Renu Electronics FlexiPanels Basicc FP2 Series User manual

User Manual
FlexiPanels Basic®HMI
FP2 series HMI with I/Os

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 2of 24
Contents
INTRODUCTION ...................................................................................................................................................4
BEFORE YOU START..............................................................................................................................................4
SAFETY PRECAUTIONS..........................................................................................................................................5
PRODUCT OVERVIEW...........................................................................................................................................6
INSTALLING FP2 WITH I/OS PRODUCTS .........................................................................................................................6
PANEL GUIDELINES...................................................................................................................................................6
PANEL CUTOUT DIMENSIONS ......................................................................................................................................6
PRODUCT DIMENSIONS .............................................................................................................................................7
MINIMUM CLEARANCES ............................................................................................................................................8
MOUNTING FP2 WITH I/OS PRODUCTS.........................................................................................................................8
CONNECTING POWER................................................................................................................................................8
POWER RATING.......................................................................................................................................................8
GROUNDING ...........................................................................................................................................................9
PRODUCT SPECIFICATIONS...................................................................................................................................9
PRODUCT NOMENCLATURE /ORDERING PART NUMBER ...................................................................................................9
DISPLAY SPECIFICATIONS ................................................................................................................................... 10
CPU, MEMORY AND POWER SUPPLY.......................................................................................................................... 10
COMMUNICATION INTERFACES.................................................................................................................................. 11
RS232 /RS485 PORT ............................................................................................................................................ 11
YTYPE CABLE........................................................................................................................................................ 12
ETHERNET PORT .................................................................................................................................................... 14
USB DEVICE PORT ................................................................................................................................................. 15
USB HOST PORT.................................................................................................................................................... 15
SUPPORTED PLUGGABLE EXPANSION MODULES............................................................................................................. 16
SUPPORTED PROTOCOLS.......................................................................................................................................... 20
ACCESSORIES ..................................................................................................................................................... 21

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 3of 24
PROGRAMMING CABLE (DOWNLOAD)......................................................................................................................... 21
COMMUNICATION CABLE ......................................................................................................................................... 21
DEFAULT PRODUCT SETTING ..................................................................................................................................... 22
ENVIRONMENTAL SPECIFICATIONS AND APPROVALS ....................................................................................................... 22
REVISION HISTORY............................................................................................................................................. 23
NOTES ............................................................................................................................................................... 24

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 4of 24
Introduction
FP2 series HMI with I/Os is suitable for simple applications. Available screen sizes are 4.3” WQVGA
and 7" WVGA Color TFT. These HMIs are powered by FlexiSoft® programming software. These
products also support the IEC61131-3 logic programming environment which gives a unique edge
to these products.
All the products are compliant to EMC directive 2014/30/EU and LVD directive 2014/35/EU and
suitable for installation in hazardous locations because they are listed for UL Class I Div. 2.
This user manual gives detailed information regarding the hardware specifications, operating
conditions, installation, mounting, and wiring. All the information published in this manual is
produced and governed by RENU Electronics Pvt. Ltd. and is protected by Indian Copyright Act.
Before you start
FlexiPanels®FP2 series HMI with I/Os products are general-purpose human machine
interface devices, suitable for a variety of simple applications across various industries.
However, RENU Electronics is not responsible or liable for any indirect or consequential
damage resulting from the use of this product.
The user should check and confirm the suitability of the product before using it in any
specific application.
The diagrams and examples in this manual are included for illustration purposes only.
RENU Electronics assumes no responsibility or liability regarding actual use based on
these diagrams or examples.
Reproduction of the contents of this manual, in any form (in part or whole), is strictly
prohibited.
Following table shows various symbols that may be used in this manual to provide
information regarding safety, precautions, and usage of the product:
WARNING: Indicates circumstances that may cause an explosion in a hazardous environment,
which may lead to injury or death, damage or economic loss
CAUTION: Indicates specific precautions to be taken by the user during installation, operation
and maintenance of the product
ATTENTION
ATTENTION: Indicates important information regarding the application and functions of the
product

