RELIANEERING SES-LOGGER HW-SES-KIT01 User manual

EN
SES-LOGGER
Instruction Manual
Publ.: 2023-01-23
Copyright © Relianeering AB

Relianeering AB 2 Simple – Easy – Smart Relianeering AB 3 Simple – Easy – Smart
Instruction manual
The SES Logger is a compact handheld single-channel vibration
data collector. It can be used together with the app ReSES
Communicator installed on a mobile device, tablet or telephone,
with Android and iOS.
The app ReSES Communicator transfers the collected data to the
cloud based platform ReSES.net and presents information from
ReSES.net to the user.
It is important to read and understand this instruction
manual before using the SES Logger. Incorrect use
might cause personal harm and/or damage to the SES
Relianeering reserves the right to correct any errors in text or
images and to make any necessary changes to or update the
technical data without prior notice. If you have any questions
regarding technical problems, please contact our support team at
[e-mail].
Safety instructions
• The SES Logger must only be used with an accelerometer
(IEPE) 100 mV/g and connected to the logger with a BNC
connector.
• The SES Logger must only be charged with a 5V DC USB
charger using a Micro USB cable.
• The SES Logger must not be disassembled.
• The SES Logger must not be used or stored in hot/humid,
explosive or ammable environments or close to strong magnetic
elds.
• The SES-logger must not be disassembled. No guarantee is
valid if the logger has been disassembled.
• Relianeering AB take no responsibility for any other use than
described in this manual.
Package content
SES Logger: HW-SES-KIT01
• 1 pc HW-SES Logger, SES Logger instrument
• 1 pc HW-SES-SEN, IEPE Accelerometer 100 mV/g
• 1 pc HW-SES-SEN-MTB, MIL to BNC cable
• 1 pc HW-SES-Z-ADP, Adapter sensor to stud
• 1 pc HW-SES-Z-USB, Micro USB cable for charging
• 1 pc HW-SES-Z-CASE, Plastic case for the kit
• 1 pc Instruction manual

Relianeering AB 4 Simple – Easy – Smart Relianeering AB 5 Simple – Easy – Smart
1. SES Logger button
2. LED ring
3. Battery level indicator (10’)
4. WiFi and pending le
transfer (11’)
5. RFID Tag indicator (12’)
6. BNC connector
7. Settling indicator (1’)
8. System indicator (2’)
9. Micro USB port (for
charging only)
The SES Logger is a data recorder
that records 3 sec vibration data.
The logger is designed for IEPE
sensors (ICP®) with 100 mV/g
sensitivity. The LED-ring indicates
operations and statuses and the
logger vibrates for haptic feedback.
When measurements are stored
in the logger, it automatically
search for a mobile device every 2
minutes to transfer the les. When
all les are transferred, the logger
empty its memory.
Data Collection
Go to the machine equipped
with CM Points UID.
Open all caps of Machine CM points.
Connect the sensor to the logger BNC
connector.
Turn on the logger. Press and hold the
button for few seconds until vibration
feedback and all LEDs become white.
Attach the accelerometer sensor
with adapter to the stud.
Quarter of turn should be sufficient.
Scan the CM Point UID (RFID TAG)
The distance between logger reader and the
CM Point cap should be less 50 mm. Once
the UID is scanned successfully the user
will feel vibrations and 12’ LED (TAG) will
become green.
CM Point UID
CM Point UID
Acceleration
100mV/g
CM Point UID
Acceleration
100 mV/g
CM Point UID
5
4
3
2
1
6
7
8
9

