Hartman ROMA PERGOLA User manual

ASSEMBLY INSTRUCTIONS
ROMA PERGOLA
(68543691)
ATTENTION:.
1. Please read these instructions carefully before assembly
2. Aluminium is soft metal and over tightening may strip thread or break the part
3. DO NOT use power tools you will need a Philips screwdriver to assemble the pergola
4. Please allow 60 minutes for assembly
5. Assembly will require 2 people and the use of a tall step ladder
ASSEMBLY STEPS:
For more information regarding maintenance of your furniture please visit
http://www.hartmanuk.co.uk/after_care_videos.html
PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to hp://faq.hartmanuk.co.uk/spares/
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
1. Lay out beams (A, B,C, C1, D& Y) and attach beams(C1&D,C&D) together using screws(Z), decorative end (G) to each
end of beams using mallet (T) to gently tap them in
2. Push legs (E) into base plate (H) and using a Philips screwdriver attach the bolts and washer (K)
3. Push beams (C1&D,C&D) into top of legs (E) using mallet (T) to gently tap them in
4. Hold leg sections up and attach beams (B) to either end of pergola using mallet (T) to gently tap them in
5. Attach end caps (M) to top of legs (E)
6. Attach beam (A) to centre of pergola and beam(Y) on the two sides of (A)using mallet (T) to gently tap them in
7. Hook double rings (I) to hook on beam (A& C,D)
8. Attach canopy (Q) to single and double rings across pergola frame
9. Insert canopy supports (F,N) through and into canopy (Q) attach canopy end supports to canopy supports (N)
10. Thread cord (O) through runners on beams (C & C1). Follow image below.
11. Attach bracket (V) to leg (E) with bolts (S) same side as beam (C1&D)
12. Fit canopy cover (U) to top of pergola nearest to beam (C1) so it covers the canopy when closed
13. Attach legs (E) to floor using bolts (L) or nails (P) if attaching to grass
14. Canopy holder ( R ) can be attached when required to hold canopy in place

Parts List Parts Picture Description Qty Part No
G Decorative beam End 18
H Base Plate 4
I Double Ring runner 2
J Single Ring runner 16
K Bolt & Washer 8
L Fixing Bolt 16
M End Cap 16
O Cord 1
P Peg 4
Parts List Parts Picture Description Qty Part No
A Beam 1
B
Y
Beam
Beam
2
4
C Beam 1
Beam
Beam
1
E
D
Leg
2
4
N Canopy Support Ends
C1
FCanopy Supports 6
6
PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to hp://faq.hartmanuk.co.uk/spares/
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
68543691A
68543691B
68543691Y
68543691C
68543691C1
68543691D
68543691E
68543691N
68543691F
1411165
1411160
1411165
1411166
1411167
1411168
1411169
1411171
1411183

1
1
2
6
1
1
1
1
8
Z
Canopy
Canopy Holder
Canopy Cover
Touch Up Pen
Bracket
Toggle Tie
Bolt
Bolt
Mallte
68543691Q
68543691R
1561182
1411175
68543691U
1411178
1411155
1411179
1600001
Pic.4Pic.3
Pic.2Pic.1
P
E
PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to hp://faq.hartmanuk.co.uk/spares/
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product

Pic.8Pic.7
Pic.10
Pic.6Pic.5
Pic.9
PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to hp://faq.hartmanuk.co.uk/spares/
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
Pic.12Pic.11
For replacement or lost spare parts please go to hp://faq.hartmanuk.co.uk/spares/
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
Pic.14Pic.13