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 5of 24
Safety Precautions
This section of the manual provides information that is critical regarding safety and therefore the
user is advised to go through the information in detail before installing the product. Users may
contact RENU Electronics technical support team at [email protected] for any
specific question(s) related to safety.
WARNING: EXPLOSION HAZARD
Do not disconnect equipment unless power has been removed or the area is known
to be nonhazardous.
The substitution of any component may impair suitability for Class I, Division 2.
Secure any external connections that mate to this equipment by using screws, sliding
latches, threaded connectors, or any other means provided with this product.
If this product contains batteries, it must only be changed in an area known to be
nonhazardous.
CAUTION: GENERAL PRECAUTIONS
Do not use this product for an emergency stop. A separate physical switch, outside
the product, must be used for any emergency stop operations.
Do not use the external power supply source that does not comply with the specified
power requirements of the product, it may cause malfunction or permanent damage
to the product.
Do not attempt to open, dismantle, or modify the product, doing so will void the
warranty.
This product is supplied as open-type equipment and it must be mounted within an
enclosure, suitably designed for specific environmental conditions.
When used in Class I, Division 2 hazardous location, the product must be mounted
in a suitable enclosure with a proper wiring method that complies with the governing
electrical codes.
The USB port is intended for temporary local programming purposes only and not
intended for permanent connection. If you connect or disconnect the USB cable with
power applied to this product or any other device on the USB network, an electrical
arc can occur, which could cause an explosion in hazardous location installations.
Make sure that connectors are securely tightened to properly seal the connections
against leaks.
Do not place the product in direct sunlight. Prolonged exposure to sunlight may
degrade the LCD and housing.

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 6of 24
Product Overview
This section of the manual provides an overview of series with I/Os products, its front and back
view, installation details, dimensional details, mounting method, and details.
Installing FP2 with I/Os products
FP2 series HMI with I/Os series products are designed for front panel mounting. Before installing
the products, the user should review the panel guidelines, panel cutout dimensions, product
dimensions, and minimum clearances.
Panel Guidelines
The panel must be at least 2mm (12gauges) so that it can provide the required support and
proper sealing against water and dust. The panel surface must be flat, without any imperfection,
to maintain the adequate seal and IP rating.
The maximum panel thickness allowed is 6mm (±0.2mm).
Panel Cutout Dimensions
The panel must be at least 2mm (12gauges) so that it can provide the required support and
proper sealing against.
Model
Height (mm)
Width (mm)
FP2043T-E
80
111
FP2043TN-E
80
111
FP2070T-E
127
175
FP2070TN-E
127
175
ATTENTION
ATTENTION: Panel cutout
Before making a panel cutout, disconnect all electrical power from the panel.
Make sure that area surrounding the panel cutout is clear.
Make sure that metal cutting does not enter any component already installed in the
panel.

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 7of 24
Product Dimensions
This section of the manual provides dimensional details of FP2 series HMI with I/Os products. All the
dimensions shown below are measured in mm.
FP2043-E
FP2070-E

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 8of 24
Minimum Clearances
Maintain clearance from enclosure walls, wires, and other adjacent devices. Keep 2” space on all sides
for adequate ventilation. Plan for adequate space around the product and inside the enclosure for
ventilation and cabling. Take into consideration the heat produced by other devices in the enclosure. The
ambient temperature around this product must be 0° to 50°C.
Mounting FP2 with I/Os Products
FP2 series HMI with I/Os products must be installed on the front panel, using the clamp accessories
shipped with the product. Before mounting, make sure that the sealing gasket is properly positioned. This
gasket forms a compression type seal. Do not use sealing compounds. Then, place the unit in the panel
cutout and tighten the mounting screws evenly (torque 0.4Nm) to maintain water and dust resistance.
ATTENTION
ATTENTION: Mounting FP2 series HMI with I/Os on Panel
Do not push the LCD display when pushing the unit into the panel as it may damage
the display.
Connecting Power
FP2 series HMI with I/Os requires a 24VDC isolated power supply. Follow the steps mentioned below to
connect the power:
Make sure that terminal is not connected to a power source
Secure the 24VDC power wires
Secure the functional earth ground wire to the functional earth ground terminal screw on the
terminal block
Apply 24VDC power to the terminal
Power Rating
Unit
Voltage
Current
Wattage
FP2043T-E
24VDC
130mA
3.12W
FP2043TN-E
24VDC
150mA
3.6W
FP2070T-E
24VDC
200mA
4.8W
FP2070TN-E
24VDC
230mA
5.52W

