REMS Helix VE User manual
1800 4 ANCRA www.ancraaustralia.com
HELIX VE
REMS Helix VE
INSTRUCTION MANUAL
Powerful, handy power tool for drilling, driving
in, loosening screws and deburring pipes. For
cordless and mains operation.
Fig. 1
6
5
8
4
1 2 3
7
9
Translation of the Original Instruction Manual
Fig. 1
1 Quick-clamping chuck
2 Torque setting ring
3 Preselection lever for hi/lo speed range
4 Rotation direction switch
5 Safety switch (accelerator)
6 LED work light
7 Switch handle
8 Battery
9 Belt clip
General Power Tool Safety Warnings
WARNING
Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
The term „power tool“ in the warnings refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of ammable liquids,
gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will reduce risk of elec-
tric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigera
tors. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord
away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric
shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected
supply. Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use
a power tool while you are tired or under the inuence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal
injuries.
c) Prevent unintentional starting. Ensure the switch is in the offposition before connecting to power
source and/or battery pack, picking up or carrying the tool. Carrying power tools with your nger on the
switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power
tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from
moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can reduce dust-related hazards.
eng
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will
do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool before making
any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely
to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into
account the working conditions and the work to be performed. Use of the power tool for operations diffe-
rent from those intended could result in a hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specied by the manufacturer. A charger that is suitable for one type of
battery pack may create a risk of re when used with another battery pack.
b) Use power tools only with specically designated battery packs. Use of any other battery packs may create
a risk of injury and re.
c) When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or a re.
d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally
occurs, ush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
6) Service
a) Have your power tool serviced by a qualied repair person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
Safety instructions for electric drills
WARNING
Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
●
Inspect the area concerned for concealed supply lines with a suitable instrument before drilling. Gas
or water pipes, electric cables or other objects can be damaged or severed when drilling. Damaged gas pipes
can cause explosions. Damaged water pipes and electric cables can cause property damage or electric shock.
●
Hold the power tool by the insulated handles when performing work where the power tool can come
into contact with concealed electric cables. Contact with a live cable can also put metal parts of the power
tool under voltage and lead to electric shock.
●
Secure the workpiece to be machined against being ung away.
●
Hold the power tool only by the switch handle (7) for all jobs. High torques can occur temporarily especially
when tightening and loosening screws.
●
Do not reach into moving parts.
●
Only operate the preselection switch for the hi/lo speed range when the power tool is out of operation.
If this cannot be pushed up to the stop, turn the drill chuck slightly.
●
Switch off the power tool immediately if the tool jams.
●
Only apply the power tool for drilling or to the screw when it is off. Rotating tool attachments can slip off.
●
More the rotation direction switch (4) to the middle rest position and/or remove the battery before
performing any work on the power tool (e.g. tool change, maintenance). There is a danger of injury from
accidental operation of the safety switch (5).
●
Check the connecting cable and any extension cables of the power tool regularly. Have these renewed
by qualied experts or by an authorised REMS service shop if damaged.
eng
eng
●
Do not look directly into the LED work light (6). Danger of blinding.
●
Dusts from materials, metals and some types of wood can be harmful to health and lead to allergic reactions,
afictions of the respiratory tract and/or cancer. Wear a respirator of lter class FFP2 if necessary. Material
containing asbestos may only be handled by specialists.
●
This power tool is not intended for use by persons (including children) with limited physical, sensory or mental
abilities or lack of experience and knowledge unless they have been instructed in the use of the power tool by
a person responsible for their safety or are supervised by such a person. Children must be supervised to ensure
that they do not play with the power tool.
●
Observe the national regulations.
Safety instructions for batteries
WARNING
Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
●
Only use the battery in the cordless LED lamp and in REMS power tools. Only then is the battery protected
against dangerous overloading.
●
Only use genuine REMS batteries with the voltage specied on the rating plate of the cordless LED lamp.
The use of other batteries can lead to injury and re due to exploding batteries.
●
Only use the battery and rapid charger in the specied operating temperature range.
