Reolink Drive User manual

Reolink Drive
Operational Instruction
@ReolinkTech
Technical Support
If you need any technical help, please visit our ocial support site and contact our support
team before returning the products.
Technische Unterstützung
Wenn Sie Hilfe brauchen, kontaktieren Sie bitte Reolink Support Team zuerst, bevor Sie Ihre
Bestellung zurücksenden.Meiste Fragen oder Probleme können von unserem Online Support
Center beantwortet und gelöst werden.
Support technique
Si vous avez besoin d’aide, veuillez contacter Reolink avant de retourner votre produit. La
plupart des questions peuvent être répondues via notre centre de support en ligne à l'adresse.
Supporto Tecnico
Se avete bisogno di aiuto, le chiediamo gentilmente di contattare Reolink prima di restituire il
prodotto.La maggior parte delle domande può essere risolta tramite il nostro centro di
assistenza online all'indirizzo.
Soporte técnico
Si necesita ayuda, comuníquese con Reolink antes de devolver su producto. La mayoría de las
preguntas se pueden responder a través de nuestro centro de soporte en línea en.
REOLINK INNOVATION LIMITED
FLAT/RM 705 7/F FA YUEN COMMERCIAL BUILDING 75-77 FA YUEN STREET MONG KOK KL
HONG KONG
EN/DE/FR/IT/ES
Hoferstasse 9B, 71636 Ludwigsburg, Germany
[email protected]
Product Ident GmbH
89 Princess Street, Manchester, M1 4HT, UK
[email protected]
APEX CE SPECIALISTS LIMITED
REP
EU
REP
UK Aug 2021
QSG1_C
58.03.005.0016

Contents
What's in the Box
Drive Introduction
Connection Diagram
Bind the Camera to the Drive
Playback the Recordings in the Drive
Install HDD to the Drive (Optional)
Troubleshooting
Specifications
Notification of Compliance
2
3
4
5
6
7
9
9
10
EN
2English
1 English
Quick Start Guide
x1
What’s in the Box
Power Adapter
x1
1m Ethernet Cable
x1
Drive
x1
Pack of Screws
x1

4English3 English
Drive Introduction Connection Diagram
Step 1: Connect the Drive to the power outlet. Please use stable power supply to avoid device
exception or even damage.
Step 2: Connect the router to the LAN port of the Drive with the Ethernet cable.
Step 3: Insert the Micro SD Card (not included in the package) in the SD card slot .
Step 4: Download and launch the Reolink App and follow the on-screen instructions to finish the
initial setup.
• On Smartphone
Scan to download the Reolink App.
Power Storage
Power LED
Storage LED
Storage LED Indicator Status:
DC 12V
Micro SD Card Slot
LAN Port
Blinking: Data transmission
Solid on: Storage device is detected

4English3 English
Drive Introduction Connection Diagram
Step 1: Connect the Drive to the power outlet. Please use stable power supply to avoid device
exception or even damage.
Step 2: Connect the router to the LAN port of the Drive with the Ethernet cable.
Step 3: Insert the Micro SD Card (not included in the package) in the SD card slot .
Step 4: Download and launch the Reolink App and follow the on-screen instructions to finish the
initial setup.
• On Smartphone
Scan to download the Reolink App.
Power Storage
Power LED
Storage LED
Storage LED Indicator Status:
DC 12V
Micro SD Card Slot
LAN Port
Blinking: Data transmission
Solid on: Storage device is detected

6English5 English
Playback the Recordings in the DriveBind the Camera to the Drive
Before you bind the camera to the Drive, please access the camera via the Reolink App and set up
the PIR schedule and the sensitivity.
If you want to playback the camera’s recordings in the Drive, you may refer to the following steps:
• Click the Drive and enter the
Homepage. Tap the camera in the
Recording list. You will see the
Playback interface.
• Choose the date on which you want
to search for videos.
• Slide the timeline to quickly locate a
specific time. Or you may click on the
specific clip to play the video.
• Tap the Drive and enter the
Homepage. Click the " " icon in the
Recording list to go to the Bind
Camera interface. Then supported
camera will show on the page.
• Click the Bind icon to bind the camera.
Once the binding succeeded, the
camera will show in the Recording list.
Then future recordings will be uploaded
to the Drive if the camera is triggered.
Drive
Drive
Camera
Recording
Bind Camera
Camera
Done
Home
Camera
Camera
Drive
Camera(Drive)
Playback
0:00 6:00 12:00 24:00

