Reshable MR11L0224 User manual

User Manual
Model Number：MR11L0224

Headrest Seat Cushion
Backrest
Left Handrest
Seat Plate
Foot Bar
Right Handrest
Pump
Long Connecting Rod
Long Connecting Rod Base
Dear Customer,
a. Theouter boxisdamaged.
c. Theparts/accessories/assembly tools are missing.
b. Theproduct isdamaged/bent/cracked whileyou open thebox.
e. Theinstructions are not clear and can notbe referred to.
f. Theproduct has functional problems.
g. Other aspects that you are not satisfied with.
d. Theproduct ishard to assemble.
Thankyouforyour purchase.
RESHABLEiscreatedtobetheperfect startingspot forany barbers. Supplyingtop-quality
barber supplies like barber chairs, salon stations, rolling makeup cases, styling drawer
cabinets, hair tool holders, and more, we help people to keep their barber store running
with thebest equipment at themost reliable prices.
Whenyou receive theproduct,pleasemake sure thatall the parts are intact. Thenplease
browsetheentire installation manual before assembly. If problemsoccur unsatisfactorily
as follows:
Please do not hesitate to contact us for help (Be sure to mark the SKU NUMBER, e.g.,
MR11R0246, and the TRACKING NUMBER). Our RESHABLE team with factory direct
after-salesservicewill replywithin24 hoursanddoour best to resolve theproblem foryou.
Our serviceis available at any time.
Sincerely,
RESHABLE Team
RESHABLE
for Profession and Creativity!
2
1
You need
22 persons are needed
A wrench & an
allen key are
required for the
assembly of the
product. (not
included)
1Tools required
Footrest

3 4
SAFETY:
To reduce the risk of injury when assembling & using the chair,
Please follow these precautions:
·Read the instructions thoroughly before assembling and
NOTICE:
If your package is missing parts or you are having issues with
the assembly, please call us directly.Our customer service team
will address any questions or concerns you may have.
Have this manual open and ready for reference.
using your salon chair.
·It is helpful to have 2 people to assemble and turn the chair
upright after assembling.
·Do not overextend the chair and the person weight cannot
exceed 300 lbs, or it will cause the risk falling or tipping and
make the occupant over.
Hardware List
１ＰＣ
Backrest
Ｐｕｍｐ
１ＰＣ
Ｆｏｏｔ B
Seat Plate
ａｒ Ｂａｓｅ
Right Handrest １ＰＣ Left Handrest １ＰＣ
１ＰＣ １ＰＣ １ＰＣ Footrest １ＰＣ
Long Connecting Rod 2ＰＣＳ 1ＰＣ
Headrest Foot Column 2ＰＣＳ 1ＰＣ
5ＰＣＳ
Tapping Screw 1ＰＣ
Gasket 4ＰＣＳ 1ＰＣ
Wrench
M10 M10Ｘ３５
Flange Bolt
M6
M5Ｘ4５
Locking Nut M4
Seat Cushion 1ＰＣ

6
5
PRODUCT ASSEMBLY
PRODUCT ASSEMBLY
STEP 2
STEP 1
Check the package contents before getting started !
First:Install Hydraulic Pump to Base Second:Install Foot Bar to the Assembled
Hydraulic Pump & Base
Step 1:Place the assembled Base & Pump on the floor. Use Allen
Wrench to loosen the screws in the crossbar (as shown). Insert Foot
Bar into the holes in the crossbar. (May require to slightly squeeze the
ends of Foot Bar towards each other, and need some maneuvering
for the bar ends to go into place. )
Step 2:Tighten the set screws to firmly hold the Foot Bar in place.
Ｐｕｍｐ Ｂａｓｅ
１ＰＣ １ＰＣ 4ＰＣＳ
Locking Nut
Ｆｏｏｔ B
Step 1:Insert the threaded bolts on the pump bottom into the
holes in the base top. Tighten the 4 locking nuts onto the
threaded bolts. (Easier when set on one side, supported by a
sturdy object.)
ａｒ １ＰＣ 1ＰＣ
Wrench
M4

Left hand-rest Right hand-rest
8
7
PRODUCT ASSEMBLY
PRODUCT ASSEMBLY
STEP 4
STEP 3
Third:Install Handrests to Seat Plate
Right Handrest １ＰＣ Left Handrest １ＰＣ
Step 1:Remove the 8 pre-fixed bolts on the seat plate.
Step 2:Install the left handrest and right handrest to the seat plate by
the 8 bolts removed from the seat plate.
１ＰＣ
Backrest
Fourth:Install Backrest to the Seat Plate
Step 1:Remove the 2 pre-fixed bolts from the holder.
Step 2:Install the backrest to the handrests by 2 bolts.
１ＰＣ
Seat Plate