●
Only charge REMS batteries in the REMS rapid charger. An unsuitable charger can cause res.
●
Fully charge the battery in the REMS rapid charger before using for the rst time to obtain full battery
power. Batteries are delivered partially charged.
●
Insert the battery into the battery chamber straight and without force. There is a danger of bending the
battery contacts and damaging the battery.
●
Protect the battery against heat, direct sunlight, re, moisture and wet. There is a danger of explosion and
re.
●
Do not use the batteries in areas where there is a risk of explosion and in the vicinity of inammable gases,
solvents, dust, fumes, wet for example. There is a danger of explosion and re.
●
Do not remove the battery or modify its construction. There is a danger of explosion and re due to short-
circuits.
●
Never use a battery with a damaged housing or damaged contacts. Fumes can be caused by damaged
batteries or improper use of the battery. The fumes can cause irritation to the respiratory tract. Provide fresh air
and consult a doctor if suffering from such symptoms.
●
Incorrect use can lead to leakage of uid from the battery. Do not touch the uid. Leaking battery uid can
cause irritation to the skin or burns. Wash off with water in case of contact. Also consult a doctor if the uid gets
into your eyes.
●
Observe the safety instructions printed on the battery and the rapid charger.
●
Keep unused batteries away from paper clips, coins, keys, nails, screws or other small metal objects
which could cause bridging of the contacts. There is a danger of explosion and re due to short-circuits.
●
Remove the battery before putting the cordless LED lamp into longer storage. Protect the battery contacts
from short-circuiting, e.g. with a cap.
●
Do not throw defective batteries in the normal household waste. Hand the defective batteries over to an
authorised REMS contract service workshop or a recognised disposal company.
Explanation of symbols
WARNING Danger with a medium degree of risk which could result in death or severe injury (irreversible)
if not heeded.
CAUTION Danger with a low degree of risk which can result in minor injury (reversible) if not heeded.
NOTICE Material damage, no safety note! No danger of injury.
Read the operating instructions before use
Power tool complies with protection class II
Power tool is not suitable for using outdoors
eng
Environmentally friendly disposal
1. Technical Data
Use for the intended purpose
WARNING
The power tool is intended for drilling in steel and other metals, stone, wood and plastic, for drilling with
REMS tile drills in ceramics, ne clay, granite and marble, for turning in/loosening screws and for removing
burr from pipes with REMS REG 10 – 42, REMS REG 10 – 54 E. All other uses are not for the intended purpose
and are prohibited.
1.1. Scope of delivery
Cordless power drill/ screw driver, Li-Ion rapid charger, battery, 1 bit with double blade slot/cross head, belt
clip (9), operating instructions, carrying bag.
1.2. Article numbers
REMS Helix VE drive unit 190000
Li-Ion 14.4 V, 1.6 Ah battery 571545
Li-Ion 14.4 V, 3.2 Ah battery 571555
Li-Ion/Ni-Cd rapid charger 571560
Li-Ion power supply 571565
Carrying bag 190053
REMS REG 10 – 42, outside/inside pipe deburrer 113810
Driver for REMS REG 10 – 42 113815
REMS REG 10 – 54 E, outside/inside pipe deburrer 113835
REMS tile drill Ø 5 mm 181710
REMS tile drill Ø 6 mm 181711
REMS tile drill Ø 8 mm 181712
REMS tile drill Ø 10 mm 181713
REMS tile drill Ø 12 mm 181714
REMS tile drill Ø 14 mm 181715
1.3. Applications
Clamping range quick-clamping chuck 0.8 – 10 mm
Drillinginsteel,stone Ø≤10mm
Drillinginwood Ø≤28mm
Drillingwithtiledrills Ø≤14mm
Turningin/looseningscrews Ø≤7mm
Operating temperature range
REMS Helix VE 0°C – +60 °C (32 °F – +140°F)
Li-Ion Plus battery –10°C – +60 °C (14 °F – +140°F)
Li-Ion/Ni-Cd rapid charger 0°C – +45 °C (32 °F – +113 °F)
1.4. Speed, torque
Lo speed stage 0 – 300 rpm
Hi speed stage 0 – 1,250 rpm
Torque in lo speed stage 31 Nm
Torque in hi speed stage 13 Nm
1.5. Electrical data
REMS Helix VE 14.4 V
–
---
Li-Ion/Ni-Cd rapid charger Input 230 V~; 50– 60 Hz; 65 W
Output 10.8– 18 V
–
---
Li-Ion power supply Input 230 V~; 50– 60 Hz
Output 14.4 V
–
---; 6 A– 33 A
1.6. Dimensions
REMS Helix VE with battery 190× 210 ×82 mm (7.5”× 8.3” ×3.2”)
eng
2.2. Setting the speed
NOTICE
Only switch the preselection lever for the speed range (3) when the power tool is out of operation.
