Renault 2005 Megane User manual

NU761_2_Gcv-FRA.qxd 4/11/05 11:12 Page 1
RENAULT s.a.s. Société par Actions Simplifiée au capital de 533 941 113 / 13-15, quai Le Gallo - 92100 Boulogne-Billancourt
R.C.S. Nanterre 780 129 987 - SIRET 780 129 987 03591 / Tél. : [phone]
BC84 - NU761-2 C:\Documentum\Checkout\NU761_2_Tcv-ENG.win 7/12/2005 9:13 -page1
Driver's handbook – 82 00 608 195 – NU 761-2 – 10/2005 – Edition anglaise
8200608195

NU761_2_Gcv-FRA.qxd 4/11/05 11:12 Page 3
BC84 - NU761-2 C:\Documentum\Checkout\NU761_2_Tcv-ENG.win 7/12/2005 9:13 - page 2
has chosen ELF
Engines of all types
except 1.9 dCi with
particle filter
1.9 dCi engines
with particle filter
Petrol and LPG engines
except 2.0T 16V
Renault Sport
Engine all types except
2.0T 16V Renault Sport
and 1.9 dCi with a par-
ticle filter
Gearbox
ELF EXCELLIUM LDX 5W-40 ACEA A3 / B4
Optimum performance and maximum protection in the most severe conditions
All types of driving
ELF EVOLUTION SXR 5W-40 ACEA A3 / B4
Optimum performance
All types of driving
ELF SOLARIS RNX 5W-30 ACEA C3
Optimum performance, particle filter protection and respect for the environment
All types of driving
ELF EVOLUTION SXR 5W-30 ACEA A5 / B5
Fuel economy, engine protection and respect for the environment.
All types of driving
ELF COMPETITION ST 10W-40
ELF TURBO DIESEL 10W-40 ACEA A3 / B4
ACEA B3 / B4
Other RENAULT approved lubricants for normal use.
Elf has developed specific lubricants for each Renault transmission:
Tranself TRJ 75W80, Tranself TRT 75W80, Tranself TRP 75W80, Tranself TRX 75W80 for manual
gearboxes, Renaultmatic D3Syn and Renaultmatic D2 for automatic transmissions.
These fluids are actively involved in the operation of your vehicle. (*)
RENAULT recommends using approved ELF products when topping up or changing the oil.
(*) Refer to your vehicle's Warranty and Services booklet for information regarding which grade of oil to use.
Consult your RENAULT Dealer or visit www.lubricants.elf.com

NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 0.01
0.01
Welcome to your new RENAULT
This Driver’s Handbook contains the information necessary:
• to enable you to get the best out of your RENAULT and to benefit from the latest technical developments that are
incorporated into your vehicle.
• to ensure that it always gives the best performance by following the simple but comprehensive advice concerning regular
maintenance.
• to enable you to deal quickly with minor faults that do not require specialist attention.
It is well worth taking a few minutes to read this handbook to familiarise yourself with the information and guidelines it
contains about the vehicle and its innovative features. If certain points are still unclear, the technicians at your local
RENAULT Dealer will be only too pleased to provide you with any additional information you may require.
The following symbol will help you when reading this handbook:
To indicate a hazard, danger or safety recommendation.
The descriptions of the models given in this handbook are based on the technical specifications at the time of writing.
This handbook covers all items of equipment (both standard and optional) available for these models but whether or not
these are fitted to the vehicle depends on the version, the options selected and the country where the vehicle is sold.
This handbook may also contain information about fittings to be introduced later in the model year.
Enjoy driving your new RENAULT.
Copying or translation, in part or in full, is forbidden unless prior written permission has been obtained from RENAULT, 92100 Billancourt 2005.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 0.01 (Black plate)

NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 0.02
0.02
Brief overview
• Tyre pressures ....................................................................................................................... 0.04 - 0.07
• RENAULT card: use .......................................................................................................... 1.02 ➟1.08
• Child restraints/seats ....................................................................................................... 1.32 ➟1.42
• Warning lights (instrument panel) .............................................................................. 1.46 ➟1.77
• Engine Stop/Start ............................................................................................................................. 2.05
• Driving .................................................................................................................................................. 2.37
Tyre pressure monitor ................................................................................................. 2.15 ➟2.18
Electronic Stability Program: ESP ......................................................................................... 2.19
Traction control: ASR .....................................................................................................2.20 - 2.21
Emergency brake assist .............................................................................................................. 2.24
Cruise control/Speed limiter .................................................................................... 2.25 ➟2.31
• Heating/air conditioning ................................................................................................ 3.02 ➟3.16
• Bonnet/maintenance ........................................................................................................ 4.02 ➟4.14
• Practical advice (changing bulbs,
fuses, breakdown, faults) ................................................................................................ 5.02 ➟5.37
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 0.02 (Black plate)

NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 0.03
0.03
CONTENTS
Sections
Getting to know your vehicle .................................................. 1
Driving .................................................................................................. 2
Your comfort ..................................................................................... 3
Maintenance ...................................................................................... 4
Practical advice ............................................................................... 5
Technical specifications ............................................................. 6
Alphabetical index ........................................................................ 7
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 0.03 (Black plate)

NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 0.04
0.04
TYRE PRESSURES (in bar or kg per cm² when cold)
Versions
Tyre sizes
Wheel sizes
Non-motorway use
• Front
• Rear
Motorway use (1)
• Front
• Rear
1.4 16V 1.6 16V 2.0 16V - 2.0 T
195/65 R15 T
205/55 R16 H
205/55 R16 V
205/50 R17 V
6.5 J 15
6.5 J 16
6.5 J 17
2.2
2.0
2.2
2.0
2.2
195/65 R15 H
205/55 R16 H
205/55 R16 V
6.5 J 15
6.5 J 16
2.2
2.0
2.3
2.0
2.3
205/50 R17 V
2.2
2.0
2.4
2.4
2.0
6.5 J 17
195/65 R15 H
205/55 R16 H
205/55 R16 V
2.2
2.0
6.5 J 15
6.5 J 16
2.4
2.0
2.3
2.0
2.4
6.5 J 17
2.5
205/50 R17 V
Emergency spare wheel
2.5
2.0
Tyre safety and use of snow chains
Refer to the paragraph on “Tyres” in Section 5 for information on maintenance and, depending on the version, the
conditions under which chains may be fitted to the vehicle.
(1) Special note concerning vehicles used under full load (Maximum Permissible All-Up Weight) and towing a trailer
The maximum speed must be limited to 60 mph (100 km/h) and the tyre pressure increased by 0.2 bar.
Refer to the information on Weights in Section 6.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 0.04 (Black plate)

NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 0.05
0.05
TYRE PRESSURES (in bar or kg/cm² when cold)(continued)
Versions
Tyre sizes
Non-motorway use
• Front
• Rear
Wheel sizes
Motorway use (1)
• Front
• Rear
Emergency spare wheel
1.5 dCi 1.9 dCi 2.0 dCi
6.5 J 17
2.6
2.0
205/50 R17 V
2.8
2.1
2.6
205/55 R16 V
2.8
2.6
2.0
6.5 J 16
2.3
2.0
2.5
2.4
2.0
2.5
2.0
205/50 R17 V195/65 R15 H
205/55 R16 H
205/55 R16 V
2.2
2.0
6.5 J 17
2.4
2.0
6.5 J 15
6.5 J 16
2.42.3
2.4
2,0
2.3
2.0
2.2
2.0
2.4
2.2
2.0
6.5 J 15
6.5 J 16
195/65 R15 H
205/55 R16 H
205/55 R16 V
6.5 J 17
205/50 R17 V
Tyre safety and use of snow chains
Refer to the paragraph on “Tyres” in Section 5 for information on maintenance and, depending on the version, the
conditions under which chains may be fitted to the vehicle.
(1) Special note concerning vehicles used under full load (Maximum Permissible All-Up Weight) and towing a trailer
The maximum speed must be limited to 60 mph (100 km/h) and the tyre pressure increased by 0.2 bar.
Refer to the information on Weights in Section 6.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 0.05 (Black plate)

NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 0.06
0.06
TYRE PRESSURES (in psi when cold)
Versions
Tyre sizes
Wheel sizes
Non-motorway use
• Front
• Rear
Motorway use (1)
• Front
• Rear
1.4 16V 1.6 16V 2.0 16V - 2.0 T
195/65 R15 T
205/55 R16 H
205/55 R16 V
205/50 R17 V
6.5 J 15
6.5 J 16
6.5 J 17
32
29
32
29
32
195/65 R15 H
205/55 R16 H
205/55 R16 V
6.5 J 15
6.5 J 16
32
29
33
29
33
205/50 R17 V
32
29
35
35
29
6.5 J 17
195/65 R15H
205/55 R16 H
205/55 R16 V
32
29
6.5 J 15
6.5 J 16
35
29
33
29
35
6.5 J 17
36
205/50 R17 V
Emergency spare wheel
36
29
Tyre safety and use of snow chains
Refer to the paragraph on “Tyres” in Section 5 for information on maintenance and, depending on the version, the
conditions under which chains may be fitted to the vehicle.
(1) Special note concerning vehicles used under full load (maximum permissible all-up weight) and towing a trailer.
The maximum speed must be limited to 60 mph (100 km/h) and the tyre pressure increased by 3 psi.
Refer to the information on Weights in Section 6.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 0.06 (Black plate)

NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 0.07
0.07
TYRE PRESSURES (in psi when cold)(continued)
(1) Special note concerning vehicles used under full load (maximum permissible all-up weight) and towing a trailer.
The maximum speed must be limited to 60 mph (100 km/h) and the tyre pressure increased by 3 psi.
Refer to the information on Weights in Section 6.
Tyre safety and use of snow chains
Refer to the paragraph on “Tyres” in Section 5 for information on maintenance and, depending on the version, the
conditions under which chains may be fitted to the vehicle.
Versions
Tyre sizes
Non-motorway use
• Front
• Rear
Wheel sizes
Motorway use (1)
• Front
• Rear
Emergency spare wheel
1.5 dCi 1.9 dCi 2.0 dCi
6.5 J 17
38
29
205/50 R17 V
40
30
38
205/55 R16 V
40
38
29
6.5 J 16
33
29
36
35
29
36
29
205/50 R17 V195/65 R15 H
205/55 R16 H
205/55 R16 V
32
29
6.5 J 17
35
29
6.5 J 15
6.5 J 16
3533
35
29
33
29
32
29
35
32
29
6.5 J 15
6.5 J 16
195/65 R15 H
205/55 R16 H
205/55 R16 V
6.5 J 17
205/50 R17 V
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 0.07 (Black plate)

NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 0.08
0.08
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 0.08 (Black plate)

NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 1.01
1.01
Section 1: Getting to know your vehicle
RENAULT Card: general information, use, deadlocking ............................................................................ 1.02 ➟1.08
Doors ...................................................................................................................................................................... 1.09 ➟1.13
Renault Anti-Intruder Device (RAID) ........................................................................................................................... 1.14
Engine immobiliser ............................................................................................................................................... 1.15 - 1.16
Headrests - Seats .................................................................................................................................................. 1.17 ➟1.20
Seat belts ............................................................................................................................................................... 1.21 ➟1.24
Additional restraint systems ............................................................................................................................. 1.25 ➟1.31
in addition to the front seat belts ............................................................................................................... 1.25 ➟1.28
in addition to the rear seat belts .............................................................................................................................. 1.29
side protection device ................................................................................................................................................ 1.30
Child safety ........................................................................................................................................................... 1.32 ➟1.42
Steering wheel ................................................................................................................................................................... 1.43
Driver’s position .................................................................................................................................................. 1.44 ➟1.47
Instrument panel ................................................................................................................................................. 1.48 ➟1.77
Trip computer ................................................................................................................................................. 1.66 ➟1.77
Clock and exterior temperature ..................................................................................................................................... 1.78
External rear-view mirrors ................................................................................................................................... 1.79 - 1.80
Audible and visual signals ............................................................................................................................................. 1.81
Lighting and exterior signals ............................................................................................................................ 1.82 ➟1.84
Headlight beam adjustment ............................................................................................................................................ 1.85
Wipers/washers ................................................................................................................................................... 1.86 ➟1.88
Fuel tank (filling with fuel) ................................................................................................................................. 1.89 - 1.90
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.01 (Black plate)

24088
3
1
2
4
NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 1.02
1.02
Driver’s responsibility
Never leave your vehicle
with the RENAULT card
inside and never leave a
child (or a pet) unsupervised. With
the card in the reader, it would be
possible to start the engine or
operate electrical equipment such
as the electric windows and there is
a risk that they may trap part of
their body (neck, arms, hands, etc.).
Risk of serious injury.
RENAULT card
1 - Unlocking the doors and luggage
compartment.
2- Locking all doors and luggage
compartment.
3- Locking/unlocking the luggage
compartment.
4- Integral emergency key.
The RENAULT card is used to:
- lock/unlock the doors and luggage
compartment and the fuel filler
flap (refer to the following pages);
- automatically close the electric
windows and the sunroof; refer to
the paragraphs on “windows with
automatic opening” and “sunroof”
in section 3 (depending on vehicle);
- start the engine; refer to the
paragraph on “Starting the engine”
in section 2.
Battery life
It is supplied by a battery which
should be replaced when the message
“Change card battery” appears on the
instrument panel (refer to the
paragraph on the “RENAULT card:
battery” in section 5).
Range of the RENAULT card
This varies according to the
environment. It is therefore
important to make sure when
handling the RENAULT card that
you do not lock or unlock the doors
by inadvertently pressing the
buttons.
Advice
Do not keep your RENAULT card in
a place where it could be damaged
accidentally, such as in a back
pocket where you might sit on it.
RENAULT CARDS: general information
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.02 (Black plate)

24089
4
5
NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 1.03
1.03
Integrated emergency key 4or
separate emergency key 5
(depending on the vehicle)
This is only used in exceptional
circumstances. It locks or unlocks
the left-hand side door if the
RENAULT card does not work:
- if the vehicle is located in a zone of
high electromagnetic radiation,
- if devices are being used with the
same frequency as the card,
- drain on the RENAULT Card
battery, flat battery, etc.
For instructions on how to use the
emergency key, refer to the
paragraph on “Locking and
Unlocking the doors”.
Once you have entered the vehicle
using the emergency key, insert the
RENAULT card into the card reader
in order to start the engine.
Replacement/need for an
additional RENAULT Card
If you lose your RENAULT card or
require another, you can obtain one
from your RENAULT Dealer.
If a RENAULT card is replaced, it
will be necessary to take the
vehicle and all RENAULT cards to
your RENAULT Dealer to initialise
the system.
You can use up to four RENAULT
cards per vehicle.
Faulty RENAULT card.
Always make sure the battery is in
good condition; they have a service
life of approximately two years.
See RENAULT card: batteries in
Section 5.
RENAULT CARDS: general information (continued)
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.03 (Black plate)

