Renco PREG-ALERT PRO User manual

PREG-ALERT PRO®
INSTRUCTIONS
(Rev. 2)
한국대리점: 길우트레이딩 02)2636-0009 팩스02)2636-4753 서울시 영등포구 양평동 3가 40-2 에이스테크노타워703호 [email protected] www.gilwoo.co.kr

PREG‐ALERTPRO®INSTRUCTIONMANUALRev.27/1/2007
©2007RencoCorporation  Page2of13
Forclarityanduniformity,wehavegivenallmetricmeasurementinmillimeters(mm),even
thoughinsomecasesthecommonpracticemaybetousecentimeters(cm).Toconverttocm,
dividemillimetersby10.Forthesamereasonswehaveomittedinchconversionsinmanycases.
Toconvertmmtoinches,dividemmby25.4ormultiplyby.04.NotethatInallcasesandforall
readings,measurementscanbeindicatedineithermmorinches.

QUICKSTARTCONTROLSANDFUNCTIONS
ON/HOLDOFF:
Presstoturninstrumenton.Toturnonwithbacklight,holdkeyfor2seconds.When
readingisdisplayed,pressON/HOLDtomaintainit.PressingagainreleasestheHOLD.
Instrumentautomaticallyturnsoffifthereisnousefor3.5minutes.

SENSKeys
Selectssensitivity1(least)through4(greatest),whichisdisplayedonthescreen.Usethe
lowestsettingthatgivesaresult.Usingtoohighasettingcouldgivespuriousresults.

DEPTHKeys
TheDEPTHKeyscontrolthepositionofaverticaldashedmarkeroneachscreen.
Adjusttodepthofinterestusingrightandleftarrowkeys.Thismarkeriscalibrated
andthedistanceisdisplayedontherightsideofthescreen

IntheseInstructions,scalesatthebottomofthevariousillustrationscreensare
evenlydivided.Minordivisionsarenotshownonthegraphicsheretoavoidclutter.

PREGNANCYSCREENS:
Theverticalmarkerdisplaysthedistancetoaspikeofinterest.Tochangefrommmto
inches,gotothefatscreenandpresstheOPTIONkey.
COW:LeftMajorDivision:101mm(4in)RightMajorDivision:338mm(13.5in)
PIG:51‐288mm(2‐11.5in)
SHEEP:51‐288mm(2‐11.5in)
OTHER:51‐209mm(2‐8.3in).(Thisscreenisforsmall&mediummammals.
UseCOWforlargemammals.)

FATScreen: Range:3mmto42mm(.12‐1.65in)OPTIONkeyselectsunits,mmorin.
LOINScreens:UseOPTIONKeytoselectloworhighrange:50mm‐140mm(2‐
5.6in)or90‐180mm(3.6‐7.2in).
FortheFATandLOINscreens,spikesthatoccurtorightoftheverticalmarker
positionwillbesuppressed,whichhelpstofurtherrefinethedisplay.


SELECTKey:
FAT:Displayrangeis3‐42mm.UseOPTIONkeytoselectin.ormm.NOTE:In
ordertoswitchmeasurementsystemwiththeOPTIONkey,theFATscreen
한국대리점: 길우트레이딩 02)2636-0009 팩스02)2636-4753 서울시 영등포구 양평동 3가 40-2 에이스테크노타워703호 [email protected] www.gilwoo.co.kr

PREG‐ALERTPRO®INSTRUCTIONMANUALRev.27/1/2007
mustbedisplayed.Theselectedmeasurementsystemwillbeusedforall
measurements.
LOIN:UseOPTIONkeytoselectthelowrange,50‐140mmorthehighrange90to
180mm.

ForbothFATandLOINmeasurements,indicationstorightoftheverticalmarkerare
suppressed,thusmitigatingextraneousinformation.

PREGNANCY:UseOPTIONkeytoselect,COW,PIG,SHEEPorOTHER.Note:The
rulerscaledivisionmarkersontheseveralpregnancyscreensrepresentdifferent
intervalsandarejustforreference.Toseetheactualdistancefromtheskinto
particularspikeofinterest,usetheDEPTHkeystomovetheverticalmarkertoitand
readthedistanceshown(inmmorinches).Tohelpavoiderrors,OPTIONkeymustbe
held½secondwhenchangingfromonescreentoanother.

COW,PIGandSHEEPscreensdisplayaheavyhorizontalbarunderthegraph,which
indicatestheproximatedistancetothenearandfarsideoftheuterus.Strongspikes
withinthisareaindicatepregnancy.