The power tool has two speeds which are set by a mechanical gear. Set the speed range preselection lever
(3) to “Lo” for low speed. Set the speed range preselection lever (3) to “Hi” for high speed. The “Lo” speed
is used preferably for drilling large diameters, removing burr and turning in/loosening screws. The “Hi” speed
is used preferably for drilling small diameters. If the speed range preselection lever (3) cannot be turned up
to the stop, turn the quick-clamping chuck slightly by hand.
2.3. Setting the torque
The torque required for the work is set with the torque setting ring (2). The numbers 1 to 25 and the symbol
are shown on the torque setting ring. The lowest torque is set at stage 1 and the highest torque at
stage 25. A low torque is preferably used for turning in small screws. A higher torque, if necessary up to symbol
, should be set for drilling, removing burr and for loosening screws.
2.4. Reversing the direction of rotation
The rotation direction switch (4) has three rest positions. In the middle rest position the safety switch (5)
cannot be pressed and therefore the power tool cannot be switched on. Select this setting for all work on the
power tool, e.g. tool change, maintenance and for transport and storage. Press the rotation direction switch
(4) with the arrow head in the direction of the quick-clamping chuck (1) up to the stop for right-hand rotation.
Press the rotation direction switch with the arrow head in the direction of the speed range preselection lever
(3) up to the stop for left-hand rotation. The rotation direction switch (4) can only be actuated when the safety
switch (5) is not pressed.
2.5. Clamping the tool
Remove the battery or move the rotation direction switch (4) to the middle rest position. The drilling spindle
is locked when the safety switch (5) is not pressed. This enables easy tightening and loosening of the tool
attachment in the quick-clamping chuck (1). The tool is clamped by turning the quick-clamping chuck (1) to
the right, loosen by turning to the left. Never open or close the quick-clamping chuck when the motor is running.
2.6. Inserting the battery
NOTICE
Charge the battery before inserting in the cordless power drill/screw driver! Push the battery into the drive
unit vertically until it snaps in audibly.
2.7. Operating the safety switch
If the safety switch (5) is only pressed slightly, the LED work light (6) lights, the quick-clamping chuck (1) does
not yet turn. When the pressure is increased the quick-clamping chuck turns at slow speed. The highest speed
is achieved when the safety switch (5) is pressed right in.
3. Operation
REMS Helix VE is equipped with a safety switch (5). This enables the drive unit to be stopped at any time
but especially in the event of danger.
3.1. Drilling
Only apply REMS Helix VE to the workpiece to be drilled when it is off. Press the safety switch (5) a little at
rst,thenpressinfully.
3.2. Turning in/loosening screws
OnlyapplyREMSHelixVEtothescrewheadwhenitisoff.Assoonasthebitisrmlyinthescrewhead,
pressthesafetyswitch(5)atrstonlyalittleandthenpressinfully.
NOTICE
Switch off the drive unit immediately if the safety clutch responds during operation.
3.3. Removing burr with REMS REG
Set the speed range preselection switch (3) to “Lo” and the rotation direction switch (4) to right-hand rotation.
Press the safety switch (5) fully in. Press the pipe to be deburred carefully against the pipe deburrer.
