily on the proper installation and use of the ceiling
fan. Here are a few tips to ensure efficient product
performance.
Using the Ceiling Fan Year Round
Summer Season: Use the ceiling fan in the counter-
clockwise direction. The airflow produced by the ceiling
fan creates a wind-chill effect, making you “feel” cooler.
Select a fan speed that provides a comfortable breeze,
lower speeds consume less energy.
Winter Season: Reversethemotor andoperate theceiling
fan at low speed in the clockwise direction. This produces
a gentle updraft, which forces warm air near the ceiling
down into the occupied space.Remember to adjust your
thermostat when using your ceiling fan - additional energy
and dollar savings could be realized with this simple step!
Electrical and Structural Requirements
Your new ceiling fan will require a grounded electrical
supply line of 120 volts AC, 60 HZ, 15 Amp Circuit.
Electrical code requires use of a fan-rated outlet box to
support the extra weight and motion associated with a
ceiling fan. A fan-rated box will be labeled as such and
typically supports up to a 70lbs ceiling fan. Fan-Rated
Outlet Boxes vary in ratings and design. Ensure the
ratings of your ceiling fan outlet box meet the
requirements for the ceiling fan being installed. Figure 1,
Figure 2 and Figure 3 depicts different structural
configurations that may be used for mounting the
outlet box.
Low-profile use (Figure 1)
A 12-in.-deep pancake box is meant to be screwed to a
joist or block. It’s used if only one cable is coming into
the box. It is also available in a saddle-mount
configuration.
CEILING
2" x 4"
CEILING JOIST
OUTLET BOX
Figure 1
Figure 2
2" x 4"
CEILING JOIST
CEILING OUTLET BOX
Deep-profile use (Figure 2)
A 2-1 -in.-deep box can be attached to blocking
between joists and is roomy enough to handle more
than one cable.
Choosing the Appropriate Mounting Location
Ceiling fans should be installed, or mounted, in the middle
of the room and at least 7 feet from floor to the blade and
18 inches from wall to the blade. If ceiling height allows,
install the fan 8 - 9 feet from floor to the blade for optimal
airflow. Consult your Fanimation Retailer for optional
mounting accessories.
Turn Off When Not in the Room
Ceiling fans cool people, not rooms. If the room is
unoccupied, turn off the ceiling fan to save energy.

6
Electrical and Structural Requirements (Continued)
If your fan is to replace an existing light fixture, turn
electricity off at the main fuse box at this time and
remove the existing light fixture.
Turning off wall switch is not sufficient. To avoid
possible electrical shock, be sure electricity is
turned off at the main fuse box before wiring. All
wiring must be in accordance with National and
Local codes and the ceiling fan must be properly
grounded as a precaution against possible electrical
shock.
WARNING
WARNING
Deep box with brace (Figure 3)
Paired with a deep box, this hanger is meant to span
between two joists and takes the place of wooden
blocking.
To avoid fire or shock, follow all wiring instructions
carefully. Any electrical work not described in these
instructions should be done or approved by a
licensed electrician.
WARNING
Figure 3
CEILING JOIST
CEILING
OUTLET BOX
To reduce the risk of fire, electric shock, or personal
injury, mount to outlet box marked acceptable for fan
support of 15.9 kg (35 lbs) or less and use mounting
screws provided with the outlet box. Most outlet boxes
commonly used for the support of luminaires are not
acceptable for fan support and may need to be
replaced, consult a qualified electrician if in doubt.
Do not operate this fan with a variable (Rheostat) wall
controller or dimmer switch. Doing so could result in
damage to the ceiling fan's remote control unit.
WARNING