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 9of 24
Grounding
The optimum method for grounding electronic equipment is to ground it separately from other high-power
systems and to ground more than one unit of electronic equipment with a single-point ground. Following
marked terminal is provided with the unit for grounding:
Product Specifications
This section of the manual provides detailed specifications of FP2 series HMI with I/Os products, ordering
part numbers, operating conditions, environment, and approvals.
Product Nomenclature / Ordering Part Number
FP2 series HMI with I/Os has 2 models, depending on display size and each model has two variants,
based on Ethernet. Detail part number or ordering information is as follows:
Model
Description
FP2043T-E
2 Serial ports#(1 RS232, 1 RS485), 1 USB Device, 1 USB Host, 1 Pluggable I/O Module
FP2043TN-E
2 Serial ports#(1 RS232, 1 RS485), 1 USB Device, 1 USB Host, 1 Ethernet, 1 Pluggable
I/O Module
FP2070T-E
2 Serial ports (RS232 / RS485), 1 USB Device, 1 USB Host, 3 Pluggable I/O Modules
FP2070TN-E
2 Serial ports (RS232 / RS485), 1 USB Device, 1 USB Host, 1 Ethernet, 3 Pluggable I/O
Modules
[ #Note: FP2043-E support one DB9 port that supports RS232 and RS485 levels on different pins. “Y” type cable
can be used for separate RS232 and RS485 levels simultaneously.]
T: Touch Screen
FP2 XXX Tx- E
Series
Display Size
043: 4.3” WQVGA (480 x 272)
070: 7” WVGA (800 x 480)
Series
T: Touchscreen
N: Supports Ethernet
E: Supports Expansion

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 10 of 24
Display Specifications
FP2 with I/Os series products support high-quality color TFT display range.
Size: 4.3” WQVGA Color TFT with 4-wire analog resistive touch screen
Resolution: 480 x 272pixels
Brightness: 400cd/m2
Backlight life: 30,000Hrs.
Size: 7” WVGA Color TFT with 4-wire analog resistive touch screen
Resolution: 800 x 480pixels
Brightness: 350cd/m2
Backlight life: 30,000Hrs.
CPU, Memory and Power Supply
CPU: 32-bit RISC Processor
RAM: 16MB
User Application
8MB
Flash
16MB
Ladder Memory
2MB
Alarm Memory
1350 Alarms
Retentive Memory
8000Words
Keep Memory
1000Words
Data Log
4MB
Power supply:
24VDC(+20%, -15%)
RTC:
Built-in, Date & Time function

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 11 of 24
Communication Interfaces
This section of the manual gives detailed information regarding various communication interfaces supported
by FP2 series HMI with I/Os, including communication interfaces between FP2 series HMI with I/Os and other
RENU or any third-party device, interfaces for programming and monitoring.
RS232 / RS485 Port
FP2043 series HMI with I/Os supports a DB9 female port that supports RS232(COM1) and RS485(COM2)
signal levels on different pins.
Pin number
Signal
1
TX+(RS485)
2
TXD(RS232)
3
RXD(RS232)
4
RX+(RS485)
5
GN
6
NC
7
NC
8
TX-(RS485)
9
RX-(RS485)
[Note: Special “Y” cable can be provided, if both the ports are to be used simultaneously.]
[REPL Part# EC-Y-FP]

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 12 of 24
Y Type Cable
Special “Y” cable for the FP unit (two communication levels on one port).
ATTENTION
ATTENTION: DB9 port
The 4.3” models have only one DB9 port that supports RS232 and RS485 signal
levels on different pins.
If the user wants to connect different devices, on RS232 and RS485 levels,
simultaneously with 4.3” HMI, then he must use ‘Y’ type cable.

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 13 of 24
FP2070 series HMI with I/Os has one terminal block port (COM1) and one DB9 female port (COM2). Both
com ports support RS232 / RS485 signal levels.
Pin number
Signal
1
RX-
2
TX-
3
RX+
4
TX+
5
GND
6
RXD
7
TXD
Pin number
Signal
1
TX+(RS485)
2
TXD(RS232)
3
RXD(RS232)
4
RX+(RS485)
5
GN
6
NC
7
NC
8
TX-(RS485)
9
RX-(RS485)

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 14 of 24
Ethernet Port
FP2 with I/Os series support Ethernet port as an ordering option. It’s having standard shielded RJ45 female
jack with built-in speed and indication LED’s.
Pin number
Signal
1
TX+
2
TX-
3
RX+
4
NC
5
NC
6
RX-
7
NC
8
NC

