Resolution Products RE102 User manual

RE102_GE-Compat_Pencil_DWS_Instructions.doc Page 1 o 3 2-Aug-11
www.ResolutionProducts.com
Wireless
Security
Solutions
RE102 GE-Compatible Pencil Door / Window
eatures
•Senses opening or separation. Narrow mounting locations.
•½ width o competitive products. Great or casements!
•Magnet and Internal reed switch operation.
•Magnet can mount beside or over sensor housing.
•Strong, reliable RF signal.
•8-10 year battery li e on 2-AAA batteries.
Key Instructions
•Battery “+” aces towards white “+” on circuit board.
•Install batteries: rear batt – tail in irst, ront battery – nose in irst.
•Board goes in and out o housing without batteries (not with).
•Reed switch is at the top o the housing, near the push button hole.
•Enrolling:
Place panel in enroll mode.
Disconnect and reconnect battery (simply pull battery
isolator tab, or silver contact away rom battery)
Panel will hear special transmission and will enroll.
Operation
•Magnetic reed switch:
Alarm, when…
… magnet is pulled away rom reed switch.
•Supervisories, every hour.
RE102_GE-Compat_Pencil_DWS_Instructions.doc Page 2 o 3 2-Aug-11
www.ResolutionProducts.com
Specifications
Magnet trip distance: 0.75 inch nominal
Mounting hardware: # 4 or #6 screws
Replacement Battery: 2 AAA Alkaline
Temperature Range: 0F to 120F
Housing dimensions: 4 x 0.6 x 0.9 inches.
Speci ications subject to change without notice.
Internal Picture
ID Barcode
Wall mount
plate
Battery
Positive
Magnet
position
Reed
Switch

RE102_GE-Compat_Pencil_DWS_Instructions.doc Page 3 o 3 2-Aug-11
www.ResolutionProducts.com
Notices
“GE”, “Honeywell”, and “DSC” are trademarks owned by General Electric Company, Honeywell
International Inc., and Tyco Sa ety Products Canada LTD, respectively.
Resolution Products, Inc. products will unction with one o either GE, DSC or Honeywell
systems. However, no Resolution product is produced by, endorsed by, nor is o icially
associated with GE, Honeywell or DSC. Resolution recommends veri ying proper enrollment
and operation, per control panel installation instructions, at installation.
Warranty
Resolution Products, Inc. will replace products that are de ective in their irst year.
FCC Notice
This device complies with Part 15 o the FCC rules. Operation is subject to the
ollowing two conditions:
This device may not cause harm ul inter erence.
This device must accept any inter erence that may be received, including
inter erence that may cause undesired operation.
Changes or modi ications not expressly approved by the Resolution Products, Inc. could
void the user's authority to operate this equipment.
FCC ID: U5X-RE102
IC Notice
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the ollowing two conditions:
1. This device may not cause inter erence, and
2. This device must accept any inter erence, including inter erence that may
cause undesired operation o the device.
Cet appareil est con orme avec d’Industrie Canada RSS standard exempts de licence.
Son onctionnement est soumis aux deux conditions suivantes:
1. Ce dispositi ne peut causer des inter érences, et
2. Ce dispositi doit accepter toute inter érence, y compris les inter érences
qui peuvent causer un mauvais onctionnement du dispositi .
IC: 8310A-RE102