7
How to Assemble Your Ceiling Fan
Figure 1
Pin
Setscrew
Hanger
Ball
1. Prior to assembly, set aside and save the hardware
bags packed in the packing. Remove the hanger ball
by loosening the setscrew in the hanger ball until the
ball falls freely down the downrod. Remove the pin
from the downrod, then remove the hanger ball.
Retain the pin and hanger ball for reinstallation in
Step 7. (Figure1)
2. Remove the hairpin clip and clevis pin from the
bottom of downrod. Retain the pin and clip for
reinstallation in Step 5. (Figure 2)
3. Remove and discard the three rubber/screws
motor stops from the motor assembly. (Figure 3)
Downrod Support
Set Screws
and Nuts (2)
4. Loosen the two set screws and locking nuts in
the downrod support of the motor assembly. Route
the black/white, blue, red, gray, yellow wires and
safety cable through the downrod. (Figure 4) Black/White, Blue, Red,
Gray, Yellow wires
and Safety Cable
Motor Stop
Motor
Assembly
Figure 2
Figure 3
Hairpin Clip
Clevis Pin
Figure 4
5. Slide downrod into the downrod support on top of
the motor. Install the clevis pin by aligning the holes
in the downrod support with holes in the downrod.
Secure clevis pin with hairpin clip. Install the two
set screws with nuts in the downrod support. Securely
tighten the set screws with screwdriver then fully tighten
the nuts by hex wrench. (Figure 5)
WARNING
It is critical that the clevis pin in the downrod
support is properly installed and the set screws
and nuts aresecurely tightened. Failure to do so
could result in the fan falling.
Hairpin
Clip
Set Screws
and Nuts (2)
Downrod
Clevis Pin
Figure 5

8
How to Assemble Your Ceiling Fan (continued)
8. Cut off excess lead wire approximately 6 to 9
inches above top of the top of the downrod. Strip
1/2 inch from the end of each lead
insulation off
wire. (Figure 8)
NOTE:
All set screws must be checked, and retightened
where necessary before installation.
Canopy Trim
Ring Assembly
Ceiling
Canopy
Motor Coupling
Cover
Figure 6
Figure 7
Figure 8
6. Route wires and safety cable through motor coupling
cover, canopy trim ring assembly and ceiling canopy.
(Figure 6)
7. Reinstall the hanger ball on the downrod as follows.
Route the black/white, blue, red, gray, yellow wires
and safety cable through the hanger ball. Position the
pin through the two holes in the downrod and align the
hanger ball so the pin is captured in the groove in the
top of the hanger ball. Pull the hanger ball up tight
against the pin. Securely tighten the set screw in the
hanger ball. A loose set screw could cause fan
wobble. (Figure 7)
Figure 9
9. Completely remove one of each right-hand screw
on either side of the flap of the hanger bracket and
retain the screws for later. Loosen the remaining
screws without fully removing them. (Figure 9)

9
1. Alternating positions, remove three motor coupling
screws from motor assembly and retain the screws
for Step 3. (Figure 1)
2. Remove the screw cover from the ceiling canopy.
(Figure 2)
3. Route your fan wires through the ceiling canopy.
Align the three big slots in the canopy to the
three screws in the motor coupler. Firmly attach
the canopy cover to the motor with the previously
removed screws. (Figure 3)
How to Assemble Your Ceiling Fan (Close to Ceiling)
Figure 2
Figure 1
NOTE: MOTOR WIRES
HAVE BEEN OMITTED
FROM DIAGRAM
Figure 3
Figure 4
NOTE: MOTOR WIRES
HAVE BEEN OMITTED
FROM DIAGRAM
Ceiling Canopy
Canopy
Screw Cover
Moter
Assembly
Canopy Trim
Ring Assembly
WARNING
Failure to seat tab in groove could cause damage to
electrical wires and possible shock or fire hazard.
WARNING
To avoid possible shock, do not pinch wires between the
downrod/hanger ball assembly and the hanger bracket.
4. Hook the motor assembly onto the ceiling bracket
assembly as shown. (Figure 4)
You can now proceed with the electrical wiring of your fan.
Hanger
Bracket
Ceiling Canopy
NOTE: MOTOR WIRES
HAVE BEEN OMITTED
FROM DIAGRAM
Hook