CAUTION
Danger of injury! Do not reach into the area of the moving pipe deburrer!
eng
3.4. Low discharge protection
REMS Helix VE is equipped with a low discharge protection. This switches off the drive unit as soon as the
battery needs recharging. In this case remove the battery and charge with the REMS rapid charger.
4. Service
4.1. Maintenance
WARNING
Pull out the mains plug or remove the battery before doing maintenance work!
Keep the power tool clean. Blow out the soiled quick-clamping chuck (1).
Only clean plastic parts (e.g. housing, batteries) with mild soap and a damp cloth. Do not use household
cleaners. These often contain chemicals which can damage the plastic parts. Never use petrol, turpentine,
solvent or similar products for cleaning plastic parts.
Liquids may never be allowed to penetrate inside the power tool. Never immerse the power tool in liquids.
4.2. Inspection/repair
WARNING
Pull out the mains plug or remove the battery before carrying out maintenance or repair work! This
workmayonlybeperformedbyqualiedpersonnel.
The gear of the REMS Helix VE is maintenance-free.
5. Faults
5.1. Fault: Drive unit does not start.
Cause:
●
Batteryatordefective.
●
Defective drive unit.
5.2. Fault: Drive unit stops during operation.
Cause:
●
Drive unit overheated or overloaded.
●
Batteryatordefective.
●
Torque set too low.
●
Defective drive unit.
5.3. Fault: No or low drill thrust.
Cause:
●
Blunt drill.
●
Wrong speed set.
eng
1.7. Weights
REMS Helix VE with battery 14,4 V, 1,6 Ah 1,3 kg (2,9 lb)
Li-Ion 14.4 V, 1.6 Ah battery 0,3 kg (0,6 lb)
Li-Ion 14.4 V, 3.2 Ah battery 0,5 kg (1,1 lb)
1.8. Noise information
Emission at workplace L
pA
= 68 dB L
WA
= 79 dB K = 3 dB
1.9. Vibrations
Weighted effective value of acceleration < 2,5 m/s² K = 1,5 m/s²
The indicated weighted effective value of acceleration has been measured against standard test procedures
and can be used by way of comparison with another device. The indicated weighted effective value of accel-
eration can also be used as a preliminary evaluation of the exposure.
CAUTION
The indicated weighted effective value of acceleration can differ during operation from the indicated value,
dependent on the manner in which the device is used. Dependent upon the actual conditions of use (periodic
duty) it may be necessary to establish safety precautions for the protection of the operator.
2. Preparations for Use
2.1. Electrical connection
WARNING
Mains voltage present! Before connecting the REMS rapid charger, check whether the voltage given on the
rating plate corresponds to the mains voltage. Only operate the electrical device on the mains with a 30 mA
fault current protection (FI switch) on building sites, in a humid environment or in similar types of application.
Rechargeable batteries
NOTICE
Always hold the battery (8) upright when inserting it in the drive unit or the rapid charger. If inserted at an
angle it can cause damage to the contacts and result in a short circuit which damages the battery.
Total discharging by undervoltage
The Li-Ion batteries may not drop below a minimum voltage because otherwise the battery could be damaged
by “total discharge”. The cells of the REMS Li-Ion battery are delivered pre-charged to approx. 40 %. There-
fore the Li-Ion batteries must be charged before use and recharged regularly. Failure to observe this regula-
tion of the cell manufacturer can lead to damage to the Li-Ion battery by total discharging.
Total discharging due to storage
If a relatively low charged Li-Ion battery is stored, self discharging can lead to total discharge damage of the
battery after longer storage. Li-Ion batteries must therefore be charged before storing and recharged every
six months at the latest and charged again before use.
NOTICE
Charge the battery before use. Recharge LiIon batteries regularly to avoid their total discharge. The
rechargeable battery will be damaged by total discharge.
Total discharging due to storage
If a relatively low charged Li-Ion battery is stored, self discharging can lead to total discharge damage of the
battery after longer storage. Li-Ion batteries must therefore be charged before storing and recharged every
six months at the latest and charged again before use.
