WG-1/906
WATER GLIDER
ELECTRIC POWERED SWIMMING BOARD
Instruction Manual
PLEASE READ ALL INSTRUCTIONS CAREFULLY AND
RETAIN FOR FUTURE USE

1
WARNING
PLEASE READ THE INSTRUCTION MANUAL THOROUGHLY.
Thank you for purchasing the ELECTRIC POWERED SWIMMING BOARD. Failure
to follow the basic instructions and safety precautions listed in the instruction manual
can lead to damage to your device, other property damage, serious bodily injury and
even death. Please retain this manual for future use and reference.
ATTENTION
1. Use only the supplied charger with this swimming board. Use of any other
charger may create fire or explosion.
2. The operating temperature range of the swimming board is 32-104°F(0-40°C).
3. When you are using this product, you should wear swimming cap, pay special
attention to anyone with long hair around you in order to avoid squeezing their
hair or clothes into the propeller.
4. Do not operate under the influence of drugs or alcohol
5. Read the instruction manual and warning labels before riding.
6. Store the swimming board in a dry, ventilated environment.
7. When transporting the swimming board, avoid violent crashes or impact.
LOW TEMPERATURE WARNING
Low temperature will affect the lubrication of moving parts inside the swimming
board, increasing internal resistance. At the same time, in low temperatures, the
discharge capacity and the capacity itself of the battery will be significantly
decreased.
Use caution when riding the swimming board in cold temperatures (below 40
degrees F).
Doing so may increase the risk of mechanical failures of the swimming board, which
may lead to damage to your device, other property damage, serious bodily injury

2
and even death.
SAFETY INSTRUCTIONS
 Keep the device away from heat sources, direct sunlight, humidity, water and
any other liquids.
 Do not operate the device if it has been exposed to water, moisture or any other
liquids to prevent against electric shock, explosion and/or injury to yourself and
damage to the device.
 Do not use the device if it has been dropped or damaged in any way.
 Repairs to electrical equipment should only be performed by the manufacturer
or approved repair center. Any improper or unauthorized repairs void the
warranty and may place the user at serious risk of injury.
 Do not puncture or harm the exterior surface of the product in any way.
 Keep the device free from dust, lint, etc.
 Do not use this device for anything other than its intended use or purpose.
Improper use may damage the device or lead to property damage, injury or
death.
 This product is not a toy. Keep out of the reach of children.
 Do not expose batteries, battery pack, or installed batteries to excessive heat,
such as direct sunlight, or open flame.
 Do not allow hands, feet, hair, body parts, clothing or similar articles to come in
contact with moving parts, wheels or drive train, while the engine is running.
 Do not operate or allow others to operate the swimming board, until the user
understands all instructions, warnings and safety features described in this
manual.
 Check with your doctor if you have a medical condition that could affect your
ability to use this swimming board.
 Persons with head, back or neck ailments or prior surgeries to those areas of
the body are not recommended to use this swimming board and should consult
a medical professional before attempting any use of this swimming board.

3
 Do not operate if you are pregnant, have a heart condition, or have both.
 Persons with any mental or physical conditions that may make them
susceptible to injury or impair their physical or mental capabilities to recognize,
understand and perform all of the safety instructions and to be able to assume
the hazards inherent in unit use, should not use this swimming board.
GETTING STARTED
 Remove the product from the box.
 Please retain all packaging after you have checked and counted all the parts
and the contents against the list.
PACKAGE CONTENTS
 Swimming board
 Wall Charger
 Instruction Manual
KEY FEATURES
 Helps swimmers of all skills to glide through water
 Holds up to 100kgs (220 lbs.) - suitable for kids & adults
 Powerful rechargeable battery
 On a single charge works between 30-60 minutes
 Waterproof tested under 30 meters of water
 IP68 waterproof rated
 Simple, easy & safe to use
 2 speed modes - high & low
 Engine rated power: 400W

4
DESCRIPTION OF PARTS
1 Nozzles 5 Intake Gate
2 Charge Port Cover 6 Drain Holes
3 Power Button/Indicator 7 EPP Pad
4 Bottom Case 8 Throttle Button
INSTRUCTIONS FOR USE
Please read the following instructions carefully.
BATTERY SPECIFICATIONS
Battery Type: Rechargeable lithium-ion battery
Fully Charging Time: 5 hours
Voltage: 32V
Initial Capacity: 4Ah
BATTERY POWER
You must stop driving your Swimming board, if the battery is exhausted or low power,
otherwise it may affect performance.