ThePreg‐AlertProisamicroprocessor‐basedinstrument,usinglowpowerA‐Modeultrasound
forthedetectionofpregnancyinmammalsandthemeasurementoffatandmuscletissue
thickness.Itcanbelikenedtoanelectronicrulerthatindicatesadistancecomputedfromthe
timeittakestoreceivethereflections(echoes)thatweregeneratedbytheultrasonicpulses
emittedbythetransducer(alsocalledthe“probe”).Soundtravelsatdifferentspeedsthrough
fatandmuscle.Theinstrumentusestheappropriatespeedforeach,whichmayresultin
differenceswhencomparedtoscanners,mostofwhichusethesamespeedforbothtissues.
Thedisplayisananalogpresentationinadigitalenvironment,whichisenhancedtoeliminate
ormitigatethepresentationofspuriousreflectionsandnoise,oftenseenonolderCRT
displays.

Therearethreeindicationsforpregnancy,whicharedisplayedasspikesonthescreen:1)
Patternrecognitionofagroupofreflectionsfromthefetus(es),2)Onespike,areflectionfrom
theinterfacebetweenamnioticfluidandthefarsideoftheintrauterinewall.3)Areflection
fromthethickenedwalloftheuterus(incattle).

Connectthecabletotheinstrumentandtheproperprobetothecable.

Note:ThatStandardprobehavingabluebodyshouldbeusedforallanimalsexcept
forveryearlypregnancytestingoncows,mares,andotherlargemammals.The
optionalDeepprobe—largerandhavingablackbody—shouldbeusedforveryearly
pregnancytestingincows,maresandotherlargemammals.TheStandardprobecan
beusedwithmostlargemammalsafter90daysgestation.TheStandardprobecanbe
usedwithlargemammalsattheearlytimes,butgettinggoodindicationsis
problematicandinanycasemoredifficult.
©2007RencoCorporation  Page3of13

한국대리점: 길우트레이딩 02)2636-0009 팩스02)2636-4753 서울시 영등포구 양평동 3가 40-2 에이스테크노타워703호 [email protected] www.gilwoo.co.kr

PREG‐ALERTPRO®INSTRUCTIONMANUALRev.27/1/2007
Theprobemustmakegoodcontactwiththeskin—airbubbleswillblockultrasound.A
couplingfluidsuchascookingoil,mustbeusedtoenablegoodcontact.Applythecoupling
fluidliberallytotheskin,probeorboth.Presstheprobetotheskin,usingarotating‐rocking
motion,suchthatallairbubblesareremoved.Thenumberoneprobleminusingultrasound
instrumentsislackofgoodskincontact.Werepeat,Ultrasoundwillnotpassthroughair
bubbles!

USINGTHEPREG‐ALERTPRO
Inordertousetheinstrumentefficientlyandwiththebestresults,itmustbeunderstood
thatthisinstrumentisatoolandlikemosttools,skillisbestobtainedbyintelligentpractice.
Theinstrumenthelpsyoubyprovidingacomputerenhanceddisplaywherespurious
informationislargelyeliminated,buttheusermustbetheonetodecidethetruemeaning
ofthedisplayedinformation.

Backfatandloinmeasurementareeasiertolearnthanpregnancy.Asregardspregnancy
detection,boththeanimaltypeanddaysafterconceptionatwhichtestingisdoneare
determiningfactorrelatedtoeaseofuseandskillrequirement.Toillustrate,ontheone
hand,swineat30daysareperhapstheeasiest,whileontheotherhand,cattleatveryearly
timesaremoredifficult.

Fatmeasurement:SelecttheFATscreen.Mostbackfattestinginswineforexampleisdone
overthelastriband40‐60mmoffthecenterline(calledthe“P2”testsite).Thistestsiteis
alsoimportantformakingthestandardloinmeasurement.Sometimes,measurementsat
multiplesitesinthisregionareused.

Loinmusclemeasurementsincludeskinandbackfat,sotomeasurejustthelointhickness,
firstdeterminebackfatthickness,usingthebackfatscreenandthenmeasuretheloinand
subtractthebackfatreading.OfthetwoLOINscreens,selecttheonewiththerange
appropriateforthetotalthicknessinvolved.Internaladjustmentsaremadetothespeedof
soundfactortominimizetheeffectofthedifferencebetweenfatandmuscletissue.