3. Make sure the electrical supply wires, including the
hanger bracket grounding wire and safety cable are
pulled through the downrod, between the hanger bracket
and the junction box so that electrical connections can be
made later.
Carefully lift the fan and seat the downrod/hanger ball
assembly on the hanger bracket that was just attached to
the ceiling joist. Be sure the groove in the ball is lined up
with tab on the hanger bracket. (Figure 4)
5. Attach the safety cable to ceiling support cable. Slide
cable clamp onto safety cable (from fan). Place the end
of cable through the loop of ceiling support cable. Pull as
much cable through loop as possible. Feed end of cable
into clamp hole and firmly tighten screw (Figure 4). Cut
off excess safety cable.
r.
of
4.
WARNING
The fan must be hung with at least 7´ of clearance from
floor to blades. (Figure 2)
WARNING
The outlet box must be securely anchored and capable
of withstanding a load of at least 35 lbs. Hanger bracket
must seat rmly against outlet box. If the outlet box is
recessed, remove wallboard until bracket contacts box.
If bracket and/or outlet box are not securely attached,
the fan could wobble or fall.
CAUTION
Do not connect fan blades until the fan is completely
installed. Hanging fan with blades connected may result
in damage to the fan blades.
WARNING
To avoid possible electrical shock, be sure electricity is
turned off at the main fuse box before hanging. (Figure 1)
NOTE: If you are not sure if the outlet box is grounded,
contact a licensed electrician for advice, as it must be
grounded for safe operation.
WARNING
Failure to seat tab in groove could cause damage to
electrical wires and possible shock or fire hazard.
10
How to Hang Your Ceiling Fan
Figure 2
Figure 1
Figure 3
Figure 4
To avoid possible shock, do not pinch wires
between the downrod/hanger ball assembly and the
hanger bracket.
WARNING
1. Using the 3»8˝x 2˝lag bolt and flat washer, attach
safety cable to ceiling joist or wood structural member.
The lag bolt will pass through the flat washer, safety
cable loop, and into the building structure (Figure 3).
You will first drill a ¼˝pilot hole into the building structure
to prevent splitting or cracking.
2. Securely attach the hanger bracket to ceiling junction
box acceptable for ceiling support.
NOTE: Ceiling support cable cannot be secured to
junction box only, it must be directly secured to ceiling
joist or structural member using the ⅜˝x 2˝lag bolt and
flat washer. (Figure 3)
˝˝ rr.
r
.
˝˝
flr.
01.'55
6*#0
(''6

CAUTION: INCORRECT WIRE CONNECTION COULD
DAMAGE THIS RECEIVER.
NOTE: If fan or supply wires are different colors than indicated, haYHWKLVXQLWLQVWDOOHGE\DTXDOL¿HGHOHFWULFLDQ
Figure 4
MAIN FUSE BOX
Figure 2
Figure 1
Figure 3
To avoid possible electrical shock, be sure electricity
is turned off at the main fuse box before wiring
(Figure 2).
WARNING
NOTE:
If you are not sure if the outlet box is
grounded, contact a licensed electrician for advice, as
LWPXVWEHJURXQGHGIRUVDIHRSHUDWLRQ
x 8
WIRE
CONNECTORS
RECEIVER HARDWARE USED:
2. Slide the receiver into the hanger bracket before wiring
as shown in figure 3.
3. Connect wires using connectors as shown in Figure 4.
WARNING
Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire
connectors. Do not operate fan until the blades are in
place. Noise and motor damage could result.
How to Wire Your Ceiling Fan
5HFHLYHU8QLW
NOTE: Supply wires
omitted for clarity
%/8(
%/$&.
:+,7(
%/$&.
:+,7(
/
1
$&32:(5
5('
*5$<
<(//2:
<(//2:
*5((1
*5281'
+$1*(5
%5$&.(7
+$1*(5
%$//
'&02725
%/$&.
$17(11$
5HFHLYHU
Dip Switch
'LS6ZLWFK
ON
1 2 3 4 5
1. To set the code on receiver unit, slide dip switches to
the same positions as set on the remote. (Figure 1)
NOTE: The remote unit has 32 different code
FRPELQDWLRQV7RSUHYHQWSRVVLEOHLQWHUIHUHQFHIURPRUWR
other remote units, simply change the combination code
LQWKHUHPRWHDQGUHFHLYHU
NOTE: Factory setting is all up. Do not use this position.
11
+DQJHU%UDFNHW
5HFHLYHU