reses638
Relianeering AB 6 Simple – Easy – Smart Relianeering AB 7 Simple – Easy – Smart
Initiate measurement
To initiate measurement press the button.
NOTE: The 12’ LED (TAG) must be green.
If it is not, scan the cap again.
Measurement
1’ LED becomes blue for 5 seconds.
Wait another 3 seconds to complete
the measurement. The rest LEDs become
blue.
Note: If 2’ is red, check connection
between the logger and sensor. Most likely
the sensor is not connected properly
Completing the measurement
When the measurement is completed
the logger will vibrate and all LEDs will
ash in green.
Detach the sensor.
Close the cap.
Move to next CM point.
Data transfer
TAG
TAG
TAG
CM Point UID
TAG
Turn on the hotspot
on your mobile device.
The hotspot password MUST be «reses638»
Note: The hotspot must be congured to use
2.4 GHz (for Android and Apple devices).
The logger does not support 5 GHz.
Start ReSES Communicator app
Note: If the app has been already
launched before to activate the hotspot,
we recommend to «kill» it and re-launch it
again.
Start SES Logger
The logger will after two minutes
automatically connect the hotspot
and the ReSES communicator
app to transfer collected data. To
immediately initiate data transfer,
press the logger button twice in
a «double click» manner. During
data transfer the 11’ LED lights in
blue
Note: 11’ LED in green-yellow
indicates that data are on the
logger memory.

Relianeering AB 8 Simple – Easy – Smart Relianeering AB 9 Simple – Easy – Smart
Data transfer notes:
• The logger and phone should be close to each other to keep
a good connection.
• Yellow circle rotation on the app main screen indicates data
transfer between logger and the mobile device.
• Dark blue circle rotation on the app main screen indicates
data transfer to ReSES.net cloud.
• When the logger is empty, 11’ LED will be white.
• The green ashing dot on the app home screen will
disappear when there is no more data to be transferred to
the cloud.
• When you launch the app on the mobile device, it will
immediately initiate data transfer, if there are still not
transferred data on the mobile device.
• The app automatically checks for new data and start
transferring it on every 5th minute.
1. Dashboard (main window)
2. Blue progress bar (sending data, mobile device to cloud)
3. Yellow progress bar (receiving data from SES logger to mobile
device)
4. WiFi indicator for mobile device (OFF when the hotspot is ON)
5. Time indicator for sending data to ReSES.net (one segment
is one minute, 5 min total). Green ashing dot indicates
availability of data that are not transferred yet.
6. ReSES access indicator (quality of the speed to reses.net)
7. Hotspot indicator for mobile device (needs to be ON for
communication between logger and mobile device)
8. ReSES.net access (login, sites, machines, measurement
point overview etc.)
9. Communication log (data transfer log between logger, mobile
device and cloud)
6
7
8
9
5
4
3
2
1
ReSES
Communicator

Setup your mobile device
1. Download and install the app ReSES communicator (free)
on your mobile device
2. Enable the hotspot on your mobile device.
3. Setup and activate a wireless hotspot on your mobile device
as described in the device's documentation and set the mobile
hotspot network password to: reses638
The name of the network can be of your own choosing.
For some of Android and Apple devices make sure that
the hotspot band is 2.4 GHz.
ReSES.net access from ReSES Communicator
The app ReSES Communicator allow the user to get information
about the measured points once the data is transferred to the cloud.
The information available in the ReSES Communicator is:
• General status of the site/s
• Measurement points in alarm and in overdue
• A mimic of the machine (Functional Location) with the drive train
• General status of the machines (Functional Locations)
• Vibration level of the CM Points
(Velocity 10–1000 Hz in mm/s rms according ISO 10816)
• Trend for each CM Point
• List of machines in overdue and recently collected number per
CM Points per machine.
Troubleshooting
If the logger doesn’t start or if the system indicator is red this could
have different causes. Check the below listed actions for trouble
shooting.
Logger doesn’t start:
• Make sure the logger is charged. The battery indicator should
light in green, yellow or red during charge.
• Be sure that you have pressed and hold the button for few
seconds.
WiFi indicator (11' LED) is red.
• 3 seconds static Red WiFi led. Access point connection problem
(user should conrm active hot spot)
• 3 seconds ashing Red WiFi led. FTP server connection problem
(user should conrm active ReSES Communicator)
System indicator (2’ LED) is red:
• Restart the logger
• Check that the sensor cable is properly connected to the BNC
connector
• Check if the cable and/or sensor is damaged
System indicator (2’ LED) is blue:
• FW is updating. Wait till logger is shutdown and start the logger
again
The battery does not charge in 4 hours:
• Within a few hours from starting charging 10’ LED should change
the colour from red to yellow and when is full charge to green.
• Check the USB cable and power supply.
Relianeering AB 10 Simple – Easy – Smart Relianeering AB 11 Simple – Easy – Smart

