Rennline ExactFit User manual

warranty voids or damage resulting from the use of these products. Due to the varying location of wiring harnesses and
(1) Thread-Locking Alloy Button Head Socket Cap Screw - 10/32 x .5” - MC92360A248
ExactFit - Magnetic Phone Mount
FX 802-893-7311
PH 802.893.7366
EM [email protected]
Order Online: WWW.RENNLINE.COM
READ BEFORE INSTALLATION
The use of any Rennline product is the sole responsibility of the end user. Rennline Inc. accepts no responsibility for
other components, carefully inspect any area prior to drilling. All Rennline products are intended for off road use only and
should be installed by a qualified automotive technician.
VW MK5 GOLF/GTI
1. Install the aluminum ball onto the metal bracket as shown using the supplied screw.
2. Pry the trim panel up from the top of the dash with a plastic trim removal tool. ( Photo 1)
3. Locate the Torx T20 screw at the very front of the panel and remove it. (Photo 2)
4. Carefully pull the front of the panel towards you while lifting up. (Photo 3)
5. Locate the two Torx T20 screws holding the vent trim and remove them. (Photo 4)
6. There are 3 clips on the forward part of the vent panel. Use your trim tool and release these clips. (Photo 5)
7. Pull the trim panel up to remove the vent panel. (photo 6)
8. Remove the two Torx T20 screws from the top of the radio trim. (Photo 7)
9. Starting at the top of one side, gently pull the trim panel forward. Slide your trim removal tool between the panel
and dash and gently pry the panel away from the dash. (Photo 8)
10. Remove the two Torx T20 screws from the side of the radio and slide your trim tool between the radio and the dash foam.
Insert the Exact-Fit phone mount between the trim tool and the dash foam. Tighten the two Torx T20 screws. (Photo 9)
11. Reinstall all the plastic trim and screws in reverse order of dissasembly.
10. Attach the phone to your mount.
11. Enjoy your new Rennline product.
P/N PM01.15 8/6/2018
PG 1
Photo 1
Part List:
(1) Mounting Bracket - P/N - PM15
(1) P/N - PM01
- Aluminum Ball
- Magnetic Pad Assembly
- Steel pads
Photo 2
Photo 3 Photo 4
All manuals and user guides at all-guides.com

PG 2
P/N PM01.15 8/6/2018
Photo 5
Photo 7
Photo 9
Photo 6
Photo 8
Photo 10
