REMEHA RemaSol200SE-2S Manual

RemaSol EN
Solar hot water calorifer
200SE-2S - 300SE-2S
L000541-B
Installation and
Service Manual
7607575-05

Declaration of conformity [
The device complies with the standard type described in
the EG declaration of conformity. It was manufactured and
commissioned in accordance with European directives.
The original declaration of conformity is available from the
manufacturer.
M003220-A

Contents
1 Safety instructions .....................................................................................6
1.1 Safety instructions ...............................................6
1.2 Recommendations ................................................8
1.3 Liabilities ...............................................................9
1.3.1 Manufacturer’s liability .............................................9
1.3.2 Installer’s liability ...................................................10
2 About this manual ....................................................................................11
2.1 Symbols used .....................................................11
2.1.1 Symbols used in the manual .................................11
2.1.2 Symbols used on the equipment ...........................11
2.2 Abbreviations ......................................................11
3 Technical description ..............................................................................12
3.1 Homologations ....................................................12
3.1.1 Certifications .........................................................12
3.1.2 Directive 97/23/EC ................................................12
3.2 General description ............................................12
3.3 Main parts ............................................................13
3.3.1 Solar domestic hot water calorifier ........................13
3.3.2 Solar station ..........................................................14
3.3.3 Solar regulator .......................................................14
3.4 Operating principle .............................................14
3.4.1 General principle ...................................................15
3.4.2 Protection against overheating on the solar
circuit .....................................................................16
3.5 Technical specifications ....................................16
3.5.1 Solar domestic hot water calorifier ........................16
3.5.2 Sensor characteristics ...........................................17
3.5.3 Solar regulator .......................................................17
3.5.4 Solar station ..........................................................18
4 Installation ................................................................................................19
4.1 Regulations governing installation ...................19
4.2 Package list .........................................................19
4.2.1 Standard delivery ..................................................19
26/04/2016 - 7607575-05 1

4.3 Choice of the location ........................................20
4.3.1 Type plate .............................................................20
4.3.2 Positioning of the appliance ..................................20
4.3.3 Main dimensions ...................................................21
4.4 Positioning the appliance ..................................22
4.5 Levelling ..............................................................22
4.6 Installing the temperature sensors ...................22
4.7 Hydraulic installation diagrams ........................23
4.7.1 Boiler for heating only (Output <45 kW) +
200/300SE-2S ......................................................23
4.7.2 Combi boiler + 200/300SE-2S .............................24
4.7.3 Combi boiler + Additional heating (Output <45 kW) +
200/300SE-2S ......................................................25
4.8 Safety unit ...........................................................26
4.9 Hydraulic connections .......................................27
4.9.1 Primary solar circuit ...............................................27
4.9.2 Primary heating circuit ...........................................31
4.9.3 Connecting the calorifer to the domestic water circuit
(secondary circuit) .................................................31
4.10 Electrical connections ........................................33
4.10.1 Recommendations ................................................33
4.10.2 Connecting the solar control system .....................34
4.10.3 Electrical diagram ..................................................34
4.10.4 Connecting the resistor .........................................36
4.10.5 Connecting the circulation pump ...........................37
4.11 Filling the DHW calorifer ....................................37
4.11.1 Drinking water quality ............................................37
4.12 Filling the primary solar circuit .........................38
4.12.1 Flowmeter .............................................................38
4.12.2 Anti-thermosiphon valve ........................................39
4.12.3 Filling the primary solar circuit ...............................39
4.13 Filling the heating circuit ...................................43
5 Commissioning ........................................................................................44
5.1 Control panels .....................................................44
5.1.1 Description of the keys ..........................................44
5.1.2 Description of the display ......................................44
5.2 Check points before commissioning ................46
5.2.1 Domestic hot water calorifer ..................................46
5.2.2 Primary solar circuit ...............................................46
5.2.3 Primary heating circuit ...........................................46
5.2.4 Electrical connection .............................................46
Contents
26/04/2016 - 7607575-05 2

