Model GXLO
Standard Spray
Standard Response
Storage and Non-storage Sprinkler
K11.2 (160 metric)
(SIN R2921) Upright
(SIN R2916) Pendent
Features
1. Upright cULus Listed as a Control Mode Density Area (CMDA)
sprinkler for storage & non-storage protection.
2. Upright and Pendent FM Approved as Standard-response,
storage and non-storage sprinklers.
3. Standard ¾-inch NPT or ISO 7-R¾ threads; optional ½-inch
NPT or ISO 7-R½ threads for upright retrofit applications only.
Listings & Approvals:
The following organizations provide Listings or Approvals
for Model GXLO sprinklers. See the Technical Data table
for listing and approvals applicable to each sprinkler.
1. Underwriters Laboratories, Inc. and Underwriters
Laboratories of Canada (cULus) - Upright only.
2. Approved by Factory Mutual (FM) as a storage and
non-storage sprinkler - Upright and Pendent.
UL Guide Number
VNIV
UL Listing Category
Sprinklers, Automatic and Open; Sprinklers for Storage
Protection (Control Mode Density Area)
Technical Data
Sprinkler
Type
Nominal K Factor Sprinkler
Height Approvals
Sprinkler
Identification
Number (SIN)
US Metric
Upright 0.64
Orifice with
¾” NPT (R¾)
11.2 160 2.71”
(68.8mm) cULus, FM R2921
Upright
Retrofit 0.64
Orifice with
½” NPT (R½)
11.2 160 2.82”
(71.6mm) cULus, FM R2921
Pendent 0.64
Orifice with
¾” NPT (R¾)
11.2 160 2.71”
(68.8mm) FM R2916
Note: This product has been tested and listed for storage applications
to qualify its use in lieu of 5.6K or 8.0K Factor sprinklers for the
protection of high-piled storage.
Product Description
The Reliable Model GXLO sprinkler is a center strut, solder
in compression, extra large orifice sprinkler that has been de-
signed for storage and non-storage applications. The Model
GXLO sprinkler is available in either an upright or pendent con-
figuration. The Model GXLO sprinkler is available with either
3/4-inch NPT or ISO 7-R3/4 threads. The Model GXLO Upright
is optionally available with either 1/2-inch NPT or ISO 7-R1/2
threads for retrofit applications only.
Design Criteria
The Model GXLO sprinkler is intended for use as a standard
response standard spray sprinkler in hydraulically designed
sprinkler systems with a minimum pressure of 7 psi (0.5 bar) in
accordance with the area/density curves of NFPA 13 or in ac-
cordance with FM Property Loss Prevention Data Sheets.
The Model GXLO sprinkler is not a “Large Drop” or “ESFR”
sprinkler.
Temperature Ratings
Classification
Sprinkler
Rating
Maximum Ambient
Temperature Frame
Color
°F °C °F °C
Ordinary
Intermediate
High
165
212
286
74
100
141
100
150
225
38
66
107
Uncolored
White
Blue
Model GXLO Upright Model GXLO Pendent
Sprinkler Guard or Water Shield Listings &
Approvals
GXLO
Upright
D-6 Guard & Water Shield cULus
D-7 Guard & Water Shield
FM
Water Shield
(factory installed)
GXLO
Pendent
D-8 Guard FM
D-9 Guard & Water Shield
Optional Guards and Water Shields

Installation
Reliable’s Model GXLO sprinkler must be installed according
to NFPA Standards or the appropriate Factory Mutual Loss Pre-
vention Data Sheets for all area/density methods of design as
well as requirements of the Authority Having Jurisdiction.
Model GXLO sprinklers must be installed with the Reliable
Model H sprinkler wrench. Any other type of wrench may dam-
age the sprinkler.
A leak tight joint should be obtained with a torque of 14 to
20 lb-ft (19 to 27 N-m) for ¾-inch NPT and ISO 7-R¾ thread
sprinklers. For ½-inch NPT and ISO 7-R½ thread sprinklers the
recommended installation torque is 8 to 18 lb-ft (11 to 24 N-m).
Do not tighten sprinklers over the maximum recommended in-
stallation torque, because it may cause leakage or impairment
of the sprinklers.