5
 Do not use the battery if it emits an odor.
 Do not use the battery if it is leaking.
 Do not allow children or animals near the battery.
 Remove the charger prior to driving.
 The battery contains dangerous substances. DO NOT OPEN THE
BATTERY. DO NOT INSERT ANYTHING INTO THE BATTERY.
 Only use the charger that was provided with the Swimming board. DO
NOT USE ANY OTHER CHARGERS.
 Do not charge a battery that has been overly discharged.
 Dispose of the battery in accordance with local laws.
 When the battery is just discharged, temperature inside the battery is very
high and charging immediately may cause over-temperature protection.
Under this status, the battery can neither charge or discharge until the
battery is cooled down to its safe temperature.
 Please remember to charge the battery in time when it is in low battery
protected status.
Status Battery level Indicator
80% - 100% Green steady light
On/Off light 40% - 80% Yellow steady light
10% - 40% Rea steady light
0% – 10% Red light on for one second
CHARGING
Only use the charger that was provided with your Swimming board.

6
 Open the charge port cover.
 Plug the charging cable into the Swimming board.
 Connect the charging cable to the power supply.
 The red light indicates that it has begun charging. If the light is green,
check whether the cable is connected correctly.
 When the indicator light turns from red to green, this indicates that the
battery is fully charged. At this time, please stop charging. Overcharging
will affect performance.
 Use a standard AC outlet.
 Charging time up to 5 Hours.
 Keep the charging environment clean and dry.
 After charging, disconnect the power supply and close back the charge
port cover securely.
TURNING ON/OFF THE SWIMMING BOARD
Power On: To turn on your swimming board, Press and hold the power button for 3
seconds to turn on, and the indicator light will light up and the power is turned on
successfully.
Power Off: Press and hold the power button again for 3 seconds to turn off. Also, the
swimming board will shut down automatically, if it is not used in 5 minutes.
STARTING UP THE SWIMMING BOARD
Press two throttle buttons at the same time to start up the swimming board. After

7
starting successfully, it only needs to press either one throttle button to keep running.
SWIMMING
Place the swimming board on the water surface and you are lying on the surface of
the EPP pad. Hold the handle of the board with your two hands and change the
direction of advancement by tilting the swimming board.
Note: Please wear life-saving equipment when using. Please also note the unit
speed becomes slow or indicator light turns red that this indicates low battery level,
you must return to shore for recharging.
SPEED CONTROL
Short press the power button twice to shift high and low speed modes when the
swimming board is on. Initial default mode is low speed when you are turning it on.
SPRAYING WATER
After the unit is spraying water, the nozzles will spray 2-3 meters long water column.
Please do not place the nozzles facing directly to your and other people’s eyes or

8
face.
AFTERCARE
After using, please use fresh water to soak the unit, then, life the handles and erect
the unit until it is fully drained in about 30 minutes.
SAFETY PRECAUTIONS
 Before using this product, please fully understand and familiarize yourself with
the water area that you would be entering into.
 Users should ensure that swimming and board activities are carried out in the
appropriate water area, including permission from the management to use
board.
 To prevent possible dangers, this product should not be used by the elderly,
pregnant women and those who are not suitable for swimming and snorkeling.
 This product is recommended for single use only, it is not suitable or
recommended that two or more people use the swimming board at the same
time.
 Do not drink alcohol or take medicine before using.

9
 When you are using this product, you should wear swimming cap, pay special
attention to anyone with long hair around you in order to avoid squeezing their
hair or clothes into the propeller.
 Do not remove the intake gate. Do not put your fingers or your other body parts
into the flow channel at any time, and do not allow any foreign objects to
penetrate into the flow channel.
 It is strictly forbidden to use this product in dangerous water or poor quality of
water.
 Please be careful your clothes, algae, ropes, shells, sand or other debris in the
water not enter the floe channel.
 Please use the included charger for charging, other models of chargers are
forbidden.
 The charger is not waterproof, for indoor use only.
 Non-manufacturer or non-authorized after-sales service staff must not perform
repairs because incorrect repairs will lead to product seal failure, product
damaged, fire or operator injury. Disassembling the product without
authorization will void the warranty.
 Before using this product, please check and ensure the battery is sufficient and
the propellers work normally. If the propellers do not work properly, please stop
using it immediately and contact your local dealer or the customer service.
 When you are using the product, please do not start continuously in non-
underwater environment for more than one minute.
 Do not place the outlet directly against yourself or other people’s eyes or face
when using this product.
 The surface of the product shall not be in contact with volatile or acidic
compound.
 The product contains batteries, please handle it gently, do not strongly vibrate
and knock it. Do not place heavy objects above the product.
 Do not leave the product in direct sunlight for an extended period of time or
immerse it in the water.