Pregnancyindications:
EachPregnancyscreenexcepttheOTHERscreen,hasablackbaratthebottom.Thebar
indicatestheproximatedistancetothenearandfarpointsoftheuterusatthenumberof
daysindicated.Itisimportanttounderstandthatalthoughthepregnancyscreensnamed
Pig,SheepandCowhavebeentailoredforthespecificanimal,thescreencanbeusedfor
anyanimalwiththeproximatebodydimensionsofthenamedanimal.Afourthpregnancy
screen,calledOTHER,canbeusedforallsmallandmediummammals,butnotforlarge
mammals.Inadditionwhentestinglargemammalsatveryearlytimes,e.g.cows,mares,
bison,etc.,theoptionalDeepprobeshouldbeused.

©2007RencoCorporation  Page4of13

한국대리점: 길우트레이딩 02)2636-0009 팩스02)2636-4753 서울시 영등포구 양평동 3가 40-2 에이스테크노타워703호 [email protected] www.gilwoo.co.kr

PREG‐ALERTPRO®INSTRUCTIONMANUALRev.27/1/2007

Table1:Approximatedistancestonearandfarpointsoftheuterusforvarious
animalsatthegestationtimesshown.

Distances DaysGestation
Pigs&Goats 2‐8in(50‐200mm) 28‐30
Cattle  4‐13.5in(100‐338mm)25‐30
Alpacas 1.6‐6in(40‐150mm) 12‐25
Sheep  1.6‐6in(40‐150mm) 28‐30
Horses  4.7‐13.5in(120‐338mm)14‐18
Llamas  2‐6in(50‐150mm) 12‐30
MiniatureHorses2‐8in(60‐200mm) 14‐18
MiniatureCattle4.7‐8in(120‐200mm) 25‐30

Theabovetableisonlyaguidethepurposeofwhichistogivetheusersomefeelforthe
distancesinvolved.Inuse,theimportantthingtolookforisastronghighspikeorgroupof
spikesintheareaofinterestasdisplayedonthescreen.

Pregnancycanbedeterminedeitherbysensingthefetusortheinterfacebetweenthe
amnioticfluidandthefarsideoftheintrauterinewall.Whendetectingthefetus(es),one
looksfor1ormorespikesnearthecenteroftherange.Whenlookingfortheamnioticfluid
interfaceatthefarsideoftheuterus,onelooksforonespikeatthefarendofrange.In
someanimals(cowsandmares)theuterinewallthickensveryearlyinpregnancyandthe
instrumentwilldisplayaspikefromthenearuterinewall(leftendofthebar)inthosecases.




©2007RencoCorporation  Page5of13

한국대리점: 길우트레이딩 02)2636-0009 팩스02)2636-4753 서울시 영등포구 양평동 3가 40-2 에이스테크노타워703호 [email protected] www.gilwoo.co.kr

PREG‐ALERTPRO®INSTRUCTIONMANUALRev.27/1/2007
DISPLAYS
(Note:Thefinerulerdivisionsarenotshowninthedisplaysbelow.TheSENSsettingisfor
illustrationonly.)



























Aboveareseveralscreenshotsillustratingthetypicaldisplaysforvariousfunctions.Inthe
Pregnancy:OTHERscreen,thedottedverticallineistheverticalmarker,whichtheusercan
settoindicatethedistanceofanyspikefromtheskinsurface.Theheavysolidverticalline
isrepresentativeoftheactualreading.Thismightinfactbemultiplecloselyspacedspikes.
IntheCOWpregnancyscreen,theverticalmarkerisshown(forillustrationpurposes)near
thespikereadingattheleftendoftheheavysolidbarbeneaththegraticule.Ifthetestis
attemptingtoidentifyveryearlypregnancy,thensincethereadingisattheleftendofthe
blackbar,itwouldprobablybeindicatingathickeneduterinewall.(TheDeepprobewould
beusedforthis.)Inactualuse,iftheuserwantedtoknowtheactualdistancebeing
measured,thespikewouldbeheldusingaHOLDkey(thelegend“HOLD”isdisplayed)and
DEPTHkeyswouldthenbeusedtosuperimposetheverticalmarkeroverthereadingand
thedistancefromskintospikewouldbedisplayed.