Step 1:Insert the headrest into the backrest.
Step 2:Assemble the U-shape reclining cylinder with the backrest
iron by Clevis Pin and Cotter Pin.
Black pin Pump
1ＰＣ
Headrest
109
PRODUCT ASSEMBLY
PRODUCT ASSEMBLY
STEP 6STEP 5
Fifth:Install Headrest and Reclining Cylinder
Clevis Pin Cotter Pin
Sixth:Install Seat & Backrest onto Hydraulic
Pump & Base
Step 1:Find the slot in the short slot under the seat This should be
aligned with the black pin on the top of the hydraulic pump.
Step 2:Set the assembled seat & backrest onto the assembled
hydraulic pump & base.
Step 3:Secure with screws.

Footrest
Foot Column
1211
PRODUCT ASSEMBLY
PRODUCT ASSEMBLY
STEP STEP 87
Eighth:Install Long Connecting Rod
Step 1:Remove the pre-fixed screws.
Step 2:Attach the long connecting rod to the chair.
Seventh:Install Foot Pedal
Step 1:Remove the two pre-installed screws and install the footrest.
Step 2:Install the two foot columns.
Foot Column 2ＰＣＳ
M10
Long Connecting Rod 2ＰＣＳ
Flange Bolt
Gasket
Footrest １ＰＣ 1ＰＣ
M10Ｘ３５
Flange Bolt 1ＰＣ
Gasket

14
13
OPERATE THE CHAIR
OPERATE THE CHAIR
Second:Raisethe Chair
1.Step down the Foot Bar repeatedly to raise the chair to the desired
height
First:Lockthe Chair
1.Lift the Foot Bar up to lock the seat in place.
.
STEP 9
Ninth:Install Seat Cushion
Step 1:Secure the seat plate with 5 automatic screws .
Hold up
Seat Cushion 1ＰＣ 5ＰＣＳ
Tapping Screw
M5Ｘ4５

16
15
OPERATE THE CHAIR
OPERATE THE CHAIR
Third:Lower the Chair
1.Step down the Foot Bar to the bottom and hold it to lower
the chair.
1.Push the lever on the side of the chair down/back while the
occupant leans back and make the legrest up . Pull the lever
up/forward to allow the backrest to raise up and make the legrest
Fourth:Recline the Backrest and Legrest
down.
Fifth:Raise and Lower the Headrest
1.Press the button on the chrome plate and pull up to raise, or push
down to lower the headrest.
Sixth:Unlock the Chair
1.Step the Foot Bar down to unlock the seat to allow to rotate freely.

Q:How to maintain the backrest or seat
daily?
Q: How to maintain the hydraulic pump?
A: The PVC leather should be cleaned
regularly. Spray a little of the leather care
solution onto a sponge and then use the
sponge to wipe the leather surfaces
gently.
A: Keep the surfaces of the hydraulic
pump (including the centre shaft) clean.
Sit on and raise/lower the chair
periodically to expel the air inside.
Regularly wipe the hydraulic pump with
anti-rust oil.
Daily Maintenance
18
17
OPERATE THE CHAIR
OPERATE THE CHAIR
Dear Customer, if you have any advice or questions on the installation
or product after receiving, please give us feedback as soon as possible.
We will provide you with professional guidance. Please feel free to use
it.
A: Please check whether the foot lever is
stepped to the lowest. If it's the lowest but
still has the problem, there could be
something wrong with the pump. You need
to replace it.
Q: What if the chair is difficult to rotate?
Q: How to prevent the chair from leaning
forward?
A: In this case, there may be something
wrong with the installation. Please check
whether the mounting direction of the seat
chassis connector is wrong. The direction
of the slot in the seat chassis connector
should be opposite to that of the footrest
(refer to the detail drawing in STEP6).
When it is confirmed, please make sure
whether the hydraulic pump is properly
inserted into the pump pin.
Q: If the chair keeps tilting and cannot be
righted, what should I do?
A: In this case, there may be air in the
pump. Please sit on the chair and raise it to
the highest, then lower it. Repeat the
above action until it can be used normally.
Q: What should I do when the seat cannot
be lifted or lowered normally?
A: When you sit on the chair and lean all
your weight forward deliberately, the chair
will indeed tilt. So please notice this point:
if both your feet are on the footrest, please
sit back as far as you can; meanwhile,
please ask the barber or someone else to
step the foot lever and set the chair to the
lowest when the guest sitting on the chair
is ready to stand up. (Note: please remind
guests not to stand on the footrest with
both feet, please put one foot on the
ground first.)
Frequently Asked Questions