24088
3
1
2
NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 1.04
1.04
Locking the doors
Press locking button 2.
The side indicator lights and hazard
warning lights flash twice to
indicate that the doors have been
locked:
- if a door or the luggage compartment
is open or not properly shut, or if a
RENAULT card is still in the reader,
the doors and luggage compartment
quickly lock then unlock and the
hazard warning lights and side
indicator lights do not flash.
Unlocking/locking the luggage
compartment only
Press button 3to unlock or lock the
luggage compartment.
The hazard warning lights and side
indicator lights flash once to
indicate unlocking if the vehicle
doors are locked.
The hazard warning lights and side
indicator lights flash twice to indicate
that the luggage compartment is
locked if the vehicle doors are locked.
Unlocking the doors
Press unlocking button 1.
The hazard warning lights and side
mounted indicators flash once to
indicate unlocking.
Special notes (for some countries):
- pressing button 1unlocks the
driver’s door only,
- pressing button 1twice in
succession unlocks the other
doors.
The card buttons are deactivated
when the engine is running.
REMOTE CONTROL RENAULT CARD: use
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.04 (Black plate)

2
13
NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 1.05
1.05
Never leave your vehicle
with the RENAULT card
inside.
RENAULT card in hands-free
mode
In addition to the RENAULT card
remote functions, this enables the
following to be carried out without
touching the key card (in hands-free
mode):
- unlocking/locking of the doors and
boot and the fuel filler flap if the
card is within access zone 1,
- and starting the engine if the card
is present inside the vehicle
passenger compartment (refer to
the information on “Starting the
engine” in section 2).
Unlocking the doors and
luggage compartment
Walk up to your vehicle carrying
your RENAULT card.
As soon as you place your hand
behind the handle of a door 2, the
vehicle will unlock.
When you press button 3, only the
luggage compartment will unlock.
Unlocking is indicated by one flash
of the hazard warning lights and the
side indicator lights.
RENAULT CARD IN HANDS-FREE MODE: use
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.05 (Black plate)

245
NU761_2_G1-FRA.qxd 10/11/05 15:52 Page 1.06
1.06
Driver’s responsibility
Never leave your vehicle
with the RENAULT card
inside and never leave a
child (or a pet) unsupervised.
There is a risk that they could start
the engine or operate electrical
equipment (electric windows) and
trap part of their body (neck, arms,
hands, etc.). Risk of serious injury.
HANDS-FREE RENAULT CARD: use (continued)
Locking the doors and luggage
compartment
Holding the RENAULT card and with
the doors and luggage compartment
closed, press button 4located on one
of the handles 2or button 5on the
luggage compartment.
The side indicator lights and hazard
warning lights flash twice to
indicate that the doors have locked.
Note: the RENAULT card must be
within the vehicle’s access zone for
locking with the buttons to be
possible.
If a door or the luggage compartment
is open or not properly shut, or if a
RENAULT card is present in the
reader, the doors or luggage
compartment lock then quickly
unlock and the hazard warning
lights and indicator lights do not
flash.
If you wish to check that the doors
are locked after locking with the
RENAULT card or the buttons on the
handles, you have approximately
three seconds to try the door
handles without unlocking them.
After this delay, the Hands-Free
mode is activated once again and
any movement of the handle will
unlock the doors.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.06 (Black plate)

24088
1
2
NU761_2_G1-FRA.qxd 10/11/05 15:53 Page 1.07
1.07
Never use deadlocking if
someone is still inside the
vehicle.
DEADLOCKING
Deadlocking the doors/luggage
compartment (for some countries)
This allows you to lock the opening
elements (doors, luggage
compartment and, depending on
vehicle, the passenger side storage
compartment) and to prevent the
doors from being unlocked using the
interior handles (for example, by
breaking the window and then
trying to open the door from the
inside).
To activate deadlocking
Vehicles equipped with rear door
electric windows
- press button 1twice in quick
succession.
- or press the exterior door handle
buttons or the luggage compartment
badge twice in quick succession.
Vehicles equipped with rear door
manual windows
Before exiting the vehicle, press the
lower section of switch 2(the
integrated indicator lights up). Press
the upper section of the switch to
unlock the doors.
In all situations
The hazard warning lights flash five
times to indicate locking.
Note: it is possible to activate this
function by two simultaneous
presses on the door handle buttons
located on the same side (for
example: front left/rear left or front
right/rear right).
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.07 (Black plate)