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 15 of 24
USB Device Port
FP2 with I/Os products support a Micro USB compliant with USB 2.0 specificationport for programming and
monitoring.
Pin number
Signal
1
VCC
2
D-
3
D+
4
NC
5
GND
USB Host Port
FP2 with I/Os products support a USB Host compliant with USB 2.0 specification port. USB Host can
handle only USB memory stick devices and can source current up to 150mA only.
The connector used: Standard USB Type a Female connector.
Pin number
Signal
1
VCC
2
D-
3
D+
4
GND
Currently USB Host can be used for Upload and Download of Application/ Firmware only. Upload and
Download of Data Logging or Recipe over USB is not supported.
1
5

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 16 of 24
Supported Pluggable Expansion Modules
Model
FPEM-1616P
FPEM-1614RP
FPEM-1212P-A0200L
FPEM-1212RP-A0200L
FPEM-1210P-A0201L
FPEM-1210RP-A0201L
FPEM-0808P-A0401U
FPEM-0808RP-A0401U
FPEM-0404P-A0402U
FPEM-0806P-A0402U

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 17 of 24
Pluggable Expansion Modules Comparison
FPEM-1616P
FPEM-1614RP
FPEM-1212P-A0200L
FPEM-1212RP-A0200L
Power Supply
Powered from FP2 base Modules
DC Inputs
16 (Sinking)
16 (Sinking)
12 (Sinking)
12 (Sinking)
High Speed
Inputs
2, 32 Bit, 200kHz
2, 32 Bit, 200kHz
2, 32 Bit, 200kHz
2, 32 Bit, 200kHz
DC Outputs
16 PNP
12 Relay, 2 PNP
12 PNP
10 Relay, 2 PNP
High Speed
Pulse Outputs
2, Normal PWM Mode:
1kHz,
Fixed Pulse Mode: 5kHz
2, Normal PWM Mode:
1kHz,
Fixed Pulse Mode: 5kHz
2, Normal PWM Mode:
1kHz,
Fixed Pulse Mode: 5kHz
2, Normal PWM Mode:
1KHz,
Fixed Pulse Mode: 5kHz
Analog
Inputs
NA
NA
Linear Type 2 Inputs,
Voltage Inputs [16 Bit]:
0 to 10VDC, 0 to 5VDC
Linear Type 2 Inputs,
Voltage Inputs [16 Bit]:
0 to 10VDC, 0 to 5VDC
Current Inputs [16 Bit]:
0 to 20mA & 4 to 20mA
Current Inputs [16 Bit]:
0 to 20mA & 4 to 20mA
Analog
Outputs
NA
NA
NA
NA
Isolation
Digital: Isolated from 24VDC power
Analog: Non-Isolated from 24VDC power and Communication, USB ground
Operating
Temperature
0°C to 50°C (While using FPEM Modules with FP2 Base models)
Storage
Temperature
-20°C to 85°C
Humidity
10 to 95% non-condensing
Approvals
CE, UL Class I Div 2
Dimensions
(mm)
48W x 108H x 41D

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 18 of 24
FPEM-1210P-A0201L
FPEM-1210RP-A0201L
FPEM-0808P-A0401U
FPEM-0808RP-A0401U
Power Supply
Powered from FP2 base Modules
DC Inputs
12 (Sinking)
12 (Sinking)
8 (Sinking)
8 (Sinking)
High Speed
Inputs
2, 32 Bit, 200kHz
2, 32 Bit, 200kHz
2, 32 Bit, 200kHz
2, 32 Bit, 200kHz
DC Outputs
10 PNP
8 Relay, 2 PNP
8 PNP
6 Relay, 2 PNP
High Speed
Pulse Outputs
2, Normal PWM Mode:
1kHz,
Fixed Pulse Mode: 5
kHz
2, Normal PWM Mode:
1KHz,
Fixed Pulse Mode: 5kHz
2, Up-to 200kHz each
2, Up-to 200kHz each
Analog
Inputs
Linear Type 2 Inputs,
Voltage Inputs [16 bit]:
0 to 10VDC, 0 to 5VDC
Linear Type 2 Inputs,
Voltage Inputs [16 bit]:
0 to 10VDC, 0 to 5VDC
Universal Type 4 Inputs,
Voltage Inputs [16 Bit]:
0 to 10VDC, 0 to 5VDC, 0
to 50mV, 0 to 100mV,
RTD-PT100,
Thermocouple J & K
type
Universal Type 4 Inputs,
Voltage Inputs [16 Bit]:
0 to 10VDC, 0 to 5VDC,
0 to 50mV, 0 to 100mV,
RTD PT100, PT1000,
Thermocouple J & K type
2 Current Inputs [16
Bit]:
0 to 20mA, 4 to 20mA
2 Current Inputs [16 Bit]:
0 to 20mA, 4 to 20mA
4 Current Inputs [16 Bit]:
0 to 20mA, 4 to 20mA
4 Current Inputs [16 Bit]:
0 to 20mA, 4 to 20mA
Analog
Outputs
1 Voltage / Current
Output [12 Bit]:
4 to 20mA, 0 to 10VDC
1 Voltage / Current
Output [12 Bit]:
4 to 20mA, 0 to 10VDC
1 Voltage / Current
Output [12 Bit]:
4 to 20mA, 0 to 10VDC
1 Voltage / Current
Output [12 Bit]:
4 to 20mA, 0 to 10VDC
Isolation
Digital: Isolated from 24VDC power
Analog: Non-Isolated from 24VDC power and Communication, USB ground
Operating
Temperature
0°C to 50°C (While using FPEM Modules with FP2 Base models)
Storage
Temperature
-20°C to 85°C
Humidity
10 to 95% non-condensing
Approvals
CE, UL Class I Div 2
Dimensions
(mm)
48W x 108H x 41D

