RELAXZEN 60-443511 User manual

For any questions, please visit our website at
www.comfortproducts.net or call our Customer Service line at
1-800-971-4630. Keep your sales receipt as documentation of your
ownership. This product includes a limited one (1) year warranty for
the original owner from the date of purchase.
CUSTOMER SERVICE
VANTIN MASSAGE RECLINER WITH 8 MOTORS AND HEAT
OPERATION MANUAL
MODEL 60-443511

11
CONTENTS
EXTRA SPARE HARDWARE INCLUDED FOR YOUR CONVENIENCE. ITEMS ARE NOT SHOWN TO SCALE.
PART DESCRIPTION QTY.
1 5# L-Wrench 1
2 4# L-Wrench 1
3 M8 x 20mm Screw 2
4 M8 x 50mm Screw 4
5 13# Wrench 1
6 M8 Nut 2
7 Wood Cap 2
8 22 x 8 x 2 4
9 M8 x 40mm Screw 4
10 M8 x 65mm Screw 2
11 M6 x 45mm Screw 4
HARDWARE KIT
#61-SCRWSET4435 (EXCLUDES PLUGS)
PART DESCRIPTION STOCK# QTY. PART DESCRIPTION STOCK# QTY.
ALeft Arm /
Right Arm
61-ARM443511L
61-ARM443511R
1
1DOttoman Base 61-443511OTBA 1
B Chair Base 61-443511B
61-443511FRAME
1
1EOttoman Post 61-443511OTBR 2
C Back Cushion 61-443511A 1 F Ottoman
Cushion 61-443511OTCU 1
PARTS LIST
PART DESCRIPTION QTY.
12
Round Male Plug
(connected to
cushion)
2
13
Round Female
Plug (connected to
cushion)
2
14 Hex Female Plug 1
15 Controller Plug 1
16 Adapter
61-ADAPTG 1
17 Controller
61-CONTRLG 1

2
STEP 2
Attach ottoman base (D) to ottoman posts (E) using
screws (9), washers (8), and wrench (1) as shown.
Attach ottoman cushion (F) to ottoman posts (E) using
screws (11), and wrench (2) as shown.
D
2, 11
1, 8, 9
E
F
9
ASSEMBLY INSTRUCTION (60-443511)
DO NOT TIGHTEN SCREWS UNTIL COMPLETELY ASSEMBLED
STEP 1
Attach left and right armrests (A) to chair frame (B) using screws (4) and wrench (1) as shown.
Attach armrests (A) to back cushion (C) using two screws (10), wrench (1), and screws caps (7) as shown.
Align and connect the back cushion (C) to the seat cushion using screws (3), nuts (6), and tools (1, 5) as shown.
NOTE: You may find it easier to align the cushions with the help of a second person.
C
A
1, 7, 10
1, 4
1, 3
5, 6
B

3
ASSEMBLY INSTRUCTION (60-443511)
DO NOT TIGHTEN SCREWS UNTIL COMPLETELY ASSEMBLED
STEP 3
Connect the controller (17) to the large connector plug
(15) on back of cushion (C).
Connect male end of power adapter (16) to the hex-
head female connector plug (14) on back cushion (C).
Connect the two round males plugs (12) from the back
cushion to the two round female plugs (13) from the
seat cushion as shown (white to white, black to black).
STEP 4
If you would like to use the ottoman massage, simply
connect the cord from underneath the front of seat
cushion to the ottoman cushion.
12
13
14 15
16
17
1716