TheLOIN(highrange)screenshownaboveindicatesareadingat150mm.Thevertical
markerpreventsanythingbeyondabout165mmfrombeingdisplayed.Useofthemarkeris
optional.PressingandholdingtheOPTIONkeymomentarilywhileintheLOIN(highrange)
©2007RencoCorporation  Page6of13
SENS-2
PREG
HOLD
BAT
OTHER
100 M
M
PREGNANCY:SCREENFOROTHER
SMALL‐MEDIUMMAMMALS
한국대리점: 길우트레이딩 02)2636-0009 팩스02)2636-4753 서울시 영등포구 양평동 3가 40-2 에이스테크노타워703호 [email protected] www.gilwoo.co.kr

PREG‐ALERTPRO®INSTRUCTIONMANUALRev.27/1/2007
display,willswitchtoasecondLOIN(lowrange)screen,whichprovidingarangeof50‐
140mm.(PressingtheOPTIONkeyagainswitchestothe90‐180mmdisplay.)
(MeasurementswouldappearininchesiftheOPTIONkeyhadbeenusedtoselectinches,
whentheFATscreenwasdisplayed.)



TESTINGANDTESTSITES
Asaninstrumentmanufacturer,weareprimarilyinstrumentpeopleandnotanimalpeople.
Whilewehavedonesomedevelopment,muchofthesiteinformationprovidedbelowis
takenfromtheliterature.

ThePreg‐AlertProcanbeusedwithsomanymammalsthatitisimpracticaltoprovide
detailedtestinginformationforallofthem.Therefore,wewillshowjustafewsothatthe
operatorwillhaveanidea,pictorially,ofthegeneralprocedure.Pregnancytestingshould
bestartedontherightsidewithmostmammals,butwithalpacas,andmares,testing
shouldbestartedontheleftside.Ifnopregnancyisdetected,thentrytheothersideinall
cases,butbecautiousoftheresultsinruminateanimals,wheretherumenmightinterfere.

FatandLointestingshouldbedoneatwhatisconventionallycalledthe“P2””site,overthe
10thriband6.5cm(2‐3in.)offthebackbone.(Someliteraturecallsoutthe12thrib,butat
leastoneresearcherclaimsthatthe10thribproducesamoreaccurateresultbecausethe
fatissmoother.Weleavethisdecisionuptotheoperator.)Manymakemeasurementson
boththerightandtheleftsideofthebackbone.Inthispreliminarywriting,wehaveshown
onepictureofthetestsite.Thiswillbeamplifiedinfuturemanuals.Notehowever,that
“attheendoftheday”,thereisno“gold”standardindeterminingtheaccuracyoffatand
loinmeasurement.Inthemeanwhile,morecompleteinformationwillbefoundinthePreg‐
Alert®Operator’sManual©onourwebsiteatwww.rencocorp.com

©2007RencoCorporation  Page7of13

한국대리점: 길우트레이딩 02)2636-0009 팩스02)2636-4753 서울시 영등포구 양평동 3가 40-2 에이스테크노타워703호 [email protected] www.gilwoo.co.kr

PREG‐ALERTPRO®INSTRUCTIONMANUALRev.27/1/2007


FatandLoinMeasurementsitesforSwine



PregnancyTestSiteforSwine
BeginTestingswineonrightsideandifnotpregnant,tryagainontheleftside.Testingcan
beginat18days,testingeverydayuntilpositivereadingsareobtained2daysinarow.
Accuracyisgreatestat30days.
©2007RencoCorporation  Page8of13
3FATLAYERS
LOIN
한국대리점: 길우트레이딩 02)2636-0009 팩스02)2636-4753 서울시 영등포구 양평동 3가 40-2 에이스테크노타워703호 [email protected] www.gilwoo.co.kr

PREG‐ALERTPRO®INSTRUCTIONMANUALRev.27/1/2007

PregnancyTestSiteforSheep
Topfigureillustratestestsiteforveryearlycheckingat25days.Bottomfigureillustrates
useat35+days.Testonleftsideifnotsuccessful.Itmaybenecessarytoremovewooland
dirtfromtestsite.


 

PregnancyTestSiteforAlpacas
BegintestingalpacasontheLEFTsideatabout45days.Testontherightsideifnot
successful.After60days,testonrightsidefirst.
©2007RencoCorporation  Page9of13
한국대리점: 길우트레이딩 02)2636-0009 팩스02)2636-4753 서울시 영등포구 양평동 3가 40-2 에이스테크노타워703호 [email protected] www.gilwoo.co.kr

PREG‐ALERTPRO®INSTRUCTIONMANUALRev.27/1/2007


PregnancyTestSiteforCows:SideandTopViews
Refertothethreeviewsofthecow:Forearlypregnancystartingatabout22days,youwill
lookforthethickeneduterinewall,ratherthanamnioticfluidorthefetus.AimtheDeep
probeasshownontherightsideintheupperregionoftheoutlineintheparalumbarfossa
atriangularregionforwardofthehookbone,justbehindtheribs,andabout8inches
(20cm)downfromthebackbone.Locatethelowestspotinthefossaintowhichtheprobe
willfitcomfortablybypressinginwardwithyourfist.Placetheprobefirmlyagainsttheskin
andpointithalfwaybetweenthehookboneandpinbonepointingitslightlydownward.
Youdon’tneedtomovetheprobeinordertoscantheuterus,justrockandtilt.