Figure 5
How to Wire Your Ceiling Fan (continued)
12
LISTED
OUTLET
BOX
WHITE
BLACK
BLUE
BLACK & WHITE
GREEN-Ground Wire
From Hanger Bracket
GREEN-Ground Wire
From Hanger Ball
GREEN-Ground Wire
From Ceiling
YELLOW
GRAY
RED
GREEN / YELLOW
- Ground Wire (2)
From Receiver
4. After connections have been made, put the white and
green leads to one side and the black leads towards the
other side. The wires should be spread apart with the
grounded conductor and the equipment-grounding
conductor on one side of the outlet box and the ungrounded
conductor on the other side. (Figure 5)

13
NOTE: This step is applicable after the necessary wiring
is completed.
WARNING
To avoid possible fire or shock, make sure that the
electricalwiresarecompletelyinsidethecanopyhousing
and not pinched between the housing and the ceiling.
How to Install Your Canopy Housing
Figure 2
Hanger Bracket
Assembly
1. Slide the ceiling canopy over the mounting bracket
with the two loosened screws going into the “L” slots
in the canopy. Be sure all wiring is tucked into the
ceiling canopy and is not pinched. Once the canopy
is flush with your ceiling, turn clockwise to seat the
screws into the keyed portion of the slot. Tighten the
screws. (Figure 1)
2. Install the remaining two screws removed in
step 9 of page 8 to secure the ceiling canopy to
the ceiling bracket. (Figure 2)
3. Push the canopy trim ring assembly up to
conceal the screws, such that the mounting tabs
seat into the dimpled grooves in the ceiling canopy
midway between the screws. (Figure 3)
NOTE: MOTOR WIRES
HAVE BEEN OMITTED
FROM DIAGRAM
NOTE: MOTOR WIRES
HAVE BEEN OMITTED
FROM DIAGRAM
Figure 1
Hanger Bracket
Assembly
Canopy
“ L” Slot
Figure 3
Canopy
Canopy Trim
Ring Assembly
Mounting
Tabs
NOTE: MOTOR WIRES
HAVE BEEN OMITTED
FROM DIAGRAM

14
How to Assemble Your Fan Blade
Figure 1
NOTE: Periodically check Blade Holder hardware and re-
secure if necessary. (see Maintenance below)
WARNING
To reduce the risk of personal injury, do not bend the
blade holders when installing, balancing the blades or
cleaning the fan. Do not insert foreign objects in between
the rotating blades.
x 9
1/4 -20
SCREWS
HARDWARE USED:
x 9
3/16ß-24
FLAT & SERRATED
HEAD SCREWS
HARDWARE USED:
Figure 2
Blade Holder Cover
Blade Holder
Blade Holder
Blade
1/4Þ-20 Screw (3 per blade holder)
Do not connect fan blades until the fan is completely
installed. Installing the fan with blades assembled
may result in damage to the fan blades.
CAUTION
NOTE: You will find the fan blade set packed in its own
carton.
1. Lay flat side of blade holder on a flat surface with
the inside of the blade holder facing up. This is the
side with the threaded posts and pitched foot.
Position the blade over the blade holder with the
threaded posts showing. Make sure the bottom edge
of the blade is fully seated against the blade holder.
Place blade holder cover on top of the blade,
positioning the holes over the threaded posts. With a
Philips screwdriver, thread both screws into the posts
but do not fully tighten. Prior to final tightening,
position the centerline of the blade holder with the
center of the end of the blade. Tighten both screws to
secure the blade. (Figure 1)
3/16Þ-24 Flat & Serrated
Head Screw (3 each per blade)
2. Attach blade holders to the bottom of the fan
PRWRUKXEXVLQJWKHݱVFUHZVZORFNZDVKHUV
from the hardware bag. Make sure the screws
with lockwashers securing the blade holders to the
fan motor hub are tight and that the blade holders
DUHSURSHUO\VHDWHG)LJXUH
Motor

15
Figure 2
How to Assemble Your Light Kit Assembly
Figure 3
Figure 4
1. Remove the three screws in the light plate
assembly and retain the screws for Step 6. (Figure 1)
2. Remove one of the three screws in the light plate
assembly and retain the screw for Step 5. Slightly
loosen the remaining two screws. (Figure 2)
3. Remove one of the three screws in the support
bracket at the bottom of the motor assembly.
(Figure 3)
4. Assemble the light plate assembly to the support
bracket using the two key slots in the light plate
assembly. Replace the third screw and securely
tighten all three screws. (Figure 4)
Figure 1
Light Plate
Assembly
Light Plate
Assembly
Light Plate
Assembly
Motor
Assembly
Motor
Assembly

