Remote Solutions SAFE-T-RACK SR-U User manual

Operation
Manual
FA
©
Because Distance is the Best Arc Flash Protection
2400-4160V
3000A
SB-50FA-3035-NM
SR-U
Our products are built to spec in our
23,000 sq ft., state-of-the-art facility
by our team of designers and
engineers in Tucson, Arizona. Each
product is custom designed to
individually fit each breaker, cubical
door, switch gear, or variant so you
know you’re getting the safest, most
reliable product on the market. We
built the best so your team stays safe.
Allis Chalmers/
Siemens
REMOTE SOLUTIONS, LLC
2475 N. Jackrabbit Avenue • Tucson, AZ 85745 • [phone] • FAX [phone] • Safe-T-Rack.com

1 each
The Spanner Bar fits between the
walls of the breaker while the
Smart Drive Bracket mounts on
top and engages with the racking
shaft.
23
©
2
Depicted in figs. 1.1 and 1.2, an Interlock
Manipulator is activated when plugged into the
Smart Drive Bracket (SDB), which engages with
the Motor Drive Unit (MDU). A Spanner Bar is
temporarily installed on which to mount the
SDB.
The Interlock Manipulator mounts on two
switch magnets inside the breaker door. The
SDB rests on the Spanner Bar and latches into
place with a spring lock. The MDU connects to
the SDB and connects the Handheld Controller
(HHC) with a 50-foot automation cable to allow
the operator to perform the racking in/out
functions from a safe distance.
Fig. 1.2
Fig. 1.1
The Portable Kit comes with a
Universal Tool Adapter Assembly
(UTAA) that is designed to be trimmed
to a specific length to accommodate
any breaker distance.
1 each
Portable Kit includes: One Motor
Drive Unit (MDU), one 50’ comm.
cable, two 28V batteries, and one
SR-U Handheld Controller (HHC)
The Smart Drive Bracket and
Interlock Actuator mount on the
Spanner Bar and breaker face,
respectively, during the racking
procedure.
Part/Image Quantity Description
1 each
1 each
Always observe all safety precautions and use all personal protective
equipment (PPE) as required by Local Site Procedures. This equipment is designed
to minimize exposure risk to the operator. Please use the cables, explained below,
to attain a safe distance from the breakers during racking. Always use appropriate
PPE. Above all, adhere to site specific regulations and requirements.
Before beginning the racking process, be sure that the breaker is open, verify that a
lockout/tag out is in place (LOTO) and allows racking of the breaker.

Sequence Process
1. Fit the Spanner Bar to the
appropriate width.
2. Secure the Spanner bar in position
Fig. 1.4
45
The Spanner Bar, depicted in fig. 1.3, mounts between the wall panels of the breaker.
The width of the Spanner Bar is adjustable and secures its position where the SDB can
be mounted.
Sequence Process
1. Attach a fully charged battery to
the MDU.
2. Set the locking pin to the open
position.
3. Insert the MDU equipped with the
UTAA through the mounting rings.
4. Align and engage the UTAA with
the SDB.
5. Release the locking pin, securing
the MDU in place.
6. Connect the SDB Automation
Cable to the MDU.
©
Sequence Process
1. Secure the Interlock Manipulator
with two switch magnets.
2. Secure the SDB to the breaker with
the spring lock.
3. Plug the SDB and the Interlock
Manipulator together.
©
The Portable Kit includes two 28V batteries. Before connecting the battery to the system,
make sure the battery is fully charged and is attached to the MDU. If preferred, an AC Power
Supply is available, negating the need of a battery.
The MDU intuitively fits into the SDB mounting rings (depicted in red), on top of which
is a locking pin (depicted in green, fig. 1.5). Set the locking pin to the open position. Insert
the MDU and align the UTAA with the SDB. Lock the MDU into place by releasing the
locking pin. When the pin fully engages the MDU is secure.
Once the MDU is secured to the SDB and fully connected to the Tool Adapter, connect the
50-foot SDB Automation Cable to the Motor Drive Unit.
Fig. 1.5
As depicted in fig. 1.4, the Interlock Manipulator mounts on two switch magnets and the
SDB rests on the Spanner Bar while a spring lock secures it to the breaker face. The two
connect via a cable so the Interlock Manipulator engages with the Interlock Handle to
perform the racking functions.
Fig. 1.3
Smart Drive Bracket/Interlock Manipulator Mount
Spanner Bar Mount

©©
6 7
The Handheld Controller connects to the MDU via a 50’ Automation Cable. If necessary
three cables may be tethered to achieve a safe distance of 150’. Once plugged in and
turned on, the Handheld Controller guides the user through the racking in/out procedure.
When racking in/out, if an obstruction or mechanism
failure occurs, the system will attempt to recover the
breaker to a safe position. Actions will be displayed with
an asterisk (*) in front of them. When done, the position
of the breaker will be displayed as determined by the recovery. Note the location
and approach with caution. Determine the cause of the failure and remedy the situation
prior to attempting additional remote racking.
NOTE: Attempting to stop or shutting down the system mid-process once it has started
is not recommended, as this will leave the breaker in an unknown position. The Remote
Racking System will only operate from “known” positions: connect or disconnect. The Remote
Racking System will not engage when the breaker is at a mid-point.
Remote Solutions, LLC
2475 N. Jackrabbit Avenue
Tucson, AZ 85745
[phone]
[email protected]
www.safe-t-rack.com
To ensure longevity from the Portable Kit and the Smart Drive Bracket, store the tools in
the provided polymer case in a dry, temperate environment. The tools are weather
resistant but should be used with care in rain and snow.
For any questions, concerns, information, or
missing/replacement parts, contact Remote
Solutions below or follow the QR link to our website.
Sequence Process
1. Connect the Handheld Controller with the 50’
Comm. Cable.
2. Move a safe distance from the breaker.
3. Twist the E-Stop switch, depicted here, to acti-
vate the HCC.
4. Turn on the Handheld Controller and follow the
on-screen prompts.