10
 Please clean and dry the product thoroughly after each use. The product should
be placed in a cool and ventilated place.
SAFE DRIVING
Carefully read the following safety precautions prior to operating your Swimming
board:
 The Swimming board should only be used for personal use and is not designed
for commercial use or applications.
 Do not allow children, the elderly, or pregnant women to ride or use the
Swimming board.
 Do not drive the Swimming board under the influence of drugs or alcohol.
 Do not carry items when driving your Swimming board.
 Be alert of obstacles in front of you and around you at all times.
 The Swimming board should only be driven by one person at a time.
 Do not exceed the maximum load at any times.
 Keep a safe distance from others at all while driving your Swimming board.
 Do not drive in dark places or places with low visibility.
 Do not drive in tight or narrow spaces.
 The Swimming board is recommended for riders ages 15 and older.
WEIGHT AND SPEED LIMITATIONS
Speed and weight limits are set for your own safety. Please do not exceed the limits
listed here in the manual.
 Maximum Weight: 220 lbs.
 Maximum Speed: Up to 3.6 feet/second
OPERATING RANGE
The swimming board can travel a distance up to 1.1 miles on a fully charged battery
in ideal conditions. The following are some of the major factors that will affect the
operating range of your device.

11
 Weight: A lighter user will have further range than a heavier user.
 Ambient temperature: Please ride and store the device under recommended
temperatures, which will increase driving distance; battery life, and overall
performance of your device.
CARE & MAINTENANCE
 Do not use abrasive cleaning solvents to clean the device.
 Do not expose the device to extremely high or low temperatures as this will
shorten the life of the electronic device, destroy the battery, and/or distort
certain plastic parts.
 Do not dispose of the device in fire as it may explode or combust.
 Do not expose the device to contact with sharp objects as this will cause
scratches and damage.
 Do not allow the device fall from high places, as doing so may damage the
internal circuitry.
 Do not attempt to disassemble the device.
SPECIFICATIONS
Product Size: (W)22.7x(D)15.7x(H)6inch (57.8x39.8x15.2 cm)
Net Weight: 11 lbs. (5 kg)
Max supported weight: 220 lbs. (100 kg)
Max Speed: Up to 3.6 feet/second (1.1m/s) (165 lbs./75kgs user)
Max Speed: Up to 2.0 feet/second (0.6m/s) (220 lbs./100kgs user)
Max Usage Time: about 1 hour
Max Thrust: 100N
Waterproof Grade: IP68
Battery Type: Lithium-ion
Battery Voltage: 32V
Battery Capacity: 4Ah

12
Battery Life: 30 minutes (continuous use); 60 minutes (mixed use)
Power Requirement: AC 100-240V, 50/60 Hz
Motor Type: Brushless DC Motor
Motor Rating: 400W, 5000rpm
FCC INSTRUCTIONS
Caution: Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the product.
NOTE: This product has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This product generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If the product does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the product and receiver.
- Connect the product into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
LIMITED WARRANTY
This product comes with a 120-day limited parts and labor warranty for

13
manufacturer’s defects. This includes defects to the motor, gyroscopic sensor,
battery, motherboards, lights, controller and Bluetooth® module.
The conditions of this warranty and our responsibilities under this warranty
are as follows:
Manufacturer's warranty is non-transferable and is limited to the original purchaser
only. Manufacturer warranty only applies to products purchased through an
authorized REPLAY retailer. Items purchased from private sellers, online auction
sites, including eBay, liquidators, sold "as-is" or “final sale" or from clearance or
going-out-of-business sales, are not covered by warranty. The warranty period
begins on date of purchase, not date of first use. Please retain a copy of your receipt
as this will be required to prove date of purchase should a warranty claim be needed.
 The warranty is not applicable if the product has been subject to improper
use along with physical abuse, improper installation, modification or repair
by unauthorized third party.
 The responsibility of manufacturer shall be limited to the repair or
replacement of the product at its sole discretion.
 The manufacturer will not take any responsibility if the failure of the unit
has resulted from accident, abuse, misuse, or any unauthorized repair,
modification or disassembly.
 This warranty gives you specific legal rights, and you may also have other
rights which vary under local laws. The following conditions comprise the
requirements and scope of our warranty conditions and do not affect our
legal and contractual warranty obligations.
We offer a warranty on our products in accordance with the following
conditions:
1) The warranty does not cover over-charging, or damages due to improperly
maintaining lithium-ion battery installed in unit. The warranty does not cover tires,
charge ports and other parts, which are considered consumables, parts that break
easily such as glass or plastic or defects based on normal wear and tear. There is