PregnancyTestSiteforCows:Backview
©2007RencoCorporation  Page10of13
한국대리점: 길우트레이딩 02)2636-0009 팩스02)2636-4753 서울시 영등포구 양평동 3가 40-2 에이스테크노타워703호 [email protected] www.gilwoo.co.kr

PREG‐ALERTPRO®INSTRUCTIONMANUALRev.27/1/2007


PregnancyTestSiteMares:SideView


PregnancyTestSiteforMares:Left:SideViewRight:BackView
©2007RencoCorporation  Page11of13
한국대리점: 길우트레이딩 02)2636-0009 팩스02)2636-4753 서울시 영등포구 양평동 3가 40-2 에이스테크노타워703호 [email protected] www.gilwoo.co.kr

PREG‐ALERTPRO®INSTRUCTIONMANUALRev.27/1/2007
Referringtothethreepictorialsformares,placetheDeepprobeontheLEFTflankarea
directlybelowthehipandinlinewiththebottomofthevulva.Aimslightlybackandacross
thebodyandscanasshown.SideViewPosition#1isforveryearlydetectionataround14‐
30days.Thisa“slidingscale”andasgestationprogressesyoushouldmovetheprobe
downwardswithintheareashownbytheoutlineinthesideview.SideViewPosition#2is
foruseafterapproximately90‐100daysandtheStandardprobemaybeused.



PregnancyTestSite:Goats
Begintestingataround30‐40days,ontheRIGHTside,2inches(5cm)infrontoftherearleg
and1inch(2.5cm)aboveteat.Ifnotsuccessfultestagainontheleftside.Itmaybe
necessarytoremovehairfromthetestsite.


©2007RencoCorporation  Page12of13
한국대리점: 길우트레이딩 02)2636-0009 팩스02)2636-4753 서울시 영등포구 양평동 3가 40-2 에이스테크노타워703호 [email protected] www.gilwoo.co.kr

PREG‐ALERTPRO®INSTRUCTIONMANUALRev.27/1/2007
©2007RencoCorporation  Page13of13
AWORDABOUTBATTERIES
ThisinstrumentisdesignedtousedisposableAAsizecarbon‐zincbatteries,ofwhichthere
areseveraltypes.Formaximumtime,ifyouaregoingtousethebacklightfeature
frequently,usethe“Alkaline”varietyandifnot,useanon‐alkalinevariety.Youmayalso
userechargeableNickelMetalHydridebatteries(NMH),butyoumustprovideyourown
chargerandtheywillnotgiveaslongatimebetweenchargesasyougetfromthecarbon‐
zinctypes.Justforreference,usagetimewithBacklightonandalkalinebatteriesisabout
50hours.Withbacklightoff,about150hours.

WARNING!DONOTMIXCARBON‐ZINCANDNMHBATTERIES!!
WhenusingNMHbatteries,thebatteriesarefullychargedwhenthebatterycharge
indicator,whichappearsoneachdisplayscreen,indicates1/4th–3/8thscharged.



SERVICE:
Therearenoserviceablepartsinsideoftheinstrument.DONOTATTEMPTTO
DISASSEMBLE.Forservice,contactthefactory:

RENCOCORPORATION
116ThirdAveNorth
Minneapolis,MN.55401,USA
Tel:612‐338‐6124
Fax:612‐333‐9026
Email:[email protected]
Internet:http://www.rencocorp.com

CAUTION!DONOTUSETHEPREG‐ALERTPROONHUMANBEINGS
CERTIFICATIONANDCOMPLIANCE
FCC Required §15.21 Information to User: Caution! Changes or modifications not expressly
approved by RENCO CORPORATION could void the user's authority to operate the equipment.
FCC §15.105 Information to User: NOTE: This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and if not installed and used in accordance with the instruction manual may
cause harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case, the user will be required to correct the
interference at his own expense. This equipment also complies with Canadian requirements.
This equipment has been certified to be in compliance with CISPR 11, the EMC Directive
89/336/EEC, AS3548, and applicable Harmonized Standards.

한국대리점: 길우트레이딩 02)2636-0009 팩스02)2636-4753 서울시 영등포구 양평동 3가 40-2 에이스테크노타워703호 [email protected] www.gilwoo.co.kr