5.3 Commissioning procedure ................................47
5.3.1 Secondary circuit (domestic water) .......................47
5.3.2 Primary solar circuit ...............................................47
5.4 Reading out measured values ...........................48
5.4.1 Resetting the values to zero ..................................48
5.5 Installer parameters ............................................49
5.5.1 Modifying the installer parameters ........................49
5.5.2 List of the parameters ...........................................49
5.5.3 Description of the installer parameters ..................51
6 Checking and maintenance .....................................................................56
6.1 General instructions ...........................................56
6.2 Safety valve or safety unit .................................56
6.3 Cleaning the casing material .............................56
6.4 Checking the magnesium anode .......................56
6.5 Descaling .............................................................57
6.6 Removing and remounting the inspection
hatches ................................................................57
6.6.1 Removing the inspection hatches .........................57
6.6.2 Remounting the inspection hatches ......................58
6.7 Inspection and maintenance of the solar
circuit ...................................................................59
6.7.1 Maintenance operations to be performed .............59
6.7.2 Adding heat transporting fluid ...............................59
6.8 Maintenance form ...............................................60
6.9 Installation report ...............................................62
7 Troubleshooting .......................................................................................64
7.1 Electricity supply ................................................64
7.2 Sensor fault .........................................................64
7.3 Incidents and solutions ......................................65
8 Spare parts ................................................................................................66
8.1 General ................................................................66
8.2 Spare parts ..........................................................67
8.2.1 Domestic hot water tanks ......................................67
8.2.2 Solar station ..........................................................69
8.2.3 Electric heating resistance For 200/400) only .......71
26/04/2016 - 7607575-05 3

9 Appendix – Information on the Ecodesign and Energy Labelling
Directives ..................................................................................................72
Contents
26/04/2016 - 7607575-05 4

26/04/2016 - 7607575-05 5

1 Safety instructions
1.1 Safety instructions
DANGER
This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have
been given supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved. Children shall
not play with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
CAUTION
1. Turn off the domestic cold water inlet.
2. Open a hot water tap on the installation.
3. Open a safety unit valve.
4. When the water stops flowing, the appliance
has been drained.
1. Safety instructions 200SE-2S - 300SE-2S
626/04/2016 - 7607575-05

CAUTION
Pressure limiter device
4The pressure limiter device (safety valve or
safety unit) must be operated regularly in
order to clear out any limescale deposits and
ensure that it is not blocked.
4The pressure limiter device must be
connected to a discharge pipe.
4As water may flow from the discharge pipe,
it must be kept open to the air, in a frost-free
environment, in a continuous downward
gradient.
For the type, characteristics and connection of
the pressure limiter device, please refer to the
section entitled Connecting the domestic hot
water tank to the drinking water network in the
installation and service manual for the domestic
hot water tank.
The user guide and the installation manual can
also be found on our internet site.
CAUTION
Allowance must be made for a means of
disconnection in the fixed pipes in accordance
with the regulations on installations.
CAUTION
If a power cord is provided with the appliance
and it turns out to be damaged, it must be
replaced by the manufacturer, its after sales
service or persons with similar qualifications in
order to obviate any danger.
200SE-2S - 300SE-2S 1. Safety instructions
26/04/2016 - 7607575-05 7

CAUTION
Respect the maximum water inlet pressure to
ensure correct operation of the appliance,
referring to the chapter "Technical
Specifications".
CAUTION
Before any work, switch off the mains supply to
the appliance.
CAUTION
In order to limit the risk of being scalded, the
installation of a thermostatic mixing valve on the
domestic hot water flow piping is compulsory.
1.2 Recommendations
CAUTION
Do not neglect to service the appliance. Service
the appliance regularly to ensure that it operates
correctly.
WARNING
Only qualified professionals are authorised to
work on the appliance and the installation.
WARNING
4The heating water and the water-propylene-
glycol mixture must not come into contact
with the domestic hot water.
4The domestic hot water must not circulate
through an exchanger.
4Solar installations can be protected against
lighting and must be earthed or connected
to an equipotential connection.
To take advantage of the guarantee, no modifications
must be made to the appliance. Only remove the covers
for maintenance and breakdown repair operations and put
the covers back in place after the maintenance and
breakdown repair operations.
Instructions stickers
1. Safety instructions 200SE-2S - 300SE-2S
826/04/2016 - 7607575-05