16
How to Assemble Your Light Kit Assembly (continued)
5. Connect the 2 single pin connectors from the LED
assembly to the 2 single pin connectors from motor
assembly. Assemble the LED assembly to the light
plate assembly using the two key slots. Replace the
third screw and securely tighten all three screws.
(Figure 5)
To reduce the risk of electric shock, disconnect the
electrical supply circult to the fan before installing
light kit.
CAUTION
The light source is designed for this specific
application and can overheat if serviced by untrained
personnel. If any servicing is required, the product
should be returned to an authorized service facility
for examination or repair.
CAUTION
6. Assemble the light housing assembly with glass
onto the light plate assembly using previously removed
screws. (Figure 6)
LED Assembly
Light Housing Asssembly
Light Plate
Asssembly
With Glass
Motor
Assembly
Figure 5
Figure 6

How to Operate Your Ceiling Fan
MAIN FUSE BOX
Figure 2
Figure 1
For illustrative purposes only-not
intended to cover all types of controls
1. IMPORTANT: Using a full range dimmer switch
(not included) to control fan speed will damage the fan.
To reduce the risk of fire or electrical shock, do not use
a full range dimmer switch to control the fan speed.
(Figure 1)
2. Restore electrical power to the outlet box by turning
the electricity on at the main fuse box. (Figure 2)
Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire
connectors, except for the ground wire. Do not
operate fan until the blades are in place. Noise and
fan damage could result.
WARNING
Do not operate this fan with a variable (Rheostat)
wall controller or dimmer switch. Doing so could
result in damage to the ceiling fan's remote control
unit.
WARNING
Figure 3
17
3. To make fan operational, install two 3V batteries
(included) in hand-held remote transmitter, with fan
power off. Then, follow the remote code setting process.
If not used for long periods of time, remove battery to
prevent damage to transmitter. Store the remote away
from excessive heat or humidly. (Figure 3)
3V CR2032
Battery (2 pcs)
4. If you have multiple fans and want to program all
fans to one handheld control. Slide the Dip Switch with
the same position in ALL receiver to ONE handheld to
set up the code for each fans and follow Step 1 of the
remote control speed set up process. Each fan needs
to be no more than 30 feet from the handheld control
that you would like to program. Please note the wall
switch that controls the power to your fan(s) should be
in the off position until you are ready to program your
handheld remote(s).
5. If you have multiple fans and want to program each
fan to separate handheld controls. Slide the Dip Switch
with the same position in both receiver and handheld to
set up the code for each fans and follow Step 1 of the
remote control speed set up process below. Repeat
these steps for each fan that you would like to program
to a separate handheld remote. Please note that the wall
switch that controls the power to your fan(s) should be
in the off position until you are ready to program your
handheld remote(s).

6. To set the remote code with a small screwdriver or
ball point pen (neither included), slide dip switches
firmly up or down to same as receiver unit. (Figure 4)
NOTE: The remote unit has 32 different code
combinations. To prevent possible interference from
or to other remote units, simply change the
combination code in the remote and receiver.
NOTE: Factory setting is all up. Do not use this
position.
Remote
Dip Switch
Figure 4
How to Operate Your Ceiling Fan (continued)
18
7. Remote Control Speed (RPM) Setting
Process : (Figure 5)
1) After installing and wiring the unit, restore power to
your fan by ensuring that the breaker and wall switch
that controls the power supply is moved to the on
position, press and hold the “LEARN” button inside of the
battery compartment of the handheld remote control for
1-3 seconds.
2) You must press the “LEARN” button within 30 seconds
of restoring power to the fan.
3) When restoring power to your fan at the wall switch
and breaker, DO NOT press any button(s) on the
handheld remote control before pressing the “LEARN”
button, otherwise the fan will fail the learn procedure.
4) If you press any button(s) on the handheld remote
control before pressing the “LEARN” button, please turn
the wall switch that controls the power to the fan to the
off position then on again, and start the process
beginning with Step 1 above.
5) When you press the "LEARN" button, the fan will make
one musical sound and light blink once if with light and
start to run beginning the control set up process.
6) DO NOT press any button(s) after pressing the LEARN
button while the fan is programming or it will fail to
program.
NOTE: If you want to change the blades: turn
WKHSRZHURIIĺFKDQJHWKHEODGHVĺWXUQWKH
SRZHURQĺSHUIRUPWKHFRQWUROVHWWLQJSURFHVV
7) The fan will run in forward direction for approximately
3 minutes.
8) When the fan stops running after approximately 3
minutes, the fan will make two musical sounds and light
blink twice if with light that means that the handheld
remote control and speed set up process is complete.
9) The fan is now ready for normal use.
LEARN
Figure 5