NOTICE
Charge the battery before use. Recharge LiIon batteries regularly to avoid their total discharge. The
rechargeable battery will be damaged by total discharge.
1 2
Only use a REMS rapid charger for charging. New Li-Ion batteries and Li-Ion batteries which have not been
used for a long time only reach full capacity after several charges.
Rapid charger Liion/NiCd (Art. No. 571560)
The left control lamp lights up and remains green when the mains plug is plugged in. If a battery is inserted
intherapidcharger,thegreencontrollampashestoindicatethatthebatteryischarging.Thegreenlight
stopsashingandremainsontosignalthatthebatteryisfullycharged.Iftheredcontrollampashes,the
battery is defective. If the red control lamp comes on and remains on, this indicates that the temperature of
the rapid charger and / or the battery is outside the permissible range.
Remove the battery before putting the cordless LED lamp into longer storage. Protect the battery contacts
from short-circuiting, e.g. with a cap.
●
Do not throw defective batteries in the normal household waste. Hand the defective batteries over to an
authorised REMS contract service workshop or a recognised disposal company.
Explanation of symbols
WARNING Danger with a medium degree of risk which could result in death or severe injury (irreversible)
if not heeded.
CAUTION Danger with a low degree of risk which can result in minor injury (reversible) if not heeded.
NOTICE Material damage, no safety note! No danger of injury.
Read the operating instructions before use
Power tool complies with protection class II
Power tool is not suitable for using outdoors
Pull out the mains plug or remove the battery before carrying out maintenance or repair work! This
workmayonlybeperformedbyqualiedpersonnel.
The gear of the REMS Helix VE is maintenance-free.
5. Faults
5.1. Fault: Drive unit does not start.
Cause:
●
Batteryatordefective.
●
Defective drive unit.
5.2. Fault: Drive unit stops during operation.
Cause:
●
Drive unit overheated or overloaded.
●
Batteryatordefective.
●
Torque set too low.
●
Defective drive unit.
5.3. Fault: No or low drill thrust.
Cause:
●
Blunt drill.
●
Wrong speed set.
●
Wrong direction of rotation set.
5.4. Fault: Bit slips out of screw head.
Cause:
●
Wrong bit inserted.
●
Defective bit or screw head.
5.5. Fault: Pipe is not deburred.
Cause:
●
Blunt pipe deburrer.
●
Wrong speed set.
●
Wrong direction of rotation set.
6. Disposal
REMS Helix VE may not be thrown into the domestic waste at the end of use but must be disposed of prop-
erly by law.
7. Manufacturer’s Warranty
Thewarrantyperiodshallbe12monthsfromdeliveryofthenewproducttotherstuser.Thedateofdelivery
shall be documented by the submission of the original purchase documents, which must include the date of
purchase and the designation of the product. All functional defects occurring within the warranty period, which
are clearly the consequence of defects in production or materials, will be remedied free of charge. The remedy
of defects shall not extend or renew the warranty period for the product. Damage attributable to natural wear
eng
and tear, incorrect treatment or misuse, failure to observe the operational instructions, unsuitable operating
materials, excessive demand, use for unauthorized purposes, interventions by the customer or a third party
or other reasons, for which REMS is not responsible, shall be excluded from the warranty.
Services under the warranty may only be provided by customer service stations authorized for this purpose
by REMS. Complaints will only be accepted if the product is returned to a customer service station authorized
by REMS without prior interference in an unassembled condition. Replaced products and parts shall become
the property of REMS.
The user shall be responsible for the cost of shipping and returning the product.
The legal rights of the user, in particular the right to make claims against the seller under the warranty terms,
shall not be affected. This manufacturer’s warranty only applies for new products which are purchased in the
European Union, in Norway or in Switzerland.
This warranty is subject to German law with the exclusion of the United Nations Convention on Contracts for
the International Sales of Goods (CISG).
8. Spare parts lists
For spare parts lists, see www.rems.de→Downloads→Partslists.
Other manuals for Helix VE
2
Table of contents
Other REMS Drill manuals