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 19 of 24
FPEM-0404P-A0402U
FPEM-0806P-A0402U
Power Supply
Powered from FP2 base Modules
DC Inputs
4 (Sinking & Sourcing)
8 (Sinking & Sourcing)
High Speed
Inputs
2, 32 Bit, 200kHz
2, 32 Bit, 200kHz
DC Outputs
4 PNP
6 PNP
High Speed
Pulse Outputs
2, Up-to 200kHz each
2, Up-to 200kHz each
Analog Inputs
Universal Type 4 Inputs, Voltage
Inputs [16Bit]:
0 to 10VDC, 0 to 5VDC
0 to 50mV, 0 to 100mV, RTD-
PT100, Thermocouple J & K type
Linear Type 2 Inputs, Voltage
Inputs [16 bit]:
0 to 10VDC, 0 to 5VDC
0 to 50mV, 0 to 100mV, RTD-
PT100, Thermocouple J & K type
Current Inputs:
0 to 20mA & 4 to 20mA
Current Inputs:
0 to 20mA & 4 to 20mA
Analog Outputs
2 Voltage/Current Output [12 Bit]:
Current: 0 to 20mA & 4 to 20mA
Voltage: 0 to 5VDC & 0 to 10VDC
2 Voltage/Current Output [12 Bit]:
Current: 0 to 20mA & 4 to 20mA
Voltage: 0 to 5VDC & 0 to 10VDC
Isolation
Digital: Isolated from 24VDC power
Analog: Non-Isolated from 24VDC power and Communication, USB
ground
Operating
Temperature
0°C to 50°C (While using FPEM Modules with FP2 Base models)
Storage
Temperature
-20°C to 85°C
Humidity
10 to 95% non-condensing
Approvals
CE, UL Class I Div 2
Dimensions
(mm)
48W x 108H x 41D

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 20 of 24
Supported Protocols
Model
Allen Bradley DF1
Modbus RTU (Unit as Slave)
Panasonic FP Series
Modbus /TCP Master (Client)
Baldor
Modbus / TCP Server (Slave)
Danfoss Drive
Omron Host Link
Delta PLCs
Omron Inverter Memobus
Fatek PLCs
Siemens Micromaster Driver (USS)
FlexiLogics Slave Driver
Siemens Step-7 Micro
FlexiLogics Master Driver
Siemens Profinet PLCs
G9SP Safety Controller
Toshiba (Link Port) Series PLCs
GE SNP
Toshiba Inverters PLCs
GE SNP-X
Toshiba T series
Idec PLCs
Toshiba PLC Ethernet Driver
Keyence KV Series
Twido PLCs
LG Master K Series PLC
Unitlelway PLCs
LG Master-K 300S
Universal Serial Driver (ASCII)
Mitsubishi FX
Tri PLC
Mitsubishi Q Series PLCs (Serial)
AB PLC EPIC PCCC
Modbus ASCII (Unit as Master)
Logix 5000 PLCs
AB PLCs
Universal Ethernet Driver(ASCII)
Modbus RTU (Unit as Master)