The instructions and warnings affixed to the appliance
must never be removed or covered and must remain
legible during the entire lifespan of the appliance.
Immediately replace damaged or illegible instructions and
warning stickers.
WARNING
Never cut the power to the solar control system,
even during extended absences. The control
system protects the installation against
overheating in summer when it is running.
WARNING
Do not modify the control system parameters
unless fully conversant with them.
During extended absences, we recommend lowering the
set point temperature in the solar DHW calorifier to 45°C.
When the user is present, the set point must be set to
60°C.
1.3 Liabilities
1.3.1. Manufacturer’s liability
Our products are manufactured in compliance with the
requirements of the various applicable European
Directives. They are therefore delivered with [ marking
and all relevant documentation.
In the interest of customers, we are continuously
endeavouring to make improvements in product quality.
All the specifications stated in this document are therefore
subject to change without notice.
Our liability as the manufacturer may not be invoked in the
following cases:
4Failure to abide by the instructions on using the
appliance.
4Faulty or insufficient maintenance of the appliance.
4Failure to abide by the instructions on installing the
appliance.
200SE-2S - 300SE-2S 1. Safety instructions
26/04/2016 - 7607575-05 9

1.3.2. Installer’s liability
The installer is responsible for the installation and
commissioning of the appliance. The installer must
respect the following instructions:
4Read and follow the instructions given in the manuals
provided with the appliance.
4Carry out installation in compliance with the prevailing
legislation and standards.
4Perform the initial start up and carry out any checks
necessary.
4Explain the installation to the user.
4If a maintenance is necessary, warn the user of the
obligation to check the appliance and maintain it in
good working order.
4Give all the instruction manuals to the user.
1. Safety instructions 200SE-2S - 300SE-2S
10 26/04/2016 - 7607575-05

2 About this manual
2.1 Symbols used
2.1.1. Symbols used in the manual
In these instructions, various danger levels are employed to draw the
user’s attention to particular information. In so doing, we wish to
safeguard the user’s safety, highlight hazards and guarantee correct
operation of the appliance.
DANGER
Risk of a dangerous situation causing serious physical
injury.
WARNING
Risk of a dangerous situation causing slight physical
injury.
CAUTION
Risk of material damage.
Signals important information.
¼Signals a referral to other instructions or other pages in the
instructions.
2.1.2. Symbols used on the equipment
Before installing and commissioning the device, read
carefully the instruction manuals provided.
Dispose of the used products in an appropriate recovery
and recycling structure.
2.2 Abbreviations
4CFC: Chlorofluorocarbon
4DHW: Domestic hot water
200SE-2S - 300SE-2S 2. About this manual
26/04/2016 - 7607575-05 11

3 Technical description
3.1 Homologations
3.1.1. Certifications
This product complies to the requirements to the european directives
and following standards:
4PHRASE NON TRADUITE : 65228 .
Reference Standard: EN 60.335.1.
Reference Standard: EN 60.335.2.21.
4PHRASE NON TRADUITE : 65229 .
Reference Standards: EN 50.081.1, EN 50.082.1, EN 55.014
3.1.2. Directive 97/23/EC
This product conforms to the requirements of european directive 97 /
23 / EC, article 3, paragraph 3, on pressure equipment.
3.2 General description
200SE-2S - 300SE-2S domestic hot water calorifiers are connected
to solar collectors by a solar station.
The calorifiers 200SE-2S - 300SE-2S are fully equipped with a solar
technical station, consisting of a charge device for each zone, a safety
device, an expansion vessel, a pump, a solar control system Delta
Sol AEL etc.
Main parts:
4The tanks are made of high quality steel lined with food quality
standard enamel vitrified at 850°C, which protects the tank from
corrosion.
4The heat exchangers welded into the tank are made of smooth
piping, the external surface of which, in contact with the drinking
water, is enamelled.
4The appliance is highly insulated with CFC-free polyurethane
foam, which reduces thermal losses to a minimum.
4The external casing is made of ABS.
4The tanks are protected against corrosion by several magnesium
anodes.
3. Technical description 200SE-2S - 300SE-2S
12 26/04/2016 - 7607575-05