The logger does not transfer data:
• Check that there is data on the logger, 11’ LED should be in light
green.
• Check the mobile device hotspot. Try to nd it with another
device. The hotspot goes off in a while, if there is no data
transfer.
• Check that the hotspot is set to use 2.4GHz band. It is valid for
Android and Apple devices.
• Check the hotspot password. It must be reses638.
• Shutdown the logger and start again. Repeat this a couple of
times.
• Try to keep logger and mobile device close to each other.
• Try to connect the logger to another mobile device with ReSES
Communicator.
• If you use local WiFi for data transfer check the rewall settings.
If none of the actions above help, please contact technical support
for assistance ([e-mail]).
SES Logger LEDs status
LEDs Colour Description
All White
ashing
slowly
The logger is in idle mode.
12’
Green CM Point UID (RFID) has been scanned successfully. The user has
а few seconds to press the button and await measurement.
1’
Green
Long measurement mode. If 12', and 1' are green, the CM Point
UID has been scanned two consecutive times. The user has a few
seconds to press the button and awaits 30 seconds measurement.
Wait for a while to exit from the long measurement mode.
2’
Green
Long measurement mode. If 12', 1', and 2' are green, the CM Point
UID has been scanned three consecutive times. The user has a few
seconds to press the button and await 60 seconds measurement.
Wait for a while to exit from the long measurement mode.
3’
Green
Long measurement mode. If 12', 1', 2', and 3' are green, the CM
Point UID has been scanned four consecutive times. The user has
a few seconds to press the button and await 180 seconds measure-
ment. Wait for a while to exit from the long measurement mode.
4’
Green
Long measurement mode. If 12', 1', 2', 3', and 4' are green, the CM
Point UID has been scanned ve consecutive times. The user has
a few seconds to press the button and await 300 seconds measure-
ment. Wait for a while to exit from the long measurement mode.
1’
Blue The measurement is initiated and logger is settling mode for 5
seconds.
2’ до
12’ Blue
Show the progress of measurement. First starts
2’ and in 3 seconds all LEDs become blue. NOTE: For the Long
measurement mode, it will take more time for all LEDs to become
blue. After completing the measurement, all LEDs are blue and start
fading until the signal is processed and stored in the logger memory.
All Flashing
shortly
in green
Data collection from the CM Point has been completed. The logger
goes to idle mode.
2’
Red System Error. Sensor is not connected. Cable or sensor are
damaged.
2’
Blue FW is updating. After completing the logger shut downs.
10’
Yellow The battery level is below 20%.
10’
Red Critical battery level. Recommend to charge immediately.
Relianeering AB 12 Simple – Easy – Smart Relianeering AB 13 Simple – Easy – Smart

Disposal
This product should be disposed of in accordance with local
regulations.
If you are unsure what to do, contact your local authority.
Technical Specication
• Input – BNC coupling
• ICP®accelerometer 100
mV/g
• 24-bit ADC
• Sampling rate 44.1 kHz
• Dynamic range above 105 dB
• Measurement range ± 50 g
• Sample length 3 s
• WiFi and Bluetooth®
• RFID reader
• Memory capacity, above
10000 measurements
• Li-ion battery 2000 mAh
• Li-ion backup battery for real-
time clock
• Micro USB contact for charging
(5 VDC)
• Operating temperature –20 to
+50°C
• Storage temperature –20 to
+45°C
• Size: 70×130×35 mm, Weight:
154 g
• Measurement time per point
less than 10 s for the standard
measurement mode.
• CE-marked
• FCC compliant
10’
Green The battery is full charged. It appears only when the logger is
connected to a charger.
11’ Yellow
green Data are available on the logger.
11’ Blue
ashing
Searching for mobile device network. When the logger connects to
the hotspot it vibrates.
11’
Red 3 seconds static red WiFi led in case of access point connection
error (user should conrm active hot spot)
11’ Red
blinking
3 seconds blinking red WiFi led in case of FTP server connection
error (user should conrm active ReSES Communicator)
Relianeering AB 14 Simple – Easy – Smart Relianeering AB 15 Simple – Easy – Smart

Relianeering AB 16 Simple – Easy – Smart
