Welcome
Congratulations on your purchase of a ReSound UniteTM TV
Streamer 2.
TV Streamer 2 will provide you with high quality streamed audio
from your TV, HiFi stereo, personal computer or similar device
directly to your hearing instruments.
Please read this manual carefully to fully benefit from the
TV Streamer 2. Ask your hearing care professional if you have
any questions.
For further information you can also visit the
www.resound.com/unite web site.
For your safety, carefully read the chapter Important Information,
on pages 28-29
Model: SAS-3
FCC ID: X26SAS-3
400248000-GB-13.05-Rev.A.indd 2
06-06-2013 13:13:06

3
Statement:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must ac-
cept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable pro-
tection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the in-
structions, may cause harmful interference to radio communica-
tions.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful inter-
ference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
400248000-GB-13.05-Rev.A.indd 3
06-06-2013 13:13:07

4
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications can void the user’s authority to operate
the equipment.
Intended use
TV Streamer 2 is intended to enable ReSound wireless hearing
instrument users to better follow TV or other audio programs. The
essential performance of the TV Streamer 2 is to transfer signals
from a TV set or other audio device to a ReSound wireless hear-
ing instrument.
List of countries
Products are intended for sale in countries within European Eco-
nomic Area as well as Switzerland.
400248000-GB-13.05-Rev.A.indd 4
06-06-2013 13:13:07

5
National restrictions:
Norway: You are not allowed to operate the equipment within 20
km of the centre of Ny Ålesund.
This product is in compliance with the following regulatory stan-
dards:
In EU : The device conforms to the Essential Requirements ac-
cording to - Annex I of Council Directive 93/42/EE C for medical
devices (MDD) and essential requirements and other relevant pro-
visions of Directive 1999/5/EC (R&TTE). The declaration of con-
formity may be consulted at www.resound.com
In US: FCC CFR 47 Part 15, subpart C.
Other identified applicable international regulatory requirements
in countries outside EU and US. Please refer to local country re-
quirements for these areas.
The product is categorized as receiver category 2 according to
EN 300 328.
Model: SAS-3
IC: 6941C-SAS3
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
400248000-GB-13.05-Rev.A.indd 5
06-06-2013 13:13:07

6
Operation is subject to the following two conditions: (1) this de-
vice may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired
operation of the device.
L’exploitation est autorisée aux deux conditions suivantes: (1)
l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur
de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonc-
tionnement.
In JP:
This device has been granted a designation number by Ministry of
Internal Affairs and Communications under “Ordinance concern-
ing Technical Regulations Conformity Certification etc. of Speci-
fied Radio Equipment (特定無線設備の技術基準適合証明 等に
関する規則)” Article 2-1-19 “This device should not be modified
(otherwise the granted designation number will be invalid)“.
400248000-GB-13.05-Rev.A.indd 6
06-06-2013 13:13:07

7
Contents
Description ........................................8
Getting Started ....................................10
Pairing to your hearing instruments.....................18
Start and stop streaming ............................21
Controls .........................................24
Adjustable delay mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Important Information ...............................28
Technical specifications .............................30
Warranty .........................................30
Troubleshooting guide ..............................32
400248000-GB-13.05-Rev.A.indd 7
06-06-2013 13:13:07

8
Description
1 Micro-USB power socket
2 Pairing button
3 Mono/stereo switch
4 Analogue mini-jack audio input
5 Optical (Toslink) audio input
6 Coaxial audio input
16 4 5
23
400248000-GB-13.05-Rev.A.indd 8
06-06-2013 13:13:07

9
7 Increase volume
8 Decrease volume
9 Power light (green)
10 Activity light (yellow)
11 Wall plug
12 Mini-USB plug
7
11
12
10
8
9
400248000-GB-13.05-Rev.A.indd 9
06-06-2013 13:13:08

10
Getting Started
Installing the TV Streamer 2
Depending on your TV, HiFi stereo, computer or other audio
setup, the installation of TV Streamer 2 may be done in several
ways described in the following section. The following steps will
guide you through the pairing and connecting process, which can
be easily accomplished by almost anyone. Start by connecting
cables between the TV Streamer 2 and the audio source and
finish by pairing the TV Streamer 2 to your hearing instruments.
iThe TV Streamer 2 supports both analogue and digital au-
dio input. Please read the following sections for information about
supported audio formats and how to connect the TV Streamer 2
to audio sources.
Connecting the TV Streamer 2 to an analogue audio source
(E.g. TV or HiFi stereo)
1. Connect the power supply to the wall socket and insert the
cable into the micro-USB socket on the TV Streamer 2
2. Insert the male stereo mini-jack on the audio cable into the fe-
male stereo mini-jack input on the TV Streamer 2 (4 on page 8)
3. Plug the other end audio cord into the ”AUDIO OUT” terminals
on the audio source
400248000-GB-13.05-Rev.A.indd 10
06-06-2013 13:13:09

11
4. The ”AUDIO OUT” is usually marked ”L – R” for left and right,
and can usually be found on the back of the audio source
iNote: With this installation, most audio sources will send
sound to both hearing instruments and additional speakers
connected to the audio source simultaneously. On some audio
sources you can adjust the balance between the AUDIO OUT and
the speakers – consult your audio source manual for instructions.
400248000-GB-13.05-Rev.A.indd 11
06-06-2013 13:13:09