3.3 Main parts
3.3.1. Solar domestic hot water calorifier
200SE-2S - 300SE-2S: External view
AExpansion vessel
ZTop inspection trap
ESide inspection plate
RSolar station
TSolar regulator
YElectrical back-up (Option)
USafety control unit for the solar circuit
All components are checked for leaks and tested in the
factory. The control system, the pump and the electrical
back-up are pre-wired.
200SE-2S - 300SE-2S: Internal view
ASolar exchanger
ZBack-up exchanger
(Boiler or heat pump)
EAnode - Side inspection plate
RAnode - Top inspection trap
All components are checked for leaks and tested in the
factory. The control system, the pump and the electrical
back-up are pre-wired.
L000430-C
5
7
4
6
1
2
3
L000598-A
4
2
1
3
200SE-2S - 300SE-2S 3. Technical description
26/04/2016 - 7607575-05 13

3.3.2. Solar station
APressure gauge
ZSolar circulation pump
EFilling valve
RDraining valve
TSafety valve
YSolar circuit air vent
UFlowmeter
IClamping ring fitting
ORed flow thermometer
PBlue flow thermometer
3.3.3. Solar regulator
ACover
ZAlphanumeric LCD display
EControl keys
RFuse 4 AT backup
TConnectors
YRouting the cables
UCover screw
IHole for fixation screw
3.4 Operating principle
The solar control system optimises the collection of solar energy in
order to reheat the domestic hot water contained in the calorifier.
1
3
5
2
4
109
6
7
8
L000415-C
M002750-A
1
4
5
8
7
7
2
8
6
3
3. Technical description 200SE-2S - 300SE-2S
14 26/04/2016 - 7607575-05

3.4.1. General principle
TC Temperature of the solar collectors
TR Temperature of the lower part of the tank
DT Reference temperature difference
SX Set temperature of the solar calorifier
PC % Solar circulation pump mode
CMIN Minimum collector temperature triggering the pump
CMAX Maximum temperature of the solar collector
tu Self-calibration time
°C Temperature
tTime
¼See chapter: "Description of the installer parameters", page
51.
Live Operating description
1The sun’s irradiation heat the transfer fluid in the collector. To trigger the circulation pump, a minimum temperature of
30°C is necessary in the collectors (CMIN) as is a temperature difference of 6 K between the temperature of the collectors
and the DHW tank.
2In the automatic calibration phase (setting parameter tu, factory setting 3 minutes), the solar pump (relay 1) operates on
full (100%) in order to stabilise the temperature in the solar circuit.
3Subsequently, the rate at which the solar pump operates is calculated dynamically to maintain a reference temperature
difference (parameter DT, factory setting 20 K) between the collectors and the DHW tank.
4The system loads the DHW tank according to the heat available in the collectors and stops when the set point temperature
of the DHW tank is reached (setting parameter SX, factory setting 60).
TC
TR
DT
SX
PC %
CMIN
CMAX
M002751-C
1 2 3 4 5678
°C
t
tu
200SE-2S - 300SE-2S 3. Technical description
26/04/2016 - 7607575-05 15

Live Operating description
5When the temperature in the collectors reaches the maximum value (adjustment parameter CMAX, factory setting 110°C),
the solar pump is triggered to cool the collectors.
The pump continues to operate until the temperature in the collectors is lower than 5 K at parameter CMAX and/or the
maximum storage temperature (80°C) is reached in the hot water storage tank.
6When there is less available sunlight, the temperature in the collectors drops and the temperature in the DHW tank is
stable.
7As soon as the temperature in the collectors drops below the temperature in the calorifier, the calorifier is cooled down to
its set temperature.
8When the set point SX is reached, the circulation pump shuts down, the temperature in the collectors drops again and the
temperature in the DHW tank falls according to any draw-offs made.
The DHW tank cooling function is inactive if using tubular
collectors (function FT active).
3.4.2. Protection against overheating on the solar
circuit
The control system has various functions, which are easy to discern
for the user, which limit overheating of the installation’s components.
3.5 Technical specifications
3.5.1. Solar domestic hot water calorifier
200SE-2S 300SE-2S
Primary circuit: Solar exchanger
Maximum operating temperature °C 110 110
Maximum operating pressure Mpa (bar) 1 (10) 1 (10)
Exchanger capacity litres 5.6 8.1
Exchange surface m20.84 1.2
Primary circuit: Back-up exchanger
Maximum operating temperature °C 110 110
Maximum operating pressure Mpa (bar) 1 (10) 1 (10)
Exchanger capacity litres 5.1 5.1
Exchange surface m20.76 0.76
Pressure drop at 2 m3/Time kPa 4 4
Secondary circuit (domestic water)
Maximum operating temperature °C 95 95
Maximum operating pressure Mpa (bar) 1 (10) 1 (10)
Water content litres 225 300
Top up volume litres 75 105
Solar volume litres 150 195
Weight
Gross weight kg 125 125
Net weight kg 109 111.5
(1) Primary temperature: 80 °C - Domestic cold water inlet: 10 °C - Domestic hot water outlet: 45 °C - Primary flow rate: 2 m3/h
(2) Primary temperature: 80 °C - Domestic cold water inlet: 10 °C - Domestic hot water outlet: 40 °C - Domestic hot water storage: 65 °C
(3) Satisfies the requirements of the EN 12977–1 standard
3. Technical description 200SE-2S - 300SE-2S
16 26/04/2016 - 7607575-05