24088
1
2
4
3
NU761_2_G1-FRA.qxd 10/11/05 15:53 Page 1.08
1.08
The door lock/unlocking control
from the inside 4is deactivated
when the vehicle is used with the
RENAULT card in the restricted
use mode.
It is only possible to restrict the use
of one RENAULT card at a time.
When using a RENAULT card in
the restricted use mode, the second
card retains all of its functions.
RENAULT CARD IN RESTRICTED MODE
The RENAULT card in restricted
mode will only unlock the driver’s
door and the fuel filler flap and start
the engine (the passenger storage
compartment and the luggage
compartment remain locked).
To cancel restricted mode, start the
vehicle with the RENAULT card in
non-restricted mode.
RENAULT card restricted use
(depending on vehicle)
In certain situations (when the
vehicle is in the hands of a third
person: valet parking, repair agent,
etc.) you may wish to restrict the
operation of the RENAULT card.
Obtain two cards. Insert one card in
card reader 3then press buttons 1
and 2on the second card at the same
time. The vehicle will be locked
then the driver’s door will be
unlocked.
The RENAULT card inserted in the
card reader switches to restricted
mode.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.08 (Black plate)

12
NU761_2_G1-FRA.qxd 10/11/05 15:53 Page 1.09
1.09
OPENING AND CLOSING THE DOORS
Opening the doors from the
outside
Once the doors have been unlocked
or you have the hands-free
RENAULT card on you, hold
handle 1and pull it towards you to
open the door.
Opening the doors from the
inside
Pull handle 2.
Lights on warning buzzer
If you have switched off the ignition
and left the lights switched on a
reminder buzzer will sound when a
door is opened.
Card reminder buzzer
A beep will let you know if you have
left the card in the reader when you
open the driver’s door, and the
“remove card” message will appear
on the instrument panel.
Special note
After switching off the engine, the
lights and any accessories that are in
operation (radio, air conditioning,
etc.) will continue to operate.
They will stop as soon as the
driver’s door is opened.
Door/luggage compartment open
buzzer
If a door (or luggage compartment) is
open or not properly closed, as soon
as the vehicle reaches a speed of
approximately 6 mph (10 km/h), the
message “luggage compartment
open” or “door open” (depending on
what is open) will appear on the
instrument panel accompanied by a
warning light.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.09 (Black plate)

34
NU761_2_G1-FRA.qxd 10/11/05 15:53 Page 1.10
1.10
If there is a fault, you will
hear a beep and the
integrated indicator will
not light up.
Rear door central locking
must be reactivated following
disconnection of the battery
by pressing switch 3.
Safety of rear occupants
The driver can inhibit
operation of the rear electric
windows and doors by
pressing switch 3on the side with
the symbol.
Driver’s responsibility
Never leave your vehicle without
removing the RENAULT card from
inside and never leave a child (or a
pet) inside. With the key in the
ignition it would be possible to
operate the electric windows and
there is a risk that a child or animal
may be seriously injured (by
trapping his or her neck, arm, hand,
etc.). If something gets trapped,
reverse the direction of travel as
soon as possible by pressing the
relevant switch.
OPENING AND CLOSING THE DOORS (continued)
Child safety
Vehicles fitted with switch 3with
integrated indicator light
Press switch 3to prevent the
operation of the rear electric windows
and opening of the rear doors.
The indicator light in the switch
lights up to confirm that the doors
are locked.
Other cases
To make it impossible for the rear
doors to be opened from the inside,
press switch 4 and check from the
inside that the doors are securely
locked.
NU761_2_G1-ENG.qxp 1/6/2006 12:23 PM Page 1.10 (Black plate)