12
Alternative analogue audio cable installations:
If it is not possible to connect the TV Streamer 2 to the AUDIO
OUTPUT of the audio source using the red and white plugs, the
following installation alternatives can be used:
Mini-jack adaptor:
1. Connect the power supply to the wall socket and insert the
cable into the micro-USB socket on TV Streamer 2
2. Insert the male stereo mini-jack on the audio cable into the fe-
male stereo mini-jack input on the TV Streamer 2 (4 on page 8)
3. Connect the stereo mini-jack adapter to the red and white
plugs at the other end of the audio cable
4. Plug the stereo mini-jack adapter into the audio sources’
”HEADPHONE” output terminal, or alternatively into your com-
puters’ audio terminal
iNote: The HEADPHONE output terminal is usually located
on the side or front of the audio source. When using the HEAD-
PHONE terminal, usually only the person wearing the hearing in-
struments will hear the sound, and audio source speakers are
muted.
400248000-GB-13.05-Rev.A.indd 12
06-06-2013 13:13:10

13
If muted speakers are not desired, please refer to the first instal-
lation, or the one on the following page. Your audio source may
support speakers and HEADPHONE being on simultaneously;
check your audio source manual for instructions.
400248000-GB-13.05-Rev.A.indd 13
06-06-2013 13:13:10

14
Scart adapter:
1. Connect the power supply to the wall socket and insert the
cable into the micro-USB socket on TV Streamer 2
2. Insert the male stereo mini-jack on the audio cable into the fe-
male stereo mini-jack input on the TV Streamer 2 (4 on page 8)
3. Connect the scart adapter to the red and white plugs at the
other end of the audio cable
4. Plug the scart adapter into the audio source’s scart terminal
iNote: The scart output ter-
minal is usually located on the
back or side of the audio source.
Please consult the manual of your
audio source if additional configu-
ration of the scart output is needed.
400248000-GB-13.05-Rev.A.indd 14
06-06-2013 13:13:11

15
Connecting the TV Streamer 2 to a digital audio source (E.g.
TV or HiFi stereo)
iThe TV Streamer 2 supports both analogue and digital au-
dio input. When using digital audio input the following formats are
supported:
Stereo PCM
- Sample rate: Up to 192 kHz
- Sample resolution: Up to 32 bit
Dolby Digital
- Channels: Max 5.1
- Bitrate: 32 kbs to 640 kbs
- Sample rate: 32, 44.1 and 48 kHz
Note: Dolby Digital Plus (requiring an HDMI interface), Dolby True-
HD, Dolby Pro Logic, Dolby Digital EX, Dolby Digital Surround EX,
and AAC (Advanced Audio Codec) are not supported.
400248000-GB-13.05-Rev.A.indd 15
06-06-2013 13:13:12

16
Using the optical (Toslink) audio input
1. Connect the power supply to the wall socket and insert the
cable into the micro-USB socket on TV Streamer 2
2. Insert one of the plugs on the optical audio cable into the opti-
cal audio input socket (5 on page 8) on TV Streamer 2
Note: Most optical cables are delivered with a small protective
cap to protect the tip of the cable. Please remove this protec-
tive cap before inserting the cable
3. Plug the other end of the optical audio cable into the “Digital
Audio Out/Optical” on your audio source
400248000-GB-13.05-Rev.A.indd 16
06-06-2013 13:13:12

17
Using the coaxial audio input
1. Connect the power supply to the wall socket and insert the
cable into the micro-USB socket on TV Streamer 2
2. Connect one of the plugs on the coaxial audio cable to the
coaxial plug (6 on page 8) on TV Streamer 2
3. Plug the other end of the coaxial audio cable into the “Digital
Audio Out/Coaxial” on your audio source
400248000-GB-13.05-Rev.A.indd 17
06-06-2013 13:13:13

18
Pairing to your hearing instruments
iNote! The following information is intended primarily for your
hearing care professional, who in most cases will complete the
necessary tasks before the TV Streamer 2 can be used with your
hearing instruments. However, the process is designed to be
simple and most people can do it themselves.
It is possible to pair up to three streaming devices - e.g. two TV
Streamers and one ReSound UniteTM Mini Microphone (optional
accessory) - with a given pair of hearing instruments. Therefore
channel 1, 2 or 3 must be selected when starting the pairing pro-
cess.
Pairing the TV Streamer 2 in channel 1
1. Make sure that the TV Streamer 2 power supply is plugged into
a wall socket and that the green light indicator on the front of the
TV Streamer 2 (9 on page 9) is ON. Your hearing instruments
must be OFF - open the battery door
2. Press the pairing button on the TV Streamer 2 (2 on page 8)
once. The yellow light indicator on the front of the TV Streamer 2
(10 on page 9) will now blink once every 2 seconds to indicate
that the TV Streamer 2 is ready to be paired in channel 1. Your
400248000-GB-13.05-Rev.A.indd 18
06-06-2013 13:13:13

19
TV Streamer 2 will remain in pairing mode for 20 seconds
3. While pairing mode is activated, close the battery doors of
both hearing instruments and make sure they are ON. A suc-
cessful pairing will be indicated by an audible melody being
played in both hearing instruments. You are now ready to use
the TV Streamer 2
Pairing the TV Streamer 2 in channel 2
1. Press the pairing button twice. The yellow light indicator on the
front of the TV Streamer 2 will now blink twice every 2 seconds
to indicate that it is ready to be paired in channel 2
2. While in pairing mode close the battery doors on the hearing
instruments
Pairing the TV Streamer 2 in channel 3
1. Press the pairing button three times. The yellow light indicator
on the front of the TV Streamer 2 will now blink three times
every 2 seconds to indicate that it is ready to be paired in
channel 3
2. While in pairing mode close the battery doors on the hearing
instruments
400248000-GB-13.05-Rev.A.indd 19
06-06-2013 13:13:13

20
Pairing button
pushes Light indicator pattern Channel
Pairing blinking pattern:
400248000-GB-13.05-Rev.A.indd 20
06-06-2013 13:13:13