SAFETY AND MAINTENANCE
MASSAGE CONTROLLER
1. TIME INDICATOR displays number of minutes remaining
for massage
2. AUTO INDICATOR shows if “AUTO” is activated
3. BODY ZONE INDICATOR lights show which body zones
are being massaged
4. HEAT INDICATOR shows if heat treatment in lumbar area
is activated
5. MODE BUTTON (up) scrolls through the 10 pre-
programmed massage modes
6. POSITION BUTTON allows user to select the desired body
area
7. ON/OFF BUTTON powers the chair on or off
8. HEAT BUTTON activates heat treatment in lumbar area
9. INTENSITY BUTTON allows user to select intensity levels.
Continue pressing to reach desired intensity level.
10. AUTO BUTTON will automatically cycle through all 10 pre-
programmed modes one after another
11. MODE BUTTON (down) scrolls through the 10 pre-
programmed massage modes
12. TIME BUTTON allows user to add minutes to the
remaining massage (DO NOT use for for than 30 minutes)
13. INTENSITY INDICATOR shows current intensity level
• DO NOT stand on the chair. DO NOT use the chair as
a stepladder.
• This product features a manual recline. To recline,
simply lean back while seated in chair, and gently
push down on the armrests.
• Use this product for seating one person at a time.
• DO NOT use this chair unless all bolts and screws are
firmly secured.
• ONLY use the power adaptor included with the chair
from the factory.
• ALWAYS unplug the massage chair from the
power source after using and before cleaning as a
precaution.
• This appliance should not be left unattended when
plugged in. Unplug from power source when adding
or removing attachments.
• If you have any health concerns regarding use of a
massage chair, please contact your doctor.
• Store the chair in a cool, dry area for long term
storage.
• Avoid contact with sharp objects to prevent
puncturing the fabric.
• Every 4 months, check all bolts and screws to ensure
they are tight.
• To clean, disconnect from power source. Use a damp
towel and mild cleaner.
• DO NOT submerge unit in liquids.
• Chair weight limit not to exceed 225 lbs.
HE AT
ON/OF F
TIME
INTENSITY
MODE
MODE
AU TO
AU TO
TIME
HE AT
INTENSITY
11
1
4
10
2
12
6
85
9
13
3
7
POSITION
4

Comfort Products, Inc.
P.O. Box 999
Memphis, TN 38101
1-800-971-4630
www.comfortproducts.net
LIMITED WARRANTY
PLEASE VISIT WWW.COMFORTPRODUCTS.NET FOR WARRANTY INFORMATION
Comfort Products warrants this product to be free from defects in material and workmanship for 1 year. This warranty is made by Comfort
Products only to the original end-user customer acquiring the product directly from Comfort Products’ authorized dealers as shown by the
original sales receipt. The end-user customer remedy pursuant to this warranty is limited to repair or replacement of parts at Comfort Products’
option within a reasonable amount of time. Comfort Products reserves the right to require damaged parts to be returned to Comfort Products
upon request. Natural markings such as scars, brands, grain, variations, wrinkles, color variations, etc. will be considered normal characteristics,
and not construed as defects. Comfort Products cannot warrant leather against scratching or scuffing, as all leather is subject to blemishes with
use. Consent from Comfort Products must be obtained before any warranty work is performed. This warranty shall not apply to any products
which must be replaced because of normal wear and tear, negligence, abuse, or “accident”, shipping damage or product use and installation
other than in accordance with written instructions or warnings. It will also not apply when a product has been modified or altered, repaired,
refurbished by someone other than Comfort Products or because of natural variations over which Comfort Products has no control. When
repairing or replacing a defective product, Comfort Products does not guarantee matching color, grain, texture or dye lots. This warranty does
not cover the cost of transportation or labor. In no event shall Comfort Products be liable in either tort or contract for any loss or direct, special,
incidental, consequential or exemplary damages. This Limited Warranty is NOT applicable to end-user customers who use Comfort Products
for rental purposes. This warranty applies only to end-user customers in the United States. All warranties are limited to the original purchaser
for normal use which is defined as a standard work week of 40 hours by a person weighing 225 lbs. or less (unless otherwise specified). For
claims or questions concerning this warranty, please visit www.comfortproducts.net. Comfort Products customer service is 800-971-4630 ext.
2, fax: [phone], e-mail [e-mail]. Any authorized return should be shipped prepaid to: Comfort Products, 9475
Fulmer Road, Olive Branch, MS 38654.
MODEL: 60-443511