6OHHS7LPHU
7KHIDQDQGOLJKWZLOOWXUQRIIDIWHUKRXU
7KHIDQDQGOLJKWZLOOWXUQRIIDIWHUKRXUV
7KHIDQDQGOLJKWZLOOWXUQRIIDIWHUKRXUV
8. 5HPRWHIXQFWLRQV)LJXUH

,QGLFDWRU/('OLJKWIDQVSHHGDQGOLJKW
GLPPHULQGLFDWRU
)DQ6SHHG
EXWWRQ7DSRQFHWRWXUQRIIWKHIDQ3UHVVDQG
KROGWKLVEXWWRQIRUVHFRQGVWRWXUQRQRUWXUQRII
WKHEX]]HU
/LJKWEXWWRQ7XUQ21?2))WKHOLJKW
7XUQRQIDQDQGWXUQVSHHGXS
7XUQRQIDQDQGWXUQVSHHGGRZQ
,QFUHDVHOLJKWRXWSXWOHYHO
'HFUHDVHOLJKWRXWSXWOHYHO
+RPH$ZD\7DSWKLVEXWWRQWKHOLJKWZLOO
EOLQNWZLFHVLJQDOLQJWKLVIHDWXUHLVRQWKHIDQ
ZLOOWXUQRIIDQGWKHOLJKWZLOOUDQGRPO\WXUQRQ
DQGRIIZKLOH\RXDUHDZD\3UHVVLQJDQ\EXWWRQ
ZLOOFDQFHOWKHIHDWXUH
6DIH([LW7DSRQFHWKHOLJKWZLOOEOLQNRQFH
IDQDQGOLJKWZLOOWXUQRIIDIWHUPLQXWH3UHVVLQJ
DQ\EXWWRQZLOOFDQFHOWKLVIHDWXUH

5HYHUVHEXWWRQ
6XPPHU7KHIDQUXQVFRXQWHUFORFNZLVH
$LUIORZZLOOSURYLGHDGRZQZDUGFRROLQJEUHH]H
:LQWHU7KHIDQUXQVFORFNZLVH$LUIORZZLOOIRUFH
ZDUPDLUGRZQZDUGZLWKRXWDQRWLFHDEOHEUHH]H
)UHVK$LU)DQVSHHGZLOOPRGXODWHWR
VLPXODWHDQDWXUDOEUHH]H
Figure 6
How to Operate Your Ceiling Fan (continued)
19

10:40 AM 80%
Petrel
904:4056%
20
Setup the fanSync App (optional)
Visit the Apple App Store or the Google Play Store by www.fanimation.com/fansync to download the freely available
fanSync app.
IMPORTANT: Bluetooth must be turned on in your smart device settings.
Figure 1
1. Open the fanSync app and tap the new fan to
begin setup. (Figure 1)
2. Press Save and your fan will be ready to operate
(Figure 2)
Figure 2
3. Fan functions as show. (Figure 3)
Figure 3
Name fo fan
Fan setting indicators
Speed / Timer / Light
Fan speed
control
Light level
control
Fan timer
Home away
Fresh air
Reverse
Setup New Fan
myFanimation DC
Petrel
myFanimation DC
10:37 AM
Setup New Fan
myFanimation DC
80%
Fans List
10:39 AM 80%
Setup Fan
Petrel
Does your fan
have a light ?
Can you dim your
light?
No Yes
Cancel Save
No Yes
Calibrate
