AN1486 Rev 0.00 Page 10 of 12
August 11, 2009
ISL6263AEVAL1Z, ISL6263BEVAL1Z
Bill of Materials
ISL6263AEVAL1Z and ISL6263BEVAL1Z evaluation boards use the same PCB and schematic, thus the same bill of materials except for the
controller.
NO. REFERENCE QTY DESCRIPTION MFG NAME MFG PART NUMBER
1 C82, C83 2 CAP, RADIAL, 68µF, 100V, 20%, ALUM.ELECTROLYTIC PANASONIC EEU-FC2A680L
2 C11, C13, C14, C18 4 CAP, SMD, 0603, 1000pF, 16V, 10%, X7R GENERICNA
3 C28 1 CAP, SMD, 0603, 0.01µF, 16V, 10%, X7R GENERIC NA
4 C15, C21, C35 3 CAP, SMD, 0603, 0.1µF, 25V, 10%, X7R GENERIC NA
5 C27, C29 2 CAP, SMD, 0603, 1µF, 6.3V, 10%, X5R GENERIC NA
6 C5 1 CAP, SMD, 0603, 180pF, 10V, 10%, X7R GENERIC NA
7 C1 1 CAP, SMD, 0603, 0.22µF, 25V, 20%, X7R GENERIC NA
8 C7 1 CAP, SMD, 0603, 330pF, 10V, 5%, NPO GENERIC NA
9 C9 1 CAP, SMD, 0603, 560pF, 10V, 10%, X7R GENERIC NA
10 C12 1 CAP, SMD, 0603, 22pF, 10V, 5%, NPO GENERIC NA
11 C26 1 CAP, SMD, 0603, 68pF, 50V, 5%, NPO GENERIC NA
12 C17 1 CAP, SMD, 0603, 0.068µF, 16V, 10%, X7R GENERIC NA
13 C19 1 CAP, SMD, 0603, 0.082µF, 16V, 10%, X7R GENERIC NA
14 C8 1 CAP, SMD, 0603, 0.018µF, 10V, 10%, X7R GENERIC NA
15 C32, C80 2 CAP, SMD, 0805, 1.0µF, 25V, 10%, X7R GENERIC NA
16 C31, C36, C46, C52, C54,
C60, C65, C66, C70
9 CAP, SMD, 0805, 10µF, 6.3V, 10%, X5R GENERIC NA
17 C81 1 CAP, SMD, 1206, 10µF, 16V, 20%, X5R GENERIC NA
18 C4, C5B 2 CAP, SMD, 1812, 10µF, 25V, 10%, X5R GENERIC NA
19 C2, C89 2 CAP, SMD, 330µF, 2V, 20%, SP-CAP PANASONIC EEF-SX0D331XR
20 L1 1 INDUCTOR, SMD, 11.5X10, 0.88µH, 20%, 17.4A NEC/TOKIN MPC1040LR88
21 U5 1 IC-HI FREQ BRIDGE DRIVER, SO8, 100V INTERSIL HIP2100IB
22 U1 1 PWM CONTROLLER, 32P, QFN, 5x5 INTERSIL ISL6263AHRZ
or
ISL6263BHRZ
23 R24 1 NTC, SMD, 0603, 10k, 1/10W, 5%, B VALUE = 4201k to
4300k
PANASONIC ERT-J1VR103J
24 Q5, Q14 2 MOSFET, N-CH, SOT23, 60V, 115mA MOTOROLA 2N7002LT1
25 Q15 1 MOSFET, N-CH, TO-252AA, 30V, 16mFAIRCHILD HUF76129D3S
26 Q1 1 MOSFET, N-CH, SO8, 30V, 9.1mIR IRF7821
27 Q2, Q4 2 MOSFET, N-CH, SO8, 30V, 4.0mIR IRF7832
28 R39 1 RES, SMD, 0603, 1, 1/10W, 1% GENERIC NA
29 R5, R46 2 RES, SMD, 0603, 10, 1/10W, 1% GENERIC NA
30 R11, R12 2 RES, SMD, 0603, 20, 1/16W, 1% GENERIC NA
31 R10, R20, R30, R48, R50,
R53
6 RES, SMD, 0603, 0, 1/16W GENERIC NA
32 R47 1 RES, SMD, 0603, 100, 1/10W, 1% GENERIC NA
33 R15, R35 2 RES, SMD, 0603, 1k, 1/10W, 1% GENERIC NA
34 R8, R13, R14, R25, R32,
R36, R37, R38, R40, R43
10 RES, SMD, 0603, 10k, 1/10W, 1%, GENERIC NA