200SE-2S 300SE-2S
Performance Primary circuit: Back-up exchanger
Power exchanged(1) kW 24 24
Performance
Flow per hour (∆T = 35 °C)(1) litres per hour 590 590
Transfer capacity over 10 minutes (∆T = 30°C)(2) litres per 10 min. 150 200
Maintenance consumption (ΔT=45K)(3) kWh/24h 1.8 2.2
Performance NL 0.7 1.2
(1) Primary temperature: 80 °C - Domestic cold water inlet: 10 °C - Domestic hot water outlet: 45 °C - Primary flow rate: 2 m3/h
(2) Primary temperature: 80 °C - Domestic cold water inlet: 10 °C - Domestic hot water outlet: 40 °C - Domestic hot water storage: 65 °C
(3) Satisfies the requirements of the EN 12977–1 standard
3.5.2. Sensor characteristics
Temperature in °C -10 0 10 20 30 40 50 60 70 80 90 100 110
Resistance in Ω
(Pt1000)
961 1000 1039 1078 1117 1155 1194 1232 1271 1309 1347 1385 1423
3.5.3. Solar regulator
nSpecifications
4ABS box
4Class of protection: IP 20 / EN 60529
4Ambient temperature: 0...35°C
4Dimensions: 144x208x43 mm
4Display: Alphanumeric LCD display
4Control: via 3 keys on the front panel
4Storage temperature: -20...+70°C
4Inputs: 3 Pt1000 temperature sensors
4Output: 1 inverter contact electromechanical relay and 2 high
output relays
4Max. current: 4 A - 250 V
4Power supply: 210...240 V(AC) - 50...60 Hz
4Consumption on standby: 0.36 W
4Total shutdown capacity: 4 (1) A (100...240)V
4Shutdown capacity of the electromechanical relay: 4 (1) A
(100...240)V
4Shutdown capacity of the high output relays: 14 (3) A (100...240)V
nFunction
4Hour run meter on the electrical back-up.
4Hour run meter on the solar pump.
L000612-A
200SE-2S - 300SE-2S 3. Technical description
26/04/2016 - 7607575-05 17

4Tubular solar collector function.
4Calorimetric balance.
4Hourly command thermostat.
43-position switch.
3.5.4. Solar station
Dimensions Spacer 100 mm
Connections for pipes DN18 clamping ring screw connections
Connection for expansion vessel 3/4 external thread (Sheet gasket)
Outflow safety valve 3/4 internal thread
Operating data Maximum admissible pressure PN 10
Maximum operating temperature 120 °C
Maximum short-term temperature 160 °C < 15 mn
Max. propylene glycol content 50%
Equipment Safety valve 0.6 (6) Mpa (bar)
Pressure gauge 0.6 (6) Mpa (bar)
Anti-thermosiphon valve 2 x 200 mmWG
Circulation pump Yonos Para ST15/7 130 9H
Materials used Valves Brass
Gaskets EPDM
Anti-thermosiphon valve Brass
3. Technical description 200SE-2S - 300SE-2S
18 26/04/2016 - 7607575-05