14
no warranty obligation in the event of marginal differences compared to the target
appearance and workmanship provided these have a negligible effect on the
product’s fitness for use, in the event of damage caused by chemical or
electrochemical effects, by water, moisture, debris or generally from abnormal
conditions.
2) The warranty will be performed in such a way that we shall decide whether to
repair the defective parts or to replace them with working parts. REPLAY reserves
the right to exchange the product for a replacement product of equal or greater value
if the product cannot be repaired within a reasonable time or at a reasonable cost.
Products and/or parts that have been replaced or exchanged become property of
REPLAY.
3) The warranty is voided if repairs or modifications are performed without the written
consent of REPLAY or if our products are equipped with additional parts or
accessories that are not approved for the REPLAY. Using any charger, other than a
genuine REPLAY charger, or a charger for a different model, voids the warranty and
is a serious fire hazard. Exposure to water, moisture, mud, dirt or debris, voids the
warranty.
4) Warranties that have been activated do not cause the warranty period to be
extended, nor do they trigger a new warranty period. The warranty period for any
replacement parts installed ends with the warranty period for the entire product.
5) Any other further claims are excluded, especially those for replacement due to
damage caused to the outside of the product, provided there is no obligatory legal
liability.
We therefore accept no liability for accidental, indirect or other consequential
damage of any kind, which leads to usage restrictions, data loss, and loss of
earnings or interruption to business. If you have purchased an extended warranty,
you will need to contact the retailer it was purchased from for assistance.
Asserting a warranty claim:
1) To make use of the warranty services, you must contact the REPLAY Service
Center by visiting www.flyreplay.com. Please contact Replay Customer Service at

15
[e-mail] or by calling [phone].
2) REPLAY will try to diagnose and solve your problem. We may require photos
and/or videos to properly diagnose the issue and verify warranty eligibility. A copy of
your receipt or online order confirmation, with purchase date visible, is required.
REPLAY reserves the right to verify purchases with the retailer and/or asset
protection databases, and will deny warranty claims if the receipt is invalid, cannot
be verified, or if the item has been returned or exchanged. If it is determined that a
warranty claim exists, at our sole discretion, REPLAY may send replacement parts
and or issue an RMA number (Return Material Authorization) to send the product to
REPLAY. If an RMA is issued, the package must be shipped within 14 days of the
RMA issuance or the package will be refused and returned to sender. If, at the sole
discretion of REPLAY's technicians, the item is found not to have a manufacturer
defect, has been subject to abuse, the malfunction is due to water, debris or moisture
exposure, or the item has been improperly maintained, customer will be charged for
return shipping and no repairs will be completed.
IMPORTANT: REPLAY will only accept parcels that have an RMA number.
The limited warranty stated above is only valid for products sold in the Contiguous
U.S. by REPLAY or its authorized resellers. Items purchased in Alaska, Hawaii and
Puerto Rico have shipping restrictions on batteries and we cannot ship replacement
units or batteries outside of the Contiguous U.S.
YOU EXPRESSLY UNDERSTAND AND AGREE THAT, TO THE MAXIMUM
EXTENT PERMITTED BY APPLICABLE LAW, REPLAY'S TOTAL LIABILITY IN
CONNECTION WITH THE APPLICABLE REPLAY PRODUCTS OR THIS
WARRANTY POLICY WILL NOT EXCEED THE AMOUNT YOU ACTUALLY PAID
FOR THE PRODUCT.
Remarks: REPLAY reserves the right, at its sole discretion, to interpret, modify and
amend this warranty policy at any time.
PARTS AVAILABILITY IS NOT GUARANTEED