6English5 English
Playback the Recordings in the DriveBind the Camera to the Drive
Before you bind the camera to the Drive, please access the camera via the Reolink App and set up
the PIR schedule and the sensitivity.
If you want to playback the camera’s recordings in the Drive, you may refer to the following steps:
• Click the Drive and enter the
Homepage. Tap the camera in the
Recording list. You will see the
Playback interface.
• Choose the date on which you want
to search for videos.
• Slide the timeline to quickly locate a
specific time. Or you may click on the
specific clip to play the video.
• Tap the Drive and enter the
Homepage. Click the " " icon in the
Recording list to go to the Bind
Camera interface. Then supported
camera will show on the page.
• Click the Bind icon to bind the camera.
Once the binding succeeded, the
camera will show in the Recording list.
Then future recordings will be uploaded
to the Drive if the camera is triggered.
Drive
Drive
Camera
Recording
Bind Camera
Camera
Done
Home
Camera
Camera
Drive
Camera(Drive)
Playback
0:00 6:00 12:00 24:00

8English7 English
Install HDD to the Drive (Optional)
If the Micro SD Card storage doesn't meet your record demand, you may manually install a HDD
for the Drive.
Power o the Drive. Loosen the
four screws on the bottom of the
Drive to remove the cover.
Connect the HDD to the SATA
connector as well as to the power
connector. And fix it with the
provided screws.
Align the edges and the corners
of the outer casing, and make
sure the two grooves are fitted.
Then close the cover.
Reassemble the Drive with screws.
1 2
3
4

8English7 English
Install HDD to the Drive (Optional)
If the Micro SD Card storage doesn't meet your record demand, you may manually install a HDD
for the Drive.
Power o the Drive. Loosen the
four screws on the bottom of the
Drive to remove the cover.
Connect the HDD to the SATA
connector as well as to the power
connector. And fix it with the
provided screws.
Align the edges and the corners
of the outer casing, and make
sure the two grooves are fitted.
Then close the cover.
Reassemble the Drive with screws.
1 2
3
4

于嘘嘘 10English9 English
Failed to Access the
Drive Locally
Troubleshooting
If you failed to access the Drive locally via
Reolink App, please try the following solutions:
• Check if the Drive is powered on.
• Connect the Drive (LAN port) to your router
with a network cable.
• Swap another Ethernet cable or plug the
Drive into other ports on the router.
If it still doesn't work, please contact
Reolink Support.
Failed to Bind the Camera
to the Drive
If you failed to bind the camera to the Drive,
please try the following solutions:
• Check if the camera model is supported.
• Check if you can access the camera via the
Reolink App on your phone.
• Upgrade the Reolink App on your phone to
the latest version.
If it still doesn’t work, please contact Reolink
Support.
Specifications
Video Format: H.264
Synchronous Playback: 1 channel
Decoding
Micro SD Card Slot: Up to 128GB.
SATA: 1 SATA interface for a HDD (Max. 3TB)
Storage
Power Supply: DC 12V/2A
Power Consumption: <3W (without HDD)
Operating Temperature:
-10°C ~ +55°C (14F~131°F), 10%~90%
Size: 215 x 212 x 47.5mm
Weight: 520g (without HDD)
General
This product comes with a 2-year limited
warranty that is valid only if purchased from
Reolink Ocial Store or a Reolink authorized
reseller. Learn more at Reolink website.
This marking indicates that this product
cannot be disposed with other household
wastes throughout the EU. To prevent possible
harm to the environment or human health
from uncontrolled waste disposal and
promote the sustainable reuse of material
resources, please recycle it responsibly. To
return your used device, please visit the
Return and Collection System or contact the
retailer from whom the product was
purchased. They can take this product away
for environmentally safe recycling.
Limited Warranty
Notification of Compliance
Reolink declares that this device is in
compliance with the essential requirements
and other relevant provisions of Directive
2014/30/EU.
Simplified EU Declaration
of Conformity
Correct Disposal of This Product
Use of the product is subject to your
agreement to the Terms of Service and
Privacy Policy at reolink.com. Keep out of
reach of children.
By using the Product Software that is
embedded on the Reolink product, you agree
to the terms of this End User License
Agreement (“EULA”) between you and
Reolink.
Terms and Privacy
End User License Agreement
NOTE: We hope that you enjoy the new
purchase. But if you are not satisfied with the
product and plan to return, we strongly
suggest that you format the SD card or take
out the inserted SD card before returning.