Ordering Information
Specify:
1. Sprinkler: Model GXLO
2. Orientation: [Upright] [Pendent]
3. Temperature Rating: [Ordinary, 165°F] [Intermediate,
212°F] [High 286°F]
4. Finish: (See Finishes Chart)
5. Threads: [¾-inch NPT] [ISO 7-R¾] [½-inch NPT (Up-
right only)] [ISO 7-R½ Upright only]
6. Optional Guard or Water Shield
Model H Wrench Use only the Model H
sprinkler wrench for sprinkler
removal and installation. Any
other type of wrench may
damage the sprinkler.
2.
Maintenance
Model GXLO Sprinklers should be inspected and the sprinkler
system maintained in accordance with NFPA 25. Do not clean
sprinklers with soap and water, ammonia or any other cleaning
fluids. Remove dust by using a soft brush or gentle vacuuming.
Replace any sprinkler which has been painted (other than fac-
tory applied) or damaged in any way. A stock of spare sprinklers
should be maintained to allow quick replacement of damaged
or operated sprinklers. Prior to installation, sprinklers should be
maintained in the original cartons and packaging until used to
minimize the potential for damage to sprinklers that would cause
improper operation or non-operation.
Fig. 1
Finishes
Standard Finishes
Bronze
Chrome (1)
Special Application Finishes
Lead Plated (1)
Wax (1) (2)
Wax/Lead (1) (2)
- 165°F (74°C), 212°F (100°C) and
286°F (141°C) Temp. Ratings
- 165°F (74°C) Clear Wax, 212°F
(100°C) Brown Wax
- 165°F (74°C) Clear Wax, 212°F
(100°C) Brown Wax
(1) cULus, upright (without shield) only.
(2) 212°F (100°C) Brown wax may be used on 286°F (141°C) Sprinklers
when maximum ambient temperatures do not exceed 150°F (66°C).

Reliable Automatic Sprinkler Co., Inc.
[phone] Sales Offices
[phone] Sales Fax
[phone] Corporate Offices
www.reliablesprinkler.com Internet Address
Manufactured by
Recycled
Paper
Revision lines indicate updated or new data.
EG. Printed in U.S.A. 05/19 P/N 9999970022
The equipment presented in this bulletin is to be installed in accordance with the latest published Standards of the National Fire Protection Association, Factory
Mutual Research Corporation, or other similar organizations and also with the provisions of governmental codes or ordinances whenever applicable.
Products manufactured and distributed by Reliable have been protecting life and property for over 90 years.
ITEM DESCRIPTION
Sprinkler Identification Number (SIN) R2921 (Upright), R2916 (Pendent)
K-factor US (Metric) 11.2 (160)
Thread Size 3/4" (ISO 7-R3/4), 1/2" (ISO 7-R1/2) Retrofit Upright
Sprinkler Orientation Upright; Pendent
Maximum Working Pressure, PSI (bar) 175 PSI (12 bar)
Model GXLO Technical Data Table A
Storage Type NFPA FM GLOBAL
Sprinkler Type CMDA Storage
Response Type SR SR
System Type Pendent-Wet
Upright- Wet,Dry, Preaction
Pendent- Wet
Upright- Wet,Dry,Preaction
Temperature Rating F ( C ) 165,212,286 (74,100,141) 165,212,286 (74, 100,141)
Roof Construction See NFPA 13 See FM Global 2-0
Ceiling Slope See NFPA 13 See FM Global 2-0
Maximum Coverage Area See NFPA 13 See FM Global 2-0
Minimum Coverage Area See NFPA 13 See FM Global 2-0
Maximum Spacing See NFPA 13 See FM Global 2-0
Minimum Spacing See NFPA 13 See FM Global 2-0
Minimum Clearance to Commodity See NFPA 13 See FM Global 2-0
Sprinkler Distance to Ceiling See NFPA 13 See FM Global 2-0
Open Frame, Single, Double,
Multiple Row, or Portable
Rack Storage of Class I - IV
and Group A or B Plastics
See NFPA 13 See FM 2-0 & 8-9
Solid Pile or Palletized Storage
of Class I - IV and Group
A or B Plastics
See NFPA 13 See FM 2-0 & 8-9
Idle Pallet Storage See NFPA 13 See FM 2-0,8-9 & 8-24
Rubber Tire Storage See NFPA 13 See FM 8-3
Rolled Paper Storage See NFPA 13 N/A Pendent
See FM 8-21 for Upright
Flammable Liquid Storage See NFPA 30 See FM 7-29 and 8-9
Aerosol Storage See NFPA 13 See FM 7-31
Auto Components in Portable Racks N/A N/A
Model GXLO Commodity Selection and Design Criteria Overview Table B
